Dynamic CCTV EZ960 User guide

002A08X2ZXB2
Versatile/Lite H.264 DVR
OSD Setup Manual
Version 2.2

OSD Setup Manual
1
Table of Contents
Menu System Overview ..................................................................................................... 7
< Username and Password > .................................................................................... 7
< Key Usage > .......................................................................................................... 7
 Key Usage in OSD Menu ............................................................................... 7
 Key Usage in Virtual Keyboard ....................................................................... 8
System Setup ..................................................................................................................... 9
< System/Version Info > ............................................................................................ 9
 Model Name ................................................................................................... 9
 Video System ................................................................................................. 9
 Hardware ........................................................................................................ 9
 Software ......................................................................................................... 9
 MAC Address 1 ............................................................................................ 10
 Software Upgrade......................................................................................... 10
 Software Upgrade Via Internet ..................................................................... 10
< Language > .......................................................................................................... 10
< Date/Time > ......................................................................................................... 11
 Date / Time ................................................................................................... 11
 Time Zone .................................................................................................... 11
 Date/Time Display ........................................................................................ 12
 Date Display Mode ....................................................................................... 12
 Time Display Mode ....................................................................................... 12
 Daylight Saving Time Setup ......................................................................... 12
- Daylight Saving Time ...................................................................... 12
- DST Start / End ............................................................................... 12
- DST Bias ......................................................................................... 13
 Network Time Protocol Setup ....................................................................... 13
- NTP Server ..................................................................................... 13
- Automatically Time Sync ................................................................. 13
- Manually Time Sync ........................................................................ 13
< Unit Name > ......................................................................................................... 14
< Show Unit Name > ............................................................................................... 14
< User Management > ............................................................................................ 14
 Password Protection..................................................................................... 14
 Auto Logout .................................................................................................. 15
 Account Setup .............................................................................................. 15
 Permissions Setup ....................................................................................... 15
 Load Default Setting ..................................................................................... 16

OSD Setup Manual
2
< Network Setup > .................................................................................................. 16
 LAN Select ................................................................................................... 16
 LAN Setup .................................................................................................... 17
- DHCP .............................................................................................. 17
- IP .................................................................................................... 17
- Netmask .......................................................................................... 18
- Gateway .......................................................................................... 18
- DNS ................................................................................................ 18
- PPPoE Account ............................................................................... 18
- PPPoE Password ............................................................................ 19
- PPPoE Max Idle .............................................................................. 19
- Connect At Booting ......................................................................... 19
- Network Restart .............................................................................. 19
 Web Port ...................................................................................................... 20
 DDNS Setup ................................................................................................. 20
- Enable DDNS .................................................................................. 20
- Service Provider .............................................................................. 20
- Host Name ...................................................................................... 21
- DDNS Port ...................................................................................... 21
- DDNS Account ................................................................................ 21
- DDNS Password ............................................................................. 22
- Submit/ Update ............................................................................... 22
- ezDDNS .......................................................................................... 22
 UPnP Setup .................................................................................................. 22
- UPnP .............................................................................................. 23
- UPnP NAT Traversal ....................................................................... 23
< RS485 Setup >..................................................................................................... 23
 Unit ID .......................................................................................................... 23
 Baud Rate .................................................................................................... 23
 Bits ............................................................................................................... 23
 Stop .............................................................................................................. 23
 Parity ............................................................................................................ 23
< Audio Output/Key Beep > ..................................................................................... 24
 Audio Output ................................................................................................ 24
 Key Beep ...................................................................................................... 24
 Split Mode Audio ........................................................................................... 24
< UPS Setup > ........................................................................................................ 25
 UPS Protocol ................................................................................................ 25
 Power Failure Scenario ................................................................................ 25
 UPS Shutdown Setting ................................................................................. 25

