DW MEGApix CaaS DWC-MB44Wi650C6 User manual

User’s Manual7FS04/22
#FGPSFJOTUBMMJOHBOEVTJOHUIFDBNFSBQMFBTFSFBEUIJTNBOVBMDBSFGVMMZ
#FTVSFUPLFFQJUIBOEZGPSGVUVSFSFGFSFODF
MEGApix® CaaSTM 4MP
Long Range #VMMFU$BNFSB
DWC-MB44Wi650C6 - 64GB storage
DWC-MB44Wi650C1 - 128GB storage
DWC-MB44Wi650C2 - 256GB storage
DWC-MB44Wi650C5 - 512GB storage
DWC-MB44Wi650C1T - 1TB storage

Safety Information
This symbol indicates that dangerous voltage
consisting a risk of electric shock is present within
this unit.
Warning Precaution
This exclamation point symbol is intended to alert the
user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
To prevent damage which may result in fire or electric shoc
hazard, do not expose this appliance to rain or moisture.
WARNING
Be sure to use only the standard adapter that is specified i
the specification sheet. Using any other adapter could caus
fire, electrical shock, or damage to the product
Incorrectly connecting the power supply or replacing battery
may cause explosion, fire, electric shock, or damage to th
product.
Do not connect multiple cameras to a single adapter.
Exceeding the capacity may cause excessive heat generation
or fire
Securely plug the power cord into the power receptacle.
Insecure connection may cause fire
When installing the camera, fasten it securely and firmly
A falling camera may cause personal injury.
Do not place conductive objects (e.g. screw drivers, coins,
metal items, etc.) or containers filled with water on top o
the camera. Doing so may cause personal injury due to fire
electric shock, or falling objects.
Do not install the unit in humid, dusty, or sooty locations.
Doing so may cause fire or electric shock
If any unusual smells or smoke come from the unit, stop
using the product. Immediately disconnect the power sorce
and contact the service center. Continued use in such a
condition may cause fire or electric shock
If this product fails to operate normally, contact the nearest
service center. Never disassemble or modify this product in
any way.
When cleaning, do not spray water directly onto parts of the
product. Doing so may cause fire or electric shock
WARNING
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Precaution
Operating
• Before using, make sure power supply and all other parts are
properly connected.
• While operating, if any abnormal condition or malfunction
is observed, stop using the camera immediately and contact
your dealer.
Handling
• Do not disassemble or tamper with parts inside the camera.
• Do not drop the camera or subject it to shock or vibration as
this can damage the camera.
• Clean the clear dome cover with extra care. Scratches and
dust can ruin the quality of the camera image.
Installation and Storage
• Do not install the camera in areas of extreme temperature,
exceeding the allowed range.
•Avoid installing in humid or dusty environments.
•Avoid installing in places where radiation is present.
•Avoid installing in places where there are strong magnetic
fields and electric signals.
•Avoid installing in places where the camera would be subject
to strong vibrations.
•Never expose the camera to rain or water.

Important Safety Instructions
Disposal of Old Appliances
1. When this crossed-out wheel bin symbol is attached to a product it means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately form the municipal waste stream
stream in accordance to laws designated by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interferenece at his own expense.
1. Read these instructions. - All safety and operating instructions should be read before installation or operation.
2. Keep these instructions. - The safety, operating and use instructions should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use instructions should be followed.
5. Do not use this device near water. - For example: near a bath tub, wash bowl, kitchen sink, laundry tub, in a wet
basement; near a swimming pool; etc.
6. Clean only with dry cloth. - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Slots and
openings in the cabinet are provided for ventilation, to ensure reliable operation of the product, and to protect it
from over-heating. The openings should never be blocked by placing the product on bed, sofa, rug or other similar
surfaces. This product should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided and the manufacturer’s instructions have been adhere to.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.

