E.Digital Odyssey 200 User manual

User’s Guide
www.edig.com
e.Digital
All manuals and user guides at all-guides.com
all-guides.com

Odyssey 200 User’s Guide
© 2002 e.Digital Corporation.
All rights reserved.
Under the copyright laws, neither the documentation nor the soft-
ware maybe copied, photocopied, reproduced, translated, or
reduced to any electronic medium or machine-readable form, in
whole or in part, without the prior expressed written consent of
e.Digital Corporation.
Odyssey 200 is a trademark of e.Digital Corporation.
Microsoft and Windows are trademarks or registered trademarks of
the Microsoft Corporation.
MusicMatch is a trademark or registered trademark of MusicMatch,
Incorporated.
All other product, service, and company names are the property of
their respective owners.
All contents of the installation CD included with this product are
copyrighted by e.Digital Corporation or used with the permission of
their copyright owners. It is unlawful to copy or distribute this infor-
mation in any way without the express written consent of e.Digital
Corporation.
All manuals and user guides at all-guides.com

Odyssey 200 User’s Guide i
Table of Contents
CHAPTER 1: INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . 1
Setup and Usage Roadmap . . . . . . . . . . . . . . . . .2
Document Conventions . . . . . . . . . . . . . . . . . . . .2
CHAPTER 2: PLAYER OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 5
Accessories Included with your Odyssey 200 . . . .6
Odyssey 200 Features and Controls Overview . . .7
Remote Control (optional) . . . . . . . . . . . . . . .9
Battery Installation . . . . . . . . . . . . . . . . . . . . . . .9
Power Odyssey 200 On and Off . . . . . . . . . . . .10
Description of Player’s LCD . . . . . . . . . . . . . . .11
Overview of Player Modes . . . . . . . . . . . . . . . .12
CHAPTER 3: INSTALL SOFTWARE . . . . . . . . . . . . . . . . . . . . . 15
Install Odyssey Manager Software . . . . . . . . . . .16
Install MusicMatch Software . . . . . . . . . . . . . . .18
All manuals and user guides at all-guides.com

ii © e.Digital Corporation Odyssey 200 User’s Guide
Windows XP Special Procedure . . . . . . . . . . . . .19
CHAPTER 4: RIP AND ADD MUSIC . . . . . . . . . . . . . . . . . . . 23
Create Digital Music Files . . . . . . . . . . . . . . . . .24
Configure MusicMatch for Windows . . . . . . .24
Rip Music for Windows . . . . . . . . . . . . . . . .26
Configure MusicMatch for Macs . . . . . . . . . .28
Rip Music for Macs . . . . . . . . . . . . . . . . . . . .29
Connect the USB Cable . . . . . . . . . . . . . . . . . .30
Download Files To Player . . . . . . . . . . . . . . . . .31
Transfer Music . . . . . . . . . . . . . . . . . . . . . . .32
Transfer Other Files . . . . . . . . . . . . . . . . . . .33
Upload Files From Player . . . . . . . . . . . . . . . . .33
Change Playback Order . . . . . . . . . . . . . . . . . .35
Erase Files from Player . . . . . . . . . . . . . . . . . . .36
Disconnect the USB Cable for Windows . . . . . .38
CHAPTER 5: PLAY, RADIO AND RECORD MODE . . . . . . . . . 39
Play Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Playback State . . . . . . . . . . . . . . . . . . . . . . .40
Pause Playback . . . . . . . . . . . . . . . . . . . . . .41
Replay Segment . . . . . . . . . . . . . . . . . . . . . .41
Radio Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Use the Joystick To Change Stations . . . . . .43
Favorite Radio Stations . . . . . . . . . . . . . . . .43
Radio Equalizer . . . . . . . . . . . . . . . . . . . . . .44
Record Mode . . . . . . . . . . . . . . . . . . . . . . . . . .44
Create Voice Recordings . . . . . . . . . . . . . . .45
CHAPTER 6: OTHER FEATURES . . . . . . . . . . . . . . . . . . . . . . 47
Backlight Option . . . . . . . . . . . . . . . . . . . . . . . .47
SMC Memory Option . . . . . . . . . . . . . . . . . . . .48
Hold Button . . . . . . . . . . . . . . . . . . . . . . . . . . .49
All manuals and user guides at all-guides.com

iii
Language Support . . . . . . . . . . . . . . . . . . . . . .50
CHAPTER 7: TROUBLESHOOTING & SPECIFICATIONS . . . . . . 51
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . .51
Player Issues . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Sound Problems . . . . . . . . . . . . . . . . . . . . . . . .53
Problems Connecting to PC . . . . . . . . . . . . . . .53
MusicMatch . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Technical Specifications . . . . . . . . . . . . . . . . . . .54
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . .56
Obtaining Warranty Service . . . . . . . . . . . . . . .57
INDEX 59
All manuals and user guides at all-guides.com

iv © e.Digital Corporation Odyssey 200 User’s Guide
All manuals and user guides at all-guides.com
all-guides.com

