E-Slide ES1200D User manual

USER MANUAL
Translation of the original version
BALANCE BIKE ELECTRIC FOLDING 12 inch
ESLIDE ES1200D

Page2
1. Warnings / Residual risks / Precautions for use
a. Warnings / Precautions for use
b. Residual risks
c. Handling / Transport / Storage / Battery
i) Handling / Transport / Storage
ii) Battery
2. Product Description
a. Description / Presentation
b. Mounting accessories
i) Mounting the footpads
ii) Seat assembly
iii) Assembling the fenders
c. Technical characteristics (technical table)
3. Functions
a. Pin System: Folding / Unfolding the Handlebar
i) Pin System : Unfolding the Handlebar
ii) Pin System : Folding the Handlebar
b. Loop system : Folding / Unfolding the Handlebar
i) Loop system : Unfolding the Handlebar
ii) Loop system : Folding the Handlebar
c. Charge the battery of the balance bike
i) Description of the charging of the battery
ii) Loading steps
iii) Warnings on charge
d. Functions
i) Position Parking
ii) Turning on / turning on the balance bike
iii) Front / Rear lighting
iv) Buzzer
Content of the manual

Page3
v) Start / Driving
vi) Mode CRUISE CONTROL
vii) Braking
4. Cleaning / Maintenance / Repairs
a. Cleaning
b. Brakes : maintenance / settings
i) Adjusting brake cable tension
ii) Brake Caliper Adjustments
c. Wheels
i) Inflation
ii) Wheel Alignment
iii) Warnings on shocks
5. Logotype information used
6. Legal indications
Imported by DPA EUROPE
Gildo Pastor Center - 7 Rue Gabian, 98000 MONACO - MONACO
User manuals in Spanish, Dutch and French are available on the
website www.dpa-europe.com.

Page4
1. Warnings/Residualrisks/Precautionsforuse
a) Warnings/Precautionsforuse
- Do not lend your electric balance bike to anyone who is not
familiar with the device.
- When using the Balance Bike please wear suitable clothing
and all necessary protective equipment: helmet, knee pads,
elbow guards and other protections.
- Do not drive after consuming alcohol or drugs.
- This article is not a toy.
- You must take out an insurance policy for this type of device
in the case of damage or injury caused to a third party but also
in the event of injury to the user. Please inquire with your
insurer.
- This device may be used by persons 14 years of age or older
and by persons with reduced physical, sensory or mental
abilities, if properly supervised by an adult, and instructions for
the use of They have been given the device safely and the
cleaning and maintenance of the balance machine can only be
done by a trained adult.
- Do not allow people under 14,the elderly and pregnant women
to use the balance bike.
- Children should not play with the balance bike. Cleaning and
maintenance by the user should not be done by children without
supervision or training.
- In the event of an accident, please stay on the spot and wait
for help.
- This device is designed for personal enjoyment, it is forbidden
to use it to transport people.
- Users should not exceed the weight indicated in the maximum
weight specifications, otherwise the driver could fall and get
hurt, or even damage the balance (stability) function of the
device.
- To ensure the safety of all, the device must be able to stop at
any time.

Page5
- Do not be distracted while driving, answering the phone,
listening to music or doing any other activity.
- This device is allowed to run only on private roads and is
tolerated on pedestrian routes at a maximum speed of 6km / h
according to local regulations, please make sure of these
different regulations.
- Please use this device only in authorized locations, if this
location requires permission, please request it.
- Do not use the product on the roadway. The device is not an
approved device.
- Do not drive in dimly lit places and in the dark.
- Avoid obstacles, smooth surfaces, snow, ice and unstable
surfaces.
- Avoid irregular objects such as rolling on a branch, rubbish,
pebbles, paved streets.
-Used on accidental passages or use too long could cause
many vibrations of the body that can trigger some pain, use this
balance bike in a reasonable way to limit these risks.
- Avoid narrow spaces or spaces with obstacles.
- Does not allow driving on slippery roads in rainy weather
- Avoid steep slopes.
- Do not roll in sand, puddles, mud, or other wet, damp or
rugged surfaces as this may damage the electronic
components of the unit.
- It is forbidden to use the electric balance bike in dangerous
places, with the presence of flammable gases, vapors, liquids,
dusts which could cause a fire or an explosion.
- The device must be used only with the power supplied with
the device, if the power supply is defective please return the
device to the seller. The device must be powered only under the
very low safety voltage corresponding to the marking of the
device.
- In case of damage to the external power cable, it must be
replaced by a cord available from the manufacturer, you must

Page6
under no circumstances disassemble the device or modify the
components of this product.
- Do not open the device, if the device is defective or
malfunctioning, contact the seller immediately, do not try to
repair it yourself.
While driving, you may be exposed to unexpected hazards or
dangerous situations, which may result in serious injury, please
exercise caution and caution.
b) Residual risks
The correct use of the balance bike respecting the good safety
conditions, does not exclude certain risks of injury and
material damage.
Residual risk
Details
Mechanicals
Cut
Training or imprisonment (caused by
hair, clothing, etc. caught by a
moving parts)
Crushing
Risks of friction or abrasion
Loss of stability
Pinching and jamming due to
handling
Collision
Thermal
Explosions
Harmful to health due to hot or cold
surfaces

