Dyna-Glo DGO1890BDC-D User manual

1
Charcoal Offset
Vertical Smoker
MODEL #DGO1890BDC-D
Français p. 19
Español p. 37
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
70-10-112 Rev. / /1
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-447-4768, a.m. – 4:30 p.m. CST,
Monday – Friday or [email protected].

2
TABLE OF CONTENTS
Safety Information ...................................................................................................................... 2
Package Contents ...................................................................................................................... 4
Hardware Contents .................................................................................................................... 5
Preparation ................................................................................................................................. 5
Assembly Instructions ................................................................................................................ 6
Operation Instructions ................................................................................................................. 12
Tips On Smoking ......................................................................................................................... 14
Care and Maintenance ................................................................................................................ 16
Warranty ...................................................................................................................................... 17
Replacement Parts List .............................................................................................................. 18
Please read and understand this entire manual before attempting to assemble, operate or
install the product. If you have any questions regarding the product, call our customer service
department at 1-877-447-4768, a.m.- 4:30 p.m. CST, Monday - Friday or
[email protected].
Use caution when lifting and moving the unit to avoid back strain or back injury. Do not move
the unit while it is in use.
•DO NOT
porches or carports. A minimum clearance of 36 in. is required.
•DO NOT operate the unit under overhead construction.
• A minimum clearance to combustible construction is 36 in. from sides and back.
•DO NOT use this appliance as a heater.
ground.
•DO NOT
• Use caution when assembling and operating this unit to avoid cuts and scrapes from edges.
SAFETY INFORMATION

3
SAFETY INFORMATION
•DO NOT use this product in a manner other than its intended purpose. It is NOT intended for
commercial use. It is not intended to be installed or used in or on a recreational vehicle and/or boats.
•DO NOT store this unit near gasoline or other combustible liquids or where other combustible
vapors may be present.
•DO NOT use or store or operate this product in an area accessible to children or pets. Store this
unit in a dry protected location.
•DO NOT leave the unit unattended while in use.
•DO NOT leave hot ashes unattended until the smoker cools completely.
•DO NOT move the unit while in use or while ashes are still hot. Allow the unit to cool completely
before moving or storing.
•NEVER
• Dispose of cold ashes by wrapping them in heavy-duty aluminum foil and placing in a
noncombustible container. Make sure that there are no other combustible materials in or near the
container.
• If you must dispose of ashes in less time than it takes for the ashes to completely cool down, then
shovel. Place the coals in aluminum foil and soak them completely with water before disposing of
them in a noncombustible container.
• Allow the unit to cool completely before conducting any routine cleaning or maintenance.
• NEVER close the damper completely while cooking.
• This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection
from hot surfaces or splatter from cooking liquids.
• Use caution when opening the door of the smoker while in operation. Keep hands, face and body
•DO NOT wear loose clothing while operating the smoker. Tie back long hair while operating the smoker.
• ALWAYS wear shoes that fully cover your feet while operating the smoker.
•NEVERuse glassware, plastic or ceramic cookware on or in your smoker. Use metallic cookware only.
while operating.
• Use of accessories not intended for this smoker is not recommended and may lead to injury or
property damage.
• Read and follow all warnings and instructions before assembling and using the appliance.
• Follow all warnings and instructions when using the appliance.
WARNING
This product and the fuels used to operate this product (charcoal or wood), and the
products of combustion of such fuels, can expose you to chemicals including carbon black,
which is known to the State of California to cause cancer, and carbon monoxide, which is
known to the State of California to cause birth defects or other reproductive harm.
For more information go to www.p65Warnings.ca.gov
CALIFORNIA PROPOSITION 65

4
PACKAGE CONTENTS
A
A
C
E
F
B
D
G
JH
I
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
A Smoke stack assembly 1
B Lifting handle 2
C Temperature gauge 1
D Door handle 1
E Cooking grate 6
F Cooking grate support 12
G Smoker body-left 1
H Leg 4
I Grease cup 1
J Smoker body-right 1
K Door latch 2
L Ash Tray 1
M Charcoal Grate 1
N Charcoal Chamber 1
O Rib Rack 1
L
K
O
M
N