Odyssey 200 User’s Guide 1
Chapter 1: Introduction
Welcome to the world of personal music players
and the digital lifestyle. Using the latest technologi-
cal advances in both hardware and software, the
Odyssey 200 allows you to carry a library of your
favorite music wherever you go.
WHAT IS MP3? MP3 stands for MPEG-1 or MPEG-2, layer 3. MP3
files can be compressed up to 1/20th of the size of
original Wave files.
You can download MP3 files from the Internet or
create them from your personal music CDs by
using the MusicMatch software. Then you down-
load the MP3 files to your player for CD quality
sound without the need for bulky cassette tapes or
CDs.
All manuals and user guides at all-guides.com

2 © e.Digital Corporation Odyssey 200 User’s Guide
SETUP AND USAGE ROADMAP
This document includes detailed information about
how to setup and use your Odyssey 200. Listed
below is a summary of the required steps.
INSTALL
SOFTWARE • e.Digital Odyssey Manager to transfer and
manage files
• MusicMatch software to rip (create) digital files
from your music CD
CREATE &
TRANSFER MUSIC • Install provided battery
• Configure MusicMatch software
• Attach USB Cable
• Transfer music to Odyssey 200
USE PLAYER
FEATURES • Play tracks
• Listen to a radio station
• Create voice recordings
• Erase and manage files on your player
DOCUMENT CONVENTIONS
To use the Odyssey 200 and related software, you
must have at least basic skills in using the Windows
or Mac operating system. This document uses con-
ventions described below.
A note symbol indicates a useful tip.
A caution symbol indicates important information
to prevent damage to your player or avoid incon-
venient situations.
Bold A word or phrase in bold indicates a menu or but-
ton selection in the software window or on the
player. For example: Click the OK button.
All manuals and user guides at all-guides.com

Chapter 1: Introduction 3
Italics A phrase in italics typically indicates a cross-refer-
ence to a section in the User’s Guide. In the PDF
version of the documentation available from the
Odyssey Manager Help menu, you can click on
the phrase to jump to the content.
>This character is used to describe menu /submenu
selections. For example, select the File > New
menu.
All manuals and user guides at all-guides.com

4 © e.Digital Corporation Odyssey 200 User’s Guide
All manuals and user guides at all-guides.com

Odyssey 200 User’s Guide 5
Chapter 2: Player Overview
This chapter describes:
•Accessories Included with your Odyssey 200
on page 6.
•Odyssey 200 Features and Controls Overview
on page 7.
•HowtoPower Odyssey 200 On and Off on
page 10.
•Description of Player’s LCD on page 11.
•Overview of Player Modes on page 12.
All manuals and user guides at all-guides.com
all-guides.com

6 © e.Digital Corporation Odyssey 200 User’s Guide
ACCESSORIES INCLUDED WITH YOUR ODYSSEY 200
When you unpack your player you will find the fol-
lowing items:
• User’s Guide
• Installation CD:
• e.Digital Odyssey Manager
• MusicMatch software
• Adobe Acrobat Reader
• PDF of User’s Guide
• Shielded USB cable
• Compact stereo earphones
• One 1.5V AA battery
• Carrying case (optional)
• Remote Control (optional)
All manuals and user guides at all-guides.com

Chapter 2: Player Overview 7
ODYSSEY 200 FEATURES AND CONTROLS OVERVIEW
This section includes illustrations of the player from
various perspectives and identifies features and
controls.
The Joystick performs a variety of functions
depending on which mode the player is in. For
example, press and release the Joystick to power
the player on and off.
Microphone
LCD
Joystick
Smart Media
Card (SMC) Slot
Eject Slider
for SMC
Battery Cover
All manuals and user guides at all-guides.com

8 © e.Digital Corporation Odyssey 200 User’s Guide
Earphone Jack
Hold Slider to lock player
Mode
Repeat or Set Radio Channel
Equalizer
Record on/off or Mark Replay
or Backlight
USB Port
All manuals and user guides at all-guides.com

