e-nova PERFORMANCE-NOVABIKE HPNB2201 User manual
Version 1.0
4.1 Parts 7
4.2 The saddle and handlebar stem 7
5. General Terms of Use 8
5.1 IMPORTANT! AIways before riding a bicycle: 8
5.2 Throttle 8
5.3 During the riding 8
5.4 Battery and Charger 8
5.5 Charging the battery 9
5.6 Removing the battery 9
5.7 Battery level 9
5.8 Brakes 10
5.9 Button and Display 10
5.10 Operating Instruction 10
6. Maintenance and repairs 11
7. Maintenance 12
7.1 Technical Specifications 12
8. Installation guide 13
8.1 Take out the Ebike and check the parts list 13
8.2 The front wheel 13
8.3 The handlebar and the stem 14
8.4 The seat post (with saddle) 14
8.5 The pedals 14
8.6 The battery 15
1. Warranty conditions
Electrical bike warrants this product to be in good working order during the warranty period. This warranty is
valid only if proof of purchase is shown in the warranty service request.
The product is intended primarily for use by consumers, which is the basis of business conduct the acquired
products are subsequently granted in these terms limited warranty.
★★Warranty Period★★
In accordance with the terms of the guarantee electrical bike:
•For consumers 12 months warranty.
•For companies and institutions 6 months warranty.
Starting from the date of delivery from the manufacturer.
Electrical bike warranty service on a centralized basis through its own service centers.
News for more information and instructions for easy warranty service connection can be found at us.
★★Exclusions and limitations★★
The warranty covers only in material and quality of the product. Granted to the product limited warranty does
not cover maintenance and cost estimates if:
•The error is caused by unlawful processing of instructions.
•This product has been damaged by any man-made factors, mechanical stress or any other product from
the outside.
•The error is caused by an accident, injury or any other warranty issuer's sphere of influence. Therefore,
outside a reason.
•The error is caused by the normal from wider use of or maybe considered normal wear and tear. The
warranty does not cover the product includes accessories, batteries or software may be delivered.
Electrical bike will not be liable for any use of the product or the product of the error caused by direct or
2
Version 1.0
indirect costs unless otherwise stipulated by mandatory law.
Safe disposal of the product
The appliance and its accessories must not be disposed of with normal household waste at the end of its life
cycle.
2.★★Safety Instructions★★
•Read the instruction manual thoroughly and follow the safety instructions in particular very carefully
before the use of bicycles.
•Always obey traffic regulations.
•Do not give up the wheel to a person who is not familiar with the bike and operating instructions before
riding.
•Wear a bicycle helmet whenever riding a bicycle.
•Check the bicycle brakes before each use, and keep in mind that the braking distance is extended wet/
icy conditions.
•Check your bicycle's tire pressure at regular intervals. Having the correct tire inflation pressure is 3.5bar.
Incorrect tire pressure can lead to tire damage and shorten operating distance significantly.
2.1 Electrical Safety
★★CAUTION! ★★
•Keep electrical appliances out of the reach of children.
•To avoid injury, use only the provided bike included charger to charge the battery.
Using the wrong charger battery may lead to an explosion and cause personal injury and property
damage.
•Use only batteries approved for this product and accessories. Use of supplies from third parties with this
wheel can result in fire, electrical shock, or personal injury.
•Do not expose the wheel electrical equipment to moisture, water or other liquids. However, if electrical
appliances are exposed to water, disconnect the charger from the wall outlet immediately and deliver
damaged parts service center for resellers for review.
•Do not expose the battery to fire and keep it away from it away. Risk of explosion!
•Unplug the charger from the wall outlet when nominees.
•Remove the charger by pulling the plug, not the cord.
•Do not use the charger if the plug or cord is damaged, or if the charger is otherwise defective.
•The charger and the battery do not contain any user-serviceable parts. Do not attempt to disassemble or
repair the charger or battery on your own.
•Do not short-circuit the battery caused by metal objects.
