Dyna-Glo DGX780BDC-D-1 User manual

1
Vertical
Charcoal Smoker
MODEL #DGX780BDC-D
Français p. 20
Español p. 39
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
70-01-115 Rev. 1/16/15
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m. CST,
Monday – Friday or log on to [email protected].

2
TABLE OF CONTENTS
Safety Information ...................................................................................................................... 2
Package Contents ...................................................................................................................... 4
Hardware Contents .................................................................................................................... 5
Preparation ................................................................................................................................. 5
Assembly Instructions ................................................................................................................ 6
Operation Instructions ................................................................................................................. 13
Tips On Smoking ......................................................................................................................... 15
Care and Maintenance ................................................................................................................ 17
Warranty ...................................................................................................................................... 18
Replacement Parts List .............................................................................................................. 19
Please read and understand this entire manual before attempting to assemble, operate or
install the product. If you have any questions regarding the product, call our customer service
department at 1-877-447-4768, 8:30 a.m.- 4:30 p.m. CST, Monday - Friday or log on to
[email protected].
Use caution when lifting and moving the unit to avoid back strain or back injury. Do not move
the unit while it is in use.
• DO NOT operate the unit near or under ammable or combustible materials such as decks,
porches or carports. A minimum clearance of 36 in. (91 cm) is required.
•DO NOT operate the unit under overhead construction.
• A minimum clearance to combustible construction is 36 in. (91 cm) from sides and back.
• DO NOT use this appliance as a heater.
• Operate the unit on a stable, level, non-ammable surface such as asphalt, concrete or solid
ground.
• DO NOT operate the unit on ammable material such as carpet or wood deck.
• Use caution when assembling and operating this unit to avoid cuts and scrapes from edges.
SAFETY INFORMATION

3
SAFETY INFORMATION
• DO NOT use this product in a manner other than its intended purpose. It is NOT intended for
commercial use. It is not intended to be installed or used in or on a recreational vehicle and/or boats.
• DO NOT store this unit near gasoline or other combustible liquids or where other combustible
vapors may be present.
• DO NOT use or store or operate this product in an area accessible to children or pets. Store this
unit in a dry protected location.
• DO NOT leave the unit unattended while in use.
• DO NOT leave hot ashes unattended until the smoker cools completely.
• DO NOT move the unit while in use or while ashes are still hot. Allow the unit to cool completely
before moving or storing.
• NEVER use gasoline, kerosene, Zippo/Ronson lighter uid or other highly volatile uids as a starter.
• Always cook your food on the grate after the ame is burned out.
• Dispose of cold ashes by wrapping them in heavy-duty aluminum foil and placing in a
noncombustible container. Make sure that there are no other combustible materials in or near the
container.
• If you must dispose of ashes in less time than it takes for the ashes to completely cool down, then
remove the ashes from the unit, using heat-resistant gloves along with long metal tongs or replace
shovel. Place the coals in aluminum foil and soak them completely with water before disposing of
them in a noncombustible container.
• Allow the unit to cool completely before conducting any routine cleaning or maintenance.
• NEVER close the damper completely while cooking.
• This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection
from hot surfaces or splatter from cooking liquids.
• Use caution when opening the door of the smoker while in operation. Keep hands, face and body
safe from hot steam or are-ups. DO NOT inhale smoke.
• DO NOT wear loose clothing while operating the smoker. Tie back long hair while operating the smoker.
• ALWAYS wear shoes that fully cover your feet while operating the smoker.
• NEVER use glassware, plastic or ceramic cookware on or in your smoker. Use metallic cookware only.
• When using avoring wood, add a sufcient amount prior to operation to avoid having to add wood
while operating.
• Use of accessories not intended for this smoker is not recommended and may lead to injury or
property damage.
• Read and follow all warnings and instructions before assembling and using the appliance.
• Follow all warnings and instructions when using the appliance.
CALIFORNIA PROPOSITION 65
Fuels used in wood and charcoal burning appliances and the products of combustion of such
fuels contain chemicals known to the State of California to cause cancer, birth defects or other
reproductive harm. This product contains chemicals, including lead and lead compounds, known to
the State of California to cause cancer, birth defects or other reproductive harm.Wash hands after
handling.

