Duratool D03411 User manual

1
Model: D03411
HANGING SCALE

2
Please read these instructions carefully before use and retain for future reference.
• Avoiding exposure to extreme heat or cold, your scale works better when operated
at normal room temperature.
• Keep your scale in a clean environment. Dust, dirt, moisture, vibration, air currents
and a close proximity to other electronic equipment can all cause an adverse effect
on the reliability and accuracy of your scale.
• Handle with care. Gently apply all items to be weighed onto the hook.
• Avoid shaking, dropping or otherwise shocking the scale. This is a precision
instrument and must be handled with extreme care.
• Only support the scale by the top support loop and not by holding the casing itself.
• Always remove the batteries if the scales are not to be used for long periods.
• The scales only operate in the vertical position.
IMPORTANT SAFETY INFORMATION
WHAT’S INCLUDED
OPERATION
FUNCTIONS
• Hanging Scales
• Instruction manual.
TARE WEIGHING:
• Turn on scale as described above.
• Place the “tare item” (eg: container) on the hook.
• Press [TARE] and wait until “0.0” is displayed.
• Add the “net-weight-item” into the container and the screen will display the weight.
WEIGHT LOCK
• Turn on the scale and wait until the LCD displays“0.0”.
• Press the [UNITS] key to switch between the weighing units (kg/lb/oz).
• Press ‘TARE” key for 1 second until the “L_ON” sign displays on the screen. Put
the object(s) to be weighed on the weighing hook.
• The weight measured will remain locked on the screen until either the power
is turned off or the “TARE” key is pressed again for 2 seconds then “L_OFF” is
displayed.
• Attach the scales by the upper loop to a solid support capable of supporting the
weights you are attempting to measure.
• Press [ON/OFF] key to turn on the scale.
• Wait until the LCD displays “0.0”.
• Put the object(s) to be weighed on the weighing hook.
• Press the [UNITS] key to switch between the weighing units (kg/lb/oz).
• The scales will automatically turn off after about 60 seconds of inactivity.
• If the display shows “0_Ld” it is overloaded - remove the excess load immediately
to avoid damage.

3
POWER OFF
• Press “ON/OFF” key to turn off under normal weighing (without “HOLD”’) mode.
• Press “ON/OFF” key to clear the “HOLD” sign and press “ON/OFF” key again to
tum off.
MAINTENANCE
Cleaning the casing
• Wipe using a moist cloth or sponge. Do not use solvents as these may damage the
casing.
• Avoid scratching the LCD screen.
• Do not immerse in water or allow moisture to enter the casing.
BATTERY REPLACEMENT
• When LCD display starts to fade or the battery symbol is lit, it is necessary to
replace the batteries. However, measurement may still be made for several hours
although accuracy cannot be guaranteed.
• Slide the battery cover away from the instrument and remove the batteries.
• Replace with new AAA batteries noting the correct polarity and ret the cover.

4
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT
These symbols indicate that separate collection of Waste Electrical and Electronic Equipment
(WEEE) or waste batteries is required. Do not dispose of these items with general household
waste. Separate for the treatment, recovery and recycling of the materials used. Contact your
local authority for details of the battery and WEEE recycling schemes available in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.1
SPECIFICATIONS
Max Load: 50kg (accuracy 10g)
Tare range: Tare full capacity
Auto off: 60 seconds
Operation temp: 50-86oF / 10-30oC
Battery: 2 x AAA batteries