OSD Setup Manual
3
- Min Remaining Battery Level .......................................................... 26
- Min Remaining Run Time ................................................................ 26
- Delay To Activate ............................................................................ 26
 UPS Info ....................................................................................................... 26
- UPS Model ...................................................................................... 26
- UPS Protocol .................................................................................. 26
- UPS Status ...................................................................................... 26
- Remaining Battery Level ................................................................. 27
- Remaining Run Time ...................................................................... 27
- Query Time ..................................................................................... 27
Monitor Setup ................................................................................................................... 28
< Show Camera Name > ......................................................................................... 28
< OSD Transparency > ........................................................................................... 28
< VGA Resolution > ................................................................................................. 28
< Show Color Bar > ................................................................................................. 28
< Mouse Sensitivity > .............................................................................................. 28
< Hide Status Bar > ................................................................................................. 29
< Status Bar Size > ................................................................................................. 29
Camera Setup ................................................................................................................... 30
< Analog Camera > ................................................................................................. 30
 Analog Camera Select.................................................................................. 30
 Dome Protocol .............................................................................................. 30
 Dome ID ....................................................................................................... 30
 Camera Name .............................................................................................. 30
 Hidden .......................................................................................................... 31
 Adjust Video ................................................................................................. 31
- Brightness ....................................................................................... 31
- Contrast .......................................................................................... 32
- Saturation........................................................................................ 32
- Hue ................................................................................................. 32
- Reset .............................................................................................. 32
 Copy Settings ............................................................................................... 32
Record Setup ................................................................................................................... 33
< Record Mode Setup > .......................................................................................... 33
 Record Resolution ........................................................................................ 33
 Record Format ............................................................................................. 33
 Max Rec. PPS .............................................................................................. 34
 CBR/VBR ..................................................................................................... 34
< Schedule Setup > ................................................................................................. 34
 Day / Night Time Start / End ......................................................................... 34

OSD Setup Manual
4
 Weekend Schedule ...................................................................................... 35
 Weekend Start / End ..................................................................................... 35
< Preset Record Configuration > ............................................................................. 35
< Per Camera Config > ........................................................................................... 36
 Camera Select .............................................................................................. 36
 Normal PPS .................................................................................................. 36
 Normal Qlty .................................................................................................. 36
 Event Max PPS ............................................................................................ 36
 Event Qlty ..................................................................................................... 36
 Event Active .................................................................................................. 36
< ezRecord Setup > ................................................................................................ 37
< Advance Schedule Setup > .................................................................................. 38
 Schedule Table ............................................................................................. 38
 Recording Profile Setup................................................................................ 39
 Holiday Seutp ............................................................................................... 39
< Data Lifetime Setup > .......................................................................................... 39
 Data Lifetime Mode ...................................................................................... 40
 Data Lifetime ................................................................................................ 40
 Data Lifetime By Day .................................................................................... 40
 Data Lifetime By Channel ............................................................................. 40
< Circular Recording > ............................................................................................ 40
< Audio Recording > ................................................................................................ 40
< Purge Data > ........................................................................................................ 41
 Purge All Data .............................................................................................. 41
 Purge All Event Data .................................................................................... 41
 Purge Event Before ...................................................................................... 41
 Start To Purge ............................................................................................... 41
Sequence Setup ............................................................................................................... 42
< Main / Call Monitor Dwell > .................................................................................. 42
< Main / Call Monitor Schedule > ............................................................................ 42
Event Setup ...................................................................................................................... 43
< Internal Buzzer > .................................................................................................. 43
< Event Icon > ......................................................................................................... 43
< Alert Notification Setup > ...................................................................................... 43
 Alert Configuration Set ................................................................................. 44
 Alert Notification ........................................................................................... 44
 Alert IP.......................................................................................................... 44
 Alert Port ...................................................................................................... 44
 Alive Interval ................................................................................................. 44
< Event Full Screen > .............................................................................................. 44

