DVTEL ioimage trk100d User manual

trk100/trk100d/trk200
Installation Manual
Rev E March 2014
The contents of this manual may not
be reproduced or reprinted in whole
or in part without the express written
permission of DVTEL, INC.
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660

Table of Contents
i
Table of Contents
1Document Information.....................................................................................................v
2Introduction.................................................................................................................... 1
2.1 Items Included in the Package ....................................................................................... 2
2.2 Hardware Description .................................................................................................... 2
2.2.1 trk100/trk100d Hardware Description .......................................................................3
2.2.2 trk200 Hardware Description .....................................................................................5
3Installing and Connecting the Unit................................................................................... 9
3.1 Installing the Unit........................................................................................................... 9
3.2 Connecting the Unit ....................................................................................................... 9
3.2.1 Grounding the Unit...................................................................................................10
3.2.2 Connecting the Unit to the Power Supply ................................................................10
3.2.3 Connecting the Unit to the Network ........................................................................11
3.2.4 Connecting the Video Source (Camera) to the Unit .................................................12
3.2.5 Connecting a Microphone to the Unit......................................................................13
3.2.6 Connecting a Loudspeaker to the Unit .....................................................................14
3.2.7 Connecting PTZ Camera Control Lines to the Unit ...................................................14
3.2.8 Connecting the Analog Video Output to an Analog Device......................................15
3.2.9 Connecting the Unit to Receive Alarms from External Devices (Alarm Inputs)........15
3.2.10 Connecting the Unit to Control an External Device (Using Relay Outputs)..............16
3.3 Resetting the Unit ........................................................................................................ 17
3.3.1 Reset Using the RESET Button ..................................................................................17
3.3.2 Reset by Removing the Power Supply ......................................................................17
3.4 Solo Setup .................................................................................................................... 17
Appendix .............................................................................................................................18
A.1. Technical Specifications ............................................................................................... 19
A.2. Connecting Leads to a Spring Clamp Terminal Block ................................................... 21
A.3. Solo Setup Window...................................................................................................... 22
A.4. Troubleshooting ........................................................................................................... 24
Contacting DVTEL.................................................................................................................27

trk100/trk100d/trk200 Installation Manual
ii
List of Figures
Figure 1: trk100/trk100d Unit.....................................................................................................................1
Figure 2: trk200 Unit..................................................................................................................................1
Figure 3: trk100, trk100d and trk200 Unit Connectivity.............................................................................1
Figure 4: trk100/trk100d Front Panel.........................................................................................................3
Figure 5: trk100/trk100d Back Panel.........................................................................................................4
Figure 6: trk200 Front Panel......................................................................................................................5
Figure 7: trk200 Back Panel ......................................................................................................................6
Figure 8: DNA Discovery Window ...........................................................................................................12
Figure 9: Microphone Connection to the Unit..........................................................................................13
Figure 10: Loudspeaker Connection to the Unit......................................................................................14
Figure 11: Relay Contact Schematic.......................................................................................................16
Figure 12: Spring Clamp Terminal Block.................................................................................................21
Figure 13: Connecting a Wire to a Terminal Block..................................................................................21
Figure 14: Solo Setup Window................................................................................................................22

Revision History
iii
Revision History
Version
Date
Author
Comments
1.1
January 2004
Elisabeth Levy
First release (released as trk100 Installation and
Setup Guide)
1.2
July 2004
Elisabeth Levy
Second release
1.3
October 2004
Elisabeth Levy
Third release
Ver. A2
August 2009
Leigh
Includes trk100d and trk200.
Rev D
April 2013
Alan Singer
Added Solo Setup. Updated look and feel.
Rev E
March 2014
Alan Singer
Added Revision History. Added DNA to section 3.2.3.
Updated look and feel.

