EARTHQUAKE XT EQ34XT-20V Assembly instructions
Visit our website at: http://www.harborfreight.com
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 21i
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for a s s e m b l y a n d s e r v i c e m a y n o t b e i n c l u d e d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety ......................................................... 2
Specifications ............................................. 7
Setup .......................................................... 7
Operation.................................................... 8
Maintenance.............................................. 10
Parts Lists and Diagrams .......................... 14
Warranty .................................................... 16
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
General Power Tool Safety Warnings
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
7KHWHUPƎSRZHUWRROƎLQWKHZDUQLQJVUHIHUVWR\RXUEDWWHU\RSHUDWHGFRUGOHVVSRZHUWRRO
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
FUHDWHVSDUNVZKLFKPD\LJQLWHWKHGXVWRUIXPHV
3. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
Page 3For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Electrical Safety
Do not expose power tools to rain or wet conditions.
:DWHUHQWHULQJDSRZHUWRROZLOOLQFUHDVHWKHULVNRIHOHFWULFVKRFN
Personal Safety
1. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power
tool while you are tired or under the
influence of drugs, alcohol or medication.
$PRPHQWRILQDWWHQWLRQZKLOHRSHUDWLQJSRZHU
WRROVPD\UHVXOWLQVHULRXVSHUVRQDOLQMXU\
2. Use personal protective equipment.
Always wear eye protection. Protective
HTXLSPHQWVXFKDVGXVWPDVNQRQVNLGVDIHW\
VKRHVKDUGKDWRUKHDULQJSURWHFWLRQXVHGIRU
DSSURSULDWHFRQGLWLRQVZLOOUHGXFHSHUVRQDOLQMXULHV
3. Prevent unintentional starting.
Ensure the Trigger is in the off-position before
connecting to power source, picking up or
carrying the tool.
&DUU\LQJSRZHUWRROVZLWK\RXUILQJHURQ
WKH7ULJJHURUHQHUJL]LQJSRZHUWRROVWKDW
have the Trigger on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on.
$ZUHQFKRUDNH\OHIWDWWDFKHGWRDURWDWLQJSDUW
RIWKHSRZHUWRROPD\UHVXOWLQSHUVRQDOLQMXU\
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
RIWKHSRZHUWRROLQXQH[SHFWHGVLWXDWLRQV
6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry
RUORQJKDLUFDQEHFDXJKWLQPRYLQJSDUWV
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Only use safety equipment that has been
approved by an appropriate standards agency.
8QDSSURYHGVDIHW\HTXLSPHQWPD\QRWSURYLGH
DGHTXDWHSURWHFWLRQ(\HSURWHFWLRQPXVWEH
$16,DSSURYHGDQGEUHDWKLQJSURWHFWLRQ
PXVWEH1,26+DSSURYHGIRUWKH
VSHFLILFKD]DUGVLQWKHZRUNDUHD
Power Tool Use and Care
1. Do not force the power tool. Use the
correct power tool for your application.
7KHFRUUHFWSRZHUWRROZLOOGRWKHMREEHWWHUDQG
safer at the rate for which it was designed.
2. Do not use the power tool if the Trigger
does not turn it on and off.
$Q\SRZHUWRROWKDWFDQQRWEHFRQWUROOHGZLWKWKH
7ULJJHULVGDQJHURXVDQGPXVWEHUHSDLUHG
3. Disconnect the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
tools. 6XFKSUHYHQWLYHVDIHW\PHDVXUHVUHGXFH
WKHULVNRIVWDUWLQJWKHSRZHUWRRODFFLGHQWDOO\
4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
DUHFDXVHGE\SRRUO\PDLQWDLQHGSRZHUWRROV
6. Keep cutting tools sharp and clean.3URSHUO\
PDLQWDLQHGFXWWLQJWRROVZLWKVKDUSFXWWLQJHGJHV
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
SRZHUWRROIRURSHUDWLRQVGLIIHUHQWIURPWKRVH
intended could result in a hazardous situation.
Page 4 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Battery tool use and care
1. Recharge only with the charger specified by
the manufacturer. A charger that is suitable
IRURQHW\SHRIEDWWHU\SDFNPD\FUHDWHDULVN
RIILUHZKHQXVHGZLWKDQRWKHUEDWWHU\SDFN
2. Use power tools only with specifically
designated battery packs. Use of any other
EDWWHU\SDFNVPD\FUHDWHDULVNRILQMXU\DQGILUH
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair person using only identical replacement parts.