5
HARDWARE CONTENTS
AA BB
M6 x 12
Screw
Qty. 32
M4 x 10
Screw
Qty. 4
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly (not included): Phillips Screwdriver, Pliers, Adjustable Wrench
CC
M6 Nut
Qty. 2

6
ASSEMBLY INSTRUCTIONS
CAUTION: Remove both doors before turning the
smoker upside down.
1. With smoker body-right (J) turned upside down,
attach smoker body-left (G) to smoker
body-right (J) using six M6x12 screws (AA).
2. Attach legs (H) to smoker body-left (G) and
smoker body-right (J) using twelve M6x12
screws (AA).
Hardware Used
AA
Hardware Used
M6 x 12mm
Screw x 6
1
2
AA
J
G
H
J
G
AA
G
AA M6 x 12mm
Screw x 12

7
ASSEMBLY INSTRUCTIONS
3. Attach door latch (K) to smoker body-left (G)
using two M4x10 screw (BB).
4. CAUTION: This unit is HEAVY! Do not attempt
this step without assistance!
With the assistance of a helper, stand the unit
(Make sure that legs are attached). Position the
square smoke stack (A) with control arm to the
left as shown. Using 4 bolts (AA), attach square
smoke stack (A) to the top of smoker body (G).
Securely tighten with a Phillips screwdriver.
Reattach both doors.
5. Attach lifting handle (B) to smoker body-left (G)
using four M6x12 screw (AA).
B
AA
G
G
A
K
G
BB
AA
3
4
5
Hardware Used
BB M4 x 10mm
Screw x 2
Hardware Used
AA M6 x 12mm
Screw x 4
Hardware Used
AA M6 x 12mm
Screw x 4

8
ASSEMBLY INSTRUCTIONS
6. Attach door latch (K) to smoker body-left (G)
using two M4x10 screw (BB).
7. Attach door handle (D) to the primary door on the
smoker body-left (G) using two M6x12 screw (AA)
and two M6 nuts (CC).
G
D
G
BB
6
7
Hardware Used
BB M4 x 10mm
Screw x 2
AA
CC
Hardware Used
AA M6 x 12mm
Screw x 2
CC M6 Nut x 2
K

9
ASSEMBLY INSTRUCTIONS
8. Remove the pre-assembled nut from the
temperature gauge (C). Insert the probe through
hole of the smoker door from the outside. Secure
with nut from inside panel. Tighten with wrench.
9. Attach lifting handle (B) to smoker body-right (J)
using four M6x12 screw (AA). J
B
C
8
9
Hardware Used
AA M6 x 12mm
Screw x 4
AA

10
ASSEMBLY INSTRUCTIONS
10. Insert the cooking grate supports (F) into the
corresponding holes inside the smoker body (G),
starting from the bottom up.
NOTE: There are 12 possible positions to install
the cooking grate according to the need of
the user.
11. Slide the cooking grates (E) onto the grate
supports (F) inside the smoker body (G).
G
F
10
F
11
G
F
E

11
ASSEMBLY INSTRUCTIONS
12. Installing the Rib Rack (Optional)
Place the rib rack (O) directly onto the desired
grate before sliding the grate onto the supports.
NOTE: The left or right edge of the rib rack should
not hang over the outer edge of the cooking grate
prior to placing back into the smoker.
13. Place the charcoal chamber (N) directly onto the
charcoal grate (M) and slide the grate onto the
support brackets located on the inside of the
smoker body - right (J). Slide the ash tray (L)
under the support brackets.
12
13
O
E
G
ML
N
J
Support Brackets
14. Slide the grease cup (I) to the grease cup support
of the smoker body-left (G) bottom.
I
G
14

