Eagle 100 Series Operating instructions

Installation & Owners Manual
Swing Gate Operators
Eagle-100 Series
Eagle-100 Series
Eagle-200 Series
Eagle-200 Series
TM
ACCESS CONTROL SYSTEMS, INC.
Made in the USA
UL 325 Compliant / UL 991 Compliant
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
Diamond Control Board or Diamond DC Control Board

1
TABLE OF CONTENTS
SWING GATE OPERATOR SPECIFICATIONS
SAFETY
METHODS OF INSTALLATION
DIAMOND BOARD ADJUSTMENTS AND WIRING
DIAMOND BOARD ONLYDIAMOND DC BOARD ONLY
Standard Installation
Compact Installation
Easy Release Alignment
Gate Arm Installation
Reverse, Phantom (Shadow) and Exit In-Ground Loop Installation
Secondary Entrapment Protection
Requirements for UL 325 Compliant Installation
UL 325 Model Classifications
UL 325 Required Entrapment Protection
Important Safety Information
General Safety Information
Diamond Board
Features Selector Switches #1 - #8
120 VAC Input Power Connection
Setting the Limit Switches
Emergency Release
Adjusting the Clutch
Reset the Motor
Close Timer for a Single or Master Operator
Two-Way Adjustable Reverse Sensor / ERD
Output Connection Descriptions
Global Inputs Descriptions
Radio Receiver Connection
Connecting the Accessories
Diamond Board Master / Slave Setup
Diamond Board Troubleshooting
Eagle-100 / Eagle-200 Models Wiring Diagram
Eagle-100 / Eagle-200 Series Replacement Parts
Pre-Installation Battery Charging
Diamond DC Board
Power Save Mode
Power Fail Operation Switches #1 - #4
Features Selector Switches #1 - #8
P/O Adjust Switches #1 - #4
Power ON/OFF Switch and 5-Pin Primary Plug for Diamond DC Board
Battery Replacement When Necessary
120/240 VAC Input Power Connection
Setting the Limit Switches
Emergency Release
Adjusting the Clutch
Close Timer for a Single or Master Operator
Two-Way Adjustable Reverse Sensor / ERD
Output Connection Descriptions
Global Inputs Descriptions
Radio Receiver Connection
Connecting the Accessories
Diamond DC Board Master / Slave Setup
Diamond DC Board Troubleshooting
Eagle-100-DC / Eagle-200-DC 120 VAC Input Models Wiring Diagram
Eagle-100-DC / Eagle-200-DC 240 VAC Input Models Wiring Diagram
Eagle-100-DC / Eagle-200-DC Series Replacement Parts
6
6
7
7
8
8
9
9
10
10
11
11
11
12
12
12
13
13
14
15
16
17
18
3
4
4
5
5
2
3
6
9
DIAMOND DC BOARD ADJUSTMENTS AND WIRING 19
© 2013 Eagle Access Control Systems, Inc.
All rights reserved. No part of this manual may be reproduced in any means: graphics, electronics or mechanical. Including photocopying
without the expressed written permission of the publisher. Materials components and specifications are subject to change without notice.
19
19
19
20
20
21
21
21
22
22
23
23
24
24
24
25
25
26
27
28
29
30
31

2
Specifications
SWING GATE OPERATOR SPECIFICATIONS
Residential Swing Gate Operators
Commercial Swing Gate Operators
Eagle-100
Eagle-100-DC
Eagle-100 Series
Eagle-200 Series
1/2 HP - 120 VAC - 5.7 amp
Input Power: 120/240 VAC (1 Phase)
Operator Power: 1/2 HP - 24 VDC
Input Power: 120/240 VAC (1 Phase)
Operator Power: 1/2 HP - 24 VDC
Input Power: 120/240 VAC (1 Phase)
Operator Power: 3/4 HP - 24 VDC
18 ft
18 ft
600 lbs
600 lbs
Diamond
Diamond DC
Continuous
Continuous
Power I (Optional) - 100
Built-in - 100
UL 325 Class I, II, III and IV
Eagle-200
Eagle-200-1HP
Eagle-200-DM
Eagle-200-DC
Eagle-200-DC-HD
1/2 HP - 120 VAC - 5.7 amp
1 HP - 120 VAC - 10.5 amp
(2) 1/2 HP - 120 VAC - 5.7 amp
20 ft
20 ft
20 ft
20 ft
20 ft
Model Motor(s) Power Max Length Max Weight Control Board Operation Battery Back-Up & Cycles
Model Motor Power Max Length Max Weight Control Board Operation Battery Back-Up & Cycles
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
18.5” 16”
28”
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
22” 17.5”
29.25”
NOTE: The number of gate
cycles when using ONLY
battery back-up power are
approximate and WILL vary
depending on length and
weight of the gate.
NOTE: The number of gate
cycles when using ONLY
battery back-up power are
approximate and WILL vary
depending on length and
weight of the gate.
NOTE: Eagle-100
can handle
lite-commercial
duty as well as
residential.
750 lbs
1000 lbs
750 lbs
800 lbs
1000 lbs
Diamond
Diamond
Diamond
Diamond DC
Diamond DC
Continuous
Continuous
Continuous
Continuous
Continuous
Power I (Optional) - 40-80
Power II (Optional) - 40-80
Power I (Optional) - 40-80
Built-in - 100
Built-in - 100

