E2S D1xL1FV725-A User manual
INSTRUCTION MANUAL
D1xL1 & D1xL2
Loudspeaker
Class I, Zone 1, 2, 21 & 22
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 1 of 6
D1xL1F
D1xL2F
D1xL2H
1) Product Table
Unit Type Code
Input
Power (Watts)
Max I/P Volts
Sound Pressure Level dB(A)
Max Rated
Pink Noise @ 1W
D1xL1FV100-A
100V Line
15
100
117
101
D1xL1FV070-A
70V Line
15
70
D1xL1FR008-A
8 Ohm
15
10.95
D1xL1FR016-A
16 Ohm
15
15.49
D1xL1FV725-A
25V
15
25V
70V
15
70.7V
D1xL2FV100-A
100V Line
25
100
123
104
D1xL2FV070-A
70V Line
25
70
D1xL2FR008-A
8 Ohm
25
14.14
D1xL2FR016-A
16 Ohm
25
20
D1xL2FV725-A
25V
25
25V
70V
25
70.7V
D1xL2HV100-A
100V Line
25
100
126
106
D1xL2HV070-A
70V Line
25
70
D1xL2HR008-A
8 Ohm
25
14.14
D1xL2HR016-A
16 Ohm
25
20
D1xL2HV725-A
25V
25
25V
70V
25
70.7V
Frequency Range: 400Hz to 8000Hz
The table shows the input current taken by the various Loudspeakers.
Nominal current at nominal voltage.
Table 1: Electrical Ratings.
2) Warnings
CAUTION
TO REDUCE THE RISK OF IGNITION OF HAZARDOUS
ATMOSPHERES:
DISCONNECT FROM SUPPLY BEFORE OPENING.
KEEP TIGHTLY CLOSED WHEN IN OPERATION.
WARNING
FIT SEALING FITTING IN CONDUIT RUNS WITHIN 18 INCHES FROM
ENCLOSURE.
EQUIPMENT MUST NOT BE INSTALLED WITH THE HORN FACING
UPWARDS OF HORIZONTAL
DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT
DO NOT OPEN WHEN ENERGISED
POTENTIAL ELECTROSTATIC CHARGING HAZARD - CLEAN ONLY
WITH A DAMP CLOTH
ATEX/IECEx & UKEx INSTALLATIONS: IF TEMPERATURE EXCEEDS
70°C AT ENTRY OR 80°C AT BRANCHING POINT USE SUITABLE
RATED CABLE AND GLANDS
ATTENTION
DANGEREUSES :
COUPER L 'ALIMENTATION AVANT OUVERTURE.
CONSERVER FERMÉ PENDANT LE FONCIONNEMENT.
AVERTISSEMENT
CONDUITS DOIVENT ETRE SCELLES EN MOINS DE 18 POUCES.
ÉQUIPEMENT NE DOIT PAS ETRE INSTALLE AVEC LE KLAXON
TOURNEE VERS LE HAUT DE HORIZONTAL.
NE PAS OUVRIR ENERGIE
DANGER POTENTIEL CHARGE ÉLECTROSTATIQUE - NETTOYER
UNIQUEMENT AVEC UN CHIFFON HUMIDE
ATEX/IECEx & UKEx INSTALLATIONS : SI LA TEMPÉRATURE
DÉPASSE 70 °C À L'ENTRÉE OU 80 °C AU POINT DE
BRANCHEMENT, UTILISER UN CÂBLE ET DES JOINTS
D'ÉTANCHÉITÉ APPROPRIÉS
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 2 of 6
3) Marking * Rating Information
3.1 Class/Division Ratings for US & Canada
Standards
UL1203 & CSA C22.2 No 30 Ed. 4
Class Division Ratings for US (NEC)
Model No:
Rating
D1xL1-V100-A/
D1xL1-V070-A/
D1xL1-R008-A/
D1xL1-R016-A
D1xL1-V725-A
D1xL2-V100-A/
D1xL2-V070-A/
D1xL2-R008-A/
D1xL2-R016-A/
D1xL2-V725-A
Class Division Ratings for Canada (CEC)
Model No:
Rating
D1xL1-V100-A/
D1xL1-V070-A/
D1xL1-R008-A/
D1xL1-R016-A/
D1xL1-V725-A
D1xL2-V100-A/
D1xL2-V070-A/
D1xL2-R008-A/
D1xL2-R016-A/
D1xL2-V725-A
Class Zone Ratings for US (NEC)
Standards
Model No:
Rating
D1xL1-V100-A/
D1xL1-V070-A/
D1xL1-R008-A/
D1xL1-R016-A/
D1xL1-V725-A
D1xL2-V070-A/
D1xL2-R008-A/
D1xL2-R016-A/
D1xL2-V725-A
D1xL2-V100-A
Class Zone Ratings for Canada (CEC)
Model No:
Rating
D1xL1-V100-A/
D1xL1-V070-A/
D1xL1-R008-A/
D1xL1-R016-A/
D1xL1-V725-A
D1xL2-V070-A /
D1xL2-R008-A /
D1xL2-R016-A/
D1xL2-V725-A
D1xL2-V100-A
Installation must be carried out in compliance with the National
Electric Code / Canadian Electric Code
3.2 ATEX / IECEx & UKEx Ratings
Standards
Model No:
Rating
D1xL1-V070-A/
D1xL1-R008-A/
D1xL1-R016-A/
Ex db IIC T5 Gb Ta -55°C to +75°C
Ex db IIC T6 Gb Ta -55°C to +60°C
Ex tb IIIC T86°C Db Ta 55°C to +75°C
D1xL1-V725-A
Ex db IIC T5 Gb Ta -55°C to +75°C
Ex db IIC T6 Gb Ta -55°C to +60°C
Ex tb IIIC T91°C Db Ta 55°C to +75°C
D1xL1-V100-A
Ex db IIC T5 Gb Ta -55°C to +75°C
Ex db IIC T6 Gb Ta -55°C to +60°C
Ex tb IIIC T92°C Db Ta 55°C to +75°C
D1xL2-V070-A/
D1xL2-R008-A/
D1xL2-R016-A/
Ex db IIC T5 Gb Ta -55°C to +75°C
Ex db IIC T6 Gb Ta -55°C to +55°C
Ex tb IIIC T91°C Db Ta 55°C to +75°C
D1xL2-V725-A
Ex db IIC T4 Gb Ta -55°C to +75°C
Ex db IIC T5 Gb Ta -55°C to +70°C
Ex db IIC T6 Gb Ta -55°C to +55°C
Ex tb IIIC T97°C Db Ta 55°C to +75°C
D1xL2-V100-A
Ex db IIC T4 Gb Ta -55°C to +75°C
Ex db IIC T5 Gb Ta -55°C to +70°C
Ex db IIC T6 Gb Ta -55°C to +50°C
Ex tb IIIC T98°C Db Ta -55°C to +75°C
See Product table for electrical ratings of each unit model
Certificate No.
