EAGTAC SX25L3 User manual
EAGTAC
High Performance Tactical Flashlight
http://www.eagletac.com
SX25L3
User Manual
Quick Start Guide
1) Unscrew the tailcap
and insert batteries
refering to the diagram
on the right (this shows
the back of the head).
Ensure positive terminals
To replace the tailcap,
align the columns to
the holes on the back
of the ashlight body.
Insert the tailcap and
tighten snugly.
of the batteries are facing the brass
contact, and the negative terminals
facing the silver coated copper spring.
Basic ON and OFF
Turn on the light by press and release
the on/o button switch (<0.4s). To turn
o the light, press and release the
switch again.
For momentary on,
press and hold
the button switch
for immediate
output.
EAGTAC SX25L3 packs big 2750 lumen in
a very compact and convenient body. It
oers versatile user interface, tough
build quality and rich accessories like no
others. Be crazy lumen output be you
with in the dark.
WARNING - Lithium and Li-ion batteries
can explode or cause burns if disas-
sembled, shorted, or exposed to high
temperature. Do not mix with used or
other battery types or install backwards.
Battery Safety Precaution
When the combined voltage falls below
9.1V, the LED will ash once every minute
to remind you that the battery is almost
out. Lower the output to extend runtime
and replace/recharge batteries. Remove
batteries if you are not going to use the
ashlight for a long period of time.
Quick Specifications
LED
LED Lumen
ANSI Lumen
Runtime
Beam distance
Output
Circuit
Batteries
Voltage
MT-G2 P0
2750
2375
1.5-350 hrs
347 yards
4 brightness level + 7 AUX
C5000 ST
3x18650, or 6xCR123A
5.4V-19V
XM-L2 U2
1505
1245
2.7-370 hrs
507 yards
On/O
Switch
Brightness
Adjustment
Tailcap
All EagleTac ashlights are designed to
use “button-top” battery (battery with
protruding positive terminal). For
rechargeable li-ion battery, use only
EagleTac li-ion battery, or other
protected li-ion battery with compatible
length and diameter. Before using the
battery, check and ensure the battery
outer wrapping (the isolating plastic lm
that wraps around the metal housing of
the battery) is complete. Broken battery
wrapping may lead to short circuit and
damage to the ashlight.
Lithium and Li-ion battery can explode
or cause burns if disassembled, shorted,
or exposed to high temperature. Do not
mix new and used batteries. Do not mix
batteries with dierent brand, capacity,
voltage, or install batteries backwards.
When the output starts to dim (this
implies battery is almost drained),
replace the batteries do not drain the
batteries completely especially when
you’re using multiple batteries wired in
series like this setup.
Adjusting output level
Twist the head to select between four
output levels. You can pre-select your
desired output
level before
turning on
the flashlight.
Maintenance
Periodically clean the thread and o-rings
with a lint free cloth and apply a thin coat-
ing of EagleTac silicon-based lubricant to
the o-rings.
Clean the battery contact, signal contact
(the gold coated pins and PCB contact
area on the body tube), and machined
thread with a lint free cloth and use a
small drop of Deoxit red cleaner solution
(D100L series) to slightly lube them for
better conductivity and smoother mode
switching experience.
Color and diuser lter
Kit models come with diuser and color
lters. Unscrew the stainless steel bezel
and replace it with the lter to use.
Tail-cap with switch
For kit versions that comes with extra
tailcap and body that is setup with rear
signal connection, user may operate the
ashlight with the rear switch.
1) Check and replace batteries
2) Ensure tailcap is tight
3) Clean all conductive contacts
(see maintenance section)
4) Check battery polarity
Troubleshooting - Flashlight does not
turn on or fails to switch between
outputs normally:
1st level
2nd, 3rd,
4th level
“No Hassle” EAGTAC Warranty
For repair, replacement, or other inquiries
contact your EAGTAC dealer. You can also
reach our customer support via email at
We warrant our ashlights to be free from
defects in workmanship and materials. We will
repair, replace at our option, without charging
any product or part which is found to be
defective under normal use within 120
months from the date of purchase with the
proof of purchase.
Electronics, chargers and rechargeable batter-
ies are covered for a period of 12 months with
purchase receipt. Such repair or replacement
shall be the purchaser’s sole and exclusive
remedy under this warranty. Normal wear and
tear including batteries draining is not
covered, nor is damage resulting from modi-
cation, misuse, abuse, neglect, faulty battery,
battery leakage, reversed charging damage,
improper maintenance or repaired by anyone
other than EAGTAC or authorized dealer.
Do not touch or attempt to clean the
reector, as it will damage the reective
coating permanently.
Hidden AUX. settings
With the head at tight position (1st
level), loosen to 3rd or 4th level and
tighten the head within one second to
enter AUX. setting. Repeat to cycle
through all settings. Turn o the light
or loosen the head to quit.
Strobe (I/II) Hi-Flash S.O.S. (I/II)
Beacon Lo-Flash (Repeat)
Instant Turbo output
At any output level, press and hold the
on/o switch for 100% output. Release
the button to return to previous level.
Instant Strobe output
At any output level (even o ), double
press and hold the on/o button switch
for strobe output. Release the button to
return to previous level.
Energy saving feature
Enabled by default, this feature
reduces output by 25% (or 10% when
disabled) after 200 seconds at turbo
mode. To toggle this feature, turn on
the ashlight at 4th level, and dial to
3rd level and then back to 4th level for
ten times within ve seconds.
To switch between tactical and regular
mode, turn on the ashlight at 1st level,
switch to 2nd level and then back to 1st
level for ten times within ve seconds.
Tactical Mode
100%
12%
Strobe I
Strobe II
Regular Mode
100%
45%
8%
1%
Level
1st
2nd
3rd
4th
“Deoxit” is a trademark of Caig Laboratories,
Periodically clean
and apply Deoxit
red to ensure
smooth mode
switching and good
long term reliability.
How to prolong battery life
1) Recharge often. No need to discharge
the battery completely before charging
as li-ion has no memory eect.
2) To prolong li-ion battery life, drain the
battery to 3.75V or below, and discon-
nect it from the ashlight before putting
it in long-term storage.
