Dyna-Glo ANSI Z83.7-2000 User manual

PROPANE CONSTRUCTION HEATER
USER’S INSTRUCTION MANUAL
RMC-FA40DLX (40,000 BTU/HR, FORCED - AIR)
RMC-FA100DLX (70,000/100,000 BTU/HR, FORCED - AIR)
RMC-FA150DLX (120,000/150,000 BTU/HR, FORCED - AIR)
RMC-FA40A (40,000 BTU/HR, FORCED - AIR)
RMC-FA50A (30,000/50,000 BTU/HR, FORCED - AIR)
RMC-FA100A (70,000/100,000 BTU/HR, FORCED - AIR)
RMC-FA150A (120,000/150,000 BTU/HR, FORCED - AIR)
FGENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTION PROVIDED
WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND
PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE EXPLOSION, BURN,
ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN
INSTRUCTION MANUAL, LADLES, ETC. CONTACT THE MANUFACTURER.
FRETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
Dyna-Glo™Delux
MODELS:
Dyna-Glo™
MODELS:
CSA 2.14-2000, ANSI Z83.7-2000
5/05 Rev.1

Page 1
TABLE OF CONTENTS
• Introduction & Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
• General Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Unpacking Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
• Size & Capacity Of Propane Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
• Installation To The Propane Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Refilling The Propane Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Leak Checking & Location Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
• Lighting & Shutdown Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
• Test Firing Heater & Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
• Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Warranty Information
FWARNING:FIRE, BURN, INHALATION, AND EXPLOSION HAZARD, KEEP
SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS
RECOMMENDED BY THE INSTRUCTIONS.
NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN
VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS
GASOLINE, SOLVENTS, PAIN THINNERS, DUST PARTICLES OR UNKNOWN
CHEMICALS.
FWARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE.

Page 2
FWARNING: Not for use with ductwork.
SPECIFICATIONS:
Dyna-Glo Propane Forced Air Construction Heaters
The heater is designed and approved for use as a construction heater under ANSI Z83.7., CSA2.14
It is hard to anticipate every use which may be made of this heater. CHECK WITH YOUR LOCAL
FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS.
Other standards govern the use of fuel gases and heat producing products in specific applications.
Your local authority can advise you about these.
IMPORTANT: Read this user's manual carefully and completely before trying to operate or
service this heater. Improper use of this heater can cause serious injury or death from fire,
explosion and carbon monoxide poisoning.
This is a direct-fired forced-air construction heater for either indoor or outdoor use. Its intended use
is primarily the temporary heating of buildings or structures under construction, alteration or repair.
All the products of combustion generated by the heater are forced through the heater and released
into the area being heated. This heater operates at approximately 98%+ combustion efficiency but
still produces a small amount of carbon monoxide. Humans can tolerate small amounts of carbon
monoxide for short periods. Carbon monoxide can build up in a heated space and failure to provide
adequate ventilation could result in poisoning or death.
Model No. RMC-FA40DLX
RMC-FA40A
-
RMC-FA(50A)
RMC-FA100DLX
RMC-FA100A
RMC-FA150DLX
RMC-FA150A
Input Rating 40,000 Btu/hr
-
30,000 Btu/hr
50,000 Btu/hr
70,000 Btu/hr
100,000 Btu/hr
120,000 Btu/hr
150,000 Btu/hr
Type of Gas Propane Propane Propane Propane
Gas Supply Pressures
to Regulator Maximum Cylinder Pressure Cylinder Pressure Cylinder Pressure Cylinder Pressure
Minimum (for purpose
of Input Adjustment) 5psig 5psig 5psig 5psig
Manifold Pressure 11” W.C. 10” W.C. 9.5” W.C 8” W.C.
Gas Consumption 1.9lbs/hr
3.3lbs/hr
2.3lbs/hr
1.4lbs/h
4.6lbs/hr
3.3lbs/h - 5.6lbs/hr
7lbs/hr
5.6lbs/hr
Electrical Input 120V, 60Hz, 1 Ø 120V, 60Hz, 1 Ø 120V, 60Hz, 1 Ø 120V, 60Hz, 1 Ø
Amperage Unload
Load
0.35A
0.63A
0.58A
0.75A
0.6A
0.8A
0.6A
0.8A
Fan Unload
Load
3550rpm
3000rpm
3570rpm
3300rpm
3580rpm
3300rpm
3580rpm
3300rpm
Ignition Piezo/Manual Spark Continuous Spark Continuous Spark Continuous Spark
Spark Gap 0.16” 0.16” 0.16” 0.16”
Size (L x Wx H) 18.1” x 7.7” x 12.8” 18.1” x 7.7” x 12.8” 25.12” x 9” x 15.5” 25.12” x 9” x 15.5”
Weight 15.2lbs (6.9kg) 15.2lbs (6.9kg) 22.7lbs (10.3kg) 22.7lbs (10.3kg)