3
UL 325 Requirements
SAFETY
1. Install the gate operator only when:
a) The operator is appropriate for the construction of the gate and the usage class of the gate.
b) All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet (1.22 m) above the
ground to prevent a 2-1/4 inch (57.2 mm) diameter sphere from passing through the openings anywhere in the gate, and in that portion
of the adjacent fence that the gate covers in the open position.
c) All exposed pinch points are eliminated or guarded, and
d) Guarding is supplied for exposed rollers.
2. The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate access opening. The
pedestrian access opening shall be designed to promote pedestrian usage. Locate the pedestrian gate such that persons will not come in
contact with the vehicular gate during the entire path of travel of the vehicular gate.
3. The gate must be installed in a location so that enough clearance is supplied between the gate and adjacent structures when opening and
closing to reduce the risk of entrapment. Swinging gates shall not open into public access areas.
4. The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. Do not over-tighten the
operator clutch or pressure relief valve to compensate for a damaged gate.
5. For gate operators utilizing Type D protection:
a) The gate operator controls must be placed so that the user has full view of the gate area when the gate is not moving.
b) The placard provided marked in letters at least 1/4 in. (6.4-mm) high with the word “WARNING” and the following statement or the
equivalent: “Moving Gate Has the Potential of Inflicting Injury or Death – Do Not Start Gate Unless Path is Clear” shall be placed adjacent
to the controls,
c) An automatic closing device (such as a timer, loop sensor, or similar device) shall not be employed, and
d) No other activation device shall be connected.
6. Controls intended for user activation must be located at least six feet (6’) away from any moving part of the gate and where the user is
prevented from reaching over, under, around or through the gate to operate the controls. Outdoor or easily accessible controls shall have a
security feature to prevent unauthorized use.
7. The Stop and /or Reset button must be located in the line-of-sight of the gate. Activation of the reset control shall not cause the operator to
start.
8. A minimum of two (2) WARNING SIGNS shall be installed, one on each side of the gate where easily visible.
9. For gate operators utilizing a non-contact sensor in accordance with Usage Class:
a) See instructions on the placement of non-contact sensors for each type of application,
b) Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate is still moving,
and
c) One or more non-contact sensors shall be located where the risk of entrapment or obstruction exists, such as the perimeter reachable
by a moving gate or barrier.
10. For gate operators utilizing a contact sensor in accordance with Usage Class:
a) One or more contact sensors shall be located where the risk of entrapment or obstruction exists, such as at the leading edge, trailing
edge, and post-mounted both inside and outside of a vehicular horizontal slide gate.
b) One or more contact sensors shall be located at the bottom edge of a vehicular vertical lift gate.
c) One or more contact sensors shall be located at the pinch point of a vehicular vertical pivot gate.
d) A hardwired contact sensor shall be located and its wiring arranged so that the communication between the sensor and the gate
operator is not subjected to mechanical damage.
e) A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for entrapment protection
functions shall be located where the transmission of the signals are not obstructed or impeded by building structures, natural
landscaping or similar obstruction. A wireless contact sensor shall function under the intended end-use conditions.
f) One or more contact sensors shall be located on the inside and outside leading edge of a swing gate.
Additionally, if the bottom edge of a swing gate is greater than 6 inches (152 mm) above the ground at any point in its arc of travel, one
or more contact sensors shall be located on the bottom edge.
g) One or more contact sensors shall be located at the bottom edge of a vertical barrier (arm).
Requirements for UL 325 Compliant Installation

4
UL 325 Model Classifications
UL 325 Required Entrapment Protection
CLASS I
Residential Vehicular Gate Operator - A vehicular gate
operator (opener or system) intended for use in a home
of one to four single family dwellings, or a garage or
parking area associated therewith.
CLASS II
Commercial/General Access Vehicular Gate Operator - A
vehicular gate operator (opener or system) intended for
use in a commercial location or building such as a
multi-family housing unit (five or more single family
units) hotel, garages, retail store or other building
servicing the general public.
CLASS III
Industrial/Limited Access Vehicular Gate Operator - A
vehicular gate operator (opener or system) intended for
use in a industrial location, loading dock area or other
location not intended to service the general public.
CLASS IV
Restricted Access Vehicular Gate Operator - A vehicular
gate operator (opener or system) intended for use in a
guarded industrial location or buildings such as airport
security area or other restricted access locations not
servicing the general public, in which unauthorized
access is prevented via supervision by security
personnel.
Entrapment Protection Requirements for Each UL 325 Classification
Proper installation must satisfy the entrapment protection chart as shown. The installation must have one PRIMARY means and a
SECONDARY means of entrapment protection in both the OPEN and CLOSE direction of gate travel.
A- Inherent (built into the gate operator) entrapment
protection.
B1 - Non-contact sensor such as photo-eye or equivalent.
B2 - Contact sensor such as edge sensor or equivalent.
C- Inherent adjustable clutch or pressure relief device.
D- Actuating device requiring continuous pressure to
maintain gate motion.
E- Inherent audio alarm.
A
B1, B2, D
A, B1, B2, C, D
A, C
A, B1, B2
A, B1, B2, D, E
A, B1, B2, C
A, B1, B2, D
A, B1, B2, D, E
A, B1, B2, D, E A, B1, B2, C, D, E
A, B1, B2, C, D
Secondary Type
Primary Type
Gate Type Protection Class I & II Class III Class IV
Horizontal Slide
Vertical Lift
Vertical Pivot Gate
Swing Gate or
Vertical Barrier (arm) Secondary Type
Primary Type
CLASS I
CLASS II
CLASS III
CLASS IV
UL 325 Requirements

5
Important Safety Information
General Safety Information
Install Warning Signs
Precautions
1. Never let children operate or play with gate controls. Keep the remote control away from children.
2. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
3. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop when an object activates the non-contact
sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust and retest the gate operator properly can
increase the risk of injury or death.
4. Use the emergency release ONLY when the gate is not moving and verify that operator power has been turned OFF.
5. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate hardware.
6. The entrance is for vehicles only. Pedestrians must use separate entrance.
7. SAVE THESE INSTRUCTIONS.
To reduce the risk of injury or death read and follow the instructions
WARNING
Be sure to read and follow all the Eagle Access Control Systems, Inc. and UL instructions before installing and
operating any Eagle Access Control System, Inc. products. Eagle Access Control Systems, Inc. is not responsible
for any improper installation procedures caused by failure to comply with local building codes.
Install warning signs on BOTH sides of the gate.
Eagle swing gate operators are for vehicular use only. They are NOT for pedestrian use.
Be sure to mount ALL gate operating devices at least ten feet (10’) away
from any moving part of the gate. They must NOT be able to be operated
reaching through the gate.
Regarding Ornamental Grill Styled Gates: Injuries may be avoided if a
mesh screen is installed on the gate. Injuries resulting from hands and
feet becoming stuck in the gate or children riding on the gate while gate
is moving can be greatly reduced if this “screen” or “mesh” is applied
to the gate as a safety precaution.
CAUTION
BYEAGLEACCESSCONTROL SYSTEMS, INC.
Moving Gate Can Cause
Serious Injury or Death
KEEPCLEAR! Gatemay move at any time
withoutprior warning.
Donot let children operate the gate or play
inthe gate area.
Thisentrance is for vehicles only.
Pedestriansmust use separate entrance.
Moving Gate Can Cause
Serious Injury or Death
KEEP CLEAR! Gate may move at any time
without prior warning.
Do not let children operate the gate or play
in the gate area.
This entrance is for vehicles only.
Pedestrians must use separate entrance.
BYEAGLEACCESSCONTROL SYSTEMS, INC.
Moving Gate Can Cause
Serious Injury or Death
KEEPCLEAR! Gatemay move at any time
withoutprior warning.
Donot let children operate the gate or play
inthe gate area.
Thisentrance is for vehicles only.
Pedestriansmust use separate entrance.
BYEAGLEACCESSCONTROL SYSTEMS, INC.
NO
General Safety