4
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Smoke stack assembly 1
B Lifting handle 2
C Temperature gauge 1
D Door handle 2
E Cooking grate 4
F Cooking grate support 8
G Smoker body 1
H Leg 4
I Grease cup 1
J Door latch 3
PART DESCRIPTION QUANTITY
K Side damper 2
L Ash tray 1
M Charcoal grate 1
N Charcoal chamber 1
O Wood chip box 1
P Upper door 1
Q Lower door 1
R Wood chip box support 2
S Wood chip box lid 1
A
A
C
E
N
B
D
MR
H
P
L
O
Q
F
G
J
I
K
S

5
HARDWARE CONTENTS
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly (not included): Phillips Screwdriver, Pliers, Adjustable Wrench
AA BB
M6 x 12
Screw
Qty. 28
M5 x 12
Shoulder
Screw
Qty. 8
CC
M4 x 10
Screw
Qty. 6
DD EE
M6 Nut
Qty. 4
M5 Nut
Qty. 8

6
ASSEMBLY INSTRUCTIONS
CAUTION: Remove the upper (P) and lower (Q)
doors before beginning assembly.
1. Remove the upper (P) and lower (Q) doors by
opening and sliding the doors up and off
the hinges.
2. With smoker body (G) turned upside down,
attach legs (H) to smoker box (G) using
twelve M6x12 screws (AA)
Hardware Used
AA M6 x 12mm
Screw x 12
1
Q
P
2
H
G
AA

7
ASSEMBLY INSTRUCTIONS
3. CAUTION: This unit is HEAVY! Do not attempt
this step without assistance!
With the assistance of a helper, stand the unit
upright on its legs on a rm and level surface.
(Make sure that the legs are attached.) Place the
upper (P) and lower (Q) doors back onto the
hinges of the smoker body (G).
4. Attach the side dampers. Dampers (K) are
installed from the inside of smoker body (G).
Thread the damper handle through the back hole
of the side damper slots. Align the damper (K)
with the mounting holes and insert four M5x12
screws (BB) from the outside of the smoker
body (G). Secure each bolt with M5 nut (EE) from
the inside of the smoker body (G). Use a Phillips
screwdriver and wrench to tighten the nuts and
bolts. Do not over-tighten. Damper must be able
to slide easily from side-to-side.
G
K
PG
Q
EE
3
4
Hardware Used
BB M5 x 12mm
Shoulder
Screw
x 8
EE M5 Nut x 8
BB

8
ASSEMBLY INSTRUCTIONS
5. Position the square smoke stack (A) with control
arm to the left as shown. Using four M6x12
screws (AA), attach square smoke stack (A) to
the top of smoker body (G). Securely tighten with
a Phillips screwdriver.
6. Insert the wood chip box supports (R) into the
bottom holes inside the smoker body (G). Repeat
this process for the cooking grate supports (F) on
each side, inserting from lower positions to
higher positions.
NOTE: There are 8 positions to install the cooking
grate supports, according to the need of the owner.
F
R
6
Hardware Used
A
G
AA
5
AA M6 x 12mm
Screw x 4
G
F

9
ASSEMBLY INSTRUCTIONS
7. Attach each door latch (J) to smoker
body-right (G) using two M4x10 screws (CC).
8. Attach the lifting handles (B) onto the side of
smoker body (G) using four M6x12 screws (AA).
Repeat on the other side.
B
CC
J
G
7
Hardware Used
G
AA
8
CC M4 x 10mm
Screw x 6
Hardware Used
AA M6 x 12mm
Screw x 8

10
ASSEMBLY INSTRUCTIONS
9. Attach door handle (D) to the upper door (P)
using two M6x12 screws (AA) and two
M6 nuts (DD). Repeat this step for the
lower door (Q).
10. Place the wood chip box lid (S) directly onto the
wood chip box (O) and slide the wood chip box
onto the supports (R) located on the inside of the
smoker body (G).
O
S
10
Q
AA
D
9DD
P
Hardware Used
AA M6 x 12mm
Screw x 4
DD M6 x Nut x 4
G
R

11
11. Place the charcoal chamber (N) directly onto the
charcoal grate (M) and slide the grate onto the
support brackets located on the inside of the
smoker body (G). Slide the ash tray (L) under the
support brackets.
M
N
11
G
L
ASSEMBLY INSTRUCTIONS
12. Slide the four cooking grates (E) onto the
cooking grate supports (F) inside the
smoker body (G).
FG
E
12

12
ASSEMBLY INSTRUCTIONS
13. Remove the pre-assembled nut from the
temperature gauge (C) and insert the probe
through hole of the smoker door. Secure with nut
from inside panel. Tighten with wrench.
14. Slide the grease cup (I) into the grease cup
support located on the bottom of the
smoker body (G).
I
14
13
G
C