Document Information
v
1Document Information
Document Scope and Purpose
The purpose of this document is to provide instructions and installation procedures for physically
connecting the trk100, trk100d and trk200 analytic encoders. After completing the physical installation,
additional setup and configurations are required before video analysis and detection can commence.
For information on the unit setup and configuration, refer to the HTML Edition Units User’s Guide.
Note:
This document is intended for use by technical users who have a basic understanding of
CCTV camera/video equipment and LAN/WAN network connections.
Warning:
Installation must follow safety, standards, and electrical codes as well as the laws that apply
where the units are being installed.
Proprietary Rights and Non-Disclosure
This manual is delivered subject to the following restrictions and conditions:
This document contains proprietary information belonging to DVTEL, Inc. This information is
supplied solely for the purpose of assisting explicitly the licensee of the DVTEL units.
No part of this document contents may be used for any other purpose, disclosed to any third
party or reproduced by any means, electronic or mechanical, without the express prior written
permission of DVTEL, Inc.
Trademarks and Copyrights
This manual and its contents herein are owned by DVTEL, Inc. All rights reserved.
DVTEL, the DVTEL logo, ioimage, the ioimage logo, ioimage analytics, ioibox, ioicam, ioiware, ioiware
command center, ioiware setup, CP-2202-361P/N, IOI-XTRK-10D, IOI-XTRK-100D, trk1, trk10d, trk100,
trk100d, trk-101, trk200, trk4000d, trk8000, mmp100dn, sc1dn-A, XPVA-10D, and XPVA-100D are
trademarks of DVTEL, Inc.
Products and trademarks mentioned herein are for identification purposes only and may be registered
trademarks of their respective companies.
DVTEL, Inc. makes no representations whatsoever about any other products or trademarks mentioned in
the manual.
© DVTEL, Inc. 2014. All rights reserved.

trk100/trk100d/trk200 Installation Manual
vi
Disclaimer
Users of DVTEL products accept full responsibility for ensuring the suitability and considering the role of the
product detection capabilities and their limitation as they apply to their unique site requirements.
DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use.
DVTEL, Inc. accepts no responsibility for improper use or incomplete security and safety measures.
Failure in part or in whole of the installer, owner, or user in any way to follow the prescribed procedures or
to heed WARNINGS and CAUTIONS shall absolve DVTEL, Inc. and its agents from any resulting liability.
Specifications and information in this guide are subject to change without notice.
Document Conventions
WARNING and CAUTION notes are distributed throughout this document, whenever applicable, to alert
you of potentially hazardous situations. These may be hazards associated with a task or a procedure you
are carrying out or are about to carry out.
The following document conventions are used throughout this manual:
A Warning is a precautionary message that indicates a procedure or condition where there
are potential hazards of personal injury or death.
A Caution is a precautionary message that indicates a procedure or condition where there
are potential hazards of permanent damage to the equipment and or loss of data.
A Note is useful information to prevent problems, help with successful installation, or to
provide additional understanding of the products and installation.
A Tip is information and best practices that are useful or provide some benefit for
installation and use of ioimage products.
General Cautions and Warnings
This section contains information that indicates a procedure or condition where there are potential
hazards. These may be hazards associated with a task or procedure a user is carrying out or about to carry
out. WARNINGS and CAUTIONS are distributed throughout this document, whenever applicable, to alert
the user of potentially hazardous situations.
SAVE ALL SAFETY AND OPERATING INSTRUCTIONS FOR FUTURE USE.
Although the unit is designed and manufactured in compliance with all applicable safety standards, certain
hazards are present during the installation of this equipment.
To help ensure safety and to help reduce risk of injury or damage, observe the following:

