Dynojet Power Commander User manual
2008 Arctic Cat 700 H1 - PCIII USB - 1i630-411www.powercommander.com
2008 Arctic Cat 700 H1
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
1Posi tap
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
USB Port
Expansion Port
1 Remove the seat.
2Remove the storage cover (Fig. A).
Fig. A
Fig. B
2008 Arctic Cat 700 H1 - PCIII USB - 2i630-411www.powercommander.com
Fig. C
3 To make the injector more accessible remove
the rubber intake snorkel. Loosen the clamp
for the snorke thru the opening under the
storage cover (Fig. B).
Loosen screw
Remove cover
4Attach the PCIII under the seat using the sup-
plied velcro. Route the PCIII wiring harness
under the seat frame and plastic shroud.
5Attach the ground wire from the PCIII to the
negative side of the battery (Fig. C).
Ground wire
6Unplug the stock wiring harness from the
injector (Fig. D)
7Plug the PCIII harness in-line of the stock
wiring harness and injector.
Fig. D
2008 Arctic Cat 700 H1 - PCIII USB - 3i630-411www.powercommander.com
8Locate the Throttle Position Sensor on the left
hand side of the throttle body.
9Using the supplied posi-tapconnect the GREY
wire of the PCIII to the GREEN/BLACK
wire of the TPS.
TPS
Posi-tap
10 Reinstall the storage cover and seat.
For more information on how to use and
adjust the PCIII go to the HELP menu in the
control center software.
Unplug
Fig. D