13
OPERATING INSTRUCTIONS
BEFORE FIRST USE
Remove all hangings or plastic straps, if present.
Before you cook food in your smoker, it is important to “season” your smoker. Seasoning seals the
paint and interior of your smoker to enhance avoring, durability and overall performance.
To season your smoker, simply use it as you normally would only do not cook any food. You will
need to follow all of the operating procedures in the next few sections of this manual.
Using your desired avoring woods and marinades, burn your smoker at low temperature
(around 175°F/79.4°C) for 45 – 60 minutes. Let the smoker cool and clean out the wood chips and charcoal.
Once seasoning is complete, your smoker’s interior will have a durable, seasoned coating.
Lighting Instructions
DO NOT USE PRETREATED, MATCH-LIGHT CHARCOAL with this smoker. Only use standard,
untreated briquettes or lump charcoal and ONLY use charcoal lighting uid approved for lighting charcoal.
Do not use lighter uid, paint thinners, gasoline, kerosene, alcohol or other ammable material for
lighting charcoal. Damage to the smoker may occur with the use of match-light charcoal.
Step 1
Remove the charcoal grate and chamber from the smoker box. Place the grate on a cement surface
that is clear from amable or combustible materials. Place the chamber directly onto the
charcoal grate. The chamber should t between the grate handles and the raised grate supports.
Refer to the assembly instructions for proper placement.
Start with at least 4 lbs. (1.8 kgs.) of charcoal (75 standard briquettes).
Make adjustments as needed when cooking in colder climates or during high winds, and/or when fair
amounts of precipitation are present.
Step 2
Note: Please refer to the manufacturer’s recommended amount of lighter uid before applying
uid to the briquettes. With the charcoal grate and chamber outside the rebox, saturate charcoal
with the amount of lighting uid as recommended by the lighter uid manufacturer. Allow the uid
to soak into the charcoal for 3 minutes before placing the grate and chamber back into the rebox
(refer to assembly instructions for proper chamber and grate placement). After soaking the charcoal,
place the lighting uid at a safe distance away from the smoker.
Step 3
With both doors open, stand back and carefully light charcoal and allow to burn until covered with
a light ash (approximately 20 minutes). Charcoal lighting uid must be allowed to completely burn off
prior to closing the doors. (Fumes will tend to collect in the upper cavity if the door is closed).

14
OPERATING INSTRUCTIONS
Lighting Instrucions(Continued)
Step 4
After 20-25 minutes, charcoal should be ready for cooking and/or adding woodchips. Refer to the
next section before adding wood chips to pre-lit charcoal.
DANGER: Closing the rebox doors during the lighting procedure could trap fumes from
the charcoal lighting uid in the smoker box and may result in a ash-re or explosion when
door is opened, resulting in property loss, personal injury or death. Never attempt to add more
lighting uid to the charcoal once it has been lit.
ADDING WOOD CHIPS (BEFORE AND DURING COOKING)
WARNING: Use caution since ames can are-up when fresh air suddenly comes in contact with re.
When opening the door, keep hands, face and body a safe distance from hot steam and ame are-ups.
Presoaked Wood Chips
Soak the desired amount of chips in water for 30 minutes. Wrap the wood chips in aluminum foil
and poke holes on the top of the foil wrapping. FOLLOW THE STEPS BELOW BEFORE ADDING
PRESOAKED WOOD CHIPS.
Dry Wood Chips
Dry wood chips can be placed directly onto the pre-lit charcoal without aluminum foil. FOLLOW THE
STEPS BELOW BEFORE ADDING DRY WOOD CHIPS.
The amount and type of wood used is entirely dependent on the desired amount of avor.
Step 1
Stand back and carefully open smoker box door allowing heat and steam to escape away from your
face. Use caution since ames can are-up when fresh air suddenly comes in contact with re. In-
spect the charcoal level in pan.
Step 2
Wearing ame retardant oven mitts/gloves, use long metal cooking tongs to lightly brush aside ashes
on hot coals. Use the long metal cooking tongs to add wood chips (and/or charcoal) to charcoal
chamber, being careful not to stir-up ashes and sparks.
WARNING: Never add charcoal lighting uid to hot or even warm coals as ashback may
occur causing severe burns.
Step 3
Close smoker box door and allow food to continue cooking.
Allow the ashes to completely cool before reusing or cleaning the smoker.