DEMKO 19ATEX2141X
IECEx ULD 19.0008X
UKEx UL UL21UKEX2132X
Epsilon x
Equipment Group
and Category:
II 2G
II 2D
CE Marking and
Notified Body No.
2813
UKCA Marking and
Notified Body No.
0518
3.3 UL Certification
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 3 of 6
All Loudspeakers comply with the following standards:
UL 1480A (Ed 1) Speakers for Commercial and Professional Use
CSA C22.2 No. 205 (Ed 3) Signal Equipment
CE, UKCA, CSFM
D1xL1FV100, D1xL2FV100, D1xL2HV100, D1xL1FV725, D1xL2FV725,
D1xL2HV725, D1xL1FR008, D1xL2FR008, D1xL2HR008, D1xL1FR016,
D1xL2FR016, D1xL2HR016 Loudspeakers also comply with the following
standards:
UL 1480 (Ed 6) Speakers for Fire Alarm and Signaling Systems,
Including Accessories
CAN/ULC-541 (Ed 4) Speakers for Fire Alarm and Signaling Systems,
Including Accessories
4) Zones, Gas Group, Category and Temperature Classification
The units can be installed in locations with the following conditions:
Area Classification Gas
Zone 1
Explosive gas air mixture likely to occur in normal
operation.
Zone 2
Explosive gas air mixture not likely to occur in
normal operation, and if it does, it will only exist for a
short time.
Gas Groupings
Group IIA
Propane
Group IIB
Ethylene
Group IIC
Hydrogen and Acetylene
Temperature Classification for Gas Applications
T1
450oC
T2
300oC
T3
200oC
T4
135oC
T5
100ºC (D1xL2-V100-A & D1xL2-V725 up to 70°C
ambient)
T6
85ºC (D1xL1 up to 60°C ambient, D1xL2 up to 55°C
ambient)
Area Classification Dust
Zone 21
Explosive dust air mixture likely to occur in normal
operation.
Zone 22
Explosive dust air mixture not likely to occur in
normal operation, and if it does, it will only exist for a
short time.
Dust Groupings
Group IIIA
Combustible Dusts
Group IIIB
Non-Conductive Dusts
Group IIIC
Conductive Dusts
Equipment Category
2G, 2D
Equipment Protection Level
Gb, Gc, Db, Dc
Maximum Surface Temperature for Dust Applications
86°C (D1xL1-V070-A, D1xL1-R008-A, D1xL1-R016-A)
92°C (D1xL1-V100-A)
91°C (D1xL2-V070-A, D1xL2-R008-A, D1xL2-R016-A, D1xL1-V725-A)
97°C (D1xL2-V725-A)
98°C (D1xL2-V100-A)
Ambient Temperature Range
-55°C to +75°C (-67°F to +167°F)
IP Rating
IP66 to EN60529
4 / 4X / 3R / 13 to UL50E / NEMA250
5) Specific Conditions of Installation
ATEx/IECEx & UKEx Installations:
The cable entries have two M20 x 1.5 6H entry thread and a
cable
glands, only suitably rated ATEx/IECEx or UKEx certified cable
glands must be used. They must be suitable for the type of cable
being used and also meet the requirements of the current
installation standards EN 60079-14 / IEC60079-14.
If the installation is made using conduit, openings must have a
sealing fitting connected as close as practical to the wall of the
enclosure, but in no case more than the size of the conduit or
50mm, whichever is the lesser.
Any unused cable entries must be closed with suitably rated
ATEx/IECEx or UKEx certified blanking plugs.
NEC / CEC Installations:
The cable entries have two M20 x 1.5 6H entry thread and a
glands, only suitably rated and certified cable glands must be
used. They must be suitable for the type of cable being used and
also meet the requirements of the current installation standards for
NEC and CEC.
If the installation is made using conduit, openings must have a
Any unused cable entries must be closed with suitably rated and
certified blanking plugs.