OSD Setup Manual
5
< Event Duration > .................................................................................................. 44
< Per Channel Config > ........................................................................................... 45
 Channel Select ............................................................................................. 45
 Video Loss Detect ........................................................................................ 45
 Motion Detect ............................................................................................... 45
 Detection Configuration ................................................................................ 45
- Detected Area Setup ....................................................................... 46
- Sensitivity ........................................................................................ 46
- Block Threshold .............................................................................. 46
 Alarm In ........................................................................................................ 46
 Alarm Out ..................................................................................................... 47
 Copy Event Settings ..................................................................................... 47
< E-mail Management > .......................................................................................... 47
 E-mail Select ................................................................................................ 47
 E-mail Activate .............................................................................................. 47
 E-mail Address ............................................................................................. 48
 E-mail Video Attachment .............................................................................. 48
 Event/Alarm Selection .................................................................................. 48
 SMTP Server Setup...................................................................................... 49
- E-mail via SMTP ............................................................................. 49
- SMTP Server .................................................................................. 49
- SMTP Port ...................................................................................... 50
- SMTP Account ................................................................................ 50
- SMTP Password ............................................................................. 50
- Use SSL Connection ....................................................................... 50
Database Setup ................................................................................................................ 51
< Total / Free Size > ................................................................................................ 51
< Avail. Rec Time > ................................................................................................. 51
< Internal Disks > .................................................................................................... 51
< Data Protection > ................................................................................................. 52
< Repair On Power Loss > ...................................................................................... 53
Configuration ................................................................................................................... 54
< Load Factory Default > ......................................................................................... 54
< Import Configuration > ......................................................................................... 54
< Export Configuration > ......................................................................................... 55
 Copy Destination .......................................................................................... 55
 Configuration Name ..................................................................................... 55
 Begin Export ................................................................................................. 55
< System Log > ....................................................................................................... 56
< Operation Log > ................................................................................................... 56

OSD Setup Manual
6
Export ............................................................................................................................... 57
< Select Device > .................................................................................................... 57
< Select Channel > .................................................................................................. 58
< From / To Time > .................................................................................................. 58
< Select Events > .................................................................................................... 58
< Data Type > .......................................................................................................... 58
< Export Format > ................................................................................................... 59
< Digital Signature > ................................................................................................ 59
< Erase Disc >......................................................................................................... 59
< Begin Export > ..................................................................................................... 59
POS Setup (Versatile H.264 DVR Only) .......................................................................... 60
< POS Function > .................................................................................................... 60
< POS Overlay > ..................................................................................................... 60
< Exception POS Setup > ....................................................................................... 60
 Exception No. ............................................................................................... 61
 Trigger .......................................................................................................... 61
 Exception String ........................................................................................... 61
 By Numerals ................................................................................................. 61
< Input Setup >........................................................................................................ 62
 Input source .................................................................................................. 62
 Camera Selection ......................................................................................... 62
 Text Filter ...................................................................................................... 63
 Manual Filter Setup ...................................................................................... 63
 Input Process ............................................................................................... 63
 Text Baud Rate ............................................................................................. 64
 Text Bit.......................................................................................................... 64
 Text Stop....................................................................................................... 64
 Text Parity ..................................................................................................... 64
Shutdown.......................................................................................................................... 65
< Power Off > .......................................................................................................... 65
< Reboot > .............................................................................................................. 65
< Power Key Privilege > .......................................................................................... 65
Appendix A: Record Duration ......................................................................................... 66
Appendix B: DVRPlayer .................................................................................................. 68
Appendix C: USB Mouse Operation ............................................................................... 73
Special Operations .................................................................................................. 73
Appendix D: HDD Copy Tool (EXT2IFS) ......................................................................... 75