•Clean the electrical product only with a dry cloth or rag.
•Avoid using an extension cord with the charger. Use an extension cord only if you are absolutely sure of
the compatibility of the extension cord with the charger.
•Before you plug in the charger, check that the power supply voltage is consistent with the marked voltage
charger.
•It is recommended that the battery is charged 10C-30'C temperature so that it remains a long age.
•If you charge the battery immediately after use, allow the battery to cool down for 30 minutes before
charging.
•To prevent fire disaster from overcharging the battery, disconnect the charger after the battery is fully
charged.
3
Version 1.0
•In order to ensure the battery life, the battery must be recharged every two months.
•Please keep the battery in a dry, cool and ventilated place. Avoid high temperature, super cold, and high
humidity the environment.
IMPORTANT! Please read this manual carefully and strictly following it during the use of this product.
Otherwise, customers will take the corresponding risks of incorrect use. Before first use, be sure to
carefully that the bicycle is assembled correctly. You can do this by submitting your bike in to the
nearest bicycle circulation, or if you are an experienced bicycle enthusiast, you can compile and
check the wheel itself. Make sure in particular that the pedals, saddle, brakes, handlebars, and any
part of a self-installing is properly installed.
NOTE：Never ride your bicycle while under the influence of alcohol. Drinking alcohol impair the ability
to react significantly limits your ability to use the wheel safely. Even a small amount of alcohol, limit
your ability to operate safely in traffic.
If you want to change the bike battery, take the battery for recycling either the retailer or to a local
recycling disposal company responsible.
3. Features
•Height-adjustable seat tube, suitable for different lengths for riders.
•Ped-eclectic assistance can also be run without electrical assistance, the mere muscular force.
•The rider's weight up to 136kg/300lbs.
•E-bike gross weight approx.32kg.
4
Version 1.0
3.1 Electrical System
•Battery: 48 Vol lithium-ion (Li-ion)13Ah
•Engine:48 V,500W, brushless
•Pedal Sensor: speed sensor
•Top speed: 42km/h(limited)
•Operating Distance: Up to 38-47km
4. Parts of the E-bike
4.1 Parts
1. Frame
2. Changeable battery
3. Seat lock lever
4. Brake lever
5. Tyres
6. Control unit
7. 48V*500W motor
8. Pedal
9. Headlight
4.2 The saddle and handlebar
stem
You may want to adjust the stem and saddle height to the desired height.
Please note that the handlebar stem and saddle, however, must not be raised more than the tubes marked
5
Version 1.0
with a safety limit of subscriptions. Failure to follow these instructions may lead to serious personal injury.
1. Open the stem I saddle lock lever.
2. Adjust the stem /saddle to the desired height. Do not exceed the safety limit indication.
3. Attach the lock lever and make sure that it remains firmly in place.
When you sit on top of the saddle, your heels should just touch the pedal when itis in its lowest position.
When cycling correctly, your knee should be slightly hooked and pedal will in the lowest position. You can also
adjust the angle of the saddle, loosen the screw below the saddle, then placing the position, and tighten the
screw back in place at the end.
5. General Terms of Use
5.1 IMPORTANT! AIways before riding a bicycle:
•Check that the stem and handlebars are tightened securely.
•Check that all bolts, nuts and fasteners are properly tightened. Pay special attention to the engine
mounts, the foot, the front fork and handlebar mounts.
•Check that the brakes and brake levers are working properly.
•You check that all reflectors and lights are in place and operate properly.
•Make sure that the battery is fully charged. Check the battery charge level of the control unit LED display.
5.2 Throttle
If the throttle lever is mounted on the handlebar, avoid dangerous, unplanned acceleration by keeping your
hand away from the throttle you specify whenever you are not using it. To ensure safe use, turn off the bike
battery ignition key and the control unit of the On/Off button after each use.
5.3 During the riding
•When ready to ride, and use the throttle grip, the bike shot up from ahead! Do not switch on the bike
before you are prepared to ride.
