Duronic MFP400 User manual

MFP400
Mini Food Processor
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
Instrukcja obsługi. Polski
5
17
29
41
53
65
Contents

4

5
English Manual

6
Features and Specications
Components
1
2
3
5
4
6
7
8
9
10
11
12
13
1. Food pusher
2. Food chute
3. Food processor spout
4. Food processor lid
5. Stainless-steel shredding &
slicing disk
6. Plastic shredding & slicing
adapter
7. Chopper lid
8. Stainless-steel chopping blade
9. Motor shaft
10. Bowl
11. Base / Motor unit
12. Control dial
13. Power cable
Model
Number Capacity Dimensions Power Voltage
MFP400 500ml 14x20x34cm 400W 220-240V
50-60Hz

7
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for indoor/household use only. Do not use outdoors.
• This appliance is not designed for commercial or industrial use; it is for
household use only.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Children should be closely supervised at all times to ensure that they do not
play with the appliance.
• Only use the appliance out of the reach of children because there are sharp
blades inside the bowl. Store the blade parts safely out of reach of children.
• Do not operate this appliance if the power cable or plug is damaged. If
either is damaged, return it to Duronic for service or repair by a professional
technician.
• Never try to replace the parts and repair the unit by yourself. Do not modify
the appliance in any way that is not described in the instructions for use. The
machine contains live parts. Repairs may only be carried out by Duronic,
using original spare parts and accessories.
• If an extension lead/cable is needed to reach the appliance to a mains power
socket that is too far away out of reach of the machine’s accompanying cable,
please ensure that:
- the marked electrical rating of the extension lead is at least as great
as the electrical rating of the appliance.
- the extension lead is of the grounded type.
- no other appliance is plugged into the same extension lead.
- the extension cable is safely positioned to avoid it being pulled on by
children or animals or being tripped over.
Safety Information

8
• Always operate the appliance on a dry, smooth, even and stable surface. Do
not place the food processor on or next to a hot surface.
• Position the appliance and its power cable to the rear of the work surface,
well out of reach of children.
• Disconnect the mains plug from the power socket if you are going to be
absent for long periods.
• Never disconnect the plug by pulling on the power cable.
• Unplug from the mains plug outlet when not in use and before cleaning.
• This appliance is not intended to be operated using an external timer or
separate remote-control system.
• Do not let the power cable hang over the edge of the table or counter, or
touch hot surfaces.
• Do not use the appliance for anything other than blending or chopping food.
• Do not operate the food processor with wet hands.
• To clean, wipe the machine body with a well-wrung wet cloth. Do not
submerge it in water or other liquids. Wash the cups and lids with warm water
and soap. Dry properly before placing the cups back into the machine.
• Do not switch the appliance on if the bowl is empty or use the food processor
for more than 30 seconds at a time as this will overheat the motor. After 30
seconds of use, allow the machine to cool down for 3 minutes.
• Be certain lid is securely locked in place before operating appliance.
• Never feed food into food chute by hand. Always use food pusher.
• Do not attempt to defeat the lid interlock mechanism.
• Make sure the blade or disc has come to a full stop before removing lid.
• Use caution when removing blade and disc from the bowl, when emptying the
bowl, and when cleaning.
Safety Information (continued)

9
• Be sure to turn switch to OFF ( O ) position after each use. Always use the
pusher to clear the food chute. When this method is not possible, turn the
motor off and disassemble unit to remove the remaining food.
• The maximum rating of this unit is based on using the Chopping Blade. Using
the Slicing/Shredding Disc may draw signicantly less power.
The MFP400 is a 2-in-1 kitchen appliance that is both a food processor and
chopper.
To change between the two modes, simply choose which blades and which lids to
use and add them to the top of the bowl.
The Food Processor
It has a long food chute which allows you to add a variety of ingredients into the
bowl from above whilst a at circular disk rotates and slices/grates the food into
the bowl. This is perfect for slicing onions, celery, carrots and grating cheese.
The Chopper
This element is like a mini-blender; it has a sharp 2-part blade that is inserted into
the bottom of the bowl and rotates to evenly chop and blend the ingredients in the
bowl to your desired consistency. This is perfect for dicing veg into tiny pieces,
pureeing food and also for making sauces.
Safety Information (continued)
Introduction

