Dyson DC22 User manual

OPERATING MANUAL
click
click
click
click
1
2
3
REGISTER
FOR YOUR
FREE 5 YEAR
GUARANTEE
TODAY
WASH FILTERS
Wash filters with cold water
at least every month.
1
month
ASSEMBLY
AB

Note your serial number for future reference
After registering for your 5 year guarantee, your Dyson
vacuum cleaner will be covered for parts and labour for
5 years from the date of purchase, subject to the terms of
the guarantee.
If you have any query about your Dyson vacuum cleaner,
call the Dyson Customer Care Helpline with your serial
number and details of where/when you bought the
vacuum cleaner. Your serial number can be found on
your rating plate which is behind the clear bin.
Most queries can be solved over the phone by one of our
trained Dyson Customer Care Helpline staff.
Alternatively visit www.dyson.co.uk/support for online
help, general tips and useful information about Dyson.
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
IRL 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
2

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. Do not leave the Dyson vacuum when plugged in. Unplug from socket when not in use and before servicing.
2. Do not use outdoors or on wet surfaces. Suitable for dry locations only. Do not use to pick up water.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children. Children should be
supervised to ensure that they do not play with the Dyson vacuum.
4. This Dyson vacuum is not intended for use by young children or infirm persons with reduced physical, sensory or reasoning
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction by a responsible
person concerning use of the Dyson vacuum to ensure that they can use the Dyson vacuum safely.
5. Use only as described in this manual. Use only Dyson recommended accessories and replacement parts. Do not carry out
any maintenance other than that shown in this manual, or advised by the Dyson Customer Care Helpline. Contact the Dyson
Customer Care Helpline when service or repair is required. Do not disassemble the Dyson vacuum as incorrect reassembly may
result in an electric shock or fire.
6. Do not use with a damaged cable or plug. If the Dyson vacuum is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, do not use and contact the Dyson Customer Care Helpline. If the supply cable is damaged it
must be replaced by Dyson, its service agent or similarly qualified person in order to avoid a hazard.
7. Do not pull or carry by cable, use cable as a handle, close a door on cable, or pull cable around sharp edges or corners. Do not
run the Dyson vacuum over cable. Keep cable away from heated surfaces. To avoid a tripping hazard rewind the cable when
not in use.
8. Always extend the cable to the red line but do not stretch or tug the cable.
9. Do not unplug by pulling on the cable. To unplug, grasp the plug, not the cable.
10. Do not handle the plug or Dyson vacuum with wet hands.
11. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may
reduce airflow.
12. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts, such as the brush bar. Do not
point the hose, wand or tools at your eyes or ears or put them in your mouth.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs. Do not work with the Dyson vacuum above you on the stairs.
15. Do not use to pick up flammable or combustible liquids, such as petrol, or use in areas where they or their vapours may be
present.
16. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
17. Do not use without the clear bin and filter in place.
18. Hold the plug when rewinding onto cable reel. Do not allow the plug to whip when rewinding.
19. The use of an extension cable is not recommended.
SAVE THESE INSTRUCTIONS
THIS VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY
Do not pull on
the cable.
3
Do not store near
heat sources.
Do not use near
naked flame.
Do not run over
the cable.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not use above
you on the stairs.
Do not put hands
near the brush bar
when the vacuum
cleaner is in use.

1
click
click
click
click
2
3
2
1
3
click
click
4
Power
Looking for blockages
Tools
Floor tool

1
click
click
click
click
2
3
2
1
3
click
click
5
Cable
Cleaning
Emptying
Storage

IMPORTANT!
WASH FILTERS
Filter A
Filter B
24 hrs
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
1
2
3
4
5
6
7
8
9
10
11 12
10x
1
month
6

Wash filters with cold water at least every month.
Filter A
Filter B
24 hrs
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
1
2
3
4
5
6
7
8
9
10
11 12
10x
Rinse and shake filters under tap. Turn
over and tap very firmly to remove motor
emissions. Repeat 10x until water runs clear.
7