15
Pairing wood chips with a specic type of food will depend on the preferences of the user.
This page can be used as a general guideline for acquiring the ideal avor.
• Hardwoods such has hickory, pecan, apple, cherry or mesquite typically burn slower and produce
more smoke over longer periods of time.
• To prolong the burn cycle for wood chips, pre-soak them in a separate bowl
of water for at least 30 minutes, and/or wrap the chips in perforated aluminum foil.
• Most smoke avoring occurs within the rst hour of cooking. Adding wood chips after the rst
hour is typically not necessary unless extra smoke avoring is desired.

16
SUGGESTED SMOKING AND MEAT TEMPERATURES
Smoking Temperatures
Acurate smoking temperatures are critical for safely cooking food when meat probes are not
available. Please understand that using the factory installed temperature gauge is an acceptable
tool for smoking food; but it’s not always the ideal means of measuring the most accurate smoking
temperature because internal smoker temperatures can vary between the top and bottom cooking
grates. Also keep in mind that the probes used on most gauges are designed to measure the
temperature at the tip of the temperature probe and not the overall temperature of the smoker.
Alternatively, it is recommended that users either purchase an aftermarket, oven-ready temperature
gauge, or a meat thermometer. Meat thermometers are the most effective way of determining when
the food is cooked to the minimum temperature required for safe consumption.
Please refer to the chart below for cooking temps.
SUGGESTED SMOKING TEMPERATURES
Meat, Poultry, Fish Game
Suggested Smoking
Temperatures
Safe Minimum Food
Temperatures
Beef, veal and lamb
(pieces and whole cuts)
Medium-rare 225°F (107.2°C) 145°F (63°C)
Medium 225°F (107.2°C) 160°F (71°C)
Well done 225°F (107.2°C) 170°F (77°C)
Pork
(ham, pork loin, ribs)
Pork (pieces and 225 - 240°F 160°F (71°C)
whole cuts) (107.2 - 115.6°C)
Ground meat and meat mixtures
(burgers, sausages, meatballs, meatloaf, casseroles
and mechanically tenderized beef)
Beef, veal (including 250 - 300°F
mechanically tenderized), (121 - 149°C) 160°F (71°C)
lamb and pork
Poultry (chicken & turkey) 250 - 300°F 165°F (74°C)
Poultry
(chicken, turkey, duck)
Pieces 250°F (121°C) 165°F (74°C)
Whole 240°F (115.6°C) 185°F (85°C)
Seafood
Fish 225 - 240°F 158°F (70°C)
(107.2 - 115.6°C)
Shellsh (shrimp, lobster, 225 - 240°F
crab, scallops, clams, (107.2 - 115.6°C) 165°F (74°C)
mussels and oysters)
Since it is dicult to use a food thermometer to check the temperature of
shellsh, discard any that do not open when cooked.
Chops, steaks and roasts
(deer, elk, moose, carribou/reindeer, antelope and pronghorn)
Well done 225°F (107.2°C) 170°F (77°C)
Large Game
Bear, bison, musk ox 250 - 300°F 165°F (74°C)
walrus, etc. (121 - 149°C)
Small game
Rabbit, muskrat, 225 - 240°F
beaver, etc. (107.2 - 115.6°C) 165°F (74°C)
Ground Meat
Ground meat and 250 - 300°F
meat mixtures (121 - 149°C) 165°F (74°C)
Ground venison 250 - 300°F
and sauage (121 - 149°C) 165°F (74°C)
Game birds/waterfowl
(wild turkey, duck, goose, partridge and pheasant)
Whole 250°F (121°C) 180°F (82°C)
Breasts and roasts 250°F (121°C) 165°F (74°C)
Thighs, wings 250°F (121°C) 165°F (74°C)
Stung(cookedalone 250°F(121°C) 165°F (74°C)
or in a bird)
Suggested Smoking
Temperatures
Safe Minimum Food
Temperatures