Document Information
vii
Warning:
1. Only qualified trained personnel should service and repair this equipment.
2. Observe local codes and laws and ensure that installation and operation are in
accordance with fire, security and safety standards.
Electrical Safety Notice and Warnings
Warning:
1. Read the installation instructions before you connect the unit to a power source.
2. Electrical safety should always be observed. All electrical connections must be
performed by a certified electrician.
3. Use the supplied power supply and protect against static electricity, ground faults
and power surges.
4. The unit uses a three-wire power cord to make sure that the product is properly
grounded when in use. The plug on this cord will only fit into a grounding-type
outlet. This is a safety feature. If the intended power outlet does not support three
prongs, one of which is a ground, contact an electrician to install the appropriate
outlet. NEVER remove or otherwise attempt to bypass the ground pin of the power
cord. Do not operate the unit in the absence of a suitably installed ground
conductor.
5. If you use an extension cord with this system, make sure that the total ampere
rating on the products plugged into the extension cord does not exceed the
extension cord ampere rating.
6. To avoid possible shock hazards or damaging the unit, assure that the positive and
negative of the power leads are properly connected to the terminal block connector
before plugging it into the unit or turning on the power source.
7. In the following situations, the electric power should be turned off immediately and
appropriate repairs, replacements or remedies should be taken if:
The power line or plug is damaged, frayed or shows heavy wear.
The unit has been physically crushed or deformed.
The unit has been exposed to water.
The unit has been exposed to, or shows signs of damage from, fire, intense heat,
heavy smoke, fumes, or vapors.
Electrical connections of the unit become abnormally hot or generate smoke.
The unit has been dropped, damaged or shows signs of loose internal parts.
The unit does not operate properly.

trk100/trk100d/trk200 Installation Manual
viii
Caution:
To avoid damage from overheating or unit failure, assure that there is sufficient
temperature regulation to support the unit’s requirements (cooling/heating). Operating
temperature should be kept in the range 0° to 50°C (32° to 122°F), with no more than 95%
non-condensing humidity.
Minimizing EMI and RFI
When wires run for a significant distance in an electromagnetic field, electromagnetic interference (EMI)
can occur. Strong EMI (e.g. lightning or radio transmitters) can destroy the units and can pose an electrical
hazard by conducting power through lines and into the system. Poor quality or worn wiring can result in
radio frequency interference (RFI). To minimize the effects of EMI and RFI, consult your reseller.
Site Preparation
There are several requirements that should be properly addressed prior to installation at the site. The
following specifications are requirements for proper installation and operation of the unit:
Ambient Environment Conditions: Avoid positioning the unit near heaters or heating system
outputs. Avoid exposure to direct sunlight. Use proper maintenance to ensure that the unit is
free from dust, dirt, smoke, particles, chemicals, smoke, water or water condensation, and
exposure to EMI.
Accessibility: The location used should allow easy access to unit connections and cables.
Safety: Cables and electrical cords should be routed in a manner that prevents safety hazards,
such as from tripping, wire fraying, overheating, etc. Ensure that nothing rests on the unit’s
cables or power cords.
Ample Air Circulation: Leave enough space around the unit to allow free air circulation.
Cabling Considerations: Units should be placed in locations that are optimal for the type of
video cabling used between the unit and the cameras and external devices. Using a cable
longer than the manufacturer’s specifications for optimal video signal may result in
degradation of color and video parameters.
Physical Security:The unit provides threat detection for physical security systems. In order to
ensure that the unit cannot be disabled or tampered with, the system should be installed with
security measures regarding physical access by trusted and un-trusted parties.
Network Security:The unit transmits over IP to security personnel for video surveillance.
Proper network security measures should be in place to assure networks remain operating and
free from malicious interference. The unit is intended for installation on the backbone of a
trusted network.
Electrostatic Safeguards:The unit as well as other equipment connected to it (relay outputs,
alarm inputs, racks, carpeting, etc.) shall be properly grounded to prevent electrostatic
discharge.
The physical installation of the unit is the first phase of making the unit operational in a security plan. The
goal is to physically place the unit, connect it to other devices in the system, and to establish network
connectivity. When finished with the physical installation, refer to the HTML Edition Units User’s Guide to
complete the second phase of installation, which is the setup and configuration of the unit.