10
How to Lock the Bowl
Align the Base Unit(11) and Bowl(10) as
illustrated. Turn the bowl clockwise until it locks
into place.
The bowl can lock onto the base in 3 different
positions for the user’s convenience.
NOTE: the food processor will not work unless
the bowl is locked into position.
How to Assemble and Lock the Lid
Align the Lid(4 or 7) as illustrated by placing a
thumb on the lid and turning it clockwise. Four
visual alignment markers are provided: one on
the bowl, one on the handle and two on the bowl
lid.
NOTE: the food processor will not work unless
the lid is locked into position.
How to Operate the Control Dial
The Control Dial(12) is conveniently located on
the front of the base. Rotate the dial clockwise to
select a speed:
• I for low
• II for high
The processor will run continuously.
For instant on/off control use the PULSE button
by rotating the dial counter-clockwise.
Before First Use

11
Assembling and Using the Food Processor
1. Position the Main Unit(11) on a at and stable surface. Check that the rubber
feet are rmly in place on the surface to ensure that the appliance doesn’t
wobble during use.
2. Check that the Control Dial(12) is turned to OFF(O) and the machine is
unplugged.
3. Lock the Bowl(10) onto Base Unit.
4. Place the Plastic Shredding and Slicing Disk(6) onto the motor shaft(9). Put
slicer/grater disk(5) on top of the plastic disk with the desired side facing up
ready for either slicing or grating.
How to Use
5. Next, place Food Processor Lid(4) onto the bowl and have the Food
Pusher(1) ready to use.
6. Place a bowl or container directly underneath the Food Processor Spout(7)
7. Plug in the main unit to a mains plug socket.
8. Place the ingredients into the Food Chute. To slice/grate large foods (such as
a chunk of cabbage, green pepper or a whole tomato) you may need to slice
it in half rst so that it ts into the Food Processing Chute.
Tip: To slice vegetables into julienne style, slice them rst, then remove from
bowl and re-stack the vegetables. Then put them into food chute with the slices
vertical. Slice again to make match-stick cut vegetables.
Grate
Slice
1
2

12
9. Insert Food Pusher into the Food Chute to guide the food through. Always
use the Food Pusher to feed food into the chute. NEVER PUSH FOOD
THROUGH THE CHUTE WITH YOUR HANDS.
10. Use the Control Dial to select the speed. While pressing on Food Pusher,
select between speeds 1 or 2, or for optimum slicing and grating, use the
PULSE function.
11. The sliced or grated food will travel through the Food Processor Spout and
collect in the container placed below it.
12. When food chute is empty, or once grating/slicing is complete, select OFF(O)
or release the dial from the PULSE position. Wait until blade has stopped
rotating before removing lid.
Tips:
To slice or shred cheese, select rm cheese like Cheddar, Monterey Jack,or
Swiss. Place cheese in freezer for 30 minutes before processing.
The Shredding and Slicing Disc has a slicing blade on one side and grating teeth
on the other. Place the disk onto Motor Shaft with desired cutting edge facing up.
Assembling and Using the Food Chopper
1. Position the Main Unit(11) on a at and stable surface. Check that the rubber
feet are rmly in place on the surface to ensure that the appliance doesn’t
wobble during use.
2. Check that the Control Dial(12) is turned to OFF(O) and the machine is
unplugged.
3. Lock the Bowl(10) onto Base Unit.
How to Use (continued)

