EarthLinked SC Series Programming manual

SC-410-QS (05/11) Copyright 2011 Earthlinked Technologies, Inc.
EarthLinked®
SC Series Compressor Unit
R-410A
Quick-Start Instructions
CONTENTS
PAGE
Pre-Installation
3
Placement & Mechanical Information
4
System Application Options
10
Electrical and Sound Data
14
230-1-60 Internal Wiring
15
230-3-60 Internal Wiring
17
460-3-60 Internal Wiring
19
575-3-60 Internal Wiring
21
Field Wiring Diagram
23
System Start-Up
25
•
Initial Charge
25
•
Final Charge
27
•
Cooling Assist Valve Adjustment
33

SC-410-QS (05/11)
Disclaimer
Proper installation of the EarthLinked®Heating and Cooling System is essential to its reliable
performance. All EarthLinked®systems must be installed by an authorized, trained technician who
has successfully completed the training class and passed the final examination. Installation must
be made in accordance with the instructions set forth in this manual and the current EarthLinked
Heating and Cooling Installation, Operation and Maintenance Manual. Failure to provide
installation by an authorized, trained installer in a manner consistent with the subject manuals will
void and nullify the limited warranty coverage for the system.
READ THE CURRENT EarthLinked Heating and Cooling Installation, Operation and
Maintenance Manual FOR COMPLETE INSTALLATION DETAILS.
EarthlinkedTechnologies shall not be liable for any defect, unsatisfactory performance, damage or
loss, whether direct or consequential, relative to the design, manufacture, construction, application
or installation of the field specified components.
Earthlinked Technologies, Inc.
4151 South Pipkin Road
Lakeland, Florida 33811
tel. [phone] ● fax [phone]
[e-mail] ● www.earthlinked.com
CSI # 23 80 00

SC-410-QS (05/11) Page 3
Pre-Installation
Upon receipt of the equipment, carefully check the shipment against the bill of lading. Reference
EarthLinked®matching system component model numbers in Figure 1. Make sure all units have
been received and model numbers are the same as those ordered.
Compressor
Unit1Air Handler Cased Coil Hydronic Water Module
Domestic
Water
Module
Auxiliary
Cooling
Module
3
Earth
Loop2
Cathodic
Protection
System
-018 AVS-1824 CCS-1824 V/H HWM-1836 DWM-1836 ACM-018 -018C CPS-1830
-024 HWM-1836 DWM-1836 ACM-024 -024C CPS-1830
-030 AVS-3036 CCS-3036 V/H HWM-1836 DWM-1836 ACM-030 -030C CPS-1830
-036 HWM-1836 DWM-1836 ACM-036 -036C CPS-3642
-042 AVS-4248 CCS-4248 V/H HWM-4248 DWM-4248 ACM-042 -042C CPS-3642
-048 HWM-4248 DWM-4248 ACM-048 -048C CPS-4872
-060 AVS-6000 CCS-6000 V/H HWM-6072 DWM-6072 ACM-060 -060C CPS-4872
1. All series Compressor Units: CC, SC, SD, SCW, SW, HC, HCW, HW, HWW
Contained in each compressor package:
•compressor unit
•four L-shaped hold down brackets
•service valves-liquid and vapor
•adapters for service valves and earth loop line set
•product literature
2. All series Earth Loops: V1, D1, T1, V1.5, D1.5, V2, D2, D3, H1, H5
3. ACMs are for CC, SC, SD, SCW and SW compressor units only.
Note: Desuperheater and all EarthLinked®thermostats can be utilized throughout capacity range.
Figure 1. Model Numbers
Guidelines for the general layout of the system components are shown in Figure 2. Before placing
the compressor unit (outside or indoors), review the guidelines in Figure 2.

SC-410-QS (05/11) Page 4
Figure 2. General System Layout
Placement
EarthLinked®compressor units may be located outside or inside the building, following these
guidelines.
OUTSIDE
Locate compressor unit:
•On a standard HVAC condensing unit pad, resting on firm, level, settled ground.
•Same as for INSIDE placement. See below.
INSIDE
Locate compressor unit:
•On a solid, level hard surface. If compressor unit is to be fastened, see Figure 3 for bracket
installation.
•Where compressor unit sound and vibration will not disturb human activities. Compressor unit
may be located in garage, basement, crawl space or utility room. Avoid placing compressor unit
in kitchen, bedroom, family/living/dining room areas.
•In a condensate pan.
•On vibration pads.
•Attic installations, where necessary, must include a drip pan, anti-vibration pads and are to be
suspended from the rafters with suspension isolators.

