EAGTAC GX25L2 User manual
EAGTAC
High Performance Tactical Flashlight
http://www.eagletac.com
GX / MX / SX
User Manual
Models
Quick Start Guide
1) Unscrew the tailcap and remove the
battery isolation disk at the end of the
battery to use. If your ashlight does not
come with battery, insert new batteries
(w/ protrude top) to use. Ensure positive
terminals is facing the LED. Replace
tailcap and tighten snugly.
Adjusting output level
Twist the head to select between four
output levels. You can pre-select the
desired output level
before turning on
the flashlight.
Basic ON and OFF
Turn on the light by press and release
the on/o button switch (<0.4s). To turn
o the light, press and release the
switch again.
For momentary on,
press and hold
the button
switch for
immediate
output.
EAGTAC GX25L2, SX25L2 and MX25L2
models oer maximum output perfor-
mance, versatile user interface, tough
build quality and rich accessories like no
other ashlight oers. This series is
designed for police, professionals, and
hobbyists.
WARNING - Lithium and Li-ion batteries
can explode or cause burns if disas-
sembled, shorted, or exposed to high
temperature. Do not mix with used or
other battery types or install backwards.
IMPORTANT - Only use the integrated built-in
charging socket to charge the original EAGTAC
7.4V battery pack. Charging unbalanced third
party 7.4V 18650 battery pack, two individual
3.7V li-ion cells, or any non-rechargeable batter-
ies (e.g. 3V CR123A) may result in ashlight
damage or even battery leak or explosion.
LED (Front) Tail-cap (Back)
1st level
2nd, 3rd,
4th level
Hidden AUX. settings
With the head at tight position (1st
level), loosen to 3rd (or 4th level) and
tighten the head within one second to
enter AUX. setting. Repeat to cycle
through all settings. Turn o the light or
loosen the head to quit.
Strobe (I/II) Hi-Flash S.O.S. (I/II)
Beacon Lo-Flash
To switch between tactical and regular
mode, turn on the ashlight at 1st level,
dial to 2nd level and then back to 1st
level for ve times within ve seconds.
Tactical Mode
100%
10%
Strobe I
Strobe II
Regular Mode
100%
35%
6%
0.1%
Level
1st
2nd
3rd
4th
Battery Isolation Disk
Quick Specifications
GX25L2 series
LED
Output
Circuit
Battery
CREE XM-L2/XP-L /XHP
Nichia 219 / Luminus SST90/SBT70
4 brightness levels + AUX
C3500/C4000/W1900/C9500
EAGTAC 2x18650 battery pack
SX25L2 series
Battery EAGTAC 2x26650 battery pack
MX25L2 series
Battery EAGTAC 2x32650 battery pack
HD
HI
35 50 70 .1/.2
Battery Safety Precaution
Battery with protruding positive terminal
is required for ashlight with physical
battery reverse protection. For recharge-
able li-ion battery, use EAGTAC li-ion
battery, or other li-ion battery with com-
patible length, diameter, and perfor-
mance. EAGTAC will not hold any respon-
sibility for incompatibility or damage
caused by third party battery or charger.
Before using any battery, check and
ensure the battery outer wrapping (the
isolating plastic lm that wraps around
the metal housing of the battery) is com-
plete. Broken battery wrapping may lead
to short circuit and damage to the ash-
light.
Lithium/Li-ion battery can explode or
cause burns if disassembled, exposed to
high temperature, or shorted. Do not mix
new/fully charged and used batteries. Do
not mix batteries with dierent brand,
capacity, voltage, or install batteries
backwards. When output starts to dim or
low battery voltage warning appears,
lower output level to extend runtime,
and replace or recharge batteries when-
ever possible. It is a good practice to not
drain the batteries completely. When you
are not going to use the ashlight for a
long period of time,
remove all batteries
from the ashlight.