OSD Setup Manual
7
Menu System Overview
The detailed functions and settings of Versatile/Lite H.264 DVR can be set by entering the
intuitive Graphical User Interface (GUI) OSD setup menu. Collaborating with a USB mouse,
setting up the DVR can be easy as operating on a PC. This chapter particularizes the items
and options in the OSD setup menu.
< Username and Password >
Press MENU and select an account to login. There are two preset accounts: “admin” and
“user”. The next step is to enter a corresponding password. The preset password for the
administrator account “admin” is “1234”, while the preset password for the account “user” is
“4321”.
NOTE: It is strongly suggested to change the preset password to prevent
unauthorized access to the unit.
An icon displayed at the status bar will show the authority level of the account. Under logout
condition, the icon will show “Guest”. When an account is logged in, its authority level
number (1~8) will be shown.
Before completely logout, other functions can also be accessed without having to login
again. There are two ways to logout: manually logout by pressing ESC key at Live mode, or
auto logout when keys are not pressed for a preset period of time (default 5 minutes) at
Live/ Menu mode.
< Key Usage >
The key usage differs under the OSD menu and in the Virtual keyboard. The difference can
be seen while setting some items, such as Unit Name and IP Address.
 Key Usage in OSD Menu
The following introduce some keys used frequently to setup the DVR via the OSD
menu.
<Direction Keys>
In the OSD menu, Direction Keys are used to move the cursor to previous or next
fields. UP / DOWN are used to change the value in the selected field.
<ENTER>
In OSD menu or selection interface, press the key to make selection or save
settings.

OSD Setup Manual
8
<ESC>
Press to cancel or exit from certain OSD menu without saving any changes.
 Key Usage in Virtual Keyboard
A virtual keyboard shows up while editing settings such as camera title, unit name,
etc. The virtual keyboard displays as follows.
!
@
#
*
-
_
+
=
,
.
/
←
1
2
3
4
5
6
7
8
9
0
Del
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z
<< >> Space Cancel
OK
<To input characters>
Move the cursor by pressing Direction keys and press ENTER to select characters.
<To move the cursor in title entry field>
Select “<<” / “>>” and press ENTER to move the cursor to left / right in the title
entry field.
<To delete previous character>
Select <Backspace> and press ENTER.
<To delete current character>
Select <Delete> and press ENTER.
<To exit the virtual keyboard>
Select <OK> and press ENTER to save the settings and exit. Otherwise press
ESC or select <Cancel> and press ENTER to exit without saving changes.
NOTE: If a USB keyboard is connected and when any key on the keyboard
is pressed, the cursor on the virtual keyboard will be automatically moved to
<OK>.

OSD Setup Manual
9
System Setup
Select <System Setup> from the Main Menu and press ENTER to enter the System Setup
menu. The items in the System Setup menu are described in the following sections.
System Setup
System/Version Info
Language
Date/Time
Unit Name
Show Unit Name
User Management
Network Setup
RS485 Setup
Audio Output/Key Beep
UPS Setup
English
DVR
No
< System/Version Info >
The System/Version Info menu allows users to view system information such as hardware
and software version. From the System Setup menu, select <System/Version Info> and
press ENTER. The following menu is displayed. The first five items are “read only”, thus
CANNOT be changed. The items in this menu are described in the following subsections.
System/Version Info
Model Name
Video System
Hardware
Software
MAC Address 1
Software Upgrade
Software Upgrade Via Internet
****
NTSC
**-**-**
****-****-****-****
**:**:**:**:**:**
 Model Name
This item shows the model name of the DVR.
 Video System
This item shows the current video system of the DVR.
 Hardware
This item shows the hardware version of the DVR.
 Software
This item shows the software version installed on the DVR.

OSD Setup Manual
10
 MAC Address 1
This item identifies the first Media Access Control (MAC) address of the DVR.
 Software Upgrade
This item is used for updating software of the Versatile/Lite H.264 DVR via local
device. The menu is displayed as follows.
Software Upgrade
Upgrade Version
xxxx-xxxx-xxxx-xxxx
Select
No
Connect an USB storage device containing upgrade software to the DVR; the
available upgrade files will be listed in the menu. To update the system, select a file
and use UP / DOWN keys to choose <Yes>. Press ENTER to confirm the selecti
on and start the upgrade process. The Versatile/Lite H.264 DVR will download
the software, update the system files, and reboot automatically.
The upgrade may take several minutes to save the changes in the memory of the
system. After the DVR is rebooted, please check the software version again.
NOTE: Power interruption is NOT allowed during the software update.
Ensure that no power interruption can occur until the DVR is completely
rebooted.
NOTE: Do not remove the external USB ThumbDrive / DVD+RW before
the DVR has completely shutdown (hard drive and fan are off). Removing
the external USB ThumbDrive / DVD+RW before shutdown can cause the
system to update improperly.
 Software Upgrade Via Internet
The item is used to upgrade the unit’s software via the internet. Select one of the
listed software versions and choose <Yes>. The DVR downloads the software,
updates the system files, and reboots automatically.
< Language >
The Language item allows users to select the language for the OSD menu and screen
messages. Language selection takes effect immediately when the selection is made. Press
UP / DOWN to select from listed languages and press ENTER to confirm.

