SDM630Pulse
DIN Rail Smart Meter for Single and Three Phase Electrical Systems
Measures kWh Kvarh, KW, Kvar, KVA, P,
F, PF, Hz, dmd, V, A, etc.
Bi-directional measurement IMP & EXP
Two pulse outputs
Din rail mounting 35mm
100A direct connection
 Better than Class 1 / B accuracy
USER MANUAL
2014 V1.0

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
1
-
Introduction
This document provides operating, maintenance and installation instructions . The unit measures
and displays the characteristics of single phase two wires(1p2w) , three phase three wires(3p3w,)
and three phase four wires(3p4w) supplies, including voltage, frequency, current, power ,active
and reactive energy, imported or exported. Energy is measured in terms of kWh, kVArh.
Maximum demand current can be measured over preset periods of up to 60 minutes. In order to
measure energy,the unit requires voltage and current inputs in addition tot he supply required to
power the product.
SDM630Pulse supports max. 100A direct connection,saves the cost and avoid the trouble to
connect external CTs,giving the unit a cost-effective and easy operation.Built-in interfaces
provides pulse.Configuration is password protected.
Unit Characteristics
The Unit can measure and display:
Line voltage and THD% (total harmonic distortion) of all phases
Line Frequency
Currents, Current demands and current THD% of all phases
Power, maximum power demand and power factor
Active energy imported and exported
Reactive energy imported and exported
The unit has password-protected set-up screens for:
Changing password
Supply system selection 1p2w, 3p3w,3p4w
Demand Interval Time(DIT)
Reset for demand measurements
Pulse output duration
Two pulse output indicates real-time energy measurement.
Pulse output
This provides two pulse outputs that clock up measured active and reactive energy. The constant
of pulse output 2 for active energy is 400imp/kWh(unconfigurable),its width is fixed at 100ms.
The default constant of configurable pulse output 1 is 400imp/kWh,default pulse width is
100ms.The configurable pulse output 1 can be set from the set-up menu.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
2
-
Start-up Screens
1 The first screen lights up all display
segments and can be used as a display
check
2 The second screen indicates the
firmware installed in the unit and its
build number.
3 The interface performs a self-test and
indicates the result if the test passes.
After a short delay, the screen will display active energy measurements.
Measurements
The buttons operate as follows:
1 Selects the Voltage and Current display screens
In Set-up Mode, this is the “Left” or “Back” button.
2 Select the Frequency and Power factor display
screens
In Set-up Mode, this is the “Up” button
3 Select the Power display screens
In Set-up Mode, this is the “Down” button
4 Select the Energy display screens
In Set-up mode, this is the “Enter” or “Right” button
Voltage and Current
Each successive pressing of the button selects a new range:

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
3
-
1-1 Phase to neutral voltages(3p4w)
1-2 Phase to neutral voltages(3p3w)
2 Current on each phase
3-1 Phase to neutral voltage THD%(3p4w)
3-2 Phase to neutral voltage THD%(3p3w)
4 Current THD% for each phase

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
4
-
Frequency and Power factor and Demand
Each successive pressing of the button selects a new range:
1 Frequency and Power Factor (total)
2 Power Factor of each phase
3 Maximum Power Demand
4 Maximum Current Demand
Power
Each successive pressing of the button select a new range:
1 Instantaneous Active Power in kW

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
5
-
2 Instantaneous Reactive Power in kVAr
3 Instantaneous Volt-amps in KVA
4 Total kW, kVArh, kVA
Energy Measurements
Each successive pressing of the button selects a new range:
1-1 Imported active energy in kWh
1-2 Exported active energy in kWh

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
6
-
2-1 Imported reactive energy in kVArh
2-2 Exported reactive energy in kVArh
3-1 Total active energy in kWh
3-2 Total reactive energy in kVArh
Set-up
To enter set-up mode, pressing the button for 3 seconds, until the password screen
appears.
Setting up is password-protected so you must enter the correct password (default ‘1000’) before
processing. If an incorrect password is entered, the display will show: Err