6
Installation
METHODS OF INSTALLATION
Standard Installation
An experienced installer should perform the installation. Improper installation may result in property damage, severe injury or death.
Read the entire manual before proceeding with the installation.
Eagle Access Control Systems, Inc. is not responsible for researching and complying with local building codes. Be sure to check all local
building codes before installation.
Recommended Concrete
Pad Dimensions:
Eagle-100 - 20” x 24”
Eagle-200 - 24” x 24”
Use four 1/2” x 3 1/2”
minimum, up to 1/2” x 6”
sleeve anchors to mount
operator to concrete pad.
NOTE: If there is limited area for
the arm and this dimension is
less than 35 inches then compact
installation is necessary.
Hinge Center
Hinge Center
Hinge Center
Hinge Center
Concrete Pad
Concrete Pad
Closed Gate
Closed Gate
Open Gate
Wall
Open Gate
A
E
I
F
G
H
24”
B
J
C
D
2”
Eagle-100 - 19.5”
Eagle-200 - 21.75”
28
30
32
35
Option 1
Option 2
Option 3
Option 4
27.5
29.5
25.5
29
34.5
36
39
36
42
43
44
45
BC DE
12
12
12
12
A
35
36
Eagle-100
Eagle-200
22
32
11
12
28
25
FG I
26
27
JH
1/2
Eagle-100 or Eagle-200 - Inches
Compact - Inches
Be sure that arms
are FULLY extended
and locked when
the gate is in the
closed position.
Suggested concrete
depth dimension.
Check local building
codes in your area for
depth of concrete
before installation.
24”
5” Ground Level
Compact Installation
Securing Operator to Pad
NOTE: If this dimension is less than
16 inches, secondary entrapment
protection is REQUIRED in this area.
See page 8 for more information.

7
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
Easy Release Alignment
Gate Arm Installation
Pin MUST fit into slot.
Support Bar
Bottom of
Easy Release
Slot
Pin
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
Arms MUST be Level!
NO
NO
Closed Gate
Open Gate
Arms MUST be FULLY extended and
in the locked position when the gate
is fully closed. Failure to do this
could result in serious injury.
DO NOT allow arms to
scissor when the gate
is fully open. This will
put too much stress
on the arms and
operator when the
gate is cycling.
Gate
Attachment
Bracket
Weld completely around gate attachment bracket
AFTER arm measurements have been determined.
These two
gaps should
remain even
for proper fit.
COMMON MISTAKES TO BE AWARE OF:
Support Bar
Installation

8
Separate
Power
Receiver
Reverse, Phantom (Shadow) and Exit In-Ground Loop Installation
Secondary Entrapment Protection
Reversing and phantom loops are used to prevent the gate from closing on a vehicle
while it is in the gates swinging path (CAUTION: phantom loop is ONLY active when gate
is FULLY open). An exit loop is used to automatically open the gate when a vehicle
approaches to exit. An experienced installer should perform this installation.
Installation of a reflective photocell sensor is recommended. Mount the sensors
just above the height of the gate operator in position shown.
Use EMX - IRB - 325 Photocell Sensors. All secondary entrapment
sensors are connected to #8 Edge Sensor Global Input.
Loop wire must be wrapped
inside the groove three times.
Fill the grooves with a proper
sealant.
Connect loop wires to Loop
Wire Input on control board.
Connect loop wires directly
to external loop detector.
Loop feed must have
the loop wires twisted
in them approximately
6 twists per foot.
Gate Swing Path
Groove
4’
4’
4’
4’ 4’4’ Reverse Loop
Cutaway of Groove Loop Feed
Eagle Plug-In Loop Detector External Loop Detector
Loop
Feed
Drawing NOT to scale
4’
4’ 4’4’ Reverse Loop
Exit Loop
Phantom Loop
(Shadow Loop)
Open Gate
Entrapment Area
1 1/2”
1/4”
Backer Rod
Sealant
Twisted
Loop Wire
Inside
PVC Conduit
Separate
Power
Loop Detector Options
Loop Detector
EG167
Sensitivity
Indicators
Push &hold Reset/Sen. button
LED will blink from1to 4 times. Release
buttonupon reaching desiredsensitivity.
1= Very Low, 2 =Low,
3=Normal, 4 = High
To changefrominductiveloop to
mini-loop- seeinstructions.
Green- Steadyindicates power
Fast blink- Shorted loop
Slowblink - Open loop
Red- Detect Indicator
EG167
Power
Detect
Reset
Vehicle
Detector
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
STOP
#5
CLOSE
#7
GLOBAL INPUTS
EDGE SENSOR
#8
Transmitter
SOLAR-ONLY LOOP DETECTOR POWER NOTE: It is recommended using
Eagle plug-in loop detectors when using solar-only power. External loop
detectors require a separate power source which is usually not available
when a solar-only configuration is used. The operator should not be used
to power external loop detectors. Please contact Eagle Access if you
would like more information about a solar-only setup.
Loops
Secondary Entrapment