Page 3
GENERAL SAFETY INSTRUCTIONS:
Accidents are always tragic especially because so many of them could have been prevented with lit-
tle care and judgment. There are some basic good practices, we hope you will follow for safe use of
your heater.
IMPORTANT SAFETY INFORMATION:
• Children should be carefully supervised, when they are in the area.
• Always maintain proper clearance from combustible materials. Minimum clearance from com-
bustibles. Side - 24”; Top - 36”; Combustible and Front - 72”. Floor -noncombustible.
• Heater must be placed on level and adequate level and stable surface
• Never place anything including clothes or other flammable items on the heater.
• The appliance area shall be kept clear and free from combustible materials, gasoline and other
flammable vapours and liquids.
• Do not modify or operate a heater which has been modified.
• Adequate clearance for accessibility and for combustion & ventilation air supply must be main-
tained at all times when the heater is operating.
• Service and repair should be done by a qualified service person. The heater should be inspected
before each use and at least annually by a qualified person. More frequent cleaning may be
required as necessary. Do not service while hot or operating.
• Never connect heater to an unregulated gas supply.
• The heater is shipped from the factory for LP(Propane) gas. This heater is for use with
propane gas only, do not convert heater to any other gas. Installation must conform to local
codes or, in the absence, with the standard for the Storage and Handling of Liquefied
Petroleum Gases ANSI/NFPA NFPA 58 and the Natural Gas and Propane Installation Code
CSA B149.1
• The minimum and maximum inlet pressures to the regulator from the gas tank are 5 psi and bottle
pressure, respectively. Use only the regulator & hose assembly provided with the heater. Inspect
the regulator/hose assembly prior to each use of the heater. If there is excessive abrasion or wear,
or hose is cut, replace with regulator/hose assembly listed on the parts list prior to using this heater.
• Gas supply connections should be checked using a 50/50 solution of liquid dish soap and never use
a flame to check for gas leaks.
• The electrical connection & grounding must comply with National Electrical Code.
ANSI/NFPA70 or in Canada CSA C22.1, Canadian Electrical Code, Part 1. Use only a properly
grounded three (3) prong receptacle.
• Do not restrict inlet or outlet by any means. The flow of combustion and ventilation air is not to be
obstructed.
• Forced air heaters should not be directed toward any propane or gas container within 20 feet of the
exit nozzle. The heater should also be located at least 6 feet away from any propane gas container
(regulations in Canada are 10 feet)
• The propane cylinder supply system must be arranged to provide for vapour withdrawal from the
operating cylinder.
WARNING: Motor and fan must be running before lighting, during operation and at shutdown, in
order to prevent a flame-out condition which could result in personal injury or property damage.
PRODUCT FEATURES:
• Portable, Stable & Fully Assembled • 100% Safety Shutoff System
• Wind Resistant & Rain Protected • Adjustable Input Ratings
• Continuous Spark Ignition or Piezo Electric Spark Ignition