Chapter 2: Player Overview 9
Remote
Control
(optional)
The optional remote control can be used in place
of the player’s Joystick to access Odyssey 200 func-
tions in Play Mode or Radio Mode.
* Or hold this button to switch to Radio Mode.
To attach the remote control:
1. Insert the remote control connector into the
player’s earphone jack.
2. Next insert the earphone connector into the
remote control’s earphone jack.
BATTERY INSTALLATION
The AA battery included with your Odyssey 200
will last for up to 12 hours of play. To replace the
battery:
1. Loosen the battery cover on the back of the
player by sliding the cover downward.
Earphone
Jack
Forward
Volume Up
or Previous
Hold Slider
Power On
or Play
or Pause
Stop or
Power Off
* Equalizer
Rewind
Volume Down
or Next
All manuals and user guides at all-guides.com

10 © e.Digital Corporation Odyssey 200 User’s Guide
2. Remove the dead battery from the player.
3. Insert new battery with + end to the left and the
- end towards the coil on the right.
4. Replace the battery cover and the player is
ready to use.
POWER ODYSSEY 200 ONAND OFF
POWER ON To turn on the player, press and release the
button. You will see an animated display followed
by a check of the player’s internal memory and if
installed, SMC memory.
POWER OFF To shut off your Odyssey 200 press and hold the
button.
Or, the player will automatically shut off after three
minutes of inactivity, for example, in Play Mode,
but not during music playback or Radio Mode.
All manuals and user guides at all-guides.com
all-guides.com

Chapter 2: Player Overview 11
DESCRIPTION OF PLAYER’SLCD
When you press and release the button the
Odyssey 200 powers on and displays the initial,
Play Mode on the LCD.
The player has four primary Modes described on
page 12, however, each mode includes some of the
icons illustrated below:
PLAYBACK ICON Displays when the player is in Play Mode. For
more information, see Overview of Player Modes
on page 12 or details in Play Mode on page 40.
EQUALIZER
OPTIONS The Odyssey 200 equalizer adjusts bass or treble to
one of five options to enhance the sound.
This option is adjusted in Play Mode or Record
Mode only, by pressing the EQ button until the
LCD shows the setting you want. The player auto-
matically returns to the previous display after each
EQ button press and displays an icon letter indicat-
ing the current equalizer setting. The five options
are:
Repeat
Options
Battery
Icon
Equalizer
Option
Playback
Icon
Record
Icon
FFlat is an equal balance of bass and treble.
PSuitable for Pop music.
RSuitable for Rock music.
CSuitable for Classical music.
BX-Bass provides more bass.
All manuals and user guides at all-guides.com

12 © e.Digital Corporation Odyssey 200 User’s Guide
BATTERY ICON Indicates the remaining battery power.
An empty battery icon indicates that only
about three minutes of power remains.
For information about replacing the bat-
tery, see page 9.
RECORD ICON Indicates the player is in Record Mode. For more
information, see Overview of Player Modes on
page 12 or details in Record Mode on page 44.
REPEAT OPTIONS Indicates one of five repeat options for playing
tracks. This option is adjusted in Play Mode or
Record Mode only. Press the REP button to one of
the following options:
OVERVIEW OF PLAYER MODES
Each time you press the Mode button on the right
side of the player, the LCD shows the next mode
cycling through a total of four:
Plays the first 10 seconds of each track.
Plays all tracks, sequentially from the start to the
end of each track.
Plays all stored tracks continuously. That is, after
the player plays the last track, it cycles back to the
first track.
Repeats only the currently selected track.
Shuffle plays tracks in a random order.
Initial, Play
Mode
page 40
FM Radio
Mode
page 42
Record
Mode
page 44
Erase
Mode
page 36
All manuals and user guides at all-guides.com

Chapter 2: Player Overview 13
Each mode is briefly described below, for detailed
information about a particular mode, see the pro-
vided page reference.
Play Mode is the initial mode when you first turn
on the player. This mode is used to display music
and voice tracks; three tracks on each display. Use
the Joystick to navigate and select a track to play.
For more information, see Play Mode on page 40.
Radio Mode is used to listen to a FM radio sta-
tion. This mode includes features to scan and seek
stations as well as set up to 20 favorite channels.
For more information, see Radio Mode on
page 42.
Record Mode is used to create a voice recording
by speaking into the internal microphone.
When there are no voice recordings on the player,
“NO TRACK” shows on the LCD. However, once
you create voice recordings, the tracks are listed in
this mode.
For more information, see Record Mode on
page 44.
There are two ways to remove files from your
player: by using the Odyssey Manager software
installed on your PC or by using the player’s Erase
Mode.
When you first enter the player’s Erase Mode, the
LCD shows as illustrated, quickly followed by two
menu choices: ERASE ALL and ERASE FILE.
For more information, see Erase Files from Player
on page 36.
You can quickly cancel Erase Mode by pressing the
Mode button.
All manuals and user guides at all-guides.com

14 © e.Digital Corporation Odyssey 200 User’s Guide
All manuals and user guides at all-guides.com