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
7
-
To exit setting-up mode, press repeatedly until the measurement screen is restored.
Set-up Entry Methods
Some menu items, such as password,require a four-digit number entry while others, such as
supply system, require selection from a number of menu options.
Menu Option Selection
1) Use the and buttons to select the required item from the menu shown in
section 4.1. selection does not roll over between bottom and top of list
2) Press to confirm your selection
3) If an item flashes, then it can be adjusted by the and buttons. If not, there
maybe a further layer.
4) Having selected an option from the current layer, press to confirm your selection.
The SET indicator will appear.
5) Having completed a parameter setting, press to return to a higher menu level. The
SET indicator will be removed and you will be able to use the and buttons for
further menu selection.
6) On completion of all set-up, press repeatedly until the measurement screen is
restored.
Number Entry Procedure
When setting up the unit , some screens require the entering of a number. In particular, on entry
to the setting up section, a password must be entered. Digits are set individually, from left to
right. The procedure is as follows:
1) The current digit to be set flashes and is set using the and buttons
2) Press to confirm each digit setting. The SET indicator appears after the last digit has
been set.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
8
-
3) After setting the last digit, press to exit the number setting routine. The SET indicator
will be removed.
Change password
1
Use the and to choose
the change password option
2-1
Press the to enter the change
password routine. The new password
screen will appear with the first digit
flashing
2-2
Use and to set the first
digit and press to confirm your
selection. The next digit will flash.
2-3 Repeat the procedure for the remaining
three digits
2-4 After setting the last digit, SET will show.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
9
-
Press to exit the number setting routine and return to the Set-up menu. SET will be
removed
DIT Demand Integration Time
This sets the period in minutes over which the current and power readings are integrated for
maximum demand measurement. The options are: off, 5, 8,10,15 30,60 minutes
1
From the set-up menu, use and
buttons to select the DIT option.
The screen will show the currently
selected integration time.
2-1
Press to enter the selection
routine.
The current time interval will flash
2-2
Use and buttons to
select the time required.
2-3
Press to confirm the selection.
SET indicator will appear.
Press to exit the DIT selection routine and return to the menu.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
10
-
Backlit set-up
1 The backlit lasting time is settable
Default lasting time is 60minutes
For example,if it’s setted as 5,the backlit
will be off in 5minutes from the last
time operation on the meter.
2
Press to enter the selection
routine. The current time interval will
flash
The options can be:
0/5/10/30/60/120minutes
Use and buttons to select the time required.Press to confirm the
set-up,
Supply System
Use this section to set the type of power supply being monitored.
1
From the Set-up menu, use
and buttons to select the
System option. The screen will show the
currently selected power supply .
2-1
Press to enter the selection
routine. The current selection will flash
2-2
Use and buttons to
select the required system option:
1P2(W),3P3(W) ,3P4(W)

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
11
-
2-3
Press to confirm the selection.
SET indicator will appear.
Press to exit the system selection routine and return to the menu. SET will disappear
and you will be returned to the main Set-up Menu
Pulse output
This option allows you to configure the pulse output 1. The output can be set to provide a pulse
for a defined amount of energy active or reactive.
Use this section to set up the pulse output—Units:
Total kWh/ Total kVArh/Import kWh/Export kWh/Import KVArh/Export KVArh
1
From the Set-up menu, use
and buttons to select the
Pulse output option.
2-1
Press to enter the selection
routine. The unit symbol will flash.
2-2
Use and buttons to
choose kWh or kVArh.
On completion of the entry procedure, press to confirm the setting and press
to return to the main set up menu.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
12
-
Pulse rate
Use this to set the energy represented by each pulse. Rate can be set to 1 pulse per
0.0025kWh/0.01kWh/0.1kWh/1kWh/10kWh/100kWh.
(It shows 1 impulse = 10kWh/kVArh)
1
From the Set-up menu, use
and buttons to select the Pulse
Rate option.
2
Press to enter the selection
routine. The current setting will flash.
0.0025/0.01/0.1/1/10/100kWh/kVArh
per pulse
Note:When it’s 0.0025,the LED display
dft(default)
Use and buttons to choose pulse rate.On Completion of the entry
procedure, press to confirm the setting and press to return to the main set
up menu.
Pulse Duration
The energy monitored can be active or reactive and the pulse width can be selected as 200, 100
or 60ms.
(It shows pulse width of 200ms)