Page 4
UNPACKING:
1. Remove heater from carton.
2. Remove all protective packing applied to heater for shipment.
3. Retain cartons and packaging material until unit is operated and found in good
condition.
4. Checker heater for any shipping damage. If heater shows any external or
internal damage, promptly inform dealer/distributor where you purchased heater.
INFORMATION ON SIZE * CAPACITY OR PROPANE GAS CYLINDERS:
The chart below shows the number and size of propane tanks needed to run this heater.
*Less gas is vaporized at lower temperatures.
You may need two or more 100 pound tanks or one larger tank in colder weather.
Temperature (°F) At
tank
Number of Tanks
40,000 BTU/h-
50,000BTU/h 100,000 BTU/h 150,000 BTU/h
Above 32°F 1 - 20lb 1 - 100lb 1 - 100lb
32°F 1 - 20lb 1 - 100lb 2 - 100lb
20°F 1 - 20lb 2 - 100lb 3 - 100lb
10°F 1 - 20lb 3 - 100lb 3 - 100lb
-10°F 2 - 20lb Use Larger Tank Use Larger Tank
-20°F 1 - 100lb Use Larger Tank Use Larger Tank
(See the parts list for your model of heater to get the specified regulator assembly.)
The propane (LP) gas tank must also be equipped with the following:
• A collar to protect the Propane gas valve.
• A shutoff valve terminating a Propane gas cylinder valve outlet as specified in the
American National Standards for Compressed Gas Cylinder Valve Outlets and Inlet
Connections.
• A safety relief valve having direct communications with the vapor space of the tank.
• An arrangement of vapor withdrawal.
The propane (LP) gas pressure regulator and hose assembly supplied with this heater
must be used without alteration.
The hose assembly shall be visually inspected prior to each use of the heater. If it is evident
that there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the
heater being put into operation. The replacement hose assembly shall be that specified by
the manufacturer. (See page 11, Part number 42)

Page 5
INSTALLATION TO THE PROPANE GAS TANK:
IMPORTANT: You must use a propane/LP gas supply cylinder that is compatible with the connec-
tion device provided with the hose and regulator.
1. Provide propane/LP supply system (see Propane/LP Supply, page 6).
2. Connect fuel gas fitting hose/regulator assembly to propane LP tank(s). Turn fuel fitting counter-
clockwise into threads on tank. Tighten firmly using a wrench. IMPORTANT: Position regulator
so that hose leaving the regulator is in a horizontal position (see Figure 1)
3. Connect hose to heater inlet. Tighten firmly using a wrench. You must use the regulator supplied
with heater.
4. Open propane/LP supply valve on propane/LP tank(s) slowly. NOTE: If not opened slowly, excess
flow device in regulator may stop gas flow. If this happens, close propane/LP supply valve, wait
one minute (or until you hear a click) and open again slowly.
5. Check all connections for leaks. Apply a 50/50 solution of liquid dish soap and water to gas joints.
Bubbles forming show a leak that must be corrected.
6. Close propane / LP supply valve before attempting to repair connection.
WARNING: Purging and filling of LP gas tanks must be performed by personnel who has
been thoroughly trained in accepted LP gas industry procedures. Failure to follow these
instructions may result in explosion, fire, severe personal injury, or death.
REFILLING THE PROPANE GAS TANK:
ALL NEW CYLINDERS MUST BE PURGED BEFORE THE FIRST FILLING.
• Turn heater gas valve knob and gas tank valve to OFF position.
• Propane tank valve equipped with the old style fitting has LEFT HANDED THREADS. Turn POL
fitting CLOCKWISE to loosen. Protect POL fitting when disconnected from tank.
• Have tank filled by your local Propane gas supplier.
• Some propane tanks have a bleed-off valve. This valve should be inspected for leaks after each fill-
ing of the tank. Turn clockwise to close the valve.
• Fasten full Propane tank and connect POL fitting to tank valve by turning COUNTERCLOCK-
WISE.
• With heater gas valve knob still in the OFF position, turn ON tank valve and check for leaks with
soap solution.