8
USING YOUR DYSON VACUUM CLEANER
PLEASE NOTE:
• Fine dust such as plaster dust or flour should only be vacuumed in very
small amounts.
• Consult your flooring manufacturer’s recommended instructions before
vacuuming and caring for your floorings, rugs and carpets.
• If used in a garage when car cleaning, care should be taken to wipe the
soleplate and wheels with a dry cloth after vacuuming to clean off any sand, dirt
or pebbles which could damage delicate floors.
• Store the vacuum cleaner indoors. Do not use or store this vacuum cleaner
below 0°C (32°F). Ensure that the vacuum cleaner is at room temperature before
operating.
EMPTYING THE CLEAR BIN
CAUTION:
• Switch OFF and unplug the vacuum cleaner before emptying the bin.
Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
To remove the clear bin from the machine press the button at the rear of the
carrying handle. To release the dirt, press the red bin release button.
Emptying into a bag is recommended for allergy sufferers.
The British Allergy Foundation has approved this product. It is a UK national
charity with the aim of improving awareness, prevention and treatment of
allergies.
PLEASE NOTE:
• Do not use the vacuum cleaner without the clear bin in place.
• To minimise dust and allergen contact when emptying, encase the clear bin
tightly in a plastic bag and empty. Remove the clear bin carefully and seal bag
tightly, dispose as normal.
CLEANING THE CLEAR BIN
CAUTION:
• Do not immerse the whole cyclone in water or pour water into the cyclones.
• Ensure the bin is completely dry before replacing.
PLEASE NOTE:
• Do not use detergents, polishes or air fresheners to clean the bin.
• Do not put the bin in a dishwasher.
• When vacuuming, certain carpets may generate small static charges in the clear
bin. These are entirely harmless and not associated with the main supply. To
minimise any effect from this, do not put your hand or insert any object into the
clear bin unless you have first emptied it and rinsed it out with cold water.
• Clean the shroud with a cloth or dry brush to remove lint and dust.
WASHING YOUR FILTERS
DO THIS EVERY MONTH
CAUTION:
• Switch OFF and unplug the vacuum cleaner before removing the filters.
• Ensure filters are completely dry before refitting into the vacuum cleaner.
This machine has two filters, located as shown. It is important to check your
filters regularly and wash at least every month according to instructions, to
maintain performance. Filter B should be rinsed and tapped out until the water
runs clean, then tapped out again to ensure all excess water is removed. This will
normally require up to 10 rinse cycles. Please leave to dry completely for
24 hours.
PLEASE NOTE:
• The filters may require more frequent washing if vacuuming fine dust.
• Do not use detergents to clean the filters.
• Do not put the filters in a dishwasher, washing machine, tumble dryer, oven,
microwave or near an open flame.
LOOKING FOR BLOCKAGES
CAUTION:
• Switch OFF and unplug the vacuum cleaner before checking for blockages.
• Beware of sharp objects when clearing blockages.
• Refit all parts of the machine securely before using.
PLEASE NOTE:
• Clearing blockages is not covered by your vacuum cleaner’s limited guarantee.
If any part of your vacuum cleaner becomes blocked, it may overheat and then
automatically shut off. Unplug the vacuum cleaner and leave to cool down.
Clear blockage before restarting.
• Large items may block the tools or wand inlet, if this happens switch the vacuum
cleaner off and remove the plug before removing the blockage. Do not operate
the wand release catch.
CLEARING BRUSH BAR OBSTRUCTIONS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before clearing brushbar
obstructions.
• If your brushbar is obstructed, it may shut off. If this happens you will need to
remove brushbar as shown and clear any obstructing debris.
DISPOSAL INFORMATION
This product should not be treated as household waste. Instead it should be
handed over to the applicable collection point for the recycling of electrical
and electronic equipment – this may be your local civic amenity site or a
facility provided by the retailer selling the product or a replacement product.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and for human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact the Dyson
Customer Care Helpline, your local authority civic amenity site or the retailer
selling the product or a replacement product.
GUARANTEE – TERMS AND CONDITIONS
DYSON CUSTOMER CARE
If you have a question about your Dyson vacuum cleaner, call the Dyson
Customer Care Helpline with your serial number and details of where and when
you bought the vacuum cleaner, or contact us via the website. The serial number
can be found on the main body of the vacuum cleaner behind the clear bin.
Most questions can be solved over the phone by one of our Dyson Customer
Care Helpline staff.
If your vacuum cleaner needs service, call the Dyson Customer Care Helpline so
we can discuss the available options. If your vacuum cleaner is under guarantee,
and the repair is covered, it will be repaired at no cost.
PLEASE REGISTER AS A DYSON MACHINE OWNER
THANK YOU FOR CHOOSING TO BUY A DYSON VACUUM CLEANER.
To help us ensure you receive prompt and efficient service, please register as a
Dyson machine owner. There are three ways to do this:
• Online at www.dyson.co.uk
• By calling the Dyson Customer Care Helpline.
• By completing and returning the enclosed form to us by mail.
This will confirm ownership of your Dyson vacuum cleaner in the event of an
insurance loss, and enable us to contact you if necessary.
LIMITED 5 YEAR GUARANTEE
TERMS AND CONDITIONS OF THE DYSON 5 YEAR LIMITED GUARANTEE.
WHAT IS COVERED
• The repair or replacement of your vacuum cleaner (at Dyson’s discretion) if your
vacuum cleaner is found to be defective due to faulty materials, workmanship or
function within 5 years of purchase or delivery (if any part is no longer available
or out of manufacture Dyson will replace it with a functional replacement part).
• Use of the vacuum cleaner in UK and Ireland.
WHAT IS NOT COVERED
Dyson does not guarantee the repair or replacement of a product as a result of:
• Normal wear and tear (e.g. fuse, belt, brush bar, batteries etc).
• Accidental damage, faults caused by negligent use or care, misuse, neglect,
careless operation or handling of the vacuum cleaner which is not in accordance
with the Dyson Operating Manual.
• Blockages – please refer to the Dyson Operating Manual for details of how to
unblock your vacuum cleaner.
• Use of the vacuum cleaner for anything other than normal domestic
household purposes.
• Use of parts not assembled or installed in accordance with the instructions
of Dyson.
• Use of parts and accessories which are not Dyson Genuine Components.
• Faulty installation (except where installed by Dyson).
• Repairs or alterations carried out by parties other than Dyson or its
authorised agents.
• If you are in any doubt as to what is covered by your guarantee, please call the
Dyson Customer Care Helpline.
SUMMARY OF COVER
• The guarantee becomes effective at the date of purchase (or the date of delivery
if this is later).
• You must provide proof of delivery/purchase before any work can be carried
out on your vacuum cleaner. Without this proof, any work carried out will be
chargeable. Please keep your receipt or delivery note.
• All work will be carried out by Dyson or its authorised agents.
• Any parts which are replaced will become the property of Dyson.
• The repair or replacement of your vacuum cleaner under guarantee will not
extend the period of guarantee.
• The guarantee provides benefits which are additional to and do not affect your
statutory rights as a consumer.
1
2
3

