Dunlop JHF3 BAND OF GYPSYS FUZZ FACE User manual

92503017849REVA

DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
SPECIFICATIONS
Input Impedance 320 kΩ
Output Impedance
Max Volume 11 kΩ
Mid Volume 64 kΩ
Max Output +9 dBV
Max Gain 60 dB
Noise Floor* -72 dBV
Eect Switching THWBY
Current Draw 3.8 mA
Power Supply 9V Battery
DESCRIPTION
• The biting, aggressive fuzz tone
used by Jimi Hendrix for the Band
of Gypsys show and other iconic
performances
• True bypass
CONTROLS
VOLUME knob controls overall
eect volume
FUZZ knob controls amount
of fuzz
FOOTSWITCH toggles on/
bypass
DIRECTIONS
• Run a cable from your guitar
to the JHF3’s INPUT jack and
another cable from the JHF3’s
OUTPUT jack to your amplier.
• Start with both controls at 12
o’clock.
• Turn the eect on by depressing
the footswitch.
• Rotate the VOLUME knob
clockwise to increase
overall eect volume or
counterclockwise to decrease it.
• Rotate the FUZZ knob clockwise
to increase amount of fuzz or
counterclockwise to decrease it.
JHF3 BAND OF GYPSYS™
FUZZ FACE®DISTORTION
POWER
The JHF3 is powered by one 9-volt
battery (remove bottom plate to
install).
Measurements made at 1 kHz, all controls max.
*A-weighted.