9
Diamond Board
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
ACTIVE
OVERLOAD OPENING
LIGHT HEAVY
ERD STATUS GATE STATUS
Eagle Diamond Control Board
Rev A4
TIMER
MIN
MASTER
SLAVE
MAX
1
ON
2345678
M/S PHASE
01
CLOSING
SELECT
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
CLOSE
STOP
OPEN
SLAVE MASTER
+ – + –
#14#13
+ MAGLOCK - 24 VDC
#10
+ ALARM - 12 VDC
#11
MAGLOCK RELAY
#9
POWER
24 VAC
#12
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
GND
GND
RCVR
24VAC
#1
LOOP WIRE INPUT
EXIT
OPEN
SHADOW
LOOP
REVERSE
LOOP
COMM PORTOUTPUTSGLOBAL INPUTS
RECEIVER
REVERSE LOOP SHADOW LOOP EXIT LOOP
REVERSE SHADOW EXIT
RESET
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
2 3 4 5 6 7 8
SELECT
DIAMOND BOARD ADJUSTMENTS AND WIRING
Feature Selector Switches #1 - #8
The Feature Selector Descriptions:
NOTE: The power MUST be turned OFF before changing the features selector switches.
Switch #1: Slave/Master - Sets the operator to work as Master or Slave. Single operator
MUST be set to MASTER.
Switch #2: Gate Opening - designates left or right opening direction.
Switch #3: Motor Brake - If the ON position is selected, the gate will stop instantly when
the limit switch is activated. This is useful for uphill/downhill applications and on all fail-safe operators.
Switch #4: Reverse Loop - Sets the reverse loop to be normally open (NO) or normally close (NC). It is useful in fail-safe applications.
Normal setting is OFF (Normally Open).
NOTE: For switches #5 - #8: Switch #1 OFF - “Slave Setting”, see page 15 “Gate Delay Functions” for descriptions.
Switch #5: One Pass (ON/OFF) - This tailgating feature works with the reverse loop to allow only one vehicle to pass the gate. After the vehicle
passes, the gate closes instantly. If a second vehicle approaches, the gate stops. The gate resumes closing after the vehicle leaves.
Switch #6: Stop-Reverse (ON/OFF) - The radio feature allows the transmitter to work as a three-button station and is useful for a partial
opening. If selected, the first command will open the gate, the second command will stop the gate and the third command will close the gate.
Switch #7: Alarm Reset (ON/OFF) - If the ON position is selected, after the five minute “Shutdown” time period, the operator will reset and any
input will be accepted. Normally, the power must be turned off to reset.
Switch #8: Close Timer (ON/OFF) - Turns the close timer ON or OFF. See page 12.
Feature Selector
See below
M/S Phase
DO NOT remove jumper or operator will NOT function.
Designates communication between master and slave
operators only. M/S operators can be set for the same
or opposite phase, depending on operators
communication (can vary).
Reset Button
Press for soft reset of operator (reset board logic).
Turns OFF activated alarm. Try this button before
preforming a hard shutdown of operator (turn
power switch OFF/ON) when operator fails.
Close Timer - See page 12
or
M/S Gate Delay - See page 15
Reverse ERD Sensor
See page 12
Limit Switches
See page 10
Global Inputs
Descriptions - See page 13
Wiring Accessories - See page 14
Outputs
See page 12
Fuse
15 Amp
250V
Slow-Blow
Factory Set
ERD Sensor
“Fine Tune”
Adjustment.
Please call
Eagle
Access
before any
adjustment.
See page 12.
Master/Slave
See page 15
3-Button Station
Cycles Operator
Radio Receiver
See page 13
In-Ground Loop Wires Connection
Connect in-ground loop wires to
corresponding loop detector Only when
using Eagle Plug-In Loop Detectors.
Loop Detector
EG167
Sensitivity
Indicators
Push & hold Reset/Sen. button
LED will blink from 1 to 4 times. Release
button upon reaching desired sensitivity.
1 = Very Low, 2 = Low,
3 = Normal, 4 = High
To change from inductive loop to
mini-loop- see instructions.
Green - Steady indicates power
Fast blink - Shorted loop
Slow blink - Open loop
Red - Detect Indicator
EG167
Power
Detect
Reset
Vehicle
Detector
EG167
Power
Detect
Reset
Vehicle
Detector
Eagle Plug-In
Loop Detector
Connections
See instructions
on the Eagle loop
detectors when
using them.
Eagle Plug-In
Loop Detector
Automatically adjusts for
proper sensitivity. Eagle
brand are designed for
“Fail-Safe” operation.
Switches #5 - #8: Switch #1 ON - Master Setting ONLY
Diamond Board ONLY