Class Zone Installation only:
For high ambient temperatures the cable entry temperature may
exceed 60ºC or the cable branching point temperature may
exceed 60ºC and therefore suitable heat resisting cables and
cable glands must be used, with a rated service temperature at
least as stated below:
Max Ambient Temp (°C)
40
45
50
55
60
65
70
75
D1xL1-V070-A, D1xL1-V100-A,
D1xL1-R008-A, D1xL1-R016-A,
Min. Rating (°C)
70
75
80
85
90
95
D1xL2-V070-A, D1xL2-V100-A,
D1xL2-R008-A, D1xL2-R016-A,
D1xL1-V725-A Min. Rating (°C)
70
75
80
85
90
95
100
D1xL2-V725-A Min. Rating (°C)
70
75
80
85
90
95
100
105
Table 2a: ATEx / IECEx & UKEx Min. Ratings of Cables & Cable
Glands.
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 4 of 6
(Appropriate
cable glands to
be customer
supplied)
Flameproof
Cover
M4 Grub
Screw
All Installations:
The plastic horn is not anti-static and the metallic enclosure has a
non-conductive coating. These may generate an ignition-capable
level of electrostatic charges under certain extreme conditions.
The user should ensure that the equipment is not installed in a
location where it may be subjected to external conditions that
might cause a build-up of electrostatic charges on non-conducting
surfaces.
6) Specific Conditions for Safe Use
Flameproof threaded joints and cemented joints are not permitted to be
repaired.
7) Product Mounting and Access
7.1 Mounting
Fig 1: Mounting Locations
7.2 Installation procedure
a. Secure the D1x unit to a flat surface via the three 7mm fixing
holes in the mounting bracket.
b. Remove the explosionproof cover of the alarm horn by
unscrewing it, taking care not to damage the explosionproof
threads in the process (Refer to section 7.4).
c. Fit an M20/NPT suitably rated cable gland or conduit entry
into the hole in the enclosure and connect the field wiring to
the appropriate terminals as shown in D190-06-201. The
power supply terminals are duplicated so that units may be
connected in parallel. An end of line monitoring resistor may
be fitted to units (see section 10). If the second and third
M20/NPT entries are not used, suitably rated stopping plugs
must always be fitted.
d. Replace the explosionproof cover of the loudspeaker, taking
care not to damage the explosionproof threads. Tighten fully.
7.3 Hornless Variants
7.4 Access to the Explosionproof Enclosure
Fig 2: Accessing the enclosure
On completion of the installation the flameproof threaded joint should be
inspected to ensure that they are clean and that they have not been
damaged during installation.
Ensure the O-ring seal is in place and undamaged.
When fitting the flameproof cover ensure the thread is engaged
correctly. Fully tighten the cover all the way, ensure no gap is visible
between the cover and base of the sounder enclosure.
Max Ambient Temp (°C)
30
35
40
45
50
55
60
65
70
75
D1xL1-V070-A, D1xL1-V100-A,
D1xL1-R008-A, D1xL1-R016-A,
Min. Rating (°C
60
65
70
75
80
85
90
95
D1xL2-V070-A, D1xL2-V100-A,
D1xL2-R008-A, D1xL2-R016-A
D1xL1-V725-A
Min. Rating (°C)
60
65
70
75
80
85
90
95
100
D1xL2-V725-A Min. Rating (°C
60
65
70
75
80
85
90
95
100
105
Table 2b: Class Zone Min. Ratings of Cables & Cable Glands.
D1xS1F
D1xS2F
D1xS2H
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 5 of 6
8) Installation Requirements
8.1 Safe Installation Requirements
Warning High voltage may be present,
risk of electric shock.
DO NOT open when energised,
disconnect power before opening.
The sounder must only be installed by suitably qualified personnel in
accordance with the latest issues of the relevant standards.
8.2 Cable Selection and Connections
When selecting the cable size, consideration must be given to the input
current that each unit draws (see table 1), the number of sounders on the
line and the length of the cable runs. The cable size selected must have
the necessary capacity to provide the input current to all the sounders
connected to the line.
A single wire with a cross sectional area of up to 2.5mm² / AWG14 can
be connected to each terminal way or if an input and output wire is
required two wires can be connected to each terminal way when crimped
with a ferrule. If more than one wire is fitted into a terminal a ferrule should
be used to securethe wires. Whenconnecting wires to theterminals great
care should be taken to dress the wire so that when the cover is inserted
into the chamber the wires do not exert excess pressure on the terminal
blocks.
D1xL2 and D1xL1 8 ohm and 16 ohm low impedance loudspeakers have
dual input terminals on the PCB assembly for input and output wiring. A
cable of up to 4.0mm² can be connected to each terminal.
Wire insulation needs to be stripped 8mm. Wires may be fitted securely
with crimped ferrules. Terminal screws need to be tightened down with a
tightening torque of 0.45 Nm / 3.5 Lb-in.
Line In: 0.2 - 2.5mm2/ AWG24 - AWG14
Low Impedance: 0.2 - 4mm2/ AWG24 - AWG12
Figure 3: Wire Preparation.
When connecting wires to the terminals great care should be taken to
dress the wires so that when the cover is inserted into the chamber the
wires do not exert excess pressure on the terminal blocks. This is
particularly important when using cables with large cross-sectional areas
such as 2.5mm².
8.3 Earthing
Figure 4: Earth Locations.
8.4 Cable Glands, Blanking Elements & Adapters
Ingress Protection
Adapters
The D1x Loudspeaker range can be supplied with the following types of
adapters:
M20 to M25
It is important to note that stopping plugs cannot be fitted onto adapters,
only directly onto the M20 entries.
Any other adapters used must be suitably rated and certified.
Internal Earth
Marked with G
External Earth
8mm
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS
Issue 3
21-12-2023
Sheet 6 of 6
9) Wiring
D1xL2 and D1xL1 8 ohm and 16 ohm low impedance loudspeakers
have dual input terminals on the PCB assembly for input and output
wiring. A cable of up to 4.0mm² can be connected to each terminal.
