E-TOP BR280n User manual

1
E-TOP BR280n
N+ High Power Broadband Router - All Broadbands
User Manual

2
Table of Contents
FCC Caution ........................................................................................................ 錯誤! 尚未定義書籤。
Notice .....................................................................................................................................................7
Chapter 1 Introduction.................................................................................................................8
1.1 Overview ......................................................................................................................8
1.2 Features.......................................................................................................................9
1.3 Specifications............................................................................................................10
1.3.1 Product Appearance ........................................................................................12
1.3.2 LED Indicator Status Description...................................................................12
1.4 System Requirements ..............................................................................................13
1.5 Get Your IP Automatically & Manually ....................................................................14
1.5.1 Network Testing................................................................................................17
1.5.2 Testing with Internet Browser.........................................................................17
1.5.2.1 Testing with DOS (Windows XP Platform).........................................................17
Chapter 2 Hardware Installation................................................................................................20
2.1 Diagram of Connecting Hardware to 11N Broadband Router ..............................20
2.1.1 Hardware Connection and Application for Router Mode.............................20
Chapter 3 One Button Setup......................................................................................................21
3.1 One Button Setup configuration for Router Mode ................................................21
Chapter 4 Basic Setup................................................................................................................25
4.1 Router Mode..............................................................................................................25
4.1.1 Administrator Setup Instruction.....................................................................25
4.2 Basic Setup................................................................................................................26
4.2.1 Time Zone Setup...............................................................................................26
4.2.2 LAN Interface Setup.........................................................................................27
4.2.3 WAN Setup........................................................................................................28
4.2.3.1 WAN Interface– Ethernet Port.............................................................................28
4.2.3.2 WAN Interface– Wireless ....................................................................................28
4.2.3.3 WAN Access Type – Static IP..............................................................................28
4.2.3.4 WAN Access Type – Dynamic IP ........................................................................28
4.2.3.5 WAN Access Type – PPPoE................................................................................29
4.2.3.6 WAN Access Type – PPTP ..................................................................................29
4.2.3.7 Wireless Setup.....................................................................................................29
4.2.3.8 Wireless Security Setup......................................................................................30
4.2.4 Basic Setup Complete .....................................................................................31
Chapter 5 Advanced Configuration ..........................................................................................33
5.1 IP Configuration........................................................................................................33

3
5.1.1 WAN ...................................................................................................................33
5.1.1.1 WAN Interface– Ethernet Port.............................................................................33
5.1.1.2 WAN Interface– Wireless ....................................................................................34
5.1.1.3 WAN Access Type – Static IP..............................................................................34
5.1.1.4 WAN Access Type –Dynamic IP .........................................................................35
5.1.1.5 WAN Access Type –PPPoE.................................................................................36
5.1.1.6 WAN Access Type – PPTP ..................................................................................38
5.1.2 LAN Interface Setup.........................................................................................39
5.1.3 Dynamic DNS Setting.......................................................................................41
5.2 Wireless Setup ..........................................................................................................42
5.2.1 Wireless Basic Settings...................................................................................43
5.2.2 Wireless Advanced Settings ...........................................................................47
5.2.3 Wireless Security Setup ..................................................................................48
5.2.4 Wireless Access Control .................................................................................50
5.2.5 WDS Settings....................................................................................................52
5.2.6 WPS ...................................................................................................................57
5.3 NAT.............................................................................................................................61
5.3.1 Visual Server.....................................................................................................61
5.3.2 Visual DMZ........................................................................................................63
5.4 Firewall.......................................................................................................................64
5.4.1 QoS....................................................................................................................64
5.4.2 Port Filtering.....................................................................................................66
5.4.3 IP Filtering.........................................................................................................68
5.4.4 MAC Filtering....................................................................................................69
5.4.5 URL Filtering.....................................................................................................71
5.5 System Management ................................................................................................72
5.5.1 Change Password ............................................................................................72
5.5.2 Upgrade Firmware............................................................................................73
5.5.3 Profiles Save.....................................................................................................74
5.5.4 Time Zone Setting ............................................................................................79
5.5.5 UPnP Setting.....................................................................................................81
5.5.6 Language Setting.............................................................................................82
5.6 Log & Status..............................................................................................................83
5.6.1 Network Config.................................................................................................83
5.6.2 Event Log..........................................................................................................84
5.7 Logout........................................................................................................................86
Chapter 6 DDNS Service Application........................................................................................88
Chapter 7 Q & A ..........................................................................................................................93

