E2S BExCP3A-PB User manual

European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH sa[email protected] Tel: [phone]
Document D150-00-101-IS Issue 6 11-08-22 Sheet 1 of 2 www.e2s.com Fax [phone]
INSTRUCTION MANUAL
BExCP3A-PB Push Button Manual Call Point
F
or
use
in
Flammable
Gas
and
Dust
Atmospheres
BExCP3A-PB
Manual Call Point – Push Button
For use in Flammable Gas and
Combustible Dust Atmospheres.
1) Introduction
The BExCP3A-PB is a push button manual call
point which is certified to the European and
International Gas and Dust standards. The unit
meets the requirements of the ATEX directive
2014/34/EU and IECEx scheme.
The call point can be used in hazardous areas
where potentially flammable gas and dust
atmospheres may be present.
All units have no monitoring resistors, diodes or
zener diodes.
The units are Group II, EPL (equipment protection
level) Gb. The equipment is certified ‘Ex db eb IIC
T6 Gb’ and as such may be used in Zones 1 and 2
with flammable gases and vapours with apparatus
groups IIA, IIB & IIC and temperature classes T1,
T2, T3, T4, T5 and T6.
These units are also Group III, EPL Db. The
equipment is certified ‘Ex tb IIIC T75ºC Db’ and as
such may be used in Zones 21 and 22 for
combustible dusts groups IIIA, IIIB & IIIC.
2) Ratings and Markings
All units have a rating label, which carries the
following important information: -
Unit Type No.:
BExCP3A-PB Manual Call Point
Input Voltage:
AC voltage 250V Max Current 5.0A Max
DC voltage 250V Max Current 0.25A Max Resistive
Load; Inductive Load 0.03A Max
DC voltage 125V Max Current 0.5A Max Resistive
Load; Inductive Load 0.03A Max
DC voltage 75V Max Current 0.75A Max
DC voltage 50V Max Current 1.0A Max
DC voltage 30V Max Current 5.0A Max Resistive
Load; Inductive Load 3.0A Max
DC voltage 12V Max Current 5.0A Max
Code:
Ex db eb IIC T6 Gb
Ex tb IIIC T75 ºC Db
IP66
–40ºC <= Ta <= +70ºC
Certificate No.:
SIRA 09ATEX3286X
IECEx SIR 09.0121X
CSAE 21UKEX3556X
Epsilon x: II 2GD
CE Marking
Notified 2813
Body No.
UKCA Marking
Notified Body No. 0518
Year/Serial No. i.e. 20/1CP3APB000001
WARNING - DO NOT OPEN WHEN AN
EXPLOSIVE ATMOSPHERE MAY BE PRESENT
3) Type Approval Standards
The call point has an EC Type examination
certificate issued by SIRA and have been approved
to the following standards: -
EN60079-0:2018 / IEC60079-0:2017
EN60079-1:2014 / IEC60079-1:2014
EN60079-7:2015 / C60079-7:2017
EN60079-18:2015 / IEC60079-18:2014
EN60079-31:2014 / IEC60079-31:2013
The equipment is certified for use in ambient
temperatures in the range -40oC to +70oC and shall
not be used outside this range.
4) Installation Requirements
Installation of this equipment shall only be carried
out by suitably trained personnel in accordance
with the applicable code of practice e.g.
IEC 60079-14/EN 60079-14
Repair of this equipment shall only be carried out
by the manufacturer or in accordance with the
applicable code of practice e.g. IEC 60079-19/EN
60079-19.
Refer to certificates SIRA 09ATEX3286X, IECEx
SIR 09.0121X and CSAE 21UKEX3556X for
special conditions of safe use.
The certification of this equipment relies on the
following materials used in its construction:
Enclosure: Aluminium Pressure Die Cast Body
LM6
Through enclosure mechanism: Plastic Nylon Zytel
Injection Moulded
Sealing of enclosure and mechanism: O-ring
Acrylonitrile-Butadiene Rubber
If the equipment is likely to come into contact with
aggressive substances, then it is the responsibility
of the user to take suitable precautions that prevent
it from being adversely affected, thus ensuring that
the type of protection is not compromised.
“Aggressive substances” - e.g. acidic liquids or
gases that may attack metals, or solvents that may
affect polymeric materials.
“Suitable precautions” - e.g. regular checks as part
of routine inspections or establishing from the
material’s data sheet that it is resistant to specific
chemicals.
5) Call Point Location and Mounting
The location of the call point should enable ease of
access for operation and testing. The unit should
be mounted using the 4 off fixing holes which will
accept up to M4 sized fixings.
View of base unit showing fixing centres (in mm).
To gain access to the mounting holes in the base
the front cover must be removed. This is achieved
by removing the 4 off M4 cap head bolts holding on
the cover.
Once the screws are removed the cover will hang
down out of the way to gain access to the Ex e
terminal block, the internal earth terminal and
mounting hole recesses.
6) Earthing
The unit has both internal and external earth
terminals. It is recommended that a cable crimp
lug is used on the earth wires. The internal earth
wire is placed under a earth clamp which will stop
the cable twisting. This is secured by an M4
screw and spring washer. The external earth lug
should be located between the two M5 washers
provided and securely locked down with the M5
spring washer and two locknuts.