•When you release the throttle or brake, power supply to the motor immediately.
•When you start moving, or you ascend the hill, pedaling as much as possible to save the battery.
Pedaling as much as possible yourself, you can also extend the life of the battery and engine life.
•When going downhill do not turn off the power wheel. This can lead to the engine control unit and
damage. If the battery runs out while you are riding, you can pedal it as anormal bike and please go
charge the battery as quickly as possible.
•Tum off the ignition and remove the key whenever you stop moving.
•Please make sure that you turn off the power first for preventing unintended acceleration.
•Taking care of the wheel to extend the working life of wheeling.
5.4 Battery and Charger
•Do not touch the battery terminals when the battery is charging. And do not let the battery terminals come
with metal or other conductive objects.
6
Version 1.0
•When you charge the battery, insert the battery into a safe place away from children.
•Only use the supplied AC charger to charge the battery. Contact your dealer if you need a new charger.
•Never open, repair or modify the charger/battery by yourself.
•Prevent liquids, metal objects, or metal chips from entering the charger.
•Avoid shocks and dropping the charger.
•Do not cover the charger during the charging process. The charger heats up during charging.
•If you notice any strange odor or overheating during the charging, stop charging immediately.
•To avoid the premature destruction of the battery, recharge and drain the battery at least once a month.
Do not use the battery nearly empty, recharge the battery fully before each use.
•Battery capacity or reduced in cold weather. This is completely normal.
•Avoid water or other liquids when charging the battery.
•Do not leave the charger connected to the battery and power source for more than 10 hours.
•Use the battery and AC charger at all times in accordance with the instructions.
5.5 Charging the battery
You can charge the battery disconnected, or when the battery is fixed to the bike. First, pull out the
charging connector cover. Then connect the AC charger to the charging plug (3) to the charging port and
an AC outlet.
5.6 Removing the battery
To remove the battery, open the battery lock key. Insert the key into the lock and turn it counterclockwise,
then remove the battery. When you're done, put the battery back in place and lock.
5.7 Battery level
You can easily check directly from the battery by pressing TOP button.
5.8 Brakes
•Do not brake too sharply or abruptly. Otherwise, you may fall on a bicycle.
•Learn how to remember which brake lever controls the front brake (left) and which one the rear brake
7
Version 1.0
(right).
•Move the body weight of backward braking, to reduce the effect of inertia.
•Keep your brakes in good condition and adjust / Export adjusted brakes if necessary. If the brake
pads are worn out, replace the brake pads in good time or deliver your bikes for repair.
•Before riding, always check the brakes.
•Remember that the braking distance can be extended considerably in slippery conditions.
•More information about the brakes, if necessary, get a bike shop or manufacturer.
5.9 Button and Display
①Headlight Button
②Bell
③Shifter
④LCD Display
⑤Throttle
5.10 Operating Instruction
①Headlight Button
②Bell
③Brake lever
④Display, long press “M” button open.
⑤Throttle, rotating it and the e-bike will forward.
6. Maintenance and repairs
IMPORTANT!
•Do not attempt to open the battery casing, motor or control unit. Failure to do so may result in
personal injury and void the warranty. In case of difficulty, please contact us.
•Make sure that the tire surface is tightened.
•Your bike is equipped with derailleur which tightens the chain automatically. If the chain starts to
slacken continuously and jumping of front chainring, you can easily tighten the chain, loosen first
the rear axle nuts slightly, and then tighten the bolts. Make sure that the chain is rotating freely
and tighten the rear axle nuts back on. Take the bike for service if you do not know what should
do.