17
CARE AND MAINTENANCE
AFTER USE SAFETY AND MAINTENANCE
WARNING
• Use caution when lifting and moving the smoker to avoid strain injuries.
Two people are recommended to lift or move the smoker.
• DO NOT store the smoker near gasoline or other combustible liquids or where combustible vapors
may be present. Keep the area around the smoker clear and free of combustible materials and vapors.
• DO NOT store this smoker in an area accessible to children or pets. Store the smoker in a dry,
protected location.
• DO NOT allow anyone to conduct activities around the smoker following use until it has cooled. It is
hot during operation and remains hot for a period of time following use.
• DO NOT leave hot ashes unattended until the smoker cools completely.
• The smoker becomes extremely hot – allow the smoker to cool completely before handling. Allow
the smoker to cool before removing and cleaning the grease pan.
• Dispose of cold ashes by wrapping them in heavy-duty aluminum foil and putting them in a
noncombustible container.
• If you must dispose of the ashes in less time than it takes for them to completely cool, remove the
charcoal tray using heat-resistant gloves and place the ashes in aluminum foil. Completely soak the
ashes with water before disposing of them in a noncombustible container.
CAUTION: All care and maintenance procedures are to be performed while the
smoker is completely cooled. Always perform maintenance by a qualied service person.
Clean the cooking grates with hot, soapy water. Rinse and dry thoroughly. You may prefer to coat the
cooking grates lightly with cooking oil or cooking spray.
To clean the inside and outside of the smoker cabinet, simply use a damp cloth.
Spray-washing with a water hose is not recommended. Moisture should be wiped away and not
allowed to stand inside or on top of the smoker. Once cleaned, you may prefer to lightly coat the
interior of the smoker cabinet with cooking oil or cooking spray.
If rust is present on the exterior surface of the smoker, clean the area with steel wool or
emery cloth and use heavy-duty, heat-resistant paint.
NEVER apply additional paint to the interior of the smoker. If rust is present on the interior of the
smoker, clean it thoroughly with steel wool or emery cloth and lightly coat the area with cooking oil or
cooking spray to help minimize recurring rust.
To protect your smoker from weather conditions, always keep it covered while not in use.

18
WARRANTY
This vertical charcoal smoker is warranted against broken or damaged parts at the time of purchase.
All other parts carry a one (1) year limited warranty except the charcoal chamber, which is
warranted to be free of defects for 90 days. Paint is warranted to be free of defects for 90 days
except for rust, which may appear after repeated use.
This warranty does not cover damage or issues related to neglect, abuse or modications to the
appliance. Repair labor is not covered.
All parts that meet the warranty requirements will be shipped at no charge via the discretion of GHP
Group Inc. (ground shipments, US Mail or Parcel Post ONLY). Any special handling charges (i.e.
Second Day, Overnight, etc.) will be the responsibility of the consumer.
All warranty claims apply only to the original purchaser and require a proof of purchase verifying
purchase date. Do not return parts to GHP address without rst obtaining a return authorization
number from our customer service. This service is available by calling toll free 1-877-447-4768,
8:30 a.m. - 4:30 p.m. CST, Monday - Friday.
Some states do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not
apply to you. This warranty gives you specic legal rights, and you may have other rights that vary
from state to state.
GHP Group Inc.
6440 W. Howard Street
Niles, Il, USA
60714-3302
Item name: Vertical Charcoal Smoker
Model #: DGX780BDC-D

19
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:30 a.m. - 4:30 p.m.
CST, Monday - Friday or log on to [email protected].
70-01-115 Printed in China
PART DESCRIPTION PART #
1 Square smoke stack 312-02009-00
2 Smoker body 70-01-230
3 Lifting handle 70-01-231
4 Temperature gauge 211-02005
5 Logo plate - Dyna-Glo* 211-02002
6 Cooking grate 312-01014-00
7 Upper door 70-01-232
8 Lower door 70-01-233
9 Door latch bracket 70-01-156
10 Side damper plate* 70-01-239
11 Leg 301-01016-00
12 Grease cup 313-12002-01
13 Charcoal grate
support - right 70-01-234
14 Charcoal grate
support - left 70-01-235
PART DESCRIPTION PART #
15 Door handle grip*
16 Door handle base
17 Ash tray
18 Charcoal grate
19 Charcoal chamber
20 Wood chip box
70-01-169
70-01-170
301-01028-00
314-00001-01
70-01-241
70-01-236
21 Cooking grate support 302-01030-00
22 Door latch 70-01-161
23 Door latch handle 70-01-160
24 Wood chip box handle
/Lid handle 301-01029-02
25 Wood chip box lid 70-01-237
26 Wood chip box support 70-01-238
n/a Hardware pack 70-09-109
n/a Instruction manual 70-10-115
A
531
6
42
710
8
9
A
15
13
17
14
16 18
21
23
22
*Hardware included
19
24
25
11
12
20
26

20
Fumoir Vertical aux
Charbons de Bois
MODELE #DGX780BDC-D
70-01-115 Rev. 1/16/15
JOIGNEZ VOTRE REÇU ICI
Numéro de série_____________________________ Date d’achat _____________________
Des questions, des problèmes, des pièces manquantes? Avant de retourner l’article
au détaillant, appelez notre service à la clientèle au 1-877-447-4768, 08:30-16 heures 30,
HNC, du lundi - vendredi ou par e-mail à [email protected].