4
7.1 Installation .................................................................................................................93
7.2 LED.............................................................................................................................93
7.3 IP Address..................................................................................................................94
7.4 OS Setting..................................................................................................................94
7.5 11n Broadband Router Setup ..................................................................................95
7.6 Wireless LAN.............................................................................................................97
7.7 Support ......................................................................................................................99
7.8 Others.......................................................................................................................100
7.9 USB Device..............................................................................................................100
Chapter 8 Appendices..............................................................................................................101
8.1 Operating Systems .................................................................................................101
8.2 Browsers..................................................................................................................101
8.3 Communications Regulation Information ............................................................101

5

6
CE Statement of Conformity
Our product has been tested in typical configuration by Ecom Sertech Corp and was found to
comply with the essential requirement of “Council Directive on the Approximation of the Laws
of the Member States relating to Electromagnetic Compatibility” (89/336/EEC; 92/31/EEC;
93/68/EEC)
Adapter core：
How to use adapter core：Open the core and make perimeter of the power cord on
core，lock the core near by DC inject side

7
Notice
Changing RF parameter is not allowed.

8
Introduction
1.1 Overview
11n Broadband Router is a convenient wireless solution for delivering 802.11n wireless
connectivity with a maximum wireless signal rate of up to 300Mbps. Use it in home or
company.
Moreover, with connect to a 3.5G (EVDO/HSPA) or WiMAX USB modem, this 11n Broadband
Router allows user to share the wireless network outdoor or be an alternative or backup to
fixed broadband.

9
1.2 Features
yUPnP Supported : insert your 3.5G or WiMAX modem card and enjoy the Internet
without extra setting
y3.5G and Wireless 11n Combo : Ideal for mobility or backup for fixed lined connection
yWPS button provides not only an easy and secured wireless network but also a WDS
repeater in one push
yMultiple APs Supported : adds or limits the properties for classed SSID, increasing the
flexibility and efficiency of the network.
ySuperior, reliable performance : 20000 fast recycling sessions provide a stable
network connection for P2P downloading.

10
1.3 Specifications
Item Specification
Key Components
Main Processor Realtek RTL8196C (400MHz )
Flash 8Mbytes Serial Flash
RAM 32Mbytes SDRAM
Wireless Chip Realtek RTL8192CE (MAC+BB+RF) 2T2R with external high
power PA
Communication Interfaces
WAN Port 1 x 10/100 Mbps RJ45, with auto MDI/MDIX
LAN Port 4 x 10/100 Mbps RJ45, with auto MDI/MDIX
USB Port USB 2.0 host x1 (supports 3.5G or WiMAX USB
dongle)
Wireless IEEE 802.11 b/g/n
Others
Wireless Antenna External 5dBi x2
Transmission Power
802.11n : 19±3dBm
802.11g : 20±3dBm
802.11b : 22±3dBm
Receive Sensitivity
11Mbps : TYP. -83dBm @ 8% PER
54Mbps: TYP. -70dBm @ 10% PER
11n (20MHz): TYP. -64dBm @ 10% PER
11n (40MHz): TYP. -61dBm @ 10% PER
Button
Reboot button / Reset button – one second for
reboot/ten seconds for restore to factory default
setting。
WPS button – When WPS button pushed，system will
enter WPS connecting mode。

11
Operation Requirement
Operating Temp. 0°C~40°C (32°F~104°F)
Storage Temp. -20°C~70°C (-4°F~158°F)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
Power Supply Power Adapter DC12V/1A
32mm*19mm*17mm CORE
Dimensions 198.2mm(L) x 107mm(W) x 39.1mm(H)
Notice:
1. USB device with power more than 500mA is not supported

12
1.3.1 Product Appearance
Power Receptor Adapter, Input:90-240Vac, Output: 12V/ 1A
WPS Push “WPS” button to looking for other WPS devices. The security will be
set up between these 2 Wi-Fi devices after pairing.
Reset Button Press “Reset” button over 10 seconds. When status indicator turns from
flashing to solid, the process is completed.All settings are back to default.
Ethernet Port 1x WAN port, 4x LAN ports
USB2.0 Ports 1 USB Port
1.3.2 LED Indicator Status Description
LED Function Color Status Description
Power x 1 Power indication Green On Power is being applied to this product
On System is ready to work
Status x 1 System status Green Blinking
120ms Reset / Firmware update in progress
On Wireless is connected
WLAN/ WPS x
1
Wireless activity
& Green
Blinking Wireless Tx/Rx activity

