Eagle EGS140 User manual

GRAVITY FEED
SPRAY GUN
MODEL EGS140
www.eaglecompressor.com
1-800-551-2406
OWNERS MANUAL

2
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
2
READ THE ENTIRE MANUAL BEFORE
PUTTING THIS TOOL IN SERVICE
DESCRIPTION
Eagle Air tools are manufactured in accordance with our strict specications and designed
to be used in light duty professional or serious DIY applications. When used in accordance
with warnings and instructions given in this manual, and when properly applied and main-
tained they should give you many years of productive and trouble free service.
This tool is NOT designed for professional, production or industrial use, when used in these
applications its life expectancy will be signicantly shortened and the warranty will be void.
Limited Air Tool Warranty
Eagle warrants air tools of its own manufacture against defects in workmanship and
materials under normal use and service for twelve(12) months from date of purchase by
original purchaser. Parts are covered by this warranty for ninety(90) days from date of
purchase.
The following expandable items are warranted against defects in workmanship and
materials for ninety(90) days from date of purchase: sockets, screw driver bits and
accessories, sanding and back-up pads, impact mechanism, chisels and their retain-
ers, cutting and grinding accessories and any other expandable items not specically
mentioned.
Normal wear and tear, service or maintenance items such as O-rings, springs, gaskets,
packing or seals, uid needles and nozzles, motor vanes or blades, collets, chucks or
any such item not specically mentioned are covered for ninety(90) days from date of
purchase warranty only.
Eagle will, at its sole discretion, repair or replace the tool or parts that have failed within
the warranty period. If repairs are considered, they will be scheduled in the normal
course of the workow at its service centre.
Not covered under this warranty:
• Indirect or consequential loss or damage or expenses resulting from the
failure or malfunction of this tool.
• Accidents or failures resulting from owners neglect, abuse or failure to oper-
ate and maintain the tool in accordance with the instructions provided in the
owner’s manual.
• Tampering, removal or alterations of safety devices will void this warranty.
• Blemishes or cosmetic defects which do not effect the tool’s operation.
• Tools used industrially, commercially or in rental applications.
To claim warranty the owner/purchasers must provide proof of purchase and mainte-
nance records, and when requested ship or deliver at owner/purchasers expense and
cost to Eagle’s factory or service centre

3
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
3
TABLE OF CONTENTS
Limited Warranty ...............................................................................................2
Description.........................................................................................................2
Inspection..........................................................................................................3
Safety Instructions.............................................................................................3
Maintenance......................................................................................................4
Operation...........................................................................................................4
Troubleshooting.................................................................................................5
Parts Breakdown...............................................................................................6
Tool Specications.............................................................................................7
INSPECTION
Upon receipt of your new tool, carefully check for any shipping damage. If your new tool is
damaged in shipping you need to le a claim with the carrier at once, and before contacting
Eagle’s customer service department.
Also carefully check to make sure all accessories (if included) are with the tool. Make sure
any loose bolts, ttings etc. are tightened before you put this tool into service.
SAFETY INSTRUCTIONS
You should operate this air tool only if you have read this entire manual, and understand
its content, and you are familiar with safety and proper use when operating this equipment.
This air tool is part of a high pressure compressed air system, the following safety precau-
tions must be followed at all times.
1) All persons in the work area must always wear approved eye and ear protection and
approved breathing apparatus when this spray gun is in operation.
2) Never aim spray gun at anyone. Do not spray near sparks, open ame, lit cigarettes,
pilot lights, space heaters or any other potential ignition source. DO NOT SMOKE IN
WORK AREA.
3) Follow manufacturers instructions and safety information to ensure safe handling and
proper use of paints, lacquers, thinners, base coats, etc. Do not use latex or other
heavy paints. They are not recommended for this spray gun.
4) WARNING! Solvents trichloroethane and methylene chloride (dichlormethane
- sometimes called methylchloride) can chemically react with aluminum used in most
spray equipment creating an explosion hazard. Read the label or data sheet from the
materials you intend to spray. NEVER USEANY MATERIALS CONTAINING THESE
SOLVENTS. If unsure as to the composition oy your material, check with your supplier.
Do not use acids for cleaning.
5) Always keep work area free from obstructions and well ventilated.
6) Always disconnect spray gun from air source before disassembly.