Page7
Vibrations
Strong vibrations can be harmful to
your health in case of prolonged use,
or if the product is not used and
maintained in accordance with the
instructions
Materials from the
environment
Inhalation of dust and noxious fumes
Formation of dust and explosive
fumes
Hydraulic fluids on the track
Damage to property and persons
resulting from the projection of
objects.
Ergonomic
Repetitive injuries
Bad posture
Non-use of personal protective
devices
Battery failure
Unexpected restoration of power
supply after a failure
c) Handling / Transport / Storage / Battery
i) Handling / Transport / Storage
When handling and / or transporting the balance bike, avoid
any physical or electrical shock.
When handling, the Balance Bike must be in the "parking"
position (kickstand in the open position, on a flat, sloping or

Page8
uneven surface), the charger must be unplugged and the
Balance Bike must be off (off).
During transport, the Balance Bike must be off (off), stand
closed, right on its wheels, properly packaged and protected to
avoid shocks or accidental start-up, this may cause
malfunctions of the device, see a significant deterioration of
the device or the battery.
Store the balance machine in a cool, ventilated, clean and dry
place, in the "parking" position (kickstand in the open position,
on a flat, sloping or uneven surface), when the charger is
disconnected and As the balance machine is off (off), the
storage location must not be subject to large temperature
differences.
Do not store the balance bike outdoors without protection, the
balance bike should not be stored in the harsh weather, and
prolonged exposure to the sun will damage the components
and the battery.
The Balance Bike can be stored / handled at temperatures
between 5 ° C and 45 ° C. Storage / handling temperatures
should not exceed these.
The Balance Bike can be transported at temperatures
between -20 ° C and 60 ° C, transport temperatures must not
exceed them.
The storage without use must not exceed 2 months, it will fully
charge the balance bike every 2 months to prevent the battery
of the balance bike is damaged.

Page9
ii) Battery
Your balance bike contains a high capacity Lithium-Ion battery,
for a safe use please follow the following instructions:
- The battery cover must not be disassembled by someone who
is not authorized.
- Only an authorized person can open the battery cover.
- Do not use the balance bike in the following cases:
o Overheating / smoke / strong smell
o Substance leaking at the battery location
- The battery used in the device contains hazardous
substances.
- Do not insert anything into the battery cover.
- Only an authorized person can change the battery.
- If the battery is defectiveor damaged, contact a Takara electric
cycle specialist who can disassemble the balance bike and
change the battery.
- The balance bike equipped with a battery must not be close to
a fire or a source of heat.
- The balance bike equipped with a battery must not be
immersed in an acid or alkaline liquid.
- Only charge the balance machine at temperatures between 5
° C and 45 ° C and use it only at temperatures between -20 ° C
and 60 ° C.
- To maintain the longevity of the battery of the balance bike,
respect the charging cycle, do not exceed the maximum
charging time, regularly recharge the balance bike.
- When not in use for a long time you must charge the balance
bike completely every 2 months.
- The battery of your balance bike is recyclable and must be
recycled or disposed of according to local regulations.

Page10
- Therefore the battery of your balance bike should not be
disposed of as a household waste and should NEVER be
incinerated as there is a risk of explosion.
- Please contact local authorities for recycling practices in your
jurisdiction.
2) Product Description
a) Description / Presentation
You have just purchased a ESLIDE model ES1200 electric
bike.
This new type of mobility, entirely electric and non-polluting,
will allow you to perform leisure activities smoothly and without
fatigue. Its 12-inch wheels equipped with disc brake allow you
to enjoy your leisure comfortably and safely.
This product must be used on private road. Prohibition of
traffic on roads open to the public.
The power of its engine will allow you to climb gentle slopes
without effort, the capacity of the battery will allow you to enjoy
your balance bike throughout the day.
When using the Balance Bike, please wear appropriate
clothing, shoes, and all necessary protective equipment:
helmet, knee pads, elbow pads and other protections.
Do not use your electric balance machine until you have read
this manual and become familiar with the device.
Before using this electric balance machine, familiarize yourself
with its operation, it will allow you to keep this device in the
best possible conditions.
This manual can help you learn how to safely operate this
electrical appliance.
This manual includes all instructions and notes for use; please
read carefully and follow these instructions.