D1xL2 and D1xL1 70V and 100V Line cable connections are made into
the terminal blocks on the PCB assembly located in the explosionproof
enclosure. See section 5 of this manual for access to the explosionproof
enclosure. The 70V and 100V Lineloudspeakers are fitted with a tenway
terminal block. Terminal A is common and one of the other terminals B,
C, D or E should be selected depending on what output level is required
(see table below).
Terminals
D1xL2 (25W)
D1xL1 (15W)
A - B
25W
15W
A - C
12.5W
7.5W
A - D
6W
3W
A - E
2W
1W
D1xL2 and D1xL1 70V / 25V Line cable connections are made into the
terminal blocks on the PCB assembly located in the explosionproof
enclosure. See section 5 of this manual for access to the explosionproof
enclosure. The 70V and 25V Line loudspeakers are fitted with a sixteen
way terminal block. Terminal is common and one of the other terminals
A, B, C, D, E, F, G or H should be selected depending on what output
level is required (see table below).
Terminals
D1xL2-V725-A
D1xL2-V725-A
Voltage
Voltage
70V
25V
70V
25V
COM - A
15W
25W
COM - B
7.5W
12.5W
COM - C
15W
5W
25W
6W
COM - D
7.5W
4W
12.5W
4W
COM - E
5W
2W
6W
2W
COM - F
4W
4W
1W
COM - G
2W
2W
COM - H
1W
Refer to Wiring Schematic D190-06-201 Configs. 1a -2d for 70V & 100V
Line in Loudspeakers, Config. 3 for Low impedance & Configs. 4a 5f for
70V/25V Line in Loudspeakers.
10) End of Line Monitoring (DC Units)
On D1xL2 and D1xL1 Loudspeakers, DC line monitoring can be used if
required. Both the Line In units and the Low Impedance units have
blocking capacitors fitted. It should be noted that each loudspeaker has a
1M ohm bleed resistor connected across the blocking capacitor and this
should be taken into account when selecting the value of the end of line
monitoring resistance.
The end of line monitoringresistor can be connected across the terminals
on the end of line unit.
For Line in units, the end of line resistor used must have a minimum
resistance value of:
Minimum resistance 4k7 ohms Minimum Power 2.5W
For low impedance units the end of line resistor used must have a
minimum resistance value of:
Minimum resistance 2k ohms Minimum Power of 0.5W
Minimum resistance 500 ohms Minimum Power of 2W
On the low impedance units care must be taken with the polarity of the
monitoring voltage. If an end of line resistor is fitted to a unit the links on
the printed circuit boards of all loudspeakers in the line must be cut for
the dc blocking capacitors to be in circuit in order to dc monitor the line
(see Fig 5).
Fig. 5 Low Impedance Line Monitoring Link
11) Maintenance, Overhaul and Repair
Maintenance, repair andoverhaulof the equipment should only becarried
out by suitably qualified personnel in accordance with the current relevant
standards:
For ATEx/IECEx or UKEx:
EN60079-19/IEC60079-19
Explosive atmospheres Equipment repair, overhaul and
reclamation
EN 60079-17/IEC60079-17
Explosive atmospheres Electrical installations inspection and
maintenance
Units must not be opened while an explosive atmosphere is present.
If opening the unit during maintenance operations, a clean environment
must be maintained and any dust layer removed prior to opening the
unit.
Potential electrostatic charging hazard Clean only with a damp cloth.
DC Line
Monitoring Link
FIRE INSTRUCTION & SERVICE MANUAL
D1xL1F, D1xL2F & D1xL2H
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH www.e2s.com Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS-UL Issue A 15-08-2023 Sheet 1 of 2
COM A
BCDEF
A
BCDEF
GHGH
D1xL1FV100, D1xL2FV100, D1xL2HV100, D1xL1FV725, D1xL2FV725, D1xL2HV725, D1xL1FR008, D1xL2FR008, D1xL2HR008, D1xL1FR016,
D1xL2FR016 & D1xL2HR016 are approved for use as Loudspeakers for Fire Alarm Systems:
UL1480 (Ed 6)
CAN/ULC S-541 (Ed 4)
Attention: Installation must be carried out by an electrician in compliance with the National Electrical Code, NFPA 70, and the National Fire
Alarm Signaling Code, NFPA 72 or CSA 22.1 Canadian Electrical Code, Part I, Safety Standard for Electrical Installations, Section 32. /
L'installation doit exclusivement être réalisée par du personnel qualifié, conformément au code national d'électricité américain, NFPA 70, et
le code national d’alarrme incendie et de signalisation NFPA 72 ou CSA 22.1 Code canadien de l'électricité, première partie, norme de
sécurité relative aux installations électriques, Section 32
Attention: Disconnect from power source before installation or service to prevent electric shock / Débranchez-le de la source d'alimentation
avant l'installation ou l'entretien pour éviter tout choc électrique.
Attention: Fire Alarm Device—Do not paint / Ne pas Peinturer—Dispositif D’Alarme
Attention: Do not change factory applied finishes / Ne pas changer le revetement applique en usine
Type 4 / 4X / 3R / 13, IP66
-55°C to +80°C / -67°F to +176°F
Units should be mounted using at least 2 of the 3-off/4-off ø7mm holes in the mounting bracket.
The Equipment must not be installed with the horn facing upwards of horizontal.
If a high IP (Ingress Protection) rating is required then a suitable sealing washer or O-ring must be fitted under any cable gland or blanking device
with metric threads.
Check that the ‘O’ ring seal is in place before replacing the cover.