7KLVZLOOHQVXUHWKDWWKHVDIHW\RIWKHSRZHUWRROLVPDLQWDLQHG
Impact Wrench Safety Warnings
1. Hold power tools by insulated gripping surfaces
when performing an operation where the cutting
tool may contact hidden wiring or its own cord.
&RQWDFWZLWKDƎOLYHƎZLUHZLOOPDNHH[SRVHGPHWDO
SDUWVRIWKHWRROƎOLYHƎDQGVKRFNWKHRSHUDWRU
2. The amount of actual torque may vary depending
on the cleanness and condition of the threads and
other factors. If tightening critical components,
check the actual torque applied to the fastener
with a mechanical torque wrench (not supplied).
3. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
4. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
5. Do not lay the tool down until it has come to
a complete stop. Moving parts can grab the
surface and pull the tool out of your control.
6. When using a handheld power tool,
maintain a firm grip on the tool with both
hands to resist starting torque.
7. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
8. The battery Charger gets hot during
use. The Charger’s heat can build up
to unsafe levels and create a fire
hazard if it does not receive adequate
ventilation, due to an electrical fault, or if it is used
in a hot environment.
Do not place the Charger on a flammable surface.
Do not obstruct any vents on the Charger.
Especially avoid placing the Charger on carpets
and rugs; they are not only flammable, but they
also obstruct vents under the Charger.
Place the Charger on a stable, solid, nonflammable
surface (such as a stable metal workbench
or concrete floor) at least 1 foot away from
all flammable objects, such as drapes or
walls. Keep a fire extinguisher and a smoke
detector in the area. Frequently monitor the
Charger and Battery Pack while charging.
9. This product is not a toy.
Keep it out of reach of children.
10. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
11. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
Page 5For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE
A LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep Battery Pack dry.
2. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
a. Open,
b. Drop,
c. Short-circuit,
d. Puncture,
e. Incinerate, or
f. Expose to temperatures greater than 140°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
Vibration Safety
This tool vibrates during use.
Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for
an extended period should first be examined
by a doctor and then have regular medical
check-ups to ensure medical problems are not
being caused or worsened from use. Pregnant
women or people who have impaired blood
circulation to the hand, past hand injuries,
nervous system disorders, diabetes, or
Raynaud’s Disease should not use this tool.
If you feel any symptoms related to vibration (such
as tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration
when there is a choice.
5. Include vibration-free periods each day of work.
6. Grip tool as lightly as possible (while still keeping
safe control of it). Let the tool do the work.
7. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
SAVE THESE INSTRUCTIONS.
Page 6 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the charger. Do not use the
charger if the power cord or plug is damaged. If damaged, have it repaired by a service facility
before use. If the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.
Extension Cords
Note: Extension cords must not be used with this item’s Charger.
Symbology
Double Insulated
VVolts
~Alternating Current
AAmperes
n0xxxx/min. No Load Revolutions
per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking concerning
Risk of Hearing Loss.
Wear hearing protection.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Page 7For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Specifications
Impact Rate 0 – 2200 IPM
Anvil Size 3/4"
Battery Pack 56596 20V Li-Ion (sold separately)
Charger 56595 20V Li-Ion (sold separately)
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to the Parts Lists and Diagrams on page 14.
Functions
Direction
Switch
Battery
Release Button
Work
Light
Battery
Trigger
Anvil
Page 8 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Make sure that the Trigger is in the off-position and remove the Battery
Pack before performing any procedure in this section.
Battery Charging
Charge battery after unpacking and before using this tool. Follow instructions included with battery charger.
Attaching/Removing Sockets
CAUTION! Only use impact rated accessories
with this tool. Other accessories may
shatter, chip, or crack during operation.
1. Connect an appropriate, impact rated square
drive socket (not included) onto the Anvil. Make
sure the socket snaps securely into place
2. To remove, pull socket forward off of the Anvil.
Socket Anvil
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Secure loose workpieces using a vise or clamps
(not included) to prevent movement while working.
3. There must not be objects, such as utility lines,
nearby that will present a hazard while working.
Page 9For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
General Operating Instructions
1. Make sure that the Trigger is in the off-position
and the Direction Switch is in the centered, Trigger
Lock position, then attach the Battery Pack.