10
Input Power ConnectionLimit Switches
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
23 4 5 6 7 8
SELECT
Diamond Board 120 VAC Input Power Connection
Setting the Limit Switches
WARNING: Eagle Access Control Systems, Inc. is not responsible for
researching and complying with local building codes. Be sure to check
all local building codes before installation.
Be sure that the circuit breaker for the input power is turned OFF
before connecting the input power to the operator.
All operators MUST be properly grounded. Installing surge protection
is recommended.
The limit switches MUST be set so the gate stops at the correct open and close positions.
the control board MUST have power for the limit LEDs when setting the limit switches
Adjust the close limit switch FIRST when the gate is in the closed position.
Open and Close
Limit LEDs will light
up on control board
for top or bottom
limit switches as
indicated.
Indicates the
direction the
gate is cycling.
IMPORTANT: DO NOT
cycle the operator before
setting the limit switches.
Damage or injury could
occur if limit switches are
NOT set. (See below)
Junction Box
Top Limit Switch
Top Limit
Switch
Bottom Limit
Switch
Top Limit
Switch Activator
Bottom Limit
Switch Activator
OPEN LEFT OPEN RIGHT
Bottom Limit Switch
3-button
station
cycles
operator.
120 VAC power
outlet provided.
Wire Color Description
Black - 120 VAC input power
White - Neutral input
Green - Ground input
(from an approved grounding method)
250 ft
14 AWG
400 ft
12 AWG
650 ft
10 AWG
1000 ft
8 AWG
2000 ft
4 AWG
CAUTION
MASTER
OPENRIGHT
BRAKEON
REVERSELOOP NC
ONEPASS
STOP-REVERSE
ALM-RST
CLOSETIMER
OFF—ON
SLAVE
OPENLEFT
BRAKEOFF
REVERSELOOP NO
OPNDLY S
OPNDLY M
OPNDLY S
OPNDLY M
ACTIVE
OVERLOAD OPENING
LIGHT HEAVY
ERD STATUS GATE STATUS
Eagle Diamond Control Board
Rev A4
TIMER
MIN
MASTER
SLAVE
MAX
1
ON
2 3 4 5 6 7 8
M/S PHASE
01
CLOSING
SELECT
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
CLOSE
STOP
OPEN
SLAVE MASTER
+ – + –
#14#13
+ MAGLOCK - 24 VDC
#10
+ ALARM - 12 VDC
#11
MAGLOCK RELAY
#9
POWER
24 VAC
#12
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
GND
GND
RCVR
24VAC
#1
LOOP WIRE INPUT
EXIT
OPEN
SHADOW
LOOP
REVERSE
LOOP
COMM PORTOUTPUTSGLOBAL INPUTS
RECEIVER
REVERSE LOOP SHADOW LOOP EXIT LOOP
REVERSE SHADOW EXIT
RESET
OFF ON
Power Switch
To Set the Limit
Switches:
Loosen set screw and
rotate top and bottom
limit switch activators
accordingly.
Set Screw
Feature Selector #2
GATE STATUS
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOS
LOS
Indicates the
direction the
gate is cycling.
Bottom Limit
Switch
Top Limit
Switch
GATE STATUS
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
CLOS
LOS
MASTER/SLAVE INPUT POWER NOTE:
Industrial setting using 3-phase must be
on the same phase.
Single Operator 120 VAC Input Wire
Guidelines
Green
120 VAC Input Power Wire
Black wire to Black wire.
White wire to White wire.
Green wire to Green wire.
Black
White
120 VAC
Diamond Board ONLY

11
Emergency Release Clutch Reset Motor
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
Emergency Release
Reset the Motor
Adjusting the Clutch
Unscrew bolt, remove top cap
and rotate easy release lever.
Depending on the weight of the gate, clutch
slippage may occur. Typical clutch slippage is
about 1/4 turn. If it does not slip, re-adjust the
clutch accordingly.
There is a red reset button on top of the 115 VAC motor. If the
motor ceases to function, TURN THE POWER OFF AND ALLOW
THE MOTOR TO COOL DOWN, then press the reset button.
These two
gaps should
remain even
for proper fit.
Diamond Board ONLY

12
Timer
Outputs ERD Reverse Sensor
ACTIVE
OVERLOAD OPENING
LIGHT HEAVY
ERD STATUS
CLOSING
V
V
V
V
OV
O
O
O
O
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
2 3 4 5 6 7 8
SELECT
Two-Way Adjustable Reverse Sensor / ERD Emergency Reversing Device
Output Connection Descriptions
Close Timer for a Single or Master Operator
IMPORTANT: The level of sensitivity
has to do with the weight of the gate
and the condition of the installation.
A heavier gate will require LESS
sensitivity and a lighter gate will
require MORE sensitivity.
Only a qualified service technician must make all adjustments to these sensors.
Proper function of reverse sensor (ERD):
When meeting an obstruction in the CLOSING direction, the gate will STOP, reverse direction and return to the FULL OPEN position.
When meeting an obstruction in the OPENING direction, the gate will STOP and reverse its direction and stop again after 4-6 inches. The gate
operator will stay in an “OVERLOAD” state for 5 minutes or until manually reset.
If the gate operator enters overload status two times in a row, the alarm will sound until manually reset.
When adjusting the sensors sensitivity:
TOO sensitive - If the gate stops or reverses by itself.
NOT sensitive enough - If the gate strikes an object
and does NOT stop or reverse.
Fine tune adjustment is ONLY necessary when stopping force
cannot be achieved within normal reverse sensor ERD range.
Three (3) full turns sets ERD in the “Normal Range”:
•Turn Clockwise for MORE force beyond normal range.
•Turn Counter-Clockwise for LESS force than normal range.
The Diamond Control Board has a sensitivity adjustment for the OPENING direction and
CLOSING direction of the gate. Both MUST be adjusted.
Adjustment must be made so that the gate stops and reverses when meeting an
obstruction equal to approximately 20 lbs. of stopping force.
NOTE: See page 15 for
master/slave close timer setup.
Clockwise increases close time.
Turn the close timer ON (#8) and adjust the TIMER from 1 to 60 seconds.
OVERLOAD LED: The OVERLOAD
LED warning light will light up when
the gate is heavier than normal for the
operator. During this warning, the
operator will NOT function properly.
CAUTION
TIMER
MIN
MAX
Feature Selector #8 (Switch #1 must be ON)
Less
Force
More
Force
More
Force
Less
Force
#9 MAGLOCK RELAY: (NO-COM-NC Relay) - Can be used to control higher powered maglocks
that can’t be powered by the diamond board’s #10 output connection.
#10 MAGLOCK (24 VDC): Provides a 24 VDC and relay output for maglock or solenoid locks.
#11 ALARM (12 VDC): Safety Alarm - If the gate hits an obstruction twice while closing or
opening, the system will shut down for 5 minutes. On the diamond board, you have two options
of reset mode (Feature Selector switch #7):
OFF setting - The system will require a “Manual Reset” of the board after the gate
hits an obstruction twice while closing or opening.
ON setting - The system will automatically reset itself.
#12 POWER (24 VAC): Provides 24 VAC power which can be used for external loop detectors
and receivers.
OUTPUTS
+ MAGLOCK - 24 VDC
#10
+ ALARM - 12 VDC
#11
POWER
24 VAC
#12
MAGLOCK RELAY
#9
COM
NO
NC
More
Sensitive Less
Sensitive
Factory Set ERD Sensor “Fine Tune” Adjustment:
Please call Eagle Access before adjusting this sensor!
Opening
Gate
Direction
Closing
Gate
Direction
LIGHT HEAVY
Diamond Board ONLY