9
ABOUT YOUR PRIVACY
Your information will be held by Dyson Limited and its partner companies for
promotional, marketing and servicing purposes.
If your personal details change, if you change your mind about any of your
marketing preferences or if you have any queries about how we use your
information, please let us know by contacting Dyson Limited, Tetbury Hill,
Malmesbury, Wiltshire SN16 0RP England, or by calling the Dyson Customer
Care Helpline on UK: 0800 298 0298 or IRL: 01 475 7109. Or you can email
us at [e-mail].
For more information on how we protect your privacy, please see our privacy
policy on www.dyson.co.uk
The British Allergy Foundation Seal of Approval is a UK registered trademark of
the British Allergy Foundation.
PRODUCT INFORMATION
Product weight 7.2kg.
Please note: Small details may vary from those shown.
This product is protected by the following intellectual rights:
PATENT/PATENT APPLICATION NUMBERS
AU 637272; EP 0636338; JP 1948863; US 5,078,761; AU 697029;
EP 0800360; JP 3449723; US 5,893,936; AU 736843; EP 1087688;
JP 3550360; AU 2001240894; EP 1268076; JP 2003-528704; US 6,835,222;
AU 2002226556; CA 2,439,250; EP 1370172; JP 2004-528876; US 6,991,666;
AU 744408; EP 1361812; JP 2004-537336; US 7,278,181; AU 2003252873;
CA 2,449,304; EP 1380247; JP 2004-100960; US 7,168,128; AU 2002233553;
CA 2,439,247; EP 1365676; JP 2004-524097; US 2004-0078925;
AU 2002225232; CA 2,438,079; EP 1361815; JP 3940082; US 6,974,488;
JP 2007-152136; GB 2407022; JP 2004-023962; AU 2003-255837;
EP 1551270; GB 2392827; JP 2004-023963; US 2006-085943; EP 1576719;
GB 2396491; JP 2006-511186; US 2006-0132081; EP 1542574; EP 1664560;
GB 2406146; JP 2007-506053; US 2007-230839;EP 1680858;
JP 2007-506398; US 2007-0194637; AU 2005243851; CA 2,564,599;
EP 1748848; GB 2413974; JP 2007-508967; US 2007-0175189;
AU 2005244379; CA 2,566,071; EP 1748718; GB 2413941; JP 2007-510099;
US 2007-0226937; AU 2005243454; CA 2,566,406; EP 1748719;
GB 2413942; JP 2007-512311; US 11/596,174; US 11/794,227; GB 2426726;
WO 2006/125945; GB 2426473; WO 2006/125946.
Designs/Design applications
AU 301268, ED 217666-0001, GB 3016553; JP 1228173; US D518933;
AU 301393; ED 241930-0001; GB 3017293; JP 1236657; US D526102;
AU 301396; ED 241930-0002; GB 3017294; JP 1236658; US D537219;
AU 301394; ED 241930-0003; GB 3017295; JP 1236659; US D519,696;
AU 314889; GB 4000251; JP 1311067; ED 701701-0001.
Equivalent patents, registered designs and applications exist in other countries.

