E.C. Woods PORT ROYAL User manual

Assembly Instructions E.C. Woods, Inc. Outdoor Furniture
PORT ROYAL TABLE
(a)
STEP 1: (a) Lay all pieces on a smooth soft surface such as cardboard or carpet to help avoid scratching. We suggest
using a 6” #2 Square bit to fasten all screws (available at your local hardware store). Be careful to not over tighten any
of the fasteners.
Tools Needed
Cordless Drill
6” #2 Square Drive Bit
Soft Hammer

STEP 2: (b) Put the legs together with the notches in the feet facing each other. Some pressure may be required to get
the feet fully seated. Be sure to place something under this joint to avoid the chance of breaking the feet. (c) Put the leg
braces together with the notches in the braces facing each other. Some pressure may be required to get the braces fully
seated. Be careful to not break the braces when putting them together. (d) Center the umbrella holder on the leg braces
(e) Secure the umbrella holder to the leg braces using the 2” round head stainless steel screws provided.
(b) (c)
(d) (e)

STEP 3: NOTE (f) Dining height will not have leg braces so the umbrella holder will mount directly to the top of the
feet. (g) Put the leg braces in the notches in the legs making sure to work the leg braces into the notches a little bit at a
time all of the way around (h) until they are all flush. (i) Fasten the leg braces to the legs with the 3” flat head stainless
steel screws provided.
(f) (g)
(h) (i)

STEP 4: (j) Place the table top upside down on a clean soft surface (k) Place the leg assembly upside down into the frame
of the table and center the legs (i) Fasten the frame to the legs with the 1 ¼” round head stainless steel screws provided.
(j) (k)
(l)