Introduction
1
2Introduction
The trk100, trk100d and trk200 units are self-contained video analytic IP encoders that monitor the video
input from a camera, providing real-time detection and autonomous tracking capabilities.
The trk100 provides a single video channel with CIF resolution
The trk100d provides a single video channel with 4CIF resolution
The trk200 provides two video channels with CIF resolution
Operators can define rules, perimeter lines, sterile zones and other criteria for intrusion detection. In
addition to its analytic capabilities, the encoder also transforms the input video into a standards-compliant,
compressed IP video stream.
Figure 1: trk100/trk100d Unit
Figure 2: trk200 Unit
The unit analyzes the captured video signal, generates alarms, and notifies operators of the presence of
people, vehicles or objects. It can stop and detect events in multiple preset zones. Users can define the
events and location in the video of the image that can be detected with user-customizable rules and
positioning criteria. The camera simultaneously provides video output in two formats: analog video and
compressed digital video over IP. On-screen overlays indicate where the detection has occurred on the
video output.
Figure 3: trk100, trk100d and trk200 Unit Connectivity
For sites with Pan/Tilt/Zoom (PTZ) cameras, once detection of a moving object has occurred, the moving
object can be tracked autonomously as the unit can guide and move a connected PTZ camera to keep the
threat centered in a magnified view. Additionally, a single PTZ camera can be configured to detect on the
camera presets, allowing it to automatically monitor large and varied areas.

trk100/trk100d/trk200 Installation Manual
2
This chapter includes the following sections:
Items Included in the Package (page 2)
Hardware Description (page 2)
2.1 Items Included in the Package
The unit package contains the following items:
QTY
Description
1
trk100, trk100d or trk200 unit
1
Power Supply with IEC power cord (C13/C14)
2
Terminal block spring clamp connectors (for relay outputs and alarm inputs)
1
Documentation and utilities CD
Note:
An AC adaptor matching the unit’s electrical specifications (part number DVT-PWR-40W)
can be purchased from DVTEL.
Related Documentation:
HTML Edition Units User’s Guide
ioi Product Selection Matrix
2.2 Hardware Description
This section describes the hardware connections of the trk100/trk100d and trk200 units:
trk100/trk100d Front Panel (page 3)
trk100/trk100d Back Panel (page 4)
trk200 Front Panel (page 5)
trk200 Back Panel (page 6)

Introduction
3
2.2.1 trk100/trk100d Hardware Description
2.2.1.1 trk100/trk100d Front Panel
Following is a description of the front panel of the trk100/trk100d unit.
Figure 4: trk100/trk100d Front Panel
Item
Description
RS232/RS485
Serial Interface
(RJ45)
For controlling a Pan/Tilt/Zoom camera via an RS232 or RS485 serial interface.
Caution:
The RS232 standard specifies a maximum open-circuit voltage
of +/-25 volts.
The RS485 standard specifies a maximum voltage of +12V and -
7V.
Exceeding these voltages can cause permanent damage to the unit.
VIDEO IN
(BNC)
Input interface for receiving the surveillance camera analog video signal
(source) for analysis and detection.
VIDEO OUT
(BNC)
Output interface that provides the analog video signal after analysis and
includes detection overlays and additional On-Screen Display (OSD)
information.
Typically connected to analog video equipment such as analog video displays or
analog video recording device (DVR).
Note:
In order to view analog video, analog video out must be enabled in
the unit settings (disabled by default). For more information on
how to enable the analog video out signal, refer to the HTML
Edition Units User’s Guide.
AUDIO IN
(RCA)
Enables remote listening to the sounds captured by a microphone connected to
the unit. See Connecting a Microphone to the Unit (page 13).
AUDIO OUT
(RCA)
Used for talking through a loudspeaker connected to the unit to people located
near the camera being monitored. See Connecting a Loudspeaker to the Unit
(page 14).
Grounding
Terminal
For connecting the unit to the protective ground (earth) according to local
regulations and codes. For more information, see Grounding the Unit (page 10).