Table of Contents
Introduction
Product & Accessories......................................................................................................................................................................4
Parts Name...........................................................................................................................................................................................5
Installation
Factory Reset.......................................................................................................................................................................................6
Installation............................................................................................................................................................................................6
Cabling..................................................................................................................................................................................................7
SD Memory Card................................................................................................................................................................................9
Network Setup
DW IP Finder......................................................................................................................................................................................10
Network Connection .....................................................................................................................................................................61
DDNS Registration..........................................................................................................................................................................62
Network Environments.................................................................................................................................................................63
Port Forwarding...............................................................................................................................................................................66
Starting the IP Camera...................................................................................................................................................................67
Web Viewer
GUI Overview....................................................................................................................................................................................11
Camera Settings
Setup > Video & Audio Setup > Video Configuration.......................................................................................................12
Setup > Video & Audio > OSD Configuration.......................................................................................................................16
Setup > Video & Audio > Region of Interest Configuration ...........................................................................................17
Setup > Video & Audio > Privacy Mask Configuration......................................................................................................18
Setup > Camera > Camera Image adjustment and Enhancement...............................................................................19
Setup > Network Settings............................................................................................................................................................27
Setup > Trigger Action..................................................................................................................................................................36
Setup > Security..............................................................................................................................................................................46
Setup > System > Firmware Update........................................................................................................................................54
Setup > System > Date & Time...................................................................................................................................................56
Setup > System > User Management......................................................................................................................................57
Setup > System > System Log....................................................................................................................................................58
Setup > System > System Information....................................................................................................................................53
Setup > System > Factory Reset................................................................................................................................................59
Setup > System > Restart.............................................................................................................................................................60
Appendix....................................................................................................................................................68
FAQs............................................................................................................................................................68
Dimensions.................................................................................................................................................69
Warranty.....................................................................................................................................................70
Limits & Exclusions.....................................................................................................................................71
Setup > Events Setup.....................................................................................................................................................................39
Disassembling the Camera.............................................................................................................................................................6
Setup > Camera > Video Enhancement..................................................................................................................................25
Setup > Edge Setup........................................................................................................................................................................43

Product & Accessories
Introduction -
Camera
Cables
Screws and plastic anchors-4pcs
Test video cable
Mounting template
Please check if all the camera and accessories are included in the package.
Hex Allen wrench Waterproof cap and gasket
DC plug cable
Quick setup guide
4

Part Name
Introduction -
Bracket
Pan/tilt stopper screw
Control board
Control board cap
Alarm in/out
Sunshield
Lens
Sunshield adjusting screws
RJ-45 connector
Waterproof cap
Audio in/out
DC power jack
5

Installation
Installation -
Before installing your camera, you have to read the following cautions.
1. You have to check whether the location can bear ve times of the weight of your camera.
2. Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise
it may cause a breakdown or re.
3. When installing your camera, don’t allow any person to approach the installation site. If you have any
valuable things under the place, move them away.
Zoom Out
Zoom In
WIDE
TELE
Reset to the Factory Default
Press the reset button for 5 seconds to return the setup
to the factory default.
Warning
If you press the ‘Reset’ button, you will lose all setting
data. If needed, please, make a note for further
installation.
1
2
3
4
Using the Template sheet, make the cabling hole on
the wall/ceiling.
Connect the network cable, power cable respectively.
See the section ‘Installation - Cabling’ for details.
Fix the camera on the wall/ceiling by screw provided.
Loosen the Pan/Tilt stoper screw a litte before xing the camera.
By using the test video cable, check the screen during
installation. You can adjust the zoom ratio using the
T-W jog button.
SD Card Slot
Reset
T-W Jog Button
Test Video Output
6

Cabling
Installation -
Power
Two Options
Use a PoE-enabled switch to connect data and power through a single cable and begin viewing and recording images instantly.
A non-PoE switch will require an adaptor for power transmission.
Ethernet cableEthernet cable
2. Not using PoE Switch or PoE Injector
If a PoE-enabled switch is not used, use a power adaptor
for power transmission and non-PoE switch for data
transmission.
Follow the illustrations below to connect the camera
without a PoE-enabled Switch.
1. Using a PoE Switch or PoE Injector
The Camera is PoE-compliant, allowing transmission of
power and data via a single Ethernet cable.
PoE eliminates the need for the dierent cables used to
power, record, or control the camera. Follow the illustration
below to connect the camera to a PoE-enabled switch using
an Ethernet cable.
7