Page11
List of product elements
19
1
2
3
25
5
6
7
7
8
9
10
11
12
13
13
2
14
15
16
17
18
4
20
22
21
23
24
26
27
28
29
30
32
33

Page12
* Sparepartsavailablefor2yearson www.dpa-europe.fr
N°
Nom
Réf.
Piècesdétachées*
1
Left brake handle
ES1201
x
2
Right brake handle
ES1202
x
3
Start button
ES1203
x
4
Folding buckle
ES1204
5
Front lighting
ES1205
x
6
Tire
ES1206
x
7
Front & rear brake disc
ES1207
x
8
Front mudguard
ES1208
x
9
Frame
ES1209
10
Footrest
ES1210
x
11
Inner tube
ES1211
x
12
Crutch
ES1212
x
13
Brake caliper
ES1213
x
14
Rear mudguard
ES1214
x
15
Rear lighting
ES1215
x
16
Saddle
ES1216
x
17
Seat height adjustment buckle
ES1217
x
18
Battery location
ES1218
19
Fork
ES1219
20
Front and rear light button
ES1220
x
21
Brake cable
ES1221
22
Brake cable
ES1222
23
Battery charge level indicator
ES1223
24
Throttle grip
ES1224
x
25
Handlebar folding ring
ES1225
26
Handle
ES1226
x
27
Buzzer
ES1227
28
Drums
ES1228
x
29
Front rim
ES1229
x
30
Engine with rear rim
ES1230
x
31
Charger
ES1231
x
32
Digital display
ES1232
x
33
Handlebar
ES1233

Page13
Seat
Fenders
Footrests
AC charger
Accessories
Manual
BEFORE
AFTER

Page14
WARNINGFITTING FOOT FEET
Make sure that the Balance Bike is in the "parking" position
(kickstand in the open position, on a flat, sloping or uneven
surface), that the charger is unplugged and that the Balance
Bike is off (off).
b) Mounting accessories
i) Mounting the footrests
Unpackthefootrests.Takethefirstfootrestandscrewitclockwise
ontotheindicatedsupport.Takethesecondfootrestandscrewit
clockwiseontheindicatedsupport:
WARNING ASSEMBLY / DISASSEMBLY
When mounting the elements you must comply with the
following instructions and the precautions to take, if you do
not comply with these instructions it could cause a
malfunction of the device and cause a loss of balance
(stability), a fall or an accident.

Page15
AWARNING
ASSEMBLY / DISASSEMBLY OF THE SEAT
Make sure that the Balance Bike is in the "parking"
position (kickstand in the open position, on a flat, sloping
or uneven surface), that the charger is unplugged and that
the Balance Bike is off (off).
ii) Seat assembly
Remove the tube frame protection, and unlock the buckle, take the
saddleandunpackit,insertthesaddleendintotheframetube,re-lock
thebuckle.
iii)Mounting the fenders
Inserting the
saddle
Tightening the
saddle down
Seat adjustment
upwards

Page16
WARNING
ASSEMBLY / DISASSEMBLY OF MUDGUARDS
Make sure that the Balance Bike is in the "parking"
position (kickstand in the open position, on a flat, sloping
or uneven surface), that the charger is unplugged and
that the Balance Bike is off (off).
WARNING
Be sure to follow the user manual and settings described
in this manual.
It is important to prevent any mounting errors.
Unpack the mudguards, the smaller one is fixed at the front
using the screw and nut provided, the larger one is fixed at the
back using the screw and the nut provided.
Front fender mounting :
Rear fender assembly :

Page17
c) Technical characteristics
Height and
weight
PARAMETERS
STANDARD DATA
Materials
Aluminum alloy / steel
Size (folded)
1080*430*490mm
Size (unfolded)
1080*430*1140mm
Wedge height
200mm
Wheel size
12 inch
Frame color
Black
Shipping weight
18.7kg
Product weight
15.7 kg
Performances
Maximum load
120kg
Maximum speed
24km/h ≈
Distance
15-18km
Slope
7.2°
Sealing
IP54
Technical
Standards
Operating
temperature
Between -10 and 45°C
Drums
6.0Ah
Max motor power
0.35kW
Basic engine power
0.25kW
Voltage of the
charger
42V
Loading time
4-5 hours
Braking system
Front and rear disc brakes
The total value of vibrations, which are exposed
the hand-arms, does not exceed 2,5 m / s² (estimate).

Page18
Thefolding/unfoldingsystemmaybedifferentdependingonthe
product. There are 2 folding/ unfolding systems:
- Pinsystem - Loop system
You will find below the details of the stepsfor each system.
3) Functions
a) Pinsystem : Folding / unfolding the handlebar
i) Pinsystem : unfoldingthe handlebar
- After unpacking the product, raise the steering column
(photos n ° 1 & 2 / p20)
- Lock the folding loop (photo n ° 3 / p20), the safety pin will
automatically position itself in the closed position.
- Unlock the handlebar locking buckle (photo n ° 4 / p20)
- Position the handlebars so that the brake handles are
horizontal (photo n ° 5 / p20)
- Re-lock the handlebar locking buckle (photo n ° 6 / p20)

Page19
PinSystem: Unfolding Detail
Photo n°1
Photo n°2
Photo n°3
Photo n°4
Photo n°5
Photo n°6

Page20
ii) PinSystem: Unfolding Detail
- Unlockthehandlebarlockingbuckle(photon°4/p20).
- Positionthehandlebarssothatthebrakehandlesare
vertical.
- Re-lockthehandlebarlockingbuckle(photon°6/p20).
- Unlockthesafetypinupintheopenpositionandunblockthe
foldingloopATTHESAMETIME:
- Then bend the steering column.