13
4. Place the Chopping Blade(8) onto the motor shaft(9).
5. Plug in the main unit to a mains plug socket.
6. Place the ingredients into the Bowl. For a more uniform result, start with your
food already cut or broken into similar sizes.
7. Next, place Chopper Lid(7) onto the bowl and lock it in place.
8. Use the Control Dial to select the speed. Select between speeds 1 or 2, or for
optimum chopping, use the PULSE function.
9. When food is chopped to your liking, select OFF(O) or release the dial from
the PULSE position. Wait until blade has stopped rotating before removing lid.
How to Use (continued)
The suction cup feet on the bottom of your Food
Processor are designed to keep the appliance
stationary during use. Each time you position the
machine on your countertop the suction pads will
attach to it.
To remove the suction cups from the countertop, lift
the base from the counter by placing your hands
underneath it (as shown) and lift it to one side. One-
by-one the suction cups will release.
How to Release the Suction Cup Feet After Use

14
Cleaning the Main Unit
Wipe the main motor unit with a well-wrung damp sponge and then dry with a dry
cloth.
Cleaning the Attachments
Wash all of the attachments - the lids, blade, discs, food pusher - in warm, soapy
water. To clean food thoroughly from the bowl and bowl lid/food chute, immerse it
in warm, soapy water.
Rinse and dry all parts thoroughly. Ensure all parts are properly dry before re-
assembling the appliance.
Storage
To store, place the bowl on to the base. Then place Chopping Blade on motor
shaft and Slicer Disc on top of the Chopping Blade. Place a Lid on Bowl but do
not lock.
NOTE: Do not store the machine with lid in the locked position; this may put strain
on the interlock tab.
Cleaning and Maintenance
CAUTION:
Handle the attachments with care as the blades are sharp. Exercise
caution when attaching, removing, cleaning and storing the
attachments.

15
Troubleshooting
Potential
Problem Probable Cause / Solution
The food
processor does
not operate on
any speed or
pulse.
1. Is the machine plugged in? Does the mains socket work ok?
2. Are the bowl, lid and feed chute all locked in place? See section
called ‘Before First Use’
Food is not
chopped, sliced
or shredded
uniformly.
Packing too much food in the feed chute, or pushing too hard on the
feed pusher may cause the processed food to be irregularly sliced or
shredded.
Unit stops and
will not come
back on.
1. Are the bowl and feed chute lid all locked in place? They may
have moved slightly during processing.
2. Is the mains plug socket still working? Check it by plugging in a
working lamp or other appliance. You may have overloaded the
circuit and blown a fuse or tripped the circuit breaker.
3. Turn the food processor OFF, allow it to stand for 3 to 4 minutes,
then turn back ON.
If none of these suggestions correct the problem, DO NOT attempt
to repair the unit. Contact the Duronic Customer Care Team for
further assistance.
Unit has a
burning smell.
There may be a residue left on the motor from the manufacturing
process, causing a slight odour during initial use. This will go away.
If a strong odour or any visible smoke appears, unplug the food
processor IMMEDIATELY and contact the Duronic Customer Care
Team.
Motor seems
weak.
1. Are you using the recommended speed for the food you are
processing?
2. Are you using the recommended food size and quantity to be
processed?

16
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions
contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect,
inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work,
under the guarantee
7. Valid in the UK only
This product is tted with CE:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.
Follow Us

17
Manuel d’utilisation en français

18
Caractéristiques et Spécications
Composants
1
2
3
5
4
6
7
8
9
10
11
12
13
1. Poussoir
2. Trappe
3. Bec du robot de cuisine
4. Couvercle
5.
du robot de cuisine
6.
Disque à râper et à trancher
en acier inoxydable
7.
Adaptateur de déchiquetage
et de tranchage en plastique
Couvercle du hachoir
8. Lame à découper en acier inoxydable
9. Arbre du moteur
10. Bol
11. Base / Unité moteur
12. Cadran
13.
de commande
Câble d'alimentation
Modèle CapacitéDimensions Puissance
MFP400 500ml 14x20x34cm 400W 220-240V
50-60Hz
Tension
d'entrée