Page 6
Propane is safe to use when properly handled. Careless handling of the Propane gas tank could result
in fire and/or an explosion. Therefore:
• Always keep tank/cylinder securely fastened in an upright position.
• Avoid tipping tank on its side when connected to a regulator since this may cause damage to
diaphragm in regulator.
• Handle valves with care.
• Never connect an unregulated Propane tank to construction heater.
• Do not subject Propane tank to excessive heat.
• Tightly close the gas shutoff valve on the Propane tank after each use.
• The POL fitting must be protected when disconnected from the propane tank.
• Never store a Propane gas tank inside a building or in the vicinity of any gas burning appliance.
THE DISCONNECTED TANK MUST NEVER BE STORED IN A BUILDING, GARAGE OR
ANY OTHER ENCLOSED AREA.
LEAK CHECKING:
Check all gas connections with a soap solution to be sure they are tight and leak proof.
• The installation of your heater must meet all local codes and/or gas utility requirements or, in the
absence of local codes, with the Storage and Handling of Liquefied Petroleum Gases,
ANSI/NFPA 58 and the Natural and Propane Installation Code, CSA B149.1.
• The minimum clearances to combustible construction shown above must be maintained at all
times.
• The hose assembly should be visually inspected prior to each use of the heater. If it is evident that
there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the heater being
put into operation.
• The replacement hose assembly shall be that specified by the manufacturer (See page 11 for part
numbers).
LIGHTING INSTRUCTIONS:
WARNING: Motor and fan must be running before lighting, during operation and shutdown, in
order to prevent a flame-out condition which could result in personal injury or property damage.
1. Connect power cord to a properly grounded three (3) prong 120V, 60Hz, single phase receptacle.
2. Turn gas valve knob clockwise to OFF position.
3. Wait five (5) minutes to clear any gas. Then smell for gas, if you don't smell gas, go to next step.
4. Turn gas supply ON by turning Propane tank valve counterclockwise.
5. Push in and turn gas control knob counterclockwise to “LOW/IGN”. This will light the burner. If
needed, keep pressing control knob until the burner lights and keep depressing and turning from
OFF to LOW/IGN on Piezo electric spark models. (“HIGH/IGN”: In case of RMC-FA40DLX)
6. Keep the valve knob depressed for at least 30 seconds after lighting the burner. After 30 seconds
release valve knob.
7. If burner does not stay lit, repeat the lighting procedure.
8. When burner is lit, turn gas valve knob counterclockwise to desired setting. (All models, except
RMC-FA40DLX, RMC - 40 has only one heat setting)

Page 7
SHUTDOWN INSTRUCTIONS:
Shutoff Heater:
WARNING: Motor and fan must be running before lighting, during operation and at shutdown, in
order to prevent a flame-out condition which could result in personal injury or property damage.
Turn gas valve knob clockwise to OFF position.
Turn gas supply OFF by turning Propane tank valve clockwise to close.
Disconnect the power cord once the heater has cooled to ambient temperature.
TEST FIRING HEATER:
Test fire your construction heater, following the lighting instructions applicable to the gas control
system employed. Leak test all gas connections with soap solution. Soap bubbles indicate gas leak-
age. DO NOT use a match or flame to test for gas leaks.
STORAGE: Never store a Propane gas tank inside a building or in the vicinity of any gas or
oil burning appliance. When the Propane tank is not disconnected from the construction heater, the
gas tank and heater must be stored outdoors in a well ventilated area, out of the reach of children. If
for any reason the heater is to be stored indoors, the tank must be disconnected and stored outdoors
in a well ventilated area out of reach of children, in accordance with the standard for the the Storage
and Handling of Liquefied Petroleum Gases, ANSI / NFPA 58 and CSA B149.1, Natural Gas and
Propane Installation Code. The plastic tank valve plug supplied with your tank must be tightly
installed when the tank is disconnected from the heater.
MAINTENANCE INSTRUCTIONS:
1. Turn unit off, allow heater to fully cool and disconnect propane hose before performing any
Maintenance functions.
2. Keep unit clean and keep the inside of the torpedo housing debris free.
3. Have unit checked by a qualified technician at least once a year, preferably prior to the heating season.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Fan does not turn when
electrical connection is
made.
1. No electric power to heater.
2. Fan blade contacts inside of heater housing.
3. Fan blade(s) bent
4. Fan motor defective.
1. Check current to electric outlet. If voltage
is correct, check power cord and exten-
sion cord for cuts and extension cord for
cuts and breaks.
2. Be sure that housing is not damaged.
Make sure there are no obstructions to
the fan.
3. Straighten blade(s) to match others.
4. Replace motor.
Heater will not fire. 1. No spark at ignitor.
2. Improper spark gap.
3. Bad electrode.
1. Check ignitor wire. Re-attach or tighten
if loose. Check Spark module. Replace if
necessary.
2. Set gap to 0.16”
3. Replace Spark Plug.
Heater quits while
running.
1. Internal temperature too high causing limit
switch to shut down operation.
2. Damaged Control Valve.
3. Dust or debris build-up inside of heater.
1. If the heaters output is restricted, internal
temperature becomes too high. Move
heater away from any obstructions.
2. Replace Control Valve.
3.Clean inside of heater.
TROUBLESHOOTING:
Always be sure to follow proper maintenance procedures, by cleaning the heater once per
month during regular usage, and check spark gap at least once per season.