12
OPERATING INSTRUCTIONS
BEFORE FIRST USE
Remove all hangings or plastic straps, if present.
Before you cook food in your smoker, it is important to “season” your smoker. Seasoning seals the
To season your smoker, simply use it as you normally would only do not cook any food. You will
need to follow all of the operating procedures in the next few sections of this manual.
(around 175°F/79.4°C) for 45 – 60 minutes. Let the smoker cool and clean out the wood chips and charcoal.
Lighting Instructions
DO NOT USE PRETREATED, MATCH-LIGHT CHARCOAL with this smoker. Only use standard,
lighting charcoal. Damage to the smoker may occur with the use of match-light charcoal.
Step 1
Remove the charcoal grate and chamber from the offset smoker box. Place the grate on a cement
Refer to the assembly instructions for proper placement.
Start with at least 5 lbs. (2.3 kgs.) of charcoal (95 standard briquettes).
Make adjustments as needed when cooking in colder climates or during high winds, and/or when fair
amounts of precipitation are present.
Step 2
(refer to assembly instructions for proper chamber and grate placement). After soaking the charcoal,
Step 3
With both doors open, stand back and carefully light charcoal and allow to burn until covered with
prior to closing the doors. (Fumes will tend to collect in the upper cavity if the door is closed).

13
OPERATING INSTRUCTIONS
Lighting Instrucions(Continued)
Step 4
After 20-25 minutes, charcoal should be ready for cooking and/or adding woodchips. Refer to the
next section before adding wood chips to pre-lit charcoal.
door is opened, resulting in property loss, personal injury or death. Never attempt to add more
ADDING WOOD CHIPS (BEFORE AND DURING COOKING)
WARNING
Presoaked Wood Chips
Soak the desired amount of chips in water for 30 minutes. Wrap the wood chips in aluminum foil
and poke holes on the top of the foil wrapping. FOLLOW THE STEPS BELOW BEFORE ADDING
PRESOAKED WOOD CHIPS.
Dry Wood Chips
Dry wood chips can be placed directly onto the pre-lit charcoal without aluminum foil. FOLLOW THE
STEPS BELOW BEFORE ADDING DRY WOOD CHIPS.
Step 1
Stand back and carefully open smoker box door allowing heat and steam to escape away from your
-
spect the charcoal level in pan.
Step 2
on hot coals. Use the long metal cooking tongs to add wood chips (and/or charcoal) to charcoal
chamber, being careful not to stir-up ashes and sparks.
WARNING
occur causing severe burns.
Step 3
Close smoker box door and allow food to continue cooking.
Allow the ashes to completely cool before reusing or cleaning the smoker.

14
• Hardwoods such has hickory, pecan, apple, cherry or mesquite typically burn slower and produce
more smoke over longer periods of time.
• To prolong the burn cycle for wood chips, pre-soak them in a separate bowl
of water for at least 30 minutes, and/or wrap the chips in perforated aluminum foil.