SC-410-QS (05/11) Page 5
•For SD compressor units (which have potable domestic water connections) where the
surrounding air temperature remains above 40°F.
•Where suggested clearance is 3 feet on both sides, top and front, for access. However, local
codes and applicable regulations take precedence. Clearance from back panel to wall and
minimum side clearance should be at least one foot. See Figure 4 for details.
•Where the total length of refrigerant line sets (from manifolds to compressor and from
compressor to air handler) do not exceed 125 feet, as shown in Figure 2.
•Where the compressor unit is no more than 20 feet higher than the earth loop manifolds.
Compressor unit may be located lower than the earth loop manifolds. See Figure 2.
•For SCW, HCW and HWW compressor units providing radiant panel hydronic hot water, where
the hydronic primary circuit is adequately protected from freezing by controlling the surrounding
lowest air temperature to 40oF minimum and/or providing an industry approved anti-freeze and
water mixture for the surrounding lowest air temperature.
Figure 3. Compressor Unit Bracket Installation
Figure 4. Compressor Unit Clearance

SC-410-QS (05/11) Page 6
Compressor units are shipped from the factory with a low pressure nitrogen holding charge.
Carefully relieve the holding charge when the compressor unit is being prepared to connect
refrigerant system piping.
The compressor unit package contains a service valve kit and an adapter kit. The two service
valves are to be installed on the earth loop vapor and liquid connections of the compressor
unit, using the adapters to right-size to the proper earth loop line set.
Installation of the service valves will provide isolation of the earth loop system from the compressor
unit and provide easy access to the refrigerant system.
The service valve configuration provided is illustrated in Figure 4a. The ball valve stem is
accessed by removing the cap. The service port is equipped with a Schrader valve insert.
Figure 4a. Service Valve Orientation
Complete service valve installation instructions are contained in the Service Valve Kit Installation
Manual, included with the service valves.

SC-410-QS (05/11) Page 7

SC-410-QS (05/11) Page 8
Figure 5. SC Connections for R-410A

SC-410-QS (05/11) Page 9
Figure 6. SC Internal Flow Schematic

SC-410-QS (05/11) Page 10
Figure 7. SC Piping

SC-410-QS (05/11) Page 11
Figure 8a. SC Air Heating and Cooling

SC-410-QS (05/11) Page 12
Figure 8b. SC Air Heating and Cooling; Domestic Hot Water by Field-Installed
Desuperheater Kit

SC-410-QS (05/11) Page 13
Figure 9. SC Radiant Panel Hydronic Heating and Air (Chilled Water) Cooling

SC-410-QS (05/11) Page 14
Compressor
Model Voltage/Phase/Hz
Voltage
LRA RLA MCA MFS
Sound Pressure Level *
@10 ft, dB(A)
Min.
Max.
-018-1C 230-1-60 207 253 58.3 15.0 18.0 30 57.0
-024-1C 230-1-60 207 253 64.0 14.3 18.0 30 57.0
-024-2C 230-3-60 207 253 58.0 9.3 11.0 20 60.0
-024-3C 460-3-60 414 506 28.0 5.7 7.9 15 60.0
-030-1C 230-1-60 207 253 77.0 15.7 19.0 30 59.0
-030-2C 230-3-60 207 253 71.0 10.0 12.0 20 60.0
-030-3C 460-3-60 414 506 38.0 6.3 8.0 15 60.0
-030-6C 575-3-60 518 632 38.5 4.2 5.0 10 60.0
-036-1C 230-1-60 207 253 112.0 20.0 25.0 40 59.0
-036-2C 230-3-60 207 253 88.0 15.1 19.0 30 62.0
-036-3C 460-3-60 414 506 44.0 6.6 8.0 15 62.0
-036-6C 575-3-60 518 632 34.0 5.5 7.0 10 62.0
-042-1C 230-1-60 207 253 117.0 24.3 30.0 45 59.0
-042-2C 230-3-60 207 253 83.1 15.3 19.0 30 62.0
-042-3C 460-3-60 414 506 41.0 6.9 8.0 15 62.0
-042-6C 575-3-60 518 632 33.0 5.4 7.0 10 62.0
-048-1C 230-1-60 207 253 134.0 27.9 34.0 50 59.0
-048-2C 230-3-60 207 253 110.0 17.7 22.0 35 62.0
-048-3C 460-3-60 414 506 52.0 7.9 10.0 15 62.0
-048-6C 575-3-60 518 632 39.5 5.7 7.0 10 62.0
-060-1C 230-1-60 207 253 158.0 33.6 41.0 60 65.0
-060-2C 230-3-60 207 253 155.0 22.9 28.0 45 65.0
-060-3C 460-3-60 414 506 75.0 10.7 13.0 20 65.0
-060-6C 575-3-60 518 632 54.0 8.5 10.0 15 65.0
LRA = Locked Rotor Amps MFS = Maximum Fuse or HACR Circuit Breaker Size
RLA = Rated Load Amps (External)
MCA = Minimum Circuit Ampacity AWG = Consult NEC and Local Codes
*Data Source is published Copeland Compressor Sound Power Levels converted to Sound Pressure Level in
dB(A) at 10 Feet, having two reflective surfaces. Effects of ETI compressor unit cabinet and components not
included.
Figure 10. Compressor Unit Electrical and Sound Data

SC-410-QS (05/11) Page 15
Figure 11. SC Electrical Ladder Diagram (230-1-60)

SC-410-QS (05/11) Page 16
Figure 12. SC Electrical Schematic (230-1-60)

SC-410-QS (05/11) Page 17
Figure 13. SC Series 230-3-60 Electrical Ladder Diagram

SC-410-QS (05/11) Page 18
Figure 14. SC Series 230-3-60 Electrical Schematic

SC-410-QS (05/11) Page 19
Figure 15. SC Series 460-3-60 Electrical Ladder Diagram

SC-410-QS (05/11) Page 20
Figure 16. SC Series 460-3-60 Electrical Schematic