Page 8
PROPANE CONSTRUCTION HEATER ILLUSTRATED
40,000 BTU/Hr - 50,000 BTU/Hr

Page 9
ITEM
NO. DESCRIPTION QTY.
PART NUMBER
REMARK
RMC-FA40DLX/
RMC-FA40A/RMC-FA50A
1OUT SHELL 1 CFM40.01
2HANDEL ASSEMBLY 1 CFM40.10
3SCREW 2 M5X10
4MOTOR ASSEMBLY 1 CFM40.09-02
4-1 FAN 1 CFM40.05-01
5SCREW 4ST3.9X8
6SUPPORT MOTOR 1 CFM40.06-02
7SUPPORT MOTOR SCREW 2 M6X15
8MOTOR BRACKET 1 CFM40.06-01
9MOTOR CONDENSER 1 CFM50.09-03
10 SCREW 1M4X8
11 GUARD FAN 1 CFM40.08
12 POWER CORD 1 CFM40.09-01A
13 PCB ASSEMBLY 1 3TH0001
13-1 SCREW 1 ST4.2X10
14 LEAD WIRE ASSEMBLY 1 CFM40.09-03.01A
15 CONNECTOR INLET 1 CFM40.13
16 BASE LOWER 1 CFM40.02-03
17 VALVE 1CK-890SL-A1(A)
17-1 VALVE KNOB 1CFM40.11
18 SCREW 4ST3.9X8
19 BASE ASSEMBLY 1 CFM40.02
20 SCREW 4 ST4.2X10
21 WING BOLT 1CFM40-M6X12
22 SCREW 1 ST4.2X10
23 HEIGHT CONTROLLER 1 CFM40.02-04
24 SHELL IN ASSEMBLY 1 CFM40.03
25 FLAME HOLDER 1 CFM40.03-02
26 NOZZLE 1 CFM40.12-01
27 THERMAL SWITCH BRACKET 1 CFM40.07-02
28 SCREW 1 ST4.2X10
29 SCREW 1ST2.9X6
30 THERMAL SWITCH 1 CFM50.09-06
31 NOZZLE NUT 1 CFM80.00-07
32 THERMOCOUPLE 11130/1395C-180
33 THERMOCOUPLE BRACKET 1 CFM40.07-01
34 SCREW 1 ST4.2X10
35 SPARK PLUG 1 CFM40.09-04
36 SPARK PLUG BRACKET 1 CFM80.00-04
37 SCREW 1 ST4.2X10
38 TUBING ASSEMBLY 1 CFM40.12
39 SCREW 3 ST4.2X10
40 SCREW 6ST3.9X8
41 REGULATOR ASSEMBLY 1TYQ-9C
ILLUSTRATED PARTS BREAKDOWN