13
Global Input Descriptions
Radio Receiver Connection
#2 REVERSE LOOP: Momentary or continuous signal - This input is active
only when the gate is closing or when its fully open, if this input is active.
The close timer is disabled. Vehicle loop detectors and photo sensors
should be connected here. Multiple devices may be connected in parallel.
#3 PHANTOM LOOP (SHADOW): Momentary or continuous signal - This
input is active only when the gate is at rest in the fully open position. The
input has no effect on the gate when fully closed or while closing or
opening. Continuous activation will prevent the gate from moving in the
close direction. When the input is removed, normal operation is resumed.
The input is intended for a vehicle loop detector to sense a vehicle in the gate path. Multiple devices may be connected in parallel.
#4 EXIT LOOP: Momentary or continuous signal - Once activated, the gate will fully open. Activation while the gate is closing will cause the
gate to re-open. Continuous activation while the gate is open will disable the close timer from automatically closing the gate.
#5 STOP: Momentary or continuous signal - This function overrides all other signals. Once activated, the gate will immediately stop and wait
for a new command to be given. If the stop input is continuously activated, the gate will not move. A jumper wire has been factory installed in
this input for the operator to function normally. It must be removed ONLY when using the 3-Button Station, see next page.
#6 KEY / KEYPAD:
Close Timer ON - Momentary or continuous signal - Once activated, the gate will fully open. Activation while the gate is closing will cause
the gate to re-open. Continuous activation while the gate is open will disable the close timer from automatically closing the gate.
Close Timer OFF - Momentary input - This function must be released and reentered to be recognized. This input is to be used for
COMMAND OPEN / COMMAND CLOSE applications. The first signal will cause the gate to begin opening. The second signal will close the
gate only when the gate is in the fully open position.
#7 CLOSE: Momentary or continuous signal - Once activated, the gate will fully close. Activation while the gate is opening will cause the gate
to stop. Activating the gate again will close the gate.
#8 EDGE SENSOR: Momentary or continuous signal - This signal is active when the gate is opening and/or closing.
If activated when the gate is OPENING: The gate will stop, pause and reverse in the close direction for 1 1/2 seconds and stop.
Continuous activation will prevent the gate from moving in the opening direction. If the second activation occurs before the limit switch is
activated, the gate will stop and reverse direction for 1 1/2 seconds and stop. Thus activating the ALARM MODE. At this point, the operator
must be manually reset (OFF/ON) before normal operation can resume.
If activated when the gate is CLOSING: The gate will stop, pause and fully re-open. During this mode, the timer to close, reverse loop, exit
loop and phantom loop are disabled. The key/keypad and receiver will cause the gate to close if a second activation occurs before the limit
switch is activated. The gate will stop and reverse direction for 1 1/2 seconds and stop again, thus activating the ALARM MODE. At this
point, the operator must be manually reset (OFF/ON) before normal operation can resume.
Radio receiver terminal is mounted on the outside of the control box for easy
installation and is pre-wired for a 3-wire or a 4-wire receiver. The Radio receiver
terminal is wired to the control board #1 as shown below.
3
Wire
24V
RADIO POWER RELAY
RELAY RET
3214
(24V)
COMMON GROUND
4
Wire
24V
RADIO POWER RELAY
(24V)
RET
3-Wire Receiver
3
Wire
24V
RADIO POWER RELAY
RELAY RET
3214
(24V)
COMMON GROUND
4
Wire
24V
RADIO POWER RELAY
(24V)
RET
4-Wire Receiver
Radio
Receiver
Terminal
Black
Grey
Grey
Red
3
Wire
24V
RADIOPOWER RELAY
RELAYRET
3214
(24V)
COMMONGROUND
4
Wire
24V
RADIOPOWER RELAY
(24V)
RET
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
GLOBAL INPUTS
Jumper Wire
GND
GND
RCVR
24VAC
#1
RECEIVER
Control Board
Connection #1
Radio Receiver
Terminal Wires
From #1
From #2
From #3
From #4
White
Orange
Red
Black
NOTE: Radio Receiver
can be connected to
the master or slave
operator for
master/slave setup.
Global Inputs Radio Receiver
Diamond Board ONLY

14
+ MAGLOCK - 24 VDC
#10
MAGLOCK RELAY
#9
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
OUTPUTSGLOBAL INPUTS
Connecting Accessories
Safety Equipment
Safety Equipment
External Phantom
Loop (Shadow Loop)
Detector
External Exit Loop
Detector
3-Button
Station
4-Wire Connection
Dry Contact
24 VDC
Max
Open
Close
Stop
External Reverse Loop
Detector
Key
Switch
Lock Box
Dry Contact
Fire Dept.
Lock Box
Dry Contact
Maglock
Edge
Sensor
Photocell Sensor
Phone Entry
System
Separate
Power
In-Ground
Reverse Loop
In-Ground
Reverse Loop
Separate
Power
Separate
Power
In-Ground
Phantom Loop
(Shadow Loop)
Separate
Power
In-Ground
Exit Loop
Transmitter
Receiver
Separate
Power
Connecting Accessories
Diamond Board ONLY