2. Push and snap socket (not included) onto the Anvil.
3. Set Direction Switch.
Forward: Push Switch in on right side
(arrow pointing forward) for clockwise rotation.
Reverse: Push Switch in on left
side (arrow pointing backward) for
counter-clockwise rotation.
Trigger Lock: Push Switch to the
center to lock the Trigger.
CAUTION! Set Direction Switch to center
Trigger Lock position during set up, when
changing sockets or when tool is idle.
Push
for
Reverse
Push
for
Forward
Push Switch to Center toPush Switch to Center to
LOCK TRIGGERLOCK TRIGGER
NOTICE: Do not change direction of rotation
while Anvil is rotating. Wait until Anvil has come
to a complete stop before changing direction.
4. Position the socket over the fastener.
5. Press Trigger to start the tool. The Work
Light will turn on when Trigger is pressed
and turn off when Trigger is released.
6. The tool has variable speed. To increase
speed, apply more pressure to Trigger. To
decrease speed, lessen pressure on Trigger.
7. Tighten or loosen the fastener(s) as required.
Note: The amount of actual torque will vary depending
on the cleanness and condition of the threads and
other factors. If tightening critical components,
chase threads before assembling components and
check the actual torque applied to the fastener
with a mechanical torque wrench (not supplied).
8. When finished using the Impact Wrench, release
Trigger and center Direction Switch to lock Trigger.
9. To prevent accidents, turn off the tool and
remove its Battery Pack after use. Clean, then
store the tool indoors out of children’s reach.
Page 10 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Make sure that the Trigger is in the off-position and remove the Battery
Pack before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• leaking, swollen, or cracked battery pack
• loose hardware
• misalignment or binding of moving parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
Page 11For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will
not start.
1. Battery Pack not properly
connected.
2. Battery Pack not
properly charged.
3. Battery Pack worn out.
4. Internal damage or wear.
(Carbon brushes or
Trigger, for example.)
1. Remove Battery Pack, make sure there are
no obstructions, clean battery contacts on
tool, reinsert the Battery Pack according to its
shape (it should only fit one way), and press
firmly until the Battery Pack locks in place.
2. Make sure Charger is connected and operating properly.
Give enough time for Battery Pack to recharge properly.
3. Dispose of old Battery Pack properly or recycle.
Replace Battery Pack.
4. Have technician service tool.
Tool operates
slowly.
1. Forcing tool to work too fast.
2. Battery Pack wearing out.
1. Allow tool to work at its own rate.
2. Dispose of old Battery Pack properly or recycle.
Replace Battery Pack.
Excessive noise
or rattling.
Internal damage or
wear. (Carbon brushes or
bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect Battery Pack and Charger power supply before service.
Page 12 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Page 13For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Parts may not be interchangeable. Specify
number when ordering. Specify UPC 193175470140 when ordering parts.
Page 14 For technical questions, please call 1-888-866-5797. Item 64350
SAFETY OPERATION MAINTENANCESETUP
Parts Lists and Diagrams
Parts List
Part Description Qty
1 Enclosure 1
2 Direction Switch 1
3 Panel 1
4 LED Cover 1
5 Screw 9
6 Screw 4
7 Soft Pad 1
8 Front Cover 1
9 Washer 1
10 Needle Roller Bearing 1
11 Anvil 1
12 Steel Ball 1
13 Motor Bracket 1
14 Shaft 4
15 Ring Gear 1
16 C-Clip 1
17 Paper Washer 1
18 O-Ring 1
19 C-Clip 1
20 Hammer 1
21 Needle Roller Bearing 1
22 Spring 1
Part Description Qty
23 Spindle 1
24 Steel Ball 2
25 Planet Gear 3
26 Shaft 3
27 Washer 1
28 Ball Bearing 1
29 Washer 1
30 Armature 1
31 Stator Assembly 1
32 Carbon Brush Base 1
33 Pinion Gear 1
34 Thermal Shrink Tube 2
35 Switch 1
36 Trigger 1
37 PCB LED Assembly 1
38 Thermal Shrink Tube 2
39 Terminal Holder 1
40 Internal Wiring 1
41 Internal Wiring 1
42 20 V Battery Pack (not shown) 1
43 20 V Charger (not shown) 1
44 Case (not shown) 1
Page 15For technical questions, please call 1-888-866-5797.Item 64350
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Diagram
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion
may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Table of contents