www.dyson.com
Dyson Customer Care
If you have a question about your Dyson vacuum cleaner, call
the Dyson Customer Care Helpline with your serial number and
details of where and when you bought the cleaner, or contact us
via the Dyson website. The serial number can be found on the
main body of the vacuum cleaner behind the clear bin.
JN.32549 PN.14220-14-04 02.03.10
UK Dyson Customer Care
[e-mail]
0800 298 0298
Dyson Ltd, Tetbury Hill, Malmesbury, Wiltshire SN16 0RP.
IRL Dyson Customer Care
[e-mail]
01 475 7109
Dyson Ireland Limited, Unit G10, Grants Lane,
Greenogue Business Park, Rathcoole, Dublin 24
IMPORTANT!
WASH FILTERS
Wash filters with cold water at least every month.
1
month

Wash filters with cold water at least every month.

REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline
Open 7am–10pm.
7 days a week.
REGISTER
ONLINE
Visit our website to register
your full parts and labour
guarantee online.
www.dyson.com/register
UK 0800 298 0298
IRL 01 475 7109
3 EASY WAYS TO REGISTER FOR YOUR FREE 5 YEAR GUARANTEE
GUARANTEE FORM
Title Surname
First name
Telephone Mobile
e-mail
Postcode
Address
Date of purchase / / Country of purchase UK IRL
Serial number
By mail Yes No
By phone Yes No
By email Yes No
By text message Yes No
Tick box if no
As a Dyson machine owner, you can hear about
Dyson inventions, services and products before anyone
else. If it’s okay to contact you, please let us know how
we may do this.
Sometimes we might ask for feedback on our ideas or invite you to try
new products and services. Would it be okay if our partner companies
occasionally get in touch about this?
