Dynavin 8 Installation guide

Jeep Wiring Diagram
GPS
ANTENNA
SUB FRONTAV-IN
V-IN
REAR
L L L
R R R
MDI&CP PHONE
GPS
MIC
WIFI-BT
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20
BT MIC
FM/AM ANTENNA
FAKRA PLUG
11,
12, 13, 14, 15, 16, 17, 18, 19, 20,
B+ (Yellow) B+ (Yellow) Rear right speaker+ (Purple) Rear left speaker+ (Green) Front right speaker+ (Grey) Front left speaker+ (White)
1, 2, 3, 4, 5, 6, 7, 8, 9,
10,
GND (Black) GND (Black) Rear right speaker- (Purple & Black) Rear left speaker- (Green & Black) Front right speaker- (Grey & Black) Front left speaker- (White & Black) AMP-CON (Blue)
BT WIFI ANTENNA
CAMERA
CAMERA POWER
GND
REVERSE IN
IR
MDI&CP
PHONE
FM/AM
Only for Dynavision Pro camera
CANBUS
DAB ANTENNA
Connect to the Ground
DAB
Fast Charge
Android
Auto
CarPlay
See the wiring diagram below for all accessory and wiring harness
connections. Please note the wiring and installation instructions
for the DAB antenna.
Youtube channel : Dynavin Europe
Installation Video Guide
Follow our YouTube channel for installation videos for some vehicles.
Quick Manual

Instruction Manual
German version
dynavin.de/d8-manual-de
English version
dynavin.de/d8-manual-en
French version
dynavin.de/d8-manual-fr
Dynavin 8 User Manual
Scan the appropriate QR code or visit the website indicated below
for the Dynavin 8 User Manual.
Navigation Map File
System Reboot
Please download the latest software version from
https://flex.dynavin.com
Support
If you have any issues during use, tap the System Reset icon
from the main menu and tap the "Restart" option.
Due to the storage space limitation, not all of the map files are
installed in the system.
Please configue the map file in the Map Updates menu.
For the latest map file, please download it from flex.dynavin.com
The Latest Map Guarantee allows one free map upgrade within
30 days of first use of the Dynaway app.
For further assistance, contact us at
https://support.dynavin.com/technical
