E-Z UP Deco User manual

''

2
TABLE OF CONTENTS
Intro.......................................................................................2
Set-up Instructions.....................................................................3
Care and Maintenance.............................................................7
Important Information................................................................7
Take Down Instructions..............................................................8
Accessories.........................................................................10
Warranty and Registration.....................................................11
THANK YOU...
for your purchase of
the Deco™ Instant
Outdoor Pavilion by
E-Z UP. For over
30 years, E-Z UP®
customers have been
thrilled with their
E-Z UP®experience.
To ensure your complete
satisfaction, take the
time to learn how
to operate your Deco™ Instant Outdoor Pavilion by E-Z UP by carefully
reviewing these set-up and care instructions.
INSTANT OUTDOOR PAVILION
by E-Z UP

3
HOW TO SET UP
INSTRUCTIONS
STEP 1
Please read each step before you attempt to set up.Save these instructions
for future reference.
NOTE - First time top and frame attachment is required
Top and frames are shipped separately to avoid damage. Once top is
permanently attached to frame, set up and take down can be easily
accomplished within minutes.
Place your Deco™ Instant Outdoor
Pavilion by E-Z UP frame in the center
of area to be shaded. With partner
on opposite side, grasp outer legs,
slightly lift off the ground and step
backwards, stopping at full arms’ length
- approximately 3/4 its total size.
STEP 2
Gently unfold the fabric top and place
it over the open frame. Align the four
corners of the top over the four corners
of the frame.
STEP 3
To secure the top to frame, align grommet
holes on valance with the bolts in frame.
Fabric Top
Top
Attachment
Nut

4
STEP 4
STEP 5
STEP 6
Unscrew top attachment nut from bolt.
Place grommeted fabric top over the
bolt, install top attachment nut and
tighten until snug. Top should rotate
easily - Do not over tighten. Repeat
on remaining grommets.
With partner, grasp the bottom of the
diamond shaped area of trusses, on
opposite sides of the shelter. Lift up
and step backwards until shelter is
fully opened. Be careful not to
pinch fingers.
Engage the Auto Slider®at each corner
by pushing up on trusses while holding
down the top of the leg with other hand.
The quick pin will engage the hole.

5
HOW TO SET UP
STEP 7
Use peak extension pole to push up
center hub, extending top frame structure.
Continue push up motion until all four
sides snap in place.
WARNING: Do not let go of center
hub until at least two sides are locked.
Complete top structure must be locked
before using shelter.
STEP 8
Secure the top to the frame by pulling
the hem down and matching Quick
Attachment Straps on the top with the
Quick Attachment Strips on the frame.
Push the straps firmly together at each
corner. Repeat at all four corners.
STEP 9
Secure all inner peak tubes with quick
release pins.

STEP 10
Lift up two adjacent outer legs and
slide out the inner legs until snap button
locks. Repeat on opposite legs. Be sure
to adjust two legs at one time to avoid
frame damage.
STEP 11
Once the shelter is fully raised to the
desired height setting, secure all legs
with quick release pins.
NOTE: Once top is permanently
attached, only perform STEPS 1
and 5 - 11 to set up.
6
Outer Leg

7
CARE & MAINTENANCE
CARE & MAINTENANCECARE & MAINTENANCE
IMPORTANT INFORMATION
For long lasting durability and the best possible protection
for your Deco™ Instant Outdoor Pavilion shelter, follow these
care and maintenance instructions:
The Deco™ Instant Outdoor Pavilion top clean-up is a breeze. Spot
wash by sponging briskly with a soapy solution of natural soap
in lukewarm water. Rinse thoroughly with clean water to remove
soap and air dry. For stubborn stains, use a fabric spot remover.
Follow directions on container. Rinse thoroughly with clean water
and air dry.
Let the top and frame dry completely before closing or storing to
avoid mildew.
Frame will operate and look better if occasionally wiped with
silicone spray, especially before and after use in damp conditions.
Remove excess silicone residue before applying top.
Use a seam sealer if top leaks or drips water. Available at most
hardware or sporting goods stores.
Slightly tighten bolts if frame becomes loose.
IMPORTANT: Read this information before proceeding. It is
the user’s responsibility to take the following precautions at
all times.
Use caution when handling the Deco™ Instant Outdoor Pavilion
folding frame.
Avoid pinching hands or fingers as frame opens or closes.
Always stake or weight down your shelter. Do not use
in any potentially windy or rainy weather. Wind, rain and snow
can damage the shelter and may also result in injury to you or
others. Therefore, do not rely on shelter for protection in heavy
or prolonged weather storms.
Do not use shelter in a lightning storm.
The Deco™ Instant Outdoor Pavilion is designed as a
seasonal shelter.
Keep all flame and heat sources away from fabric top.
Do not build fires within shelter enclosure

8
TAKE DOWN INSTRUCTION
STEP 1
With partner, disengage quick release
pins. Depress snap button on legs and
telescope inner legs into outer legs.
Repeat on other legs, making sure to do
two legs at a time.
STEP 2
Stand under shelter and locate center
hub. Disengage quick release pins.
While holding center peak pole, release
top frame inner peak beams by pushing
snap buttons one at a time on all top
frame inner peak beams to disengage.
WARNING: After all peak beam
assembly snap buttons are released
GENTLY lower center hub. Center
hub should drop down in an inverted
position and rest near the ground.
Snap Button
Quick
Release
Pin

9
HOW TO TAKE DOWN
STEP 3
Release Auto Slider®at each corner by
first lifting hem of top. With one hand,
push up on truss near slider, release
quick pin by pulling ring.
STEP 4
With one or two partners at opposite
sides of shelter make sure peak beam
assembly snap buttons are disengaged.
Lift shelter up slightly and shake while
stepping toward one another until shelter
is fully closed. Be careful not to pinch
fingers. Store shelter in cover bag.
NOTES
Pull

10
ACCESSORIES
ACCESSORIES
DELUXE STAKE KITS DELUXE WEIGHT BAGS

11
WARRANTY & REGISTRATION
1-888-474-3583
www.bungalowbyezup.com
5 YEAR WARRANTY
For long lasting durability and the best possible protection.
INTERNATIONAL E-Z UP, INC., manufacturer of the Deco™ Instant Outdoor
Pavilion, warrants to the original purchaser who provides a dated sales receipt
from an Authorized Dealer, each part of the Deco™ Instant Outdoor Pavilion
frame and top to be free from defects in material or workmanship for a period
of five years after the date of original purchase. This warranty applies only for
normal and expected uses, as determined by the manufacturer.
INTERNATIONAL E-Z UP, INC.’s obligation and liability under this warranty
is limited to the repair or replacement (at its option) of the product or its parts,
after its own review and examination.
RETURN ADVISORY - Before returning any part or product to INTERNATIONAL
E-Z UP, INC. or its designated representative, please phone or write to obtain
specific return shipping instructions. All shipping costs must be prepaid, and
INTERNATIONAL E-Z UP, INC. is not responsible for products damaged
in transit.
CONDITIONS - This warranty shall be void as to any product which has been
altered or modified in any manner. This warranty does not apply to damages
caused by wind, rain, or other forces of nature, not to accidental or deliberated
damage of the product, nor to use of the product that does not conform with the
product instructions. This warranty is provided in lieu of all other warranties,
expressed or implied.
© Copyright 2014 International E-Z UP, Inc. USA. All rights reserved.
OM_DECO_1010_0824 13393B