To maintain the enclosure rating, the cable entries must be fitted with suitably rated cable entry and/or blanking devices or suitably sized conduit
during installation. If entries are fitted with adaptors they must be suitable for the application.
Connections are to be made into the terminal blocks using solid or stranded wire, sizes 0.5-2.5mm
2
/ AWG 20-14. Wire insulation needs to be
stripped 8mm. Wires may be fitted securely with crimped ferrules. Terminal screws need to be tightened down with a tightening torque of 0.45 Nm
/ 4 Lb-in.
A single wire with a cross sectional area of up to 2.5mm² / AWG14 can be connected to each terminal way. When connecting wires to the terminals
great care should be taken to dress the wire so that when the cover is inserted into the chamber the wires do not exert excess pressure on the
terminal blocks.
Units can be located indoor or outdoor wet use, wall or ceiling mounted.
D1xL1FV725, D1xL2FV725, D1xL2H725 Wiring Terminals
D1xL1FV070, D1xL2FV070, D1xL2HV070, D1xL1FV100, D1xL2FV100 & D1xL2HV100 Wiring Terminals
COM 15W
25W 7W
12.5W 3W
6W 1W
2W
D1xL1FV725
D1xL2FV725,
D1xL2HV725
Terminals
Voltage Voltage
70.7V 25V 70.7V 25V
COM -
A
- 15W - 25W
COM - B - 7.5W - 12.5W
COM - C 15W 5W 25W 6W
COM - D 7.5W 4W 12.5W 4W
COM - E 5W 2W 6W 2W
COM - F 4W - 4W 1W
COM - G 2W - 2W -
COM - H - - 1W -
Terminals D1xL1FV070 D1xL1FV100 D1xL2FV070,
D1xL2HV070,
D1xL2FV100,
D1xL2HV100
COM
–
25W/15W 15W 15W 25W 25W
COM
–
12.5W/7W 7W 7W 12.5W 12.5W
COM
–
6W/3W 3W 3W 6W 6W
COM
–
2W/1W 1W 1.1W 2W 2.1W
FIRE INSTRUCTION & SERVICE MANUAL
D1xL1F, D1xL2F & D1xL2H
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH www.e2s.com Tel: +44 (0)208 743 8880
Document No. D190-00-201-IS-UL Issue A 15-08-2023 Sheet 2 of 2
Sound Pressure Level
Directional Characteristics
UL1480 Product Data
Unit Type
Code Input Power Max Input SPL Output (dB(A)) at different Transformer Tappings
1W 2W - 4W 5W 6W 7.5W 12.5W 15W 25W
D1xL1FV725
70V Line 15W 70.7V - 90.19 - 93.04 95.51 - 98.18 - 100.39 -
25V Line 15W 25V - 86.83 - 89.97 92.59 - 97.56 - 99.56 -
D1xL2FV725
70V Line 25W 70.7V 91.17 94.00 - 96.71 - 98.24 - 100.75 - 103.19
25V Line 25W 25V 87.83 89.42 - 92.27 - 95.45 - 100.06 - 101.00
D1xL2HV725
70V Line 25W 70.7V 91.42 94.10 - 96.93 - 98.27 - 101.03 - 103.29
25V Line 25W 25V 88.27 89.94 - 93.04 - 95.88 - 100.57 - 101.58
Unit Type
Code Input Power Max Input SPL Output
(
dB
(
A
))
at different Transformer Tappin
g
s
1.1W 2.1W 3W -- 6W 7.5W 12.5W 15W 25W
D1xL1FV100 100V Line 15W 100V 90.66 - 95.17 - - - 98.57 - 100.90 -
D1xL2FV100 100V Line 25W 100V - 93.86 - - - 98.20 - 100.80 102.90
D1xL2HV100 100V Line 25W 100V - 94.16 - - - 98.13 - 100.56 - 102.47
D1xL1FR008 8 Ohm 15W 10.95V 100.03
D1xL1FR016 16 Ohm 15W 15.49V 100.68
D1xL2FR008 8 Ohm 25W 14.14V 102.25
D1xL2FR016 16 Ohm 25W 20.00V 102.76
D1xL2HR008 8 Ohm 25W 14.14V 102.66
D1xL2HR016 16 Ohm 25W 20.00V 102.68
CAN/ULC S-541 Directional Characteristics
Unit Type Code Rated
Angle
Horizontal Axis Vertical Axis
-3dB(A) -6dB(A) Reduction
@ 90° -3dB(A) -6dB(A) Reduction
@ 90°
D1xL1FV100
0° +/-25 +/-65 -9.1 +/-30 +/-65 -8.8
D1xL1FV725
D1xL1FR008
D1xL1FR016
D1xL2FV100
0° +/-30 +/-50 -11.4 +/-25 +/-45 -11.4
D1xL2FV725
D1xL2FR008
D1xL2FR016
D1xL2HV100
0° +/-20 +/-30 -16.2 +/-20 +/-30 -16.3
D1xL2HV725
D1xL2HR008
D1xL2HR016
CAN/ULC S-541 Product Data
Unit Type
Code Input Power Max Input SPL Output
(
dB
(
A
))
at different Transformer Tappin
g
s
1W 2W - 4W 5W 6W 7.5W 12.5W 15W 25W
D1xL1FV725
70V Line 15W 70.7V - 95.60 - 98.36 100.80 - 103.50 - 106.10 -
25V Line 15W 25V - 92.32 - 95.50 98.32 - 103.40 - 105.30 -
D1xL2FV725
70V Line 25W 70.7V 97.25 100.10 - 102.80 - 104.70 - 107.20 - 109.70
25V Line 25W 25V 94.53 96.14 - 99.54 - 102.30 - 107.10 - 108.20
D1xL2HV725
70V Line 25W 70.7V 99.96 102.80 - 105.60 - 107.10 - 109.70 - 111.90
25V Line 25W 25V 97.43 98.94 - 102.00 - 105.10 - 109.70 - 110.70
Unit Type
Code Input Power Max Input SPL Output
(
dB
(
A
))
at different Transformer Tappin
g
s
1.1W 2.1W 3W -- 6W 7.5W 12.5W 15W 25W
D1xL1FV100 100V Line 15W 100V 97.30 - 101.70 - - - 105.10 - 107.80 -
D1xL2FV100 100V Line 25W 100V - 101.30 - - - 105.70 - 108.10 - 110.50