OSD Setup Manual
11
< Date/Time >
Users can set the current date, time and other OSD parameters in this menu. Login using
account with proper privilege to enter the submenu. In System Setup menu, select
<Date/Time> and press ENTER. The Date/Time menu displays as follows.
Date/Time
Date
Time
Time Zone
Date/Time Display
Date Display Mode
Time Display Mode
Daylight Saving Time Setup
Network Time Protocol Setup
2011/02/21
PM 10:39:26
OFF
ON
Y/M/D
12 HR
NOTE: The reset of Date / Time setting only applies to new video. The date and time
of previously recorded video will not be changed.
NOTE: To avoid database corruption, formatting the database is recommended after
changing Date / Time setting.
 Date / Time
Select <Date> or <Time> and press ENTER to adjust the settings. LEFT / RIGHT
keys are used to move the cursor to previous or next field, ENTER is for selecting,
and UP / DOWN are used to change the value in the selected field.
 Time Zone
Press ENTER to set users’ local time zone. Please refer to the following figure or
visit www.greenwichmeantime.com to find out users’ local time zone.

OSD Setup Manual
12
NOTE: <Time Zone> must be set to users’ local time zone or the <Network
Time Protocol Setup> will not be accessible.
 Date/Time Display
Select <ON> or <OFF> to setup whether to display date/time information on the
screen. Press ENTER and use the UP / DOWN keys to change the setting.
 Date Display Mode
This menu allows users to set the display type of the date. Three options are
provided: <Y/M/D>, <M/D/Y> or <D/M/Y>. “Y” represents “Year”, “M” represents
“Month” and “D” represents “Day”. Use UP / DOWN keys to change the setting.
 Time Display Mode
Users can set the time format to <12 HR> or <24 HR>. Use the UP / DOWN keys
to change the format.
 Daylight Saving Time Setup
This function is for people who live in certain regions to observe Daylight Saving
Time. The menu displays as follows:
Daylight Saving Time Setup
Daylight Saving Time
DST Start
DST End
DST Bias
Off
Apr 1st Sun 01:00
Oct Last Sun 01:00
60 Min
- Daylight Saving Time
Select <On> to enable, or <Off> to disable the function. If the function is
disabled, the DST Start / End time and DST Bias will be grayed out and
cannot be accessed. If this function is enabled, the date/time information
will be shown on the screen with a DST icon when playing back recorded
video or searching video in the event list. “S” indicates summer time and
“W” indicates winter time.
- DST Start / End
These items are used to set duration of daylight saving time. Use LEFT /
RIGHT to move the cursor to the previous or next field, UP / DOWN to
change the settings.

OSD Setup Manual
13
- DST Bias
This item allows users to set the amount of time to move forward from the
standard time for daylight saving time. Available options are <30>, <60>,
<90> and <120> minutes.
 Network Time Protocol Setup
After time zone is set, the <Network Time Protocol Setup> option will be available.
Network Time Protocol Setup
NTP Server
Automatically Time Sync
Manually Time Sync
time.nist.gov
Off
No
- NTP Server
Enter this item to setup a feasible time server. The default time server is
time.nist.gov. Users can change it to any other time server if desired. IP
addresses of other time servers are listed below for reference.
129.6.15.28 129.6.15.29 132.163.4.101
132.163.4.102 132.163.4.103 128.138.140.44
192.43.244.18 131.107.1.10 69.25.96.13
206.246.118.250 208.184.49.9 64.125.78.85
207.200.81.113 64.236.96.53 68.216.79.113
- Automatically Time Sync
Select <ON> and the time will be synced once an hour.
- Manually Time Sync
Select <Yes> to sync the time immediately.