15
Diamond Board Master / Slave Setup
BYEAGLEACCESS CONTROL SYSTEMS, INC. BYEAGLEACCESS CONTROL SYSTEMS, INC.
IMPORTANT: The 115 VAC power for the master and slave operators MUST be on the same circuit breaker.
It is recommended that each gate operator’s initial set-up is completed (Direction of gate travel, limit
switches, ERD reverse sensor and feature selector switches #1 - #4) before connecting the operators
together. After each operator functions individually, proceed to Master/Slave connection and operation.
NOTE: #1 & #2 switch settings are
based on the illustration above.
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
2 3 4 5 6 7 8
SELECT
MASTER
Operator SLAVE Operator
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
2 3 4 5 6 7 8
SELECT
Connect Master and Slave Operators Together
Choose your board type and use 20 GA stranded wire.
Correct polarity is VERY important. DO NOT cross
polarity. Operators will NOT function properly if not
wired correctly.
SLAVE MASTER
+ – + –
#14#13
COMM PORT
SLAVE MASTER
+ – + –
#14#13
COMM PORT
Use the feature selector to choose #2 - #8
options for the master operator. Switch #1
MUST be ON. Refer to page 9 for more
information about each of the features.
Use the Close Timer (#8 ON) on the
master board only to set the gates
closing time 1 - 60 seconds.
Use the feature selector to choose #2 - #3
options for the slave operator. Switch #1
MUST be OFF. Switch #4 is not used.
Refer to page 9 for more information
about each of the features.
If NO gate delay is needed:
Switches #5 - #8 MUST be OFF.
Setting the OPEN Delay Feature:
#5 OPEN DELAY S: Turning #5 - ON delays opening the SLAVE gate by 1.5 seconds.
# 6 must be turned OFF. This is useful for magnetic lock applications.
#6 OPEN DELAY M: Turning #6 - ON delays opening the MASTER gate by 1.5 seconds.
# 5 must be turned OFF. This is useful for magnetic lock applications.
Setting the CLOSE Delay Feature:
#7 CLOSE DELAY S: Turning #7 - ON delays closing the SLAVE gate by 1 - 6 seconds,
adjustable by the close timer on the slave board. #8 must be turned OFF.
#8 CLOSE DELAY M: Turning #8 - ON delays closing the MASTER gate by 1 - 6 seconds,
ad
j
ustable b
y
the close timer on the slave board. #7 must be turned OFF.
ACCESSORIES NOTE: The Diamond Board
allow you to connect accessories to the master
or slave boards).
See page 14 for accessory wiring connections.
Opens to the Left Opens to the Right
Feature Selector (Master Operator)
Close Timer (Master Operator)
Feature Selector (Slave Operator)
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
MASTER
SLAVE
1
ON
2 3 4 5 6 7 8
SELECT
Feature Selector (Slave #5 - #8)
Switch #1 MUST be OFF (Slave Operator)
Gate Delay Functions
For overlapping bi-parting gates
Diamond
Board
ONLY
(Slave Operator)
Diamond
Board
ONLY
(Master Operator)
TIMER
MIN
MAX
TIMER
MIN
MAX
Close Timer on the
slave operator
1 - 6 seconds
Diamond Board Master / Slave
Diamond Board ONLY

16
Diamond Board Troubleshooting
Gate stops and
reverses direction
in mid cycle and
the OVERLOAD
LED remains ON.
(A) Gate operator is not plumb and level.
(B) ERD current sensor may be set too sensitive.
(C) Gate encountered an obstruction while cycling.
(A) The radio receiver’s LED remains on.
(B) One or more of the global input LEDs remain active.
(C) Gate has re-opened because in encountered an
obstruction while closing.
(D) The loop detector LED is on.
(E) Switch #8 CLOSE TIMER is not functioning.
(A) The radio receiver or remote control has
malfunctioned in the “ON” position.
(B) Check global inputs for a short circuit.
(C) Only Key/Keypad will resume normal operation.
(D) Reset loop detector. Verify correct loop wiring. Set
loop detector to a different frequency and/or change the
sensitivity of the loop detector.
(E) Be sure Switch #8 is in the “ON” position.
(A) Motor Overload LED is on.
(B) Radio receiver is not “ON” when the remote
control button is activated.
(C) The green “Power” LED is off.
(D) The Fuse is blown.
• Feature selector Switch #1 MUST be set to the “MASTER ON” position unless the operator is being used as a slave operator.
• Safety external loop detector must be connected to the “REVERSE LOOP” input (see pages 13 & 14).
• If the CLOSE TIMER feature is desired, switch #8 MUST be in the “ON” position.
• It is OK to call the Eagle Access Customer Service Department with any questions... we are here to serve YOU!
1-800-708-8848
(A) Reset motor (see page 11).
(B) Radio receiver has malfunctioned in the “OFF”
position.
(C) Turn on operator power switch and/or reset the main
circuit breaker.
(D) Check and/or replace the fuse with same amp fuse.
(A) Remount operator.
(B) Turn the ERD current sensor slightly in the
clockwise direction.
(C) Check and remove all obstructions
Gate will not close.
Gate will not open.
SYMPTOMS PROBABLE CAUSE
COMMON OVERSIGHTS TO BE AWARE OF:
REMEDY
Diamond Board Troubleshooting
Diamond Board ONLY

17
Diamond Board Wiring Diagram
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS
STOP-REVERSE
ALM-RST
CLOSE TIMER
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
OPN DLY S
OPN DLY M
OPN DLY S
OPN DLY M
ACTIVE
OVERLOAD OPENING
LIGHT HEAVY
ERD STATUS GATE STATUS
Eagle Diamond Control Board
Rev A4
TIMER
MIN
MASTER
SLAVE
MAX
1
ON
2 3 4 5 6 7 8
M/S PHASE
01
CLOSING
SELECT
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
CLOSE
STOP
OPEN
SLAVE MASTER
+ – + –
#14#13
+ MAGLOCK - 24 VDC
#10
+ ALARM - 12 VDC
#11
MAGLOCK RELAY
#9
POWER
24 VAC
#12
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
GND
GND
RCVR
24VAC
#1
LOOP WIRE INPUT
EXIT
OPEN
SHADOW
LOOP
REVERSE
LOOP
COMM PORTOUTPUTSGLOBAL INPUTS
RECEIVER
REVERSE LOOP SHADOW LOOP EXIT LOOP
REVERSE SHADOW EXIT
RESET
Eagle-100 / Eagle-200 Models Wiring Diagram
Radio
ReceiverTerminal
Dual Motors
Limit Switches
Power
Switch
115 VAC
Outlet
115 VAC
Input
Eagle-100
Eagle-200Eagle-200-DMEagle-200-1HP
Orange N.O. (Top Switch)
Ground
Black
White
Green
Red
White Black Red Orange
Black
Gray
Gray
Gray
2 1/2” Pulley2 1/2” Pulley 2” Pulley2” Pulley
Red
Red
Red
Blue
Green
Green Com
Black
Hot
Black
12-Pin
Plug
12-Pin Plug12-Pin Plug12-Pin Plug
Green
Green
Gray
Red
Blue
Blue Blue
Blue
White
Neutral
Yellow N.O. (Bottom Switch)
OFF
ON
1/2 HP
Motor
1 HP
Motor
1/2 HP
Motor
1/2 HP
Motor
3
Wire
24V
RADIO POWER RELAY
RELAY RET
3214
(24V)
COMMON GROUND
4
Wire
24V
RADIO POWER RELAY
(24V)
RET
2
12
11
10
9
8
7
6
5
4
3
2
1
3
4
17
8
1
2
3
4
7
8
9
11
12
1
4
6
2
7
8
11
12
11
12
9
10
5
6
Junction Box
Diamond Board
Alarm
Motor Wire Configurations
Adding YOUR selected
operator motor wire
configuration from the
three illustrations below to
this 12-pin plug will
complete YOUR selected
operator wiring diagram.
Diamond Board ONLY