D1xL2HV100 100V Line 25W 100V - 103.90 - - - 107.60 - 110.30 - 112.50
D1xL1FR008 8 Ohm 15W 10.95V 106.10
D1xL1FR016 16 Ohm 15W 15.49V 106.30
D1xL2FR008 8 Ohm 25W 14.14V 109.60
D1xL2FR016 16 Ohm 25W 20.00V 109.00
D1xL2HR008 8 Ohm 25W 14.14V 111.50
D1xL2HR016 16 Ohm 25W 20.00V 112.40
warning signals
2S
EUROPEAN SAFETY SYSTEMS LTD
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
WWW.E2S.COM
C
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
IF IN DOUBT, ASK -
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78
6
5
D
C
134
2
A
B
D190-06-201
D.HOWGILL
R.N.POTTS
R.N.POTTS
18/11/20
OF
NTS 1 5
AINTRODUCTION
D.H 18/11/20
18/11/20
18/11/20
D1xL1 & D1xL2 LINE IN & LOW IMPEDANCE
LOUDSPEAKER WIRING DIAGRAMS
D1xL1
D1xL2
1INTRODUCTION
RSR 16/03/22
-ve
-ve
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
D1xL1V070 & D1xL1V100 Line in Config.: 1a
Optional Line Monitoring
15W: Apply Signal to Common & 15W
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
4K7Ω MIN, 2.5W MIN
MINIMUM VALUE:
R1
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
D1xL1V070 & D1xL1V100 Line in Config.: 1b
Optional Line Monitoring
7.5W: Apply Signal to Common & 7.5W
D1xL1V070 & D1xL1V100 Line in Config.: 1c
Optional Line Monitoring
3W: Apply Signal to Common & 3W
D1xL1V070 & D1xL1V100 Line in Config.: 1d
Optional Line Monitoring
1W: Apply Signal to Common & 1W
+ve
+ve
-ve
-ve
-ve
-ve
-ve
-ve
+ve
+ve
+ve
+ve
+ve
+ve
2ADDITION OF 70 / 25V VARIANTS
ACN0123 RSR 31/03/23
warning signals
2S
EUROPEAN SAFETY SYSTEMS LTD
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
WWW.E2S.COM
C
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
IF IN DOUBT, ASK -
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78
6
5
D
C
134
2
A
B
D190-06-201
D.HOWGILL
R.N.POTTS
R.N.POTTS
18/11/20
OF
NTS 2 5
18/11/20
18/11/20
D1xL1 & D1xL2 LINE IN & LOW IMPEDANCE
LOUDSPEAKER WIRING DIAGRAMS
D1xL1
D1xL2
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
D1xL2V070 & D1xL2V100 Line in Config.: 2a
Optional Line Monitoring
25W: Apply Signal to Common & 25W
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
4K7Ω MIN, 2.5W MIN
MINIMUM VALUE:
R1
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
COM 15W 7.5W 3W 1W
25W 12.5W 6W 2W
R1
D1xL2V070 & D1xL2V100 Line in Config.: 2b
Optional Line Monitoring
12.5W: Apply Signal to Common & 12.5W
D1xL2V070 & D1xL2V100 Line in Config.: 2c
Optional Line Monitoring
6W: Apply Signal to Common & 6W
D1xL2V070 & D1xL2V100 Line in Config.: 2d
Optional Line Monitoring
2W: Apply Signal to Common & 2W
ASEE SHEET 1
D.H 18/11/20
1SEE SHEET 1
RSR 16/03/22
-ve
-ve
-ve
-ve
-ve
-ve
-ve
-ve
+ve
+ve
+ve
+ve
+ve
+ve
+ve
+ve
2SEE SHEET 1
ACN0123 RSR 31/03/23
warning signals
2S
EUROPEAN SAFETY SYSTEMS LTD
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
WWW.E2S.COM
C
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
IF IN DOUBT, ASK -
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78
6
5
D
C
134
2
A
B
D190-06-201
D.HOWGILL
R.N.POTTS
R.N.POTTS
18/11/20
OF
NTS 3 5
ASEE SHEET 1
D.H 18/11/20
18/11/20
18/11/20
D1xL1 & D1xL2 LINE IN & LOW IMPEDANCE
LOUDSPEAKER WIRING DIAGRAMS
D1xL1
D1xL2
1SEE SHEET 1
RSR 16/03/22
D1xL1R008, D1xL1R016, D1xL2R008, D1xL2R016 Config.: 3
Low Impedance
Optional Line Monitoring
Apply Signal to +ve & -ve
-ve
-ve
+ve
+ve
R1
-
-
+
+
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
500Ω MIN, 2W MIN OR 2KΩ MIN, 0.5W MIN
MINIMUM VALUES:
R1
For DC Line
Monitoring Cut Link
2SEE SHEET 1
ACN0123 RSR 31/03/23
warning signals
2S
EUROPEAN SAFETY SYSTEMS LTD
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
WWW.E2S.COM
C
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
IF IN DOUBT, ASK -
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78
6
5
D
C
134
2
A
B
D190-06-201
D.HOWGILL
R.N.POTTS
R.N.POTTS
18/11/20
OF
NTS 4 5
AINTRODUCTION
D.H 18/11/20
18/11/20
18/11/20
D1xL1 & D1xL2 LINE IN & LOW IMPEDANCE
LOUDSPEAKER WIRING DIAGRAMS
D1xL1
D1xL2
1INTRODUCTION
RSR 16/03/22
-ve
-ve
COM A
B
D1xL1V725 Line in Config.: 4a
Optional Line Monitoring
15W:
25V: Apply Signal to Common & A
70V: Apply Signal to Common & C