trk100/trk100d/trk200 Installation Manual
4
2.2.1.2 trk100/trk100d Back Panel
The following image shows the back panel of the trk100/trk100d unit.
Figure 5: trk100/trk100d Back Panel
The back panel of the unit includes the following connections:
Item
Description
POWER
For powering the unit from a 12VDC power source.
LED
Indicators
The unit includes 4 LEDs. Only the POWER and ACTIVE LEDs are used.
POWER
Steady green LED indicates power is on.
ACTIVE
Flashing green LED indicates the unit is
working properly on the network.
External
Device
Connections
Terminal block for the following connections:
ALARM INPUT: Single alarm input connection (a set of two wires) used to
receive alarm signals from an external device —for example, a fire sensor, PIR
(passive infrared) sensor, fence sensor, etc. —with a dry contact output to the
terminal block. Four independent alarm inputs are available (maximum 24VDC,
100mA input).
RELAY OUTPUT: Output signal (opto-isolated) used to provide an indication
signal for controlling a single external device, such as an electrical door lock.
Two independent relay outputs are available, each including the following
terminals:
o NO: Terminal for NORMALLY OPEN configurations
o C: Terminal for COMMON wire configurations for either NC or NO
o NC: Terminal for NORMALLY CLOSED configurations
10/100
Network
Port
(2x RJ45)
Primary Ethernet port (1) for connecting the unit to the network.
Secondary Ethernet port (2) for connecting as a daisy chain connection
between multiple units.
RESET
Button
For resetting the unit to previous settings.

Introduction
5
2.2.2 trk200 Hardware Description
2.2.2.1 trk200 Front Panel
Following is a description of the front panel of the trk200 unit.
Figure 6: trk200 Front Panel
Item
Description
RS232/RS485
Serial Interface
(RJ45)
For controlling a Pan/Tilt/Zoom camera via an RS232 or RS485 serial interface.
Caution:
The RS232 standard specifies a maximum open-circuit voltage
of +/-25 volts.
The RS485 standard specifies a maximum voltage of +12V and -
7V.
Exceeding this voltage can cause permanent damage to the unit.
VIDEO IN
(BNC)
Input interfaces (Channel 1 and 2) for receiving the surveillance camera analog
video signal (source) for analysis and detection. One BNC connector is provided
for each video channel.
VIDEO OUT
(BNC)
Output interfaces (channels 1 and 2) that provide the analog video signal after
analysis and include detection overlays and additional OSD information.
Typically connected to analog video equipment, such as analog video displays
or an analog video recording device (DVR). One BNC connector is provided for
each video channel.
Note:
In order to view analog video, analog video out must be enabled in
the unit settings (disabled by default). For more information on
how to enable the analog video out signal, refer to the HTML
Edition Units User’s Guide.
AUDIO IN
(RCA)
Enables remote listening to the sounds captured by a microphone connected to
the unit through this interface. One RCA connector is provided for each
channel. See Connecting a Microphone to the Unit (page 13).

trk100/trk100d/trk200 Installation Manual
6
Item
Description
AUDIO OUT
(RCA)
Used for talking through a loudspeaker connected to the unit to people located
near the camera being monitored. One RCA connector is provided for each
channel. See Connecting a Loudspeaker to the Unit (page 14).
Grounding
Terminal
For connecting the unit to the protective ground (earth) according to local
regulations and codes. For more information, see Grounding the Unit (page 10).
2.2.2.2 trk200 Back Panel
The following image shows the back panel of the trk200 unit.
Figure 7: trk200 Back Panel
The back panel of the unit includes the following connections:
Item
Description
POWER
For powering the unit from a 12VDC power source.
LED
Indicators
The unit includes 4 LEDs per channel. Only the POWER, ACTIVE and PTZ PLAYLIST
LEDs are used on Channel 1. Only the POWER and ACTIVE LEDs are used on
Channel 2.
POWER
Steady green LED
indicates power is on.
ACTIVE
Flashing green LED
indicates the unit is
working properly on
the network.
PTZ PLAYLIST
(Channel 1)
Flashing green LED if
a PTZ playlist is
running (default is
OFF).