18
3
Wire
24V
RADIOPOWER RELAY
RELAYRET
3214
(24V)
COMMONGROUND
4
Wire
24V
RADIOPOWER RELAY
(24V)
RET
MASTER
OPENRIGHT
BRAKEON
REVERSELOOP NC
ONEPASS
STOP-REVERSE
ALM-RST
CLOSETIMER
OFF—ON
SLAVE
OPENLEFT
BRAKEOFF
REVERSELOOP NO
OPNDLYS
OPNDLYM
OPNDLYS
OPNDLYM
ACTIVE
OVERLOAD OPENING
LIGHT HEAVY
ERDSTATUS GATESTATUS
Eagle Diamond Control Board
Rev A4
TIMER
MIN
MASTER
SLAVE
MAX
1
ON
2 3 4 5 6 7 8
M/SPHASE
01
CLOSING
SELECT
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
CLOSE
STOP
OPEN
SLAVE MASTER
+ – + –
#14#13
+MAGLOCK -24 VDC
#10
+ALARM -12 VDC
#11
MAGLOCK RELAY
#9
POWER
24VAC
#12
REVERSE LOOP
#2
PHANTOM LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
GND
GND
RCVR
24VAC
#1
LOOPWIRE INPUT
EXIT
OPEN
SHADOW
LOOP
REVERSE
LOOP
COMMPORTOUTPUTSGLOBALINPUTS
RECEIVER
REVERSELOOP SHADOW LOOP EXITLOOP
REVERSE SHADOW EXIT
RESET
BY EAGLE ACCESSCONTROLSYSTEMS,INC.
Eagle-100 / Eagle-200 Series Replacement Parts
E101 - Eagle-100 Limit Switch Assembly (Complete)
E102 - Eagle-100 Limit Switch Bracket
E103 - Limit Switch
E104 - Eagle-200 Limit Switch Bracket
E105 - Eagle-200 Limit Switch Assembly (Complete)
E111 - Eagle-100 Operator Cover
E114 - Eagle-100 Release Cover
E115 - Eagle-100 Release Cover Cap
E116 - Easy Release Main Swing Arm
E130 - Electrical Outlet
E131 - Power Switch
E146 - Pulley (SGR)
E147 - 2 1/2” Motor Pulley (1/2 HP or 1 HP)
E148 - 2” Motor Pulley (DM)
E151 - Eagle-200 limit Chain #35
E152 - Clutch Kit (Complete)
E153 - Eagle-200 Sprocket (SGR)
E173 - 1/2 HP V-Belt (Single Motor)
E174 - 1 HP/Dual Motor V-Belt
E175 - Limit Switch Activator
E180 - Eagle-200 Primary Gear Reducer (PGR)
E182 - Eagle-100 Primary Gear Reducer (PGR)
E185 - 1/2 HP Motor
E186 - Secondary Gear Reducer (SGR)
E190 - Eagle-200 Chassis
E191 - Control Board Box
E192A - Eagle-200 Right Chassis Leg
E192B - Eagle-200 Left Chassis Leg
E193 - Eagle-200 Leg Bracket
E195 - Eagle-100 Chassis
E196A - Eagle-100 Right Chassis Leg
E196B - Eagle-100 Left Chassis Leg
E197 - Eagle-100 Leg Bracket
E222 - Eagle-200 Operator Cover
E223 - Operator Cover Door Frame
E224 - Operator Cover Door
E225 - Eagle-200 Release Cover
E226 - Eagle-200 Release Cover Cap
E471 - Large Arm
E472 - Small Arm
E473 - Arm Attachment Plate
E475 - Extension Arm
E476 - Weld Plate (Gate Attachment Bracket)
E515 - Swing Arm Assembly (Complete)
E525 - Plastic Eagle Logo Plaque
E555 - Diamond Control Board
E721 - Arm Hub
E722 - Plastic Cup
E723 - Sprocket (PGR)
E724 - Pillow Block
E725 - Limit Sprocket
E726 - Limit Shaft
E727 - Limit Box
E728 - Eagle-100 Limit Chain #35
E729 - Drive Chain #50 (Side Position)
E-Number Part Description
Right
Leg
Left
Leg
E180/
E182
Right
E192A/
E196A
Left
E192B/
E196B
E193/
E197
E727
E725
E175
E190/
E195
E724
E151/
E728
E721
E116
E722
E723
E185
E225/
E114
E226/
E115
E222/
E111
Complete Limit
Switch Assembly
E105/E101
Complete Clutch Kit E152
Complete Swing
Arm Assembly
E515
E223
E224
E525
E186
E146
E147 E148
E103
E473
E471
E472
E475
E476
E102/
E104
V-Belt
E173/
E174 (DM)
E191
E555
E131
E726
E130
E153
E729
If you are uncertain about a specific
part you may need, please call us for
assistance:
1-800-708-8848
Diamond Board Replacement Parts
Diamond Board ONLY