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
4K7Ω MIN, 2.5W MIN
MINIMUM VALUE:
R1
R1
D1xL1V725 Line in Config.: 4b
Optional Line Monitoring
7.5W:
25V: Apply Signal to Common & B
25V: Apply Signal to Common & D
D1xL1V725 Line in Config.: 4c
Optional Line Monitoring
5W:
25V: Apply Signal to Common & C
70V: Apply Signal to Common & E
D1xL1V725 Line in Config.: 4d
Optional Line Monitoring
4W:
25V: Apply Signal to Common & D
70V: Apply Signal to Common & F
25V
25V
D1xL1V725 Line in Config.: 4e
Optional Line Monitoring
2W:
25V: Apply Signal to Common & E
70V: Apply Signal to Common & G
C D E F
-ve
-ve
-ve
-ve
70V
70V
-ve
-ve
-ve
-ve
25V
25V
25V
25V
25V
25V
25V
25V
70V
70V
70V
70V
70V
70V
70V
70V
COM
COM
COM
COM
A
B C D E F
A
B
R1
C D E F
A
B C D E F
A
B
R1
C D E F
A
B C D E F
A
B
R1
C D E F
A
B C D E F
A
B
R1
C D E F
A
B C D E F
G HG H
G HG H
G HG H
G HG H
G HG H
2SEE SHEET 1
ACN0123 RSR 31/03/23
warning signals
2S
EUROPEAN SAFETY SYSTEMS LTD
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
WWW.E2S.COM
C
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
DRAWING TO BS8888:2000
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
ANGULAR DIMENSIONAL TOLS
STANDARDS
MOD No. REASON - INITIAL - DATEISSUE
DATE
APPROVED
CHECKED DATE
DATE
DRAWN WEIGHT (Kg)
SURFACE FINISH
MATERIAL
ALTERNATIVE MATERIAL SHEETSCALE
TITLE
A3
IF IN DOUBT, ASK -
DO NOT SCALE
ALL DIMENSIONS IN MM
DRAWING NUMBER
A
B
C
D
E
F
G
109
G
F
E
78
6
5
D
C
134
2
A
B
D190-06-201
D.HOWGILL
R.N.POTTS
R.N.POTTS
18/11/20
OF
NTS 5 5
AINTRODUCTION
D.H 18/11/20
18/11/20
18/11/20
D1xL1 & D1xL2 LINE IN & LOW IMPEDANCE
LOUDSPEAKER WIRING DIAGRAMS
D1xL1
D1xL2
1INTRODUCTION
RSR 16/03/22
D1xL2V725 Line in Config.: 5a
Optional Line Monitoring
25W:
25V: Apply Signal to Common & A
70V: Apply Signal to Common & C
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
4K7Ω MIN, 2.5W MIN
MINIMUM VALUE:
R1
D1xL2V725 Line in Config.: 5b
Optional Line Monitoring
12.5W:
25V: Apply Signal to Common & B
70V: Apply Signal to Common & D
D1xL2V725 Line in Config.: 5c
Optional Line Monitoring
6W:
25V: Apply Signal to Common & C
70V: Apply Signal to Common & E
D1xL2V725 Line in Config.: 5d
Optional Line Monitoring
4W:
25V: Apply Signal to Common & D
70V: Apply Signal to Common & F
D1xL2V725 Line in Config.: 5e
Optional Line Monitoring
2W:
25V: Apply Signal to Common & E
70V: Apply Signal to Common & G
D1xL2V725 Line in Config.: 5f
Optional Line Monitoring
1W:
25V: Apply Signal to Common & F
70V: Apply Signal to Common & H
-ve
-ve
COM A
B
R1
25V
25V
C D E F
70V
70V
A
B C D E F
-ve
-ve
COM A
B
R1
C D E F
70V
70V
A
B C D E F
25V
25V
-ve
-ve
COM A
B
R1
C D E F
70V
70V
A
B C D E F
25V
25V
G HG H
G HG H
G HG H
-ve
-ve
COM A
B
R1
C D E F
70V
70V
A
B C D E F
25V
25V
G HG H
-ve
-ve
COM A
B
R1
C D E F
70V
70V
A
B C D E F
25V
25V
G HG H
-ve
-ve
COM A
B
R1
C D E F
70V
70V
A
B C D E F
25V
25V
G HG H
2SEE SHEET 1
RSR 31/03/23
ACN0123
E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: sales@e2s.com www.e2s.com DC-067_Issue_J (D1x).docx - Page 1 of 2 - QAF_252_Issue_5
EU Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Authorised Representative: E2S Warnsignaltechnik UG
Charlottenstrasse 45-51
72764 Reutlingen
Germany
Equipment Type: D1xS1, D1xS2
D1xL1, D1xL2
D1xC1X05, D1xC1X10, D1xC2X05, D1xC2X10
D1xB2XH1, D1xB2XH2
Directive 2014/34/EU: Equipment and Protective Systems for use in Potentially Explosive Atmospheres (ATEX) - D1xS1, D1xS2, D1xL1, D1xL2, D1xC1X05, D1xC1X10,
D1xC2X05 and D1xC2X10 only
Notified Body for EU type Examination (Module B):
UL International Demko A/S
Borupvang 5A
2750 Ballerup
Denmark
EU-type Examination Certificate (Module B):
DEMKO 19 ATEX 2141X
Notified Body for Quality Assurance Notification / Conformity to EU-type
based on
quality assurance of the production process (Module D):
Sira Certification Service
Notified Body No.: 2813
Unit 6, Hawarden Industrial Park, Hawarden, Deeside, CH5 3US, UK
Quality Assurance Notification (Module D):
SIRA 05 ATEX M342
Provisions fulfilled by the equipment:
II 2G Ex db IIC T6…T3 GB
II 2D Ex tb IIIC T82 C…145 C Db
Standards applied:
EN 60079-0:2018