N.C
Activation
Activation
N.O ,Q
&20
,Q
&20
,Q
&20
,Q
&20
Cabling
Installation -
1
4Alarm In
1Audio In 2Audio Out
3
4
2
Red : ALARM_OUT+
Black : ALARM_OUT-
Yellow : GND
White : ALARM_IN+
Alarm Out
It connects to the alarm lights, siren or lamps and the sensor
types are normal open and normal close.
Alarm & light bar + need to be connected with
power + or adaptor +.
Alarm out+ need to be connected with Alarm - or light bar -.
Alarm out- need to be connected with power - or adaptor -.
Alarm In
Cable of the sensor/alarm input device should connect to
white and yellow line of the Alam cable.
Audio In
Cable of the sensor/alarm input device should connect to
alarm in+ and alarm in- of the cable slot.
Audio Out
It connects to the alarm lights, siren or lamps and the sensor
types are normal open and normal close.
Cable of the alarm output device should connect to alarm
out+ and alarm out- of the cable slot.
3Alarm Out
If the speaker without the amplier is connected to Audio Out port, it
Out port, it doesn’t work properly. Therefore, the speaker with the
amplier or the separate amplier is needed.
8

Inserting/Removing SD Memory Card
Installation -
1Inserting an SD Memory Card
Insert the SD card in the arrow direction.
Don’t insert the SD memory card while it’s upside down by force.
Otherwise, it may damage the SD memory card.
Use the tweezers when inserting or picking out the SD card.
2Removing an SD Memory Card
Removing an SD Memory Card Gently press down on the
exposed end of the memory card as shown in the diagram
to eject the memory card from the slot.
Pressing too hard on the SD memory card can cause the card to
shoot out uncontrollably from the slot when released.
If you have saved data in the SD memory card, removing the SD
memory card prior to setting record to OFF will cause damage to
the data stored in the card.
Micro
The memory card is an external data storage device
that has
to record and share video, audio, and text data using
digital devices.
Recommended SD Card Specication (Not Included)
- Type: Micro SD (SD/SDHC/SDXC)
- Manufacturer: Transcend, Kingston, Toshiba, SanDisk
- Capacity: 4GB~128GB
- Class: over UHS-I U3 Class 10
9

10
Network Setup -
DW IP Finder™
1To install the DW IP Finder, go to: http://www.digital-watchdog.com
2Enter “DW IP Finder” on the search box at the top of the page.
3Go to the “Software” tab on the DW IP Finder page to download the installation file.
4Follow the installation to install the DW IP Finder. Open the DW IP Finder and
click ‘Scan Devices’. It will scan the selected network for all supported devices
and list the results in the table. During the scan, the DW® logo will turn gray.
5When connecting to the camera for the first time, a password must be set. To
set up a password for your camera:
a. Check the box next to the camera in the IP Finder’s search results. You can
select multiple cameras.
b. Click “Bulk Password Assign” on the left.
c. Enter admin/admin for the current username and password. Enter a new
username and password to the right.
Passwords must have a minimum of 8 characters with at least 4
combinations of uppercase letters, lowercase letters, numbers and
special characters. Passwords cannot contain the user ID.
d. Click “change” to apply all changes.
6Select a camera from the list by double-clicking on the camera’s image or
clicking on the ‘Click’ button under the IP Conf. column. The pop-up
window will show the camera’s current network settings, allowing admin
users to adjust the settings as needed.
7To access the camera’s web page, click on the ‘View Camera Website’
from the IP Config window.
8To save changes made to the camera’s setting, enter the username and
password of the camera’s admin account and click ‘Apply’.
Thumbnail view Firmware version
Camera’s uptime
Open IP configuration
settings
Ping camera
Camera’s network
information
Camera’s name, IP and
MAC addresses
Filter results
Scan network
Select network to scan
Show/hide thumbnail view
Refresh thumbnail view
Bulk password assignment
Bulk IP assignment
Firmware upgrade
Selected camera’s
username and
password

