Dunlop AUTHENTIC HENDRIX 69 PSYCH SERIES OCTAVIO... User manual

jimdunlop.com/jhw2
AUTHENTIC
HENDRIX™
’6 9 PSYCH
SERIES
OCTAVIO®

JHW2 | AUTHENTIC HENDRIX™'69 PSYCH SERIES OCTAVIO®FUZZ 2
This classic effect has been updated
with a switch to toggle between the
iconic octave-up sound that Jimi Hendrix
made famous and super snarling silicon
saturation. It all comes in an MXR mini
housing emblazoned with the trippy,
kaleidoscopic designs of award-winning
UK-based design crüe ILOVEDUST.

JHW2 | AUTHENTIC HENDRIX™'69 PSYCH SERIES OCTAVIO®FUZZ 3
1LEVEL knob sets overall volume of effect
2OCTAVE switch toggles octave-up fuzz on/off (indicated by red LED)
3FUZZ knob sets intensity of fuzz effect
4FOOTSWITCH toggles effect on/bypass (white LED indicates on)
13
2
4
External Controls

JHW2 | AUTHENTIC HENDRIX™'69 PSYCH SERIES OCTAVIO®FUZZ 4
Basic Operation
1 Run a cable from your guitar to JHW2’s INPUT jack and another
cable from JHW2’s OUTPUT jack to your amplifier.
2 Start with VOLUME and FUZZ controls at 12 o’clock.
3 Turn effect on by depressing the footswitch.
4 Rotate LEVEL knob clockwise to increase overall volume or
counterclockwise to decrease it.
5 Rotate FUZZ knob clockwise to increase the amount of fuzz or
counterclockwise to decrease it.
6 By default, the octave-up fuzz effect is disabled. To engage it,
push the OCTAVE switch to its IN position.
Authentic Hendrix™'69 Psych Series Octavio®Fuzz is
powered by the Dunlop ECB003 9-volt adapter or the
DC Brick™ , Iso-Brick™ , and Mini Iso-Brick™power supplies.
This pedal cannot be powered by a battery.
Power
Directions

JHW2 | AUTHENTIC HENDRIX™'69 PSYCH SERIES OCTAVIO®FUZZ 5
Specifications
*Drive stage adjusted maximum CW
**With all controls at mid position
Input Impedance 10 kΩ
Output Impedance
Max Volume 400 kΩ
Mid Volume 50 kΩ
Max Output -3 dBV
Max Gain 43 dBV
Bypass True Hardwire
OCTAVE OFF
Input Impedance 10 kΩ
Output Impedance
Max Volume 20 kΩ
Mid Volume 30 kΩ
Max Output -2 dBV
Max Gain 31 dBV
Bypass True Hardwire
OCTAVE ON
Current Draw 5 mA
Power Requirements 9 volts DC
POWER REQUIREMENTS