EN 60079-1:2014
EN60079-31:2014
Regulation EU No. 305/2011: Construction Products Regulation (CPR) –D1xS1FDC024***A1R & D1xS1FDC024***A1G only –tones 1, 2, 5, 8, 40, 44, 53 only
Notified Product Certification Body for Certificate of Constancy of
Performance or EC Type Examination Certificate and continuous
surveillance, assessment and evaluation of factory production control:
BRE Global Assurance (Ireland) Limited
Notified Body No.: 2831
DCU Alpha, Old Finglas Road, Glasnevin, Dublin, D11 KXN4
Certificate of Constancy of Performance or EC Type Examination
Certificate:
2831-CPR-F4858
Standards applied:
EN 54-3:2001 + A1:2002 + A2:2006
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN 61000-6-1:2007
EN 61000-6-2:2005
EN 61000-6-3:2007 / A1:2011 / AC: 2012
EN 61000-6-4:2007 / A1: 2011
Directive 2014/35/EU: Low Voltage Directive (LVD)
Standards applied:
EN 60947-1:2007 + A2:2014
E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: sales@e2s.com www.e2s.com DC-067_Issue_J (D1x).docx - Page 2 of 2 - QAF_252_Issue_5
Martin Streetz
Document No.:
DC-067_Issue_J
Quality Assurance Manager
Date and Place of Issue:
London, 01/09/2023
EU Declaration of Conformity
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.
Other Standards and Regulations
EN 60529:1992+A2:2013 - Degrees of protection provided by enclosures (IP code) –enclosure rated IP66/67
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.
E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: sales@e2s.com www.e2s.com DC-097_Issue_B (D1x UKCA).docx - Page 1 of 2 -
QAF_252_Issue_5
UKCA Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Equipment Type: D1xS1, D1xS2
D1xL1, D1xL2
D1xC1X05, D1xC1X10, D1xC2X05, D1xC2X10
Directive UKSI 2016:1107 (as amended by UKSI 2019:696) –Schedule 3A, Part 1 : Product or Protective System Intended for use in Potentially Explosive Atmospheres
(UKCA)
Notified Body for UK type Examination (Module B):
UL International (UK) Ltd
Notified Body No.: 0843
Unit 1-3 Horizon Kingsland Business Park, Wade Road,
Basingstoke, Hampshire RG24 8AH UK
UK-type Examination Certificate (Module B):
UL21UKEX2132X
Notified Body for Quality Assurance Notification / Conformity to EU-type
based on
quality assurance of the production process (Module D):
Sira Certification Service
Notified Body No.: 0518
Rake Lane, Eccleston, Chester CH4 9JN, UK
Quality Assurance Notification (Module D):
CSAE 22UKQAN0046
Provisions fulfilled by the equipment:
II 2G Ex db IIC T6…T3 GB
II 2D Ex tb IIIC T82 C…145 C Db
Standards applied:
EN 60079-0:2018
EN 60079-1:2014
EN60079-31:2014
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN 61000-6-1:2007
EN 61000-6-2:2005
EN 61000-6-3:2007 / A1:2011 / AC: 2012
EN 61000-6-4:2007 / A1: 2011
Regulation EU No. 305/2011: Construction Products Regulation (CPR) –D1xS1FDC024***A1R & D1xS1FDC024***A1G only –tones 1, 2, 5, 8, 40, 44, 53 only
Notified Product Certification Body for Certificate of Constancy of
Performance or EC Type Examination Certificate and continuous
surveillance, assessment and evaluation of factory production control:
BRE Global Limited
Notified Body No.: 0832
Bucknalls Lane, Garston, Watord, Hertfordshire, UK, WD25 9XX
Certificate of Constancy of Performance or EC Type Examination
Certificate:
0832-UKCA-CPR-F1782
Standards applied:
EN 54-3:2001 + A1:2002 + A2:2006
Directive 2014/35/EU: Low Voltage Directive (LVD)
Standards applied:
EN 60947-1:2007 + A2:2014
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.
E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: sales@e2s.com www.e2s.com DC-097_Issue_B (D1x UKCA).docx - Page 2 of 2 -
QAF_252_Issue_5
Martin Streetz
Document No.:
DC-097_Issue_B
Quality Assurance Manager
Date and Place of Issue:
London, 01/09/2023
UKCA Declaration of Conformity
Other Standards and Regulations
EN 60529:1992+A2:2013 - Degrees of protection provided by enclosures (IP code) –enclosure rated IP66/67
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.
Page left Intentionally blank
Page left Intentionally blank
Page left Intentionally blank
This manual suits for next models
16
Table of contents
Other E2S Speakers manuals