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
13
-
1-1
From the Set-up menu, use
and buttons to select the Pulse
width option.
1-2
Press to enter the selection
routine. The current setting will flash.
Use and buttons to choose pulse width.On Completion of the entry
procedure, press to confirm the setting and press to return to the main set
up menu.
CLR
The meter provides a function to reset the maximum demand value of current and power.
1
From the Set-up menu, use
and buttons to select the reset
option.
2
Press to enter the selection
routine. The MD will flash.
Press to confirm the setting and press to return to the main set up menu.
Specifications
Measured Parameters
The unit can monitor and display the following parameters of a single phase two wire(1p2w),
three phase three wire(3p3w) or four phase four wire(3p4w) supply.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
14
-
Voltage and Current
Phase to neutral voltages 100 to 289V a.c. (not for 3p3w supplies)
Voltages between phases 173 to 500V a.c. (3p supplies only)
Percentage total voltage harmonic distortion (THD%) for each phase to N ( not for 3p3w supplies)
Percentage voltage THD% between phases (three phase supplies only)
Current THD% for each phase
Power factor and Frequency and Max. Demand
Frequency in Hz
Instantaneous power:
Power 0 to 3600 MW
Reactive Power 0 to 3600 MVAr
Volt-amps 0 to 3600 MVA
Maximum demanded power since last Demand reset Power factor
Maximum neutral demand current, since the last Demand reset (for 3p4w supply only)
Energy Measurements
Imported active energy 0 to 999999.99 kWh
Exported active energy 0 to 999999.99 kWh
Imported reactive energy 0 to 999999.99 kVArh
Exported reactive energy 0 to 999999.99 kVArh
Total active energy 0 to 999999.99 kWh
Total reactive energy 0 to 999999.99 kVArh
Measured Inputs
Voltage inputs through 4-way fixed connector with 2.5mm²stranded wire capacity. single phase
two wire(1p2w), three phase three wire(3p3w) or four phase four wire(3p4w) unbalanced. Line
frequency measured from L1 voltage or L3 voltage.
Accuracy
Voltage 0·5% of range maximum
Current 0·5% of nominal
Frequency 0·2% of mid-frequency
Power factor 1% of unity (0.01)
Active power (W) ±1% of range maximum
Reactive power (VAr) ±2% of range maximum
Apparent power (VA) ±1% of range maximum
Active energy (Wh) Class 1 IEC 62053-21
Reactive energy (VARh) ±2% of range maximum
Total harmonic distortion 1% up to 31st harmonic
Temperature co-efficient Voltage and current = 0.013%/°C typical
Active energy = 0·018%/°C, typical
Response time to step input 1s, typical, to >99% of final reading, at 50 Hz.

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
15
-
Interfaces for External Monitoring
Three interfaces are provided:
an Pulse output(Pulse 1) indicating real-time measured energy.(configurable)
an pulse output(Pulse 2) 400imp/kWh
The pulse output assignments (kW/kVArh, import/export etc.) are configured through the Set-up
screens.
Pulse Output
The unit provides two pulse outputs. Both pulse outputs are passive type.
Pulse output 1 is configurable. The pulse output can be set to generate pulses to represent total /
import/export kWh or kVarh.
The pulse constant can be set to generate 1 pulse per:
dft = 2.5 Wh/VArh
0.01 = 10 Wh/VArh
0.1 = 100 Wh/VArh
1 = 1 kWh/kVArh
10 = 10 kWh/kVArh
100 = 100 kWh/kVArh
Pulse width: 200/100/60ms
Pulse output 2 is non-configurable. It is fixed up with active kWh. The constant is 400imp/kWh.
Reference Conditions of Influence Quantities
Influence Quantities are variables that affect measurement errors to a minor degree. Accuracy is
verified under nominal value (within the specified tolerance) of these conditions.
Ambient temperature 23°C ±1°C
Input waveform 50 or 60Hz ±2%
Input waveform Sinusoidal (distortion factor < 0·005)
Magnetic field of external origin Terrestrial flux
Environment
Operating temperature -25°C to +55°C*
Storage temperature -40°C to +70°C*
Relative humidity 0 to 90%, non-condensing
Altitude Up to 2000m
Warm up time 1 minute
Vibration 10Hz to 50Hz, IEC 60068-2-6, 2g

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
16
-
Dimensions
Wiring diagram
Three phase three wires Three phase four wires

EASTRON SDM630Pulse User Manual
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: [phone] Fax: [phone] Web: www.eastron.com.cn
-
17
-
Single phase two wires