Introduction
7
Item
Description
External
Device
Connections
Terminal block for the following connections:
ALARM INPUT: Single alarm input connection (a set of two wires) used to
receive alarm signals from an external device —for example, a fire sensor, PIR
(passive infrared) sensor, fence sensor, etc. —with a dry contact output to the
terminal block. Four independent alarm inputs are available for use by any
channel (maximum 24VDC, 100mA input).
RELAY OUTPUT: Output signal (opto-isolated) used to provide an indication
signal for controlling a single external device, such as an electrical door lock.
Two independent relay outputs are available for use by any channel, each
including the following terminals:
o NO: Terminal for NORMALLY OPEN configurations
o C: Terminal for COMMON wire configurations for either NC or NO
o NC: Terminal for NORMALLY CLOSED configurations
10/100
Network
Port
(2x RJ45)
Primary Ethernet port (1) for connecting the unit to the network
Secondary Ethernet port (2) for connecting as a daisy chain connection
between multiple ioimage units
RESET
Button
For resetting the unit to previous settings.

Installing and Connecting the Unit
9
3Installing and Connecting the Unit
This section describes how to install and connect the unit and includes the following sections:
Installing the Unit (page 9)
Connecting the Unit (page 9)
Resetting the Unit (page 17)
Note:
After connecting the unit, proceed to configure the unit as described in the HTML Edition
Units User’s Guide.
3.1 Installing the Unit
The unit can be installed inside an equipment room on a regular shelf or in a rack. When installing the unit,
make sure that:
It is securely tied down and cannot be easily dislodged
Operating temperatures are kept between the minimum/maximum allowed at all times
Proper ventilation is provided so that the air is free to circulate around the unit
The unit is protected from direct weather conditions (for example, sunlight, rain, dust, etc.)
Caution:
To avoid damage from overheating or unit failure, ensure that there is sufficient
temperature regulation to support the unit’s cooling/heating requirements. Ambient
operating temperature should be kept within 0°to 50°C (32° to 122°F), with no more than
95% non-condensing humidity.
3.2 Connecting the Unit
This section describes the procedures for connecting the unit and includes the following sub-sections:
Grounding the Unit (page 10)
Connecting the Unit to the Power Supply (page 10)
Connecting the Unit to the Network (page 11)
Connecting the Video Source (Camera) to the Unit (page 12)
Connecting a Microphone to the Unit (page 13)
Connecting a Loudspeaker to the Unit (page 14
Connecting PTZ Camera Controller Lines (page 14)
Connecting the Analog Video Output to an Analog Device (page 15)
Connecting the Unit to Receive Alarms from External Devices (Alarm Inputs) (page 15)
Connecting the Unit to Control an External Device (Using Relay Outputs) (page 16)

trk100/trk100d/trk200 Installation Manual
10
3.2.1 Grounding the Unit
The unit must be grounded according to local regulations and codes.
To ground the unit
1. Loosen the screw of the grounding terminal located on the back panel of the unit. See Figure 5:
trk100/trk100d Back Panel (page 4) and Figure 7: trk200 Back Panel (page 6).
2. Attach a properly rated ground cable. Make sure the ring/spade terminal of the grounding
cable is positioned between the toothed washers. Tighten the screw.
3. Ensure that the other end of the ground cable is connected to protective earth according to
local regulations and codes.
3.2.2 Connecting the Unit to the Power Supply
You can power the unit by using the 12VDC power supply provided by DVTEL or from a power outlet. An AC
adaptor matching the required specifications can be purchased as an accessory from DVTEL.
Caution:
Before connecting to the power, review the Electrical Safety Notice and Warnings (page
vii).
To power to the unit from a power outlet
1. When powering the unit from a power outlet, observe the following recommended AC adaptor
specifications:
o Power Adaptor Input: 110-240VAC, 47-63Hz, 1A
o Power Adaptor Output: 12VDC, 0.6A
o Polarity:
2. Connect the AC adaptor output to the unit power input on the back panel of the unit. See
Figure 5: trk100/trk100d Back Panel (page 2) and Figure 7: trk200 Back Panel (page 6).
3. Connect the AC adaptor to the power outlet.
Warning:
1. To prevent bodily injury or damage to the unit, use only properly rated and
approved power supplies and/or AC adaptors.
2. Make sure that the power supply connection matches the positive and negative
polarity on the unit.
3. Make sure that the power supply matches the required specifications. Electrical
safety should always be observed.