Page 10
PROPANE CONSTRUCTION HEATER ILLUSTRATED
100,000 BTU/Hr - 150,000 BTU/Hr

Page 11
ILLUSTRATED PARTS BREAKDOWN
ITEM
NO. DESCRIPTION QTY.
PART NUMBER
REMARK
RMC-FA100DLX/
RMC-FA100A
RMC-FA150DLX/
RMC-FA150A
1OUT SHELL 11A0091A 1A0091B
2HANDEL ASSEMBLY 13A0197 3A0197
3SCREW 1PMF 4012Y PMF 4012Y
4NUT 1HOT04Y HOT04Y
5MOTOR ASSEMBLY 12A0169B 2A0169B
5-1 MOTOR FAN 13A0199B 3A0199B
6MOTOR SUPPORT 13A0196 3A0196
7MOTOR SUPPORT SCREW 2HBT 0620W HBT 0620W
8MOTOR BRACKET 12A0157 2A0157
9MOTOR CONDENSER 1 7µF 7µF
9-1 SCREW 1BT1408W BT1408W
10 GUARD FAN 12TH0009 2TH0009
11 POWER CORD 13TPH013A 3TPH013A
12
13 SPARK MODULE 13A0198B 3A0198B
14 CIRCUIT BOARD ASSEMBLY 13TH0001 3TH0001
15 CIRCUIT SCREW BT1408W BT1408W
16 LEAD WIRE ASSEMBLY 1 4TPH013 4TPH013
17 VALVE 1DMV110PB DMV110PC
18 MPU LEAD WIRE ASSEMBLY 1 4A0304 4A0304
19 CONNECTOR INLET 14A0234 4A0234
20 VALVE KNOB 13D00279 3D00279
21 SCREW 4BT1408W BT1408W
22 BASE ASSEMBLY 1 1A0090 1A0090
23 SCREW 6BT1408B BT1408B
24 HEIGHT ADJUSTER KNOB 14TH0034 4TH0034
25 BASE LOWER 11A0092 1A0092
26 SCREW 6BT1408B BT1408B
27 HEIGHT CONTROLLER 13A0192A 3A0192A
28 COMBUSTION CHAMBER 11A0093 1A0093
29 FLAME HOLDER 12A0156 2A0155
29-1 SCREW 3BT1406W BT1406W
30 THERMAL SWITCH 14A0229A 4A0229A
31 THERMAL SWITCH BRACKET 24TH0004 4TH0004
31-1 SCREW 1TBQ22362 TBQ22362
31-2 SCREW 1TBQ1830V TBQ1830V
32 THERMAL SWITCH CABLE 14A0299 4A0299
33 NOZZLE 14A0233B 4A0247
34 NOZZLE NUT 14A0207B 4A0235
35 THERMOCOUPLE 13A0207A 3A0207A
36 THERMOCOUPLE BRACKET 14A0260 4A0260
36-1 SCREW 1PT2406W PT2406W
37 SPARK PLUG 14A0287B 4A0287C
38 SPARK PLUG BRACKET 14A0261 4A0261
39 SCREW 1PT2406B PT2406B
40 TUBING ASSEMBLY 13A0222 3A0212
41 SCREW 11BT1408W BT1408W
42 REGULATOR ASSEMBLY15TH0002 5TH0002

Page 12
WIRING DIAGRAMS:

WARRANTY:
SERVICE AND LIMITED WARRANTY
CFM Home Products warrants this product to be free from defects in materials and
components for two (2) years from the date of first purchase, provided that the product
has been properly installed, operated and maintained in accordance with all applicable
instructions. To make a claim under warranty the Bill of Sale or cancelled check must be
presented.
This warranty is extended only to the original retail purchaser. This warranty covers the
cost of part(s) required to restore this heater to proper operating condition and an
allowance for labor when provided by a CFM Home Products Authorized Service Center.
Warranty part(s) MUST be obtained through authorized dealers of this product and/or CFM
Home Products who will provide original factory replacement parts. Failure to use original
factory replacement parts voids this warranty. The heater MUST be installed by a qualified
installer in accordance with all local codes and instructions furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal
wear and tear, or parts that fail or become damaged as a result of misuse, accidents, lack
of proper maintenance or defects caused by improper installation. Travel, diagnostic cost,
labor, transportation and any and all such other costs related to repairing a defective
heater will be the responsibility of the owner.
TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS
THE SALE OF THE PRODUCT; THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL
OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL
IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE TO TWO (2) YEARS FROM THE DATE OF FIRST
PURCHASE PRICE OF THE PRODUCT AND CFM HOME PRODUCTS SHALL NOT BE
LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL
OR CONSEQUENTIAL DAMAGES.
Some states do not allow a limitation on how long an implied warranty lasts or an
exclusion or limitation of incidental or consequential damages, so the above limitation on
implied warranties, or exclusion or limitation on damages may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary
from state to state.
Contact CFM Home Products for consumer information, technical assistance and to obtain
replacement parts. You will need to provide the following information when
communicating with the help desk:
• Heater type and model number
• Serial Number
• Description of the part or problem.
CFM Home Products
2695 Meadowvale Blvd.
Mississauga, Ontario L5N 8A3 Canada
Tel [phone]
