Eachine VR005 User manual

User Manual
FPV Goggles
VR005

1
Main function
No.
Name
Function
Power
switch
●Long press to start when when in shutdown
● Long press to power off when in boot state.
S
Menu/
Automati
cally
●Click button “S” to bring up Setting menu, and
then click again to go to next menu.
● Long press to search channel automatically

2
Operation
1. S Channel auto-searching
Click button “ S”, the device will search the signal according
to the 48 channel one by one , and will stop once get the video signal.
If the video signal is not you want to get, please click this button
again to continue search.
2. B Bands
Click to this button continuously to switch bands between the
six bands “A, B, C, D, E, F” when search channels manually.
4. CH Channel
When search channels manually, and after bands settled, click
this button continuously to switch the 8 channels one by one in settled
B
Bands
●Click button “B”to switch bands between
“A,B, C, D, E, F”when in 5.8G mode
● Used as “-“ when in Setting menu
CH
Channel
●Click button “CH”to switch channel between
“1,2---8”when in 5.8G mode
● Used as “+“ when in Setting menu
USB
USB
● For charging (DC 5V power)

3
band.
Product Specification
Screen Size: 2.7 inches,
Resolution: 960*240 pix
Brightness : 300cd / m2 of high brightness, for outdoor use
Field of view: 0/120 degrees (horizontal / vertical)
Magnification: 3.5x
Distortion: No distortion
Material: PMMA
Transparency: > 98%
Power consumption: 1.4W
RX：Built-in 48CH 5.8G Hz
Working temperature：-10℃-60℃
Storage temperature：-20℃-90℃
Product weight：145 g
Product size：150mmX120mmX60mm

4
48 Channels as following:
Band A：5645，5665，5685，5705，5885，5905，5925，5945
Band B：5740，5760，5780，5800，5820，5840，5860，5880
Band C：5725，5745，5765，5785，5805，5825，5845，5865
Band D：5733，5752，5771，5790，5809，5828，5847，5866
Band E：5658，5695，5732，5769，5806，5843，5880，5917
Band F：5362，5399，5436，5473，5510，5547，5584，5621
