Duratool D03407 User manual

1
Models: D03407 and D03408
POCKET WEIGHING SCALE

2
Please read these instructions carefully before use and retain for future reference.
• Avoiding exposure to extreme heat or cold, your scale works better when operated
at normal room temperature.
• Always allow the scale to acclimate to normal room temperature for at least 1 hour
before use.
• Allow sufcient warm up time. Usually 30 seconds to give the internal components
time to stabilize before calibration or use.
• Keep your scale in a clean environment. Dust, dirt, moisture, vibration, air currents
and a close proximity to other electronic equipment can all cause an adverse effect
on the reliability and accuracy of your scale.
• Handle with care. Gently apply all items to be weighed onto the tray top.
• Avoid shaking, dropping or otherwise shocking the scale. This is a precision
instrument and must be handled with extreme care.
• Only operate the scale on a stable, at, vibration free surface.
• Always remove the batteries if the scales are not to be used for long periods.
IMPORTANT SAFETY INFORMATION
WHAT’S INCLUDED
OPERATION
FUNCTIONS
• Pocket Scales
• Instruction manual.
TARE WEIGHING:
• Turn on scale as described above.
• Place the “tare item” (eg container) on the platform.
• Press [TARE] and wait until “0.0” is displayed.
• Add the “net-weight-item” (into the container0 and the screen will display the
weight.
COUNTING FUNCTION
• Turn on the scale and wait until the LCD displays“0.0”.
• Place a sample amount (25pcs, 50pcs, 75pcs or 100pcs) of the quantity you wish to
weigh and count onto the platform.
• Place scale on a horizontal at surface.
• Press [ON/OFF] key to turn on the scale.
• Wait until the LCD displays “0.0”.
• Put the object(s) to be weighed on the weighing platform.
• Press the [UNITS] key to switch between the weighing units.
• Using the [LIGHT] key to turn the display backlight on or off.
• The scales will automatically turn off after about 30 seconds of inactivity.
• If the display shows “0_Ld” it is overloaded - remove the excess load immediately
to avoid damage.
• If the display shows “--” and the gures uctuate, the scales are not properly
supported on a at surface.

3
• Press and hold [PCS] key for 2 seconds; the LCD will display a random number, for
example “100” and “PCS” will ash in the corner.
• Press [UNITS] key to set the correct sample amount of items that you have put onto
the platform.
• Briey press [PCS] key to conrm the above information, the LCD will now display
“PCS” solid in the corner to show that the scale is in counting mode.
• Remove the sample quantity from the platform.
• Now can place any amount of your item(s) on the scale and the LCD will display a
count.
• You can switch between weighing mode and counting mode by pressing [UNITS] or
[PCS] key respectively.
CALIBRATION
• Reset the scale by pressing [ON/OFF] key.
• Wait until the LCD displays “0.0” and then press and HOLD [UNITS] key for 3
seconds.
• The LCD will display “CAL”, and then release the [UNITS] key.
• Press [UNITS] key again, the LCD will display “CAL” followed by the required
calibration weight.
• Add the required calibration weight, the display will show “PASS” and return to
normal weighing mode.
• Store the calibration weight safely and press [ON/OFF] to turn off the scale and the
calibration is complete.
MAINTENANCE
Cleaning the casing
• Wipe using a moist cloth or sponge. Do not use solvents as these may damage the
casing.
• Avoid scratching the LCD screen.
• Do not immerse in water or allow moisture to enter the casing.
BATTERY REPLACEMENT
• When LCD display starts to fade, it is necessary to replace the batteries. However,
measurement may still be made for several hours although accuracy cannot be
guaranteed.
• Slide the battery cover away from the instrument and remove the batteries.
• Replace with new AAA batteries noting the correct polarity and ret the cover.

4
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT
These symbols indicate that separate collection of Waste Electrical and Electronic Equipment
(WEEE) or waste batteries is required. Do not dispose of these items with general household
waste. Separate for the treatment, recovery and recycling of the materials used. Contact your
local authority for details of the battery and WEEE recycling schemes available in your area.
Made in China
PR2 9PP
PO Box 13362 Dublin 2
Man Rev 1.1
SPECIFICATIONS
D03407 Max Load: 200g (accuracy 0.01g)
D03408 Max Load: 500g (accuracy 0.1g)
Calibration: Auto calibration
Tare range: Tare full capacity
Auto off: 30 seconds
Operation temp: 50-86oF / 10-30oC
Battery: 2 x AAA batteries