4
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
Air and uid volume controls: These two controls
are used in conjunction with each other to accurately
adjust air/uid (Paint) ratio and will vary for different
paints. Changing one control affects the other so
alternating back and forth between them to ne tune
your adjustment will yield optimum results
Air volume control: Air volume is adjusted by turning
the air knob control. Turning knob in reduces volume,
turning knob out increases volume.
Fluid volume control: Fluid volume is adjusted by
turning the uid volume control knob. Turning knob
in decreases volume, turning knob out increases vol-
ume. Once a satisfactory volume is set, you can lock
the adjustment by turning the lock nut in tight.
Fluid Volume Lock Nut
Fluid Volume control
MAINTENANCE
Clean gun before and after each use. To protect the precision machined internal parts
and ttings in this gun from corrosion during shipping, some oils or other corrosion resistant
agents may have been applied. It is important to remove any such residue before attempt-
ing to use the gun. To clean, place a small amount of appropriate thinner into paint cup
and spray through gun while pulling and releasing trigger repeatedly. Wipe exterior of gun,
nozzles and paint cup. In some cases if the gun becomes clogged, disassemble completely
and soak all parts in thinner. After soaking, use a thin cleaning brush to clear small internal
passages. Check and clean paint cup lter, when installed. Replace if worn.
A clean air source is imperative to ensure peak performance. The use of an in-line air lter
is highly recommended to keep any contaminants from entering the spray gun.
In some painting applications proper air drying and ltration equipment may be required.
Inspect all ttings and hardware to ensure proper seating. Be sure air line ttings are tight
with no leaks. Replace any worn parts as necessary.
Check needle and nozzles for nicks, scratches or burrs. Any such conditions will seriously
impair performance. Replace as necessary.
OPERATION

5
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Half-Moon shaped pat-
tern.
This is usually caused by
clogged air holes on the air
nozzle ears.
Carefully clean out holes with wire
after soaking in thinner
Irregular or offset pattern.
1) A dirty or damaged
needle tip or uid nozzle.
2) Clogged atomization
holes on air nozzle around
the center.
1) Clean or replace needle or uid
nozzle.
2) Clean air nozzle.
Spitting.
1) Too little material in cup.
2) Loose uid nozzle.
3) Damaged needle pack-
ing.
4) Dirty or damaged needle
and nozzle set.
1) Rell cup.
2) Tighten nozzle.
3) Replace packing.
4) Clean or replace parts.
Material in cup bubbles
or boils.
1) Loose, clogged or dam-
aged uid nozzle.
2) Loose, clogged or dam-
aged air nozzle.
1) Clean, tighten or replace.
2) Clean, tighten or replace.
Your spray gun was constructed with quality materials and workmanship and will give you
many years of trouble free use when cared for and descr bed in the maintenance section of
this manual. However, as with any mechanical device periodic adjustments are necessary
to maintain a peak level of performance. Should your spray gun be displaying any of the
following symptoms, the simple procedures below will correct the problem.

6
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
PARTS BREAKDOWN
INDEX PART DESCRIPTION QTY
1 CF29701 Gun Body 1
2 CF29702 Regulate Plug 1
3 CF29703 Washer 2
4 CF29704 Washer 1
5 CF29705 Nut 1
6 CF29706 Handle 1
7 CF29707 Air Inlet Bushing 1
8 CF29709 Washer 2
9 CF29710 O-Ring 1
10 CF29711 Needle Valve Bushing 1
11 CF29712 Needle Valve 1

7
Wear hearing protection.
Wear eye protection.
Wear respiratory protection. Read the instruction manual
12 CF29713 Spring 1
13 CF29714 Valve Body 1
14 CF29715 O-Ring 1
15 CF29716 Regulator 1
16 CF29717 Needle 1
17 CF29718 Spring 1
18 CF29719 Washer 1
19 CF29720 Fluid Volume Control Knob 1
20 CF29721 Valve 1
21 CF29722 E-Clip 1
22 CF29723 Washer 2
23 CF29724 Spring 1
24 CF29725 O-Ring 1
25 CF29726 Spray Regulator Nut 1
26 CF29727 Spray Regulator Screw 1
27 CF29728 E-Clip 2
28 CF29729 Trigger 1
29 CF29730 Trigger Pivot Pin 1
30 CF29731 Retainer Ring 1
31 CF29732 Washer 1
32 CF29733 Air Nozzle 1
33 CF29734 Fluid Nozzle 1
34 CF29735 Nylon Gasket 1
35 CF29756 Plug 1
36 CF29736 Paint Cup Bushing 1
37 CF29737 Gasket 1
38 CF29738 Paint Cup Assembly 1
39 CF29740 Washer 1
Air Pressure..............................................................................................................50 PSI
Spray Head & Needle..............................................................................................2.0 mm
Cup Capacity............................................................................................................600 ml
Average air consumption (CFM)...................................................................................16.3
Fluid Inlet (NPT) ............................................................................................................3/8”
Air inlet (NPT)................................................................................................................1/4”
Hose size (ID)................................................................................................................3/8”