OSD Setup Manual
14
< Unit Name >
Users are allowed to assign a unit name, up to 11 characters, to the Versatile/Lite H.264
DVR.
Follow the steps below to edit the unit name.
 Select <Unit Name> from System Setup menu and press ENTER. A virtual
keyboard displays as below.
!
@
#
*
-
_
+
=
,
.
/
←
1
2
3
4
5
6
7
8
9
0
Del
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z
<< >> Space Cancel
OK
 Use Direction keys to move the cursor to the wanted character.
 Press ENTER to add the character to the entry field (up to 11 characters).
 When the unit name is entered, move the cursor to <OK> and press ENTER to
save the settings and exit.
< Show Unit Name >
This item enables the unit name of the Versatile/Lite H.264 DVR to be shown on the
monitor. Select <Yes> to show or select <No> to hide.
< User Management >
The DVR provides the option to create up to seven sets of usernames and passwords with
customized authority, excluding the preset “admin” account. The menu is as the following.
User Management
Password Protection
Auto Logout
Account Setup
Permissions Setup
Load Default Setting
On
300 Sec
No
 Password Protection
Select <On> to request for username and password for accessing functions listed
in Authority Setup menu, or select <Off> to allow free access.

OSD Setup Manual
15
 Auto Logout
Users can setup time for automatic logout of system when no operation is
performed. Select from <60 Sec>, <120 Sec>, <300 Sec> and <600 Sec>.
Alternatively, select <Disable> and the system will not automatically logout.
 Account Setup
Setup customized username, password, and authority level in this menu. Note that
the account is case sensitive and password cannot contain the number “0”. Press
Direction keys and ENTER to select items. The privilege level ranks from levels
1~8, which level 8 has the highest authority. Alternatively, select <Disable> to stop
using the account.
Account Setup
Account: admin
Mod
Password:
****
Mod
Privilege: Level 8
.
Confirm
Cancel
NOTE: The account name and privilege level of the preset “admin” account
cannot be changed.
 Permissions Setup
Setup permitted authority level for accessing the functions listed in this menu. The
functions include: Playback/Search, Hidden Camera, Dome Control, Live
Operation, Call Control, Export Data, Menu Access, System Setup, Monitor Setup,
Camera Setup, Record Setup, Sequence Setup, Event Setup, Database Setup,
Configuration, POS Setup and Shutdown. Press Direction keys and ENTER to
select from items. In accordance with users’ privilege level defined in <Account
Setup>, the authority level here also ranks from levels 1~8, with level 8 as the
highest level. Users will be able to access any function that is set to their
equivalent level or lower. Alternatively, select <DISABLE> to allow free access.
Permissions Setup
Item
Playback/Search
Hidden Camera
Dome Control
Live Operation
Call Control
Export Data
Authority
DISABLE
LEVLE8
DISABLE
DISABLE
DISABLE
DISABLE

OSD Setup Manual
16
NOTE: The “Menu Access” cannot be set to <Disable>.
When the account does not have authority to access certain functions, an error
message will be displayed on the screen.
 Load Default Setting
This item is for restoring the default settings. Select <Yes> to load default setting or
select <No> to exit.
< Network Setup >
The Network Setup menu allows users with proper privilege to configure the network by
specifying the network related settings, such as IP address and Netmask, etc. Check with
the network administrator and/or network service provider for more specific information.
The menu is as the following. Items in this menu are described in the following sections.
Network Setup
LAN Select
LAN Setup
Web Port
DDNS Setup
UPnP Setup
LAN
80
 LAN Select
This item allows users to select the network type among <LAN>, <PPPoE>, and
<None>. If the internet connection is a local area network communication, please
select <LAN>. If the internet connection is a broadband medium, such as DSL Line
or cable modem, please select <PPPoE>. PPPoE stands for Point-to-Point
Protocol over Ethernet. It is a specification for connecting the users on an Ethernet
to the Internet through a common broadband medium.
If <None> is selected, then there is no need to set further LAN or PPPoE settings.
Therefore, the second item <LAN Setup>will be inaccessible.