European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH sa[email protected] Tel: [phone]
Document D150-00-101-IS Issue 6 11-08-22 Sheet 2 of 2 www.e2s.com Fax [phone]
7) Cable connections
There are 3 off cable entry holes suitable for
M20x1.5 Ex e approved cable glands or stopping
plugs
The unit can be wired in a number of different ways
depending whether normally open or normally
closed contacts are required. See wiring schematic
D150-06-001 for wiring options
When wiring to Increased Safety terminal
enclosures, you are only permitted to connect one
wire into each way on the terminal block, unless a
pair of wires are crimped into a suitable ferrule.
For the six-way terminal block wire sizes allowable
are 0.5mm² to 4.0mm²
Leads connected to the terminals shall be insulated
for the appropriate voltage and this insulation shall
extend to within 1mm of the metal of the terminal
throat. They shall only be installed and wired with
cable in an ambient temperature of -10°C to +80°C
All terminal screws, used or unused, shall be
tightened down to between 0.5 Nm and 0.7 Nm
8) Testing unit operation
The push button unit can be tested without the
need to replace any element.
To test, lift the cover lift flap to reveal the push
button. The button should be pressed into the body
to activate the unit and place it into the operated
condition.
The call point switch will now change over its
contacts to operate the alarm.
Once testing is complete the unit needs to be reset
from the operated condition.
Rotate the push button anticlockwise by an angle
of 55º, see guide alignment marks on button and
cover, shown below (1). The push button should
pop back up to its original position.
Ensure that the push button has also twisted back
clockwise by 55º to its original position see guide
marks on button and cover, shown below (2).
The unit is now reset.
1. On operated unit 2. Button should pop
Twist push button up and twist back to
Anticlockwise 55º original position to
reset
Note: use
alignment marks
circled to indicate
the push button’s
status
/position.
Unit currently
shown as ‘standby
condition’
Resetting an operated unit is the same as
resetting a tested unit.
9) SIL 2 Reliability Data
Reliability and Functional safety IEC/EN61508
which has been assessed and is considered
suitable for use in low demand safety function:
• Random Hardware Failures and Systematic
Failures (route 2H)
• As an unvoted item (i.e. hardware fault tolerance
of 0) at SIL 2
The product was assessed against failure modes:
• Failure to close a contact when the call point is
struck with specified force
• Failure to open a contact when the call point is
struck with specified force
• Spurious output despite no input
Integrity in respect of failure to
close
SIL 2
Total Failure rate 0.133 pmh
“hazardous” failure rate (revealed) 0 pmh
“hazardous” failure rate
(unrevealed)
0.1 pmh
“safe” failure rate (revealed) 0.033 pmh
“safe” failure rate (unrevealed) 0
Diagnostic Coverage 99%
System type A
Hardware Fault Tolerance 0
Safe Failure Fraction >99%
PFD (hazardous failure) 1.25 x 10-3
Proof Test Interval Up to 1 year
Internal Earth
terminal
Ex e terminal
block
External
Earth Stud