19
•
VEUILLEZ LIRE ATTENTIVEMENT CE MANUEL ET LE GARDER
COMME REFERENCE FUTURE
•
Cet appareil a été conçu pour un usage intérieur. Ne l'utilisez pas à l'extérieur.
•
N'utilisez pas cet appareil pour un usage industriel ou commercial, il
est destiné à un usage domestique seulement.
•
Cet appareil n'est pas conçu pour être utilisé par des personnes (y compris des
enfants) dont les capacités physiques, sensorielles ou mentales sont limitées
ou qui manquent de savoir et d'expérience, à moins qu'elles ne soient
supervisées ou qu'elles aient reçu les instructions nécessaires à l'utilisation de
cet appareil par la personne responsable de leur sécurité.
•
Les enfants doivent être supervisés à tout instant afin de s'assurer qu'ils ne
jouent pas avec l'appareil.
•
Utilisez l'appareil uniquement hors de portée des enfants car il y a des lames
tranchantes à l'intérieur du bol. Rangez les lames en toute sécurité hors de
portée des enfants.
•
N'utilisez pas cet appareil si le câble ou la prise sont endommagés. Si l'un est
endommagé, veuillez retourner l'appareil à Duronic pour une réparation par
un technicien professionnel.
•
N'essayez jamais de remplacer les pièces et de réparer l'appareil par
vous-même. Ne modifiez pas l'appareil d'une manière qui n'est pas décrite dans
les instructions d'utilisation. La machine contient des pièces sous tension. Les
réparations ne peuvent être effectuées que par Duronic, en utilisant des pièces
de rechange et des accessoires d'origine.
Si une rallonge/un câble est nécessaire pour relier l'appareil à une prise de
courant trop éloignée et hors de portée du câble fourni avec la machine, veuillez
vous assurer que:
- les caractéristiques électriques de la rallonge sont au moins aussi
élevées que les caractéristiques électriques de l'appareil.
- la rallonge a une mise à la terre.
- aucun autre appareil n'est branché sur cette même rallonge.
-
de sécuritéInstructions
la rallonge est positionnée de façon sécurisée afin d'éviter qu'un
enfant ou un animal ne puisse tirer dessus ou qu'elle se décroche.

20
• Utilisez toujours l'appareil sur une surface plate, stable et sèche. Ne
placez pas le robot de cuisine sur ou à côté d'une surface chaude.
• Placez l'appareil et son câble d'alimentation à l'arrière du plan de travail,
hors de portée des enfants.
•
•
Débranchez l'appareil de la prise si vous ne l'utilisez pas pendant une
longue période ou si vous êtes absent pendant une longue période.
•
Ne débranchez jamais la prise en tirant sur le câble.
•
Débranchez l'appareil de la prise lorsqu'il n'est pas utilisé ou avant de le nettoyer.
•
Cet appareil n'est pas conçu pour être utilisé avec un minuteur externe
ou un système de contrôle à distance.
•
Ne laissez pas le câble d'alimentation pendre de l'extrémité d'une surface
ou toucher des surfaces chaudes.
•
N'utilisez pas l'appareil pour autre chose que mélanger ou hacher des aliments.
•
N'utilisez pas le robot de cuisine en ayant les mains mouillées.
•
Pour nettoyer, essuyez le corps de la machine avec un chiffon humide bien
essoré. Ne le plongez pas dans l'eau ou d'autres liquides. Lavez les tasses et
les couvercles avec de l'eau tiède et du savon. Séchez avant de replacer les
tasses dans la machine.
•
N'allumez pas l'appareil si le bol est vide et n'utilisez pas le robot culinaire
plus de 30 secondes d'affilée car cela surchaufferait le moteur. Après 30
secondes d'utilisation, laissez la machine refroidir pendant 3 minutes.
•
Assurez-vous que le couvercle est bien verrouillé en place avant d'utiliser
l'appareil.
•
N'introduisez jamais d'aliments dans la trappe à la main. Utilisez toujours
le poussoir.
•
N'essayez pas de défaire le mécanisme de verrouillage du couvercle.
•
Assurez-vous que la lame ou le disque est complètement arrêté avant de
retirer le couvercle.
Instructions de sécurité (suite)
Soyez prudent lorsque vous retirez la lame et le disque du bol, lorsque vous
videz le bol et lors du nettoyage.