15
SUGGESTED SMOKING AND MEAT TEMPERATURES
Smoking Temperatures
Acurate smoking temperatures are critical for safely cooking food when meat probes are not
available. Please understand that using the factory installed temperature gauge is an acceptable
temperature because internal smoker temperatures can vary between the top and bottom cooking
grates. Also keep in mind that the probes used on most gauges are designed to measure the
temperature at the tip of the temperature probe and not the overall temperature of the smoker.
Alternatively, it is recommended that users either purchase an aftermarket, oven-ready temperature
gauge, or a meat thermometer. Meat thermometers are the most effective way of determining when
the food is cooked to the minimum temperature required for safe consumption.
Please refer to the chart below for cooking temps.
SUGGESTED SMOKING TEMPERATURES
Suggested Smoking
Temperatures
Safe Minimum Food
Temperatures
Meat, Poultry, Fish
Beef, veal and lamb
(pieces and whole cuts)
Medium-rare 225° F (107.2° C) 145° F (63° C)
Medium 225° F (107.2° C) 160° F (71° C)
Well done 225° F (107.2° C) 170° F (77° C)
Pork
(ham, pork loin, ribs)
Pork (pieces and whole
cuts)
225 - 240° F
(107.2 - 115.6° C)
Ground meat and meat mixtures
(burgers, sausages, meatballs, meatloaf, casseroles
and mechanically tenderized beef)
Beef, veal (including
mechanically tenderized),
lamb and pork
250 - 275° F
(121 - 135° C) 160°F (71° C)
Poultry (chicken & turkey) 250 - 275° F
(121 -135° C) 165°F (74° C)
Poultry (chicken, turkey, duck)
Pieces 250° F (121° C) 165° F (74° C)
Whole 250° F ( ° C) 165° F (74° C)
Seafood
Fish 225 - 240° F
(107.2 - 115.6° C)
225 - 240° F
(107.2 - 115.6° C)
Suggested Smoking
Temperatures
Safe Minimum Food
Temperatures
Game
Chops, steaks and roasts
(deer, elk, moose, caribou/reindeer, antelope and pronghorn)
Large Game
Bear, bison, musk ox
walrus, etc.
250 - 300° F
(121 - 149° C)
Small game
Rabbit, muskrat,
beaver, etc.
225 - 240° F
(107.2 - 115.6° C)
Ground Meat
Ground meat and
meat mixtures
250 - 300° F
(121 - 149° C) 165° F (74° C)
Ground venison
and sausage
250 - 300° F
(121 - 149° C) 165° F (74° C)
Game birds/waterfowl
(wild turkey, duck, goose, partridge and pheasant)
Whole 250° F (121° C)
Breasts and roasts 250° F (121° C) 165° F (74° C)
Thighs, wings 250° F (121° C) 165° F (74° C)
in a bird) 250° F (121° C) 165° F (74° C)
Medium-rare 225° F (107.2° C) 145° F (63° C)
Medium 225° F (107.2° C) 160° F (71° C)
Well done 225° F (107.2° C) 170° F (77° C)

16
CARE AND MAINTENANCE
AFTER USE SAFETY AND MAINTENANCE
WARNING
• Use caution when lifting and moving the smoker to avoid strain injuries.
Two people are recommended to lift or move the smoker.
•DO NOT store the smoker near gasoline or other combustible liquids or where combustible vapors
may be present. Keep the area around the smoker clear and free of combustible materials and vapors.
•DO NOT store this smoker in an area accessible to children or pets. Store the smoker in a dry,
protected location.
•DO NOT allow anyone to conduct activities around the smoker following use until it has cooled. It is
hot during operation and remains hot for a period of time following use.
•DO NOT leave hot ashes unattended until the smoker cools completely.
• The smoker becomes extremely hot – allow the smoker to cool completely before handling. Allow
the smoker to cool before removing and cleaning the grease pan.
• Dispose of cold ashes by wrapping them in heavy-duty aluminum foil and putting them in a
noncombustible container.
• If you must dispose of the ashes in less time than it takes for them to completely cool, remove the
charcoal tray using heat-resistant gloves and place the ashes in aluminum foil. Completely soak the
ashes with water before disposing of them in a noncombustible container.
CAUTION: All care and maintenance procedures are to be performed while the
Clean the cooking grates with hot, soapy water. Rinse and dry thoroughly. You may prefer to coat the
cooking grates lightly with cooking oil or cooking spray.
To clean the inside and outside of the smoker cabinet, simply use a damp cloth.
Spray-washing with a water hose is not recommended. Moisture should be wiped away and not
allowed to stand inside or on top of the smoker. Once cleaned, you may prefer to lightly coat the
interior of the smoker cabinet with cooking oil or cooking spray.
If rust is present on the exterior surface of the smoker, clean the area with steel wool or
emery cloth and use heavy-duty, heat-resistant paint.
NEVER apply additional paint to the interior of the smoker. If rust is present on the interior of the
smoker, clean it thoroughly with steel wool or emery cloth and lightly coat the area with cooking oil or
cooking spray to help minimize recurring rust.
To protect your smoker from weather conditions, always keep it covered while not in use.