Web Viewer Screen -
Basic Screen
Web viewer is optimized with explorer10 or above version and Firefox.
If VLC is not installed or VLC plugin is not supported (Chrome), Live buffering and Channel select menu on 3, 4 will be changed to Live Viewer menu,
and then if HTML5(MJPEG) is selected on Live Viewer menu, then you can check the video.
Live video display. This is the region for live video stream from the camera.
Setup popup button. Click it to open the Setup page to setup details of IP camera like Video, Network, Events, System and etc.
See the section ‘Setup’ .
When the image goes unsmoothly because of bad network connection, it stored image during setup time and shows the image on
the live view screen.
User will see the delayed images as much as setup time.
Channel Select button. Select a stream produced from the camera between Stream 1 ~ 3 to display it in the live view screen.
Refer the ‘Setup > Video & Audio > Video’ to setup the Video Stream.
Below “Menu” is supported in accordance with models.
PTZ Control - Depending on the product model, zoom and focus may not be available.
Preset - Does not support.
Speaker Control - Does not support.
Alarm Input - Does not support.
Relay Out - Does not support.
Motion - It shows the Motion event status.
Event Alert Icon ( ) appears if ‘Motion Detection’ is activated.
Camera Time - Display the camera time.
11

Setup - Video & Audio Setup
Video Configuration
Detail Page - When you selects an item from the menu, you can set the details for the selected item.
Setup Constitution
Video&Audio
[ VIDEO, OSD, ROI, PRIVACY MASK ]
Camera
[ IMAGE ADJUSTMENT, EXPOSURE, DAY&NIGHT, BACKLIGHT, WHITE BALANCE, IMAGE, VIDEO ]
Network
[ STATUS, NETWORK SETTING, AUTO IP, ONVIF, UPNP, DDNS, FTP, SMTP, SNMP, RTSP INFORMATION ]
Trigger Action
[ ACTION RULES, IMAGE TRANSFER ]
Events
[ EVENT RULES, MOTION, TEMPERATURE ]
Edge
[ SPECTRUM EDGE, STORAGE ]
Security
[ IP ADDRESS FILTER, RTSP AUTHENTICATION, IEEE 802.1x, HTTPS, CERTIFICATES, SERVICE ]
System
[ INFORMATION, FIRMWARE UPDATE, DATE&TIME, USER MANAGEMENT, LOG, FACTORY RESET, RESTART ]
12

Setup - Video & Audio Setup
Video Configuration
Live Video Channel Setup - The video can be configured to variety settings with a combination of codec and resolution.
The camera performance has to be considered when setting multiple channels. This effects on the performance of the camera.
Codec - Choose the video codec. According to the selected codec, the subcategories can be changed automatically.
Description - Input the additional description about the selected channel. Max. 30 alphabets are allowed(Including space). For
the description, English Alphabets, numbers and special characters ( - _ @ . ) can be used.
Resolution - Select the video resolution.
Available resolution can be depends on the codec setup between the channels.
4M
3M
1080p/i
720p/i
SVGA
VGA
4CIF
CIF
NTSC
2560 x 1440
2304 x 1296
1920 x 1080
1280 x 720
800 x 600
640 x 480
704 x 576
704 x 480
352 x 288
352 x 240
PAL
2560 x 1440
2304 x 1296
1920 x 1080
1280 x 720
800 x 600
640 x 480
704 x 576
704 x 480
352 x 288
352 x 240
<Resolution of Video Format>
Frame Rate - Select the maximum Frame Rate.
Available Frame Rate can be different although same codecs were set up.
13

