Dunlop Fuzz Face JHM1 User manual

92503013523revA
DUNLOP MANUFACTURING INC.
P.O. BOX 846 BENICIA, CA 94510
U.S.A. JIMDUNLOP.COM
Dunlop Manufacturing, Inc.
150 Industrial Way
P. O. Box 846
Benicia, CA 94510
Phone: [phone]
Fax: [phone]
WARNING: The information contained
in this document is the intellectual
property of Dunlop. Any use and/or
reproduction, in whole or in part, must
have the written permission of Jim
Dunlop Manufacturing, Inc.
JHM1 Mxr fuzz face
4/4 cOLOr PrOceSS
DUNLOP PART #: 92503013523REVA
UPC #: N/A
FILE NAME:
92503013523REVA_JHM1FUZZ_MAN.INDD
FILE DATE: 09/14/12
DIELINE DOES NOT PRINT
FLAT SIZE: W= 8” X L= 4.875“
FINISHED SIZE: W= 4” X L= 4.875”
PRINT MATERIAL: 100# DULL COVER
PRINTING SIDE 1: 4CP = CMYK
PRINTING SIDE 2: 4CP = CMYK
FONTS: (ALL FONTS OUTLINED)
LINKED IMAGES: N/A
BINDERY: SCORE & FOLD
NOTES:
PROOF
REVISED
FINAL ART
PROJECT DIRECTOR: GRAHAM SHAW
DESIGNER: HANK ALVA
CONTACT: [e-mail]
92503013523revA_JHM1_man.indd 1-2 9/14/12 10:32 AM

DIRECTIONS
•Runacablefromyourguitartothe
FuzzFace’sInputjackandrunanother
cablefromtheFuzzFace’sOutputjack
toyouramplier.
•StartwithVOLUMEandFUZZcontrols
at12o’clock.
•Turntheeffectonbydepressing
thefootswitch.
•RotateVOLUMEknobclockwise
toincreaseoverallvolumeor
counterclockwisetodecreaseit.
•RotateFUZZknobclockwisetoincrease
theamountoffuzzorcounterclockwise
todecreaseit.
SAMPLE SETTINGS
SPECIFICATIONS
InputImpedance 10kΩ
OutputImpedance
 MaxVolume 2kΩ
 MidVolume 50kΩ
M a x  O u t p u t  - 6 d B V 
MaxGain 45dB
Bypass TrueHardwire
C u r r e n t  D r a w  3 . 4 m A 
PowerRequirement 9voltsDC
DESCRIPTION
•BuiltaroundthetonefulBC108
silicontransistor
•Jimi’sFuzzFacetoneinapedalboard-
friendlyhousing
•Limitededitionnishfeaturingart
bylegendaryrockartistJohn
VanHamersveld
POWER
TheJHM1JimiHendrix70thAnniversary
TributeSeriesFuzzFacecanbepowered
byone9voltbattery(accessedviathe
bottomofthepedal),aDunlopECB003
ACadapter(ECB003EinEurope)ora
DC Brick™seriespowersupply..
CONTROLS
•VOLUMEknobcontrolsoverallvolume
ofeffect
•FUZZknobcontrolsamountoffuzz
•FOOTSWITCHtoggleseffecton/bypass
(indicatedbyblueLED)
VOODOO CHILD
(SLIGHT RETURN)
SPANISH CASTLE
MAGIC
VOLUME VOLUMEFUZZ FUZZ