17
WARRANTY
This vertical charcoal smoker is warranted against broken or damaged parts at the time of purchase.
All other parts carry a one (1) year limited warranty except the charcoal chamber, which is
warranted to be free of defects for 90 days. Paint is warranted to be free of defects for 90 days
except for rust, which may appear after repeated use.
appliance. Repair labor is not covered.
All parts that meet the warranty requirements will be shipped at no charge via the discretion of GHP
Group Inc. (ground shipments, US Mail or Parcel Post ONLY). Any special handling charges (i.e.
Second Day, Overnight, etc.) will be the responsibility of the consumer.
All warranty claims apply only to the original purchaser and require a proof of purchase verifying
number from our customer service. This service is available by calling toll free 1-877-447-4768,
a.m. - 4:30 p.m. CST, Monday - Friday.
Some states do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not
from state to state.
GHP Group Inc.
6440 W. Howard Street
Niles, IL, USA
60714-3302
Item name: Charcoal Offset Vertical Smoker
Model #: DGO1890BDC-D

18
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, a.m. - 4:30 p.m.
CST, Monday - Friday or [email protected].
70-10-112 Printed in China
PART DESCRIPTION PART #
1 Square smoke stack 312-02009-00
2 Smoker body - 70-10-207
3 Lifting handle 301-01010-00
4 Temperature gauge 211-02005
5
Logo plate - Dyna-Glo* 211-02002
6 Cooking grate 70-01-167
7 Smoker door - 313-02202-00
8 Door handle base 70-01-170
9 Door handle grip 70-01-169
10 Side damper plate 403-02003-08
11 Leg - standard 301-01016-00
12 Grease cup 313-12002-01
13 Smoker body - 70-01-208
14 Smoker door - 70-01-209
15
Door handle grip-right 403-02003-05
PART DESCRIPTION PART #
16
Door handle crank-right 313-02202-03
17 Right handle washer 313-02202-04
18 Right door latch 313-02202-05
19 Ash Tray 301-01028-00
20 Sausage hooks 70-01-159
21 Cooking grate support 302-01030-00
22 Charcoal grate 314-00001-01
23 Charcoal chamber 314-00001-02
24 Rib rack 70-01-157
25 Door latch bracket 70-01-156
26 Door latch 70-01-161
27 Door latch handle 70-01-160
n/a Hardware pack 70-09-106
n/a Instruction manual 70-10-112
*Hardware included
A
531
6
42
10
8
9
11 12
A
15
13
17
16
20 18
21
19
23
22
26
24
25 27

19
Charbonsde Bois
MODELE #DGO1890BDC-D
70-10-112
JOIGNEZ VOTRE REÇU ICI
Des questions, des problèmes, des pièces manquantes?
au détaillant, appelez notre service à la clientèle au 1-877-447-4768, 8 - 16 h 30, HNC,
du lundi - vendredi ou par e-mail à [e-mail].
Español p. 37

20
TABLE DES MATIÈRES
Consignes de sécurité ................................................................................................................ 20
Contenu de l’emballage .............................................................................................................. 22
Quincaillerie incluse .................................................................................................................... 23
Préparation ................................................................................................................................. 23
Instructions pour l’assemblage ..................................................................................................... 24
Mode d’emploi ............................................................................................................................. 30
Conseils pour le fumage aliments ............................................................................................... 32
Entretien ...................................................................................................................................... 34
Garantie ...................................................................................................................................... 35
Liste des pièces de rechange .................................................................................................... 36
Assurez-vous de lire et de comprendre l’intégralité de ce manuel avant de tenter d’assembler,
d’utiliser ou d’installer le produit. Si vous avez des questions concernant ce produit, veuillez
téléphoner au service à la clientèle au 1-877-447-4768, , HNC,
du lundi - vendredi.
•IL NE FAUT PAS
•IL NE FAUT PAS
•IL NE FAUT PAS utiliser cet appareil comme chaufferette.
ciment. Et sur un sol ferme.
•IL NE FAUT PAS
vous égratigner sur les rebords.
•IL NE FAUT PAS
véhicule récréatif ou sur un bateau.
•IL NE FAUT PAS
•IL NE FAUT PAS utiliser, ranger ou utiliser cet appareil dans un endroit accessible aux enfants
et animaux domestiques. Rangez cet appareil dans un endroit sec et sécuritaire.
•IL NE FAUT PAS
CONSIGNES DE SÉCURITÉ