Setup - Video & Audio Setup
Video Configuration
GOP(Group of Pictures) Size - Set up the number of frames (P-frame) which contain only changed information based on basic
frame (I-frame). Regarding videos with lots of movement, if you set GOP size bigger, only the number of P-frames is bigger.
As a result, video resolution will be low but ‘File size’ and ‘Bit-rate can be decreased.
GOP(Group of Pictures) Size is..
I-frame and P-frame can be created for MPEG4 and H.264 video compression. I-frame(=key-frame) means the whole image data for one specific scene
of video. P-frame is image data which has been changed information compared to I-frame GOP is made up of one I-frame and corresponding several P-
frames. To improve video quality, set the number of P-frames smaller and to decrease image size, set the number of P-frames bigger.
Profile - The profile defines the subset of bit stream features in an H.264 stream, including color reproduction and additional
video compression.
Baseline - A simple profile with a low compression ratio. The Baseline profile supports I-frames and P-frames.
Main - An intermediate profile with a medium compression ratio. The main profile supports I-frames, P-frames, and B-frames.
High - A complex profile with a high compression ratio. The high profile supports I-frames, P-frames, and B-frames.
Smart Bitrate Control
Off - You can not use the Smart Bitrate Control function.
CVBR (Framerate priority) - This Mode is for cameras which do not want absolute any frame drop, but still want to get lower
bitrate. It has limitation when the Target bitrate is set to be very low, but actual motion is big or scene is very noisy.
CVBR (Quality priority) - When the Target bitrate is set to very low, and motion is big, then LBR will try to drop frames, and make
the final fps to be lower, so that it can save its and make the output frames to have better quality.
CBR - This Mode is a CBR alike mode which is close to traditional security IPCAM, and it's not designed for LBR, It's provided as an
option in LBR library just to help comparison.
14

Setup - Video & Audio Setup
Video Configuration
Bitrate Mode - Select the bitrate control scheme of video compression from CBR (Constant Bit Rate) or VBR (Variable Bit Rate).
CBR - To guarantee the designated constant bit rate, the quality of video are controlled in this mode. Therefore, the quality of
video is likely to be varying when network traffic is changing.
VBR - To guarantee the designated quality, the bit rate of video stream is changed in this mode. Therefore, the frame rate of
video is likely to be varying when network traffic is changing.
This category won't be appear if you select the codec.
Target Bitrate - If Bitrate Control is set to be CBR, you can set the Target Bitrate.
Extension Option
Off - You can not use the Extension Option.
SVC-T On - The H.264 SVC (Scalable Video Coding) is a video compression algorithm that enables effective and efficient transmission
of video files over low bandwidth networks.
Quality - For VBR control mode, The Target Quality of video can be setup.
Click ‘Apply’ to make above setting effective.
15

Setup - Video & Audio Setup
OSD Configuration
Date / Time - Display the current time.
User Text - Output the TEXT entered by the user. Support a maximum of 30 characters.
Click ‘Apply’ to make above setting effective.
16

Setup - Video & Audio Setup
Region of Interest Configuration
Region of interest function gives much more efficiency picture quality for indicated area to improve picture qualities of movement scene
at the same bandwidth.
Stream - Select the Stream.
Currently it supports only Channel1.
Activation - The Region of interest can be enable or disable.
Quality - Set the quality of the set area.
Click ‘Save’ to save the current settings.
Click 'Cancel' to return to the previous setting.
17

Setup - Video & Audio Setup
Privacy Mask Configuration
Use this function to mask areas that you want to hide on screen to protect privacy.
Activation - The Privacy mask function can be enable or disable.
Area - Select the Area1 ~ Area16 and Set the privacy area.
Click ‘Save’ to save the current settings.
Click 'Cancel' to return to the previous setting.
Click ‘Clear Area' to delete the selected Area1~Area16.
18

Setup - Camera Setup
Camera Image Adjustment
Sharpness - Using this control, sharpness of image can be adjusted to meet your preference.
Brightness - Using this control, brightness of image can be adjusted to meet your preference.
Contrast - Using this control, contrast of image can be adjusted to meet your preference.
Saturation - Using this control, Saturation of image can be adjusted to meet your preference.
Hue - Using this control, Hue of image can be adjusted to meet your preference.
Click ‘Save’ to save the current settings.
Click 'Cancel' to return to the previous setting.
Click 'Default' to settings to the factory defaults.
19