13
30msWPS status
Reddish
Orange
Blinking
120ms WPS function in progress
On 100Mbps Ethernet is connected
Green Blinking
30ms 100Mbps Ethernet Tx/Rx activity
On 10Mbps Ethernet is connected
WAN x 1 WAN port activity
Green Blinking
120ms 10Mbps Ethernet Tx/Rx activity
On 100Mbps Ethernet is connected
Green Blinking
30ms 100Mbps Ethernet Tx/Rx activity
On 10Mbps Ethernet is connected
LAN x 4 LAN port activity
Green Blinking
120ms 10Mbps Ethernet Tx/Rx activity
1.4 System Requirements
To begin with 11n Broadband Router, you must have the following minimum system
requirements. If your system can’t correspond to the following requirements, you might get
some unknown troubles on your system.
XDSL/Cable Modem and broadband Internet Account.
One Ethernet (10 BASE-T or 10/100 BASE-TX) network interface card.
One PC or Notebook with web browser software installed (E.g.: Internet Explorer 5.0,
Netscape Navigator 7.x, Apple Safari 2.03 or higher version).
At lease one 802.11b/g/n wireless adapter for wireless mobile clients.
Recommended OS: Win2000 or WinXP / Linux.

14
1.5 Get Your IP Automatically & Manually
After 11n Broadband Router connected with your computer, please make sure your IP is in
the automatic IP position or you adjust it manually in order to activate the Internet network
from home to Internet. If you don’t know how to enter the settings, please follow the steps as
below.
Step 1. Go to Start>Settings>Network Connections and then select Local Area
Connection.
Step 2. Click on Properties

15
Step 3. Double click on Internet Protocol (TCP/IP).
Step 4-1. For getting IP automatically if you are one of the users under 11n Broadband Router,
please skip Use the following IP address and then select Obtain an IP address
automatically and Obtain DNS server address automatically and then click on OK button.

16
Step 4-2. For getting IP manually in order to specify a Virtual Server, such as Print Server,
FTP Server and so on, please skip Obtain an IP address automatically and then select Use
the following IP address. And the following default setting of 11n Broadband Router should
be noted:
yIPAddress: 192.168.1.10 (as your Print Server for example)
ySubnet Mask: 255.255.255.0
yDefault Gateway: 192.168.1.1
Note:If you configure your computer’s IP Address manually, it needs to be on the same
network segment.
For example:
zIPAddress: 192.168.1.xxx (xxx can be any number between 2 and 253, but it can’t be
repeated, we use 100 to be the example.)
zSubnet Mask: 255.255.255.0
zGateway: 192.168.1.1 (this is the IP address of 11n Broadband Router in Router Mode)
zDNS: 192.168.1.1 (use 11n Broadband Router’s IP address or on your own choice)
Note:IP address and Default gateway cannot be the same.

17
1.5.1 Network Testing
There are two ways to test your Network whether it can work on Internet or not. They are
“Testing with Internet Browser” and “Testing with Dos”.
1.5.2 Testing with Internet Browser
Open an Internet Browser, such as Internet Explore or Netscape. Input a valid web address
you like, for example, http://www.yahoo.com in the web address blank and then press
enter. If the website appears, that means your Internet is working under normal situation.
1.5.2.1 Testing with DOS (Windows XP Platform)
Step 1. Go to start > Run.

18
Step 2. Input cmd in the blank, and then click OK button. The Command Prompt window
appears.
Step 3. Input ipconfig in the flashing area then press enter. You will get an IP Address
192.168.1.100, for example, and Default Gateway as 192.168.1.1.
Step 4. Ping a legal WAN Address such as 192.168.1.1. If Internet works, it will show Reply
from 192.168.1.1: bytes = 32 time = 3ms TTL =64, for example.

19
If it can’t work, it will show Request timed out.

20
Chapter 2 Hardware Installation
2.1 Diagram of Connecting Hardware to 11N Broadband Router
11n Broadband Router is a portable and convenient wireless solution for delivering 802.11n
wireless connectivity with a maximum wireless signal rate of up to 300Mbps. Use it in
conference rooms, hotel rooms, or even at hotspots.
2.1.1 Hardware Connection and Application for Router Mode
When 11n Broadband Router switches to Router Mode, there will be each WAN and LAN port
existing, the administrator can do the Quick Setup including WAN Setup, LAN Setup,
Wireless Setup, Time Server Setup, Password Setup, Firewall Setup, QoS Setup.