OSD Setup Manual
17
 LAN Setup
The network related settings in the LAN Setup menu should be associated with the
network service type. Select <LAN Setup> in Network Setup menu and press
ENTER to set the parameters. The menu displays as follows.
LAN Setup
DHCP
IP
Netmask
Gateway
DNS
PPPoE Account
PPPoE Password
PPPoE Max Idle
Connect At Booting
Network Restart
Off
192.168.1.150
255.255.255.0
192.168.1.1
0.0.0.0
35 Min
Yes
No
- DHCP
This item allows users to obtain a dynamic IP address from DHCP
(Dynamic Host Configuration Protocol) server when the DVR boots up.
When using DHCP, the settings are dynamic and will change every time
the DVR power on or off, depending on the network's setup.
If the item is enabled (On), a dynamic IP will be assigned to
Versatile/Lite H.264 DVR. In this case, users do not need to set a static
IP and the Ethernet settings, including IP address, Netmask, Gateway,
and DNS settings will be read-only.
If the DVR is using a permanent address, disable DHCP (Off) to manually
set IP Address, Netmask, Gateway, and DNS. See the network system
administrators or IT personnel for appropriate values.
- IP
This item is used to configure the IP (Internet Protocol) address of the
DVR. The IP address is the identifier for the DVR on a TCP/IP LAN.
Please note that to set a static IP address, DHCP must be set to <Off>.

OSD Setup Manual
18
- Netmask
A netmask is a 32-bit mask used to divide an IP address into subnets and
specify the networks available hosts. Its value is defined by the network
administrator. It takes the form as ***.***.***.***, for example,
255.255.255.255.
This item allows users to enter the value of the Netmask for the DVR.
Please note that to configure this item, DHCP must be set to <Off>.
- Gateway
Gateway is a node on a network that serves as an entrance to another
network. Users are allowed to specify the IP address of the gateway or
router associated with this DVR. To configure this item, DHCP must be
set to <Off>.
- DNS
DNS is the abbreviation for “Domain Name Server”, which is an Internet
service that translates domain names into IP addresses. The advantage
of using DNS is that domain names are easier to remember.
This item allows users to specify the IP address of the Domain Name
System associated with the DVR. To configure this item, DHCP must be
set to <Off>.
If the server is unavailable when using DHCP, the DVR will search for the
network server and boots up more slowly. This network search continues
until it times out.
- PPPoE Account
The item allows users to setup the PPPoE login username.
NOTE: For accessing the PPPoE settings, select <PPPoE> as the
Network Type in Network Setup menu.

OSD Setup Manual
19
To setup the login username, follow the steps:
 Select <PPPoE Account> from LAN Setup menu and press ENTER.
A virtual keyboard displays.
!
@
#
*
-
_
+
=
,
.
/
←
1
2
3
4
5
6
7
8
9
0
Del
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z
<< >> Space Cancel
OK
 Use Direction keys to move the cursor to the desired character.
 Press ENTER to add the character to the entry field.
 When it’s done, move the cursor to <OK> and press ENTER to save
the setting and exit.
- PPPoE Password
The item allows users to setup the PPPoE password. Follow these steps
to setup the login password.
 Select <PPPoE Password> from LAN Setup menu and press ENTER.
A virtual keyboard displays.
 Use Direction keys to select from characters.
 Press ENTER to add the selected character to the entry field.
 When it’s done, move the cursor to <OK> and press ENTER to save
the setting and exit.
- PPPoE Max Idle
The item indicates the duration that the modem connection remains
active if there is no acknowledgement from the remote PC. Users can
select the idle time from 0 to 600 minutes.
- Connect At Booting
The DVR is allowed to automatically connect to the internet when booting
up. Select <Yes> to connect at booting, otherwise select <No>.
- Network Restart
Network restart is required after network settings are changed. Select
<Yes> to restart the network connection.