--
++
M/S 1
M/S 1
654321
R Y B
5
-
4
-
3
+
2
+
R.N.POTTS
warning signals
2S
BExCP3A CALL POINTS
INTRODUCTION
1
07-02-20
07-02-20
1
WWW.E2S.COM
C
LONDON W3 7QH
ACTON
MANSELL ROAD
IMPRESS HOUSE
EUROPEAN SAFETY SYSTEMS LTD
1NTS
D.A.H - 07-02-2020
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
EUROPEAN SAFETY SYSTEMS LTD.
WRITTEN CONSENT.
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
LINEAR DIMENSIONAL TOLS
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78 6
5
D
C
134
2
A
B
D150-06-001
D.A.H - 22-02-2022
D.HOWGILL
R.N.POTTS
07-02-20
OF
IF IN DOUBT, ASK -
POINT WIRING SCHEMATIC
BExCP3A-BG/PB/PT MANUAL CALL
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
FORMAT UPDATED
2
BExCP3A-BGWIRING SCHEMATIC FOR PRODUCTS:
BExCP3A-PB
IS-CP4A-PT
CONFIG. 1SINGLE SWITCH
BEXCP3A-BG[s][t][l][e][m][d][v][o][x][u]
BExCP3A-PT
IS-CP4A-BG
IS-CP4A-PB
AND
Circuit shown in Unoperated condition
Unoperated condition
(Glass Intact / Standby Condition)
Terminal +(2,3) & (6)
switch contacts closed
Terminals +(2,3) & -(4,5) switch contacts open
Operated Condition
(Glass Broken / Button pushed in)
Terminal +(2,3) & (6)
switch contacts open
Terminals +(2,3) & -(4,5)
switch contacts closed

E2S Telephone: [phone] Fax: [phone] Email: [email protected]m www.e2s.com DC-007_Issue_N (BExCP3) - Page 1 of 2 - QAF_252_Issue_5
EU Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Authorised Representative: E2S Warnsignaltechnik UG
Charlottenstrasse 45-51
72764 Reutlingen
Germany
Equipment Type: BExCP3A-BG, BExCP3A-PB, BExCP3A-PT, BExCP3B-BG, BExCP3B-PB, BExCP3B-PT,
BExCP3C-BG, BExCP3C-PB, BExCP3C-PT, BExCP3D-BG, BExCP3D-PB, BExCP3D-PT,
BExCP3E-BG, BExCP3E-PB, BExCP3E-PT
Directive 2014/34/EU: Equipment and Protective Systems for use in Potentially Explosive Atmospheres (ATEX)
Notified Body for EU type Examination (Module B):
Sira Certification Service
Notified Body No.: 2813
CSA Group Netherlands B.V, Utrechtseweg 310, 6812 AR, Arnhem, Netherlands
EU-type Examination Certificate (Module B):
SIRA 09ATEX3286X
Notified Body for Quality Assurance Notification / Conformity to EU-type
based on
quality assurance of the production process (Module D):
Sira Certification Service
Notified Body No.: 2813
CSA Group Netherlands B.V, Utrechtseweg 310, 6812 AR, Arnhem, Netherlands
Quality Assurance Notification (Module D):
SIRA 05 ATEX M342
Provisions fulfilled by the equipment: BExCP3A:
BExCP3B:
BExCP3C:
BExCP3D:
BExCP3E:
II 2G Ex db eb IIC T6 Gb (-40°C ≤ Ta ≤ +70°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +70°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +50°C)
II 2D Ex tb IIIC T60°C Db (-40°C ≤ Ta ≤ +50°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +65°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +65°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +70°C)
II 2D Ex tb IIIC T80°C Db (-40°C ≤ Ta ≤ +70°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +65°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +65°C)
Standards applied:
EN IEC 60079-0:2018
EN 60079-1:2014
EN 60079-7:2015/A1:2108
IEC 60079-18:2015/AC:2018
EN 60079-31: 2014
IP6X Dust Protection to EN60079-0 / EN 60079-31
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN 61000-6-1:2007
EN 61000-6-2:2005
EN 61000-6-3:2007 / A1:2011 / AC: 2012
EN 61000-6-4:2007 / A1:2011
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.