8
Version 1.0
7. Maintenance
Problem
Solution
Low top speed
Charging the battery fully
Power switched on but the engine does not work
Install the battery again
Shortened Range
View tire pressures
Charge the battery again or let the charger
examined
Replace the battery with a new battery
Power switched on; the bike does not work
The control unit or the motor must be replaced
Power switched on; the bike works only with throttle
The controller, the motor or pedal sensor
replacement
Throttle unresponsive
View battery charge level and recharge fully if
necessary
The control unit or the motor must be replaced
The cycle goes away by itself
Check that the throttle is not jammed lubricate
or replace the throttle grip
The cycle does not start after stop
Check that the brake lever is released
completely
The charger is connected, the signal light does not
burn
Ensure that the charger is receiving power
The charger connected to the bike and plug sockets
Check that the battery is not fully charged
already
Check that the charger is properly connected
Please contact us if the problem cannot be solved the above-mentioned.
7.1 Technical Specifications
Model
PERFORMANCE-NOVABIKE
Product Code
HPNB2201
9
Version 1.0
Type
Pedelec
Weight
32kg
Permissible Gross Weight
Maximum 120 kg
Dimensions (W D H) mm
× ×
1540x300x880
Maximum Speed
42km/h(Limited)
Maximum Mileage
38-47km
Display
3 step LCD
Battery
48V, Li-ion,13Ah
Chargers
100V~240V/42V*2A
Charging time
3~4 hours
Brakes
Disc Brake
Motor
48V 500W
×
Pedal sensor
Speed sensor
8. Installation guide
8.1 Take out the Ebike and check the parts list
① Complete Ebike packaging is as shown in the figure below, and check whether the parts are damaged.
②Check whether the parts are complete. The seat post saddle and handlebars are tied to the Ebike, and the
front wheel quick release is tied to the front fork legs. (Use scissors to cut the cable tie for assembling use)
In addition, there are pedals, charger, charger cable and tools in the cardboard box.
8.2 The front wheel
①Tear off the front fork packaging and install the front wheel on the front fork.
②Pay attention to the orientation of the front wheel: the front wheel disc is on the same side as the front fork
disc brake seat, and the axles on both sides are installed in place.
③Install the quick release, loosen the screw, the quick release handle is in the same direction as the disc
brake, pass the other side, install the spring and nut.
④Tighten the nut and turn the quick release handle upward Press tightly, pay attention to the handle pressing
force not too loose, to ensure that the front wheel is locked.
⑤After the front wheel is assembled. turn the front wheel to check whether the front wheel rotates smoothly.
10
Version 1.0
8.3 The handlebar and the stem
①Hold the stem upright and pre-lock the upper screws of the stem.
②Loosen the 4 screws of the front cover of the stem, then take the handlebar and put it into the stem to lock
the handlebar, pay attention to the corresponding middle position of the handlebar, and tighten the screws
at a proper angle of the handlebar.
③Adjust the center of the handlebar to be in a straight line with the center of the front wheel. Tighten the
screws of the stem left and right with a 5# Allen key.
8.4 The seat post (with saddle)
①Loosen the quick release and insert the saddle into the seat tube.
②Straighten the angle of the saddle so that it is in line with the main tube of the frame, and adjust the height
to a suitable height (be careful not to exceed the handlebar safety line) and lock the quick release handle.
8.5 The pedals
①Take out the pedals, pay attention to the left and right pedals, and the specifics are displayed according to
the signs on the pedal axis. The left pedal is equipped with the crank side, and the right pedal is equipped
with the chain side.
②Take out the tool and use one end of a 15# open-end wrench to lock the pedal, the left pedal is locked in a
counterclockwise direction, and the right pedal is locked in a clockwise direction. Note that the pedal needs
to be locked.
11
Version 1.0
8.6 The battery
①Take out the battery, align it with the notch on the left, and slide it in to the left. The battery is flush with the
plastic part. When you hear the sound of the key lock, then itis locked.
②Check whether the battery is locked. Do not move the key, push the battery to the right to see if it can be
moved.
8.7 The front light
①Take the screw out and pass the screw through the center hole of the front light corresponding to the front
fork gantry, paying attention to the gasket on the screw head.
②Take 4# hex key, fix the front screw and lock the screw, pay attention to the position of the front light.
12
Table of contents
Other e-nova Bicycle manuals