E2S Telephone: [phone] Fax: [phone] Email: [email protected]m www.e2s.com DC-007_Issue_N (BExCP3) - Page 2 of 2 - QAF_252_Issue_5
Martin Streetz
Document No.:
DC-007_Issue_N
Quality Assurance Manager
Date and Place of Issue:
London, 23/12/2020
EU Declaration of Conformity
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.
Other Standards and Regulations
EN 60529:1992+A2:2013 - Degrees of protection provided by enclosures (IP code) –enclosure rated IP66
Construction and design requirements according to EN54-11:2001 clause 4.7 –BExCP3A-BG / B-BG / C-BG / D-BG only (fitted with burning house symbol shown in
figure 3a and no lift flap)
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.

E2S Telephone: [phone] Fax: [phone] Email: [email protected] www.e2s.com DC-093_Issue_A (BExCP3) - Page 1 of 2 - QAF_252_Issue_5
UKCA Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Equipment Type: BExCP3A-BG, BExCP3A-PB, BExCP3A-PT, BExCP3B-BG, BExCP3B-PB, BExCP3B-PT,
BExCP3C-BG, BExCP3C-PB, BExCP3C-PT, BExCP3D-BG, BExCP3D-PB, BExCP3D-PT,
BExCP3E-BG, BExCP3E-PB, BExCP3E-PT
Directive UKSI 2016:1107 (as amended by UKSI 2019:696) – Schedule 3A, Part 1 : Product or Protective System Intended for use in Potentially Explosive Atmospheres
(UKCA)
Notified Body for
UK
type Examination
(Module B)
:
Sira
Certification Service
Notified Body No.: 0518
Rake Lane, Eccleston, Chester CH4 9JN, UK
UK
-
type Examination Certificate
(Module B)
:
CSAE 21
UKEX3556X
Notified Body for Quality Assurance Notification
/
Conformity to EU
-
type
based on
quality assurance of the production process (Module D):
Sira
Certification Service
Notified Body No.: 0518
Rake Lane, Eccleston, Chester CH4 9JN, UK
Quality Assurance Notification
(Module D)
:
CSAE 22UKQAN0046
Provisions fulfilled by the equipment:
BExCP3A
:
BExCP3B:
BExCP3C:
BExCP3D:
BExCP3E:
II 2G Ex
db
e
b
IIC T6 Gb
(
-
40°C
≤ Ta ≤ +
70
°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +70°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +50°C)
II 2D Ex tb IIIC T60°C Db (-40°C ≤ Ta ≤ +50°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +65°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +65°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +70°C)
II 2D Ex tb IIIC T80°C Db (-40°C ≤ Ta ≤ +70°C)
or
II 2G Ex db eb mb IIC T4 Gb (-40°C ≤ Ta ≤ +65°C)
II 2D Ex tb IIIC T75°C Db (-40°C ≤ Ta ≤ +65°C)
Standards applied:
EN IEC
60079
-
0:2018
EN 60079-1:2014
EN 60079-7:2015/A1:2108
IEC 60079-18:2015/AC:2018
EN 60079-31: 2014
IP6X Dust Protection to EN60079-0 / EN 60079-31
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN
61000
-
6
-
1:2007
EN 61000-6-2:2005
EN 61000-6-3:2007 / A1:2011 / AC: 2012
EN 61000-6-4:2007 / A1:2011
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.

E2S Telephone: [phone] Fax: [phone] Email: [email protected] www.e2s.com DC-093_Issue_A (BExCP3) - Page 2 of 2 - QAF_252_Issue_5
Martin Streetz Document No.: DC-093_Issue_A
Quality Assurance Manager Date and Place of Issue: London, 24/02/2022
UKCA Declaration of Conformity
Other Standards and Regulations
EN 60529:1992+A2:2013 - Degrees of protection provided by enclosures (IP code) – enclosure rated IP66
Construction and design requirements according to EN54-11:2001 clause 4.7 – BExCP3A-BG / B-BG / C-BG / D-BG only (fitted with burning house symbol shown in
figure 3a and no lift flap)
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.
