Eastron SDM630MCT-MBUS V2 User manual

EASTRON SDM630M CT User Manual
SDM630MCT-MBUS V2
DIN Rail Energy Meter for Single and Three Phase Electrical Systems
Measures kWh Kvarh, KW, Kvar, KVA, P,
F, PF, Hz, dmd, V, A, THD,etc.
Bi-directional measurement IMP & EXP
Two pulse outputs
MBUS
Din rail mounting 35mm
1/5A CT connection
Better than Class 1 / B accuracy
USER MANUAL
2016 V1.4
EASTRON Germany (B+G e-tech GmbH)
Franz-Mehring Str. 36 • DE 01979 Lauchhammer • Germany
ww.eastron-germany.de

EASTRON SDM630M CT User Manual
-1 -
Introduction
This document provides operating, maintenance and installation instructions. The unit measures
and displays the characteristics of single phase two wires (1p2w), three phase three wires(3p3w,)
and three phase four wires(3p4w) supplies, including voltage, frequency, current, power ,active
and reactive energy, imported or exported. Energy is measured in terms of kWh, kVArh.
Maximum demand current can be measured over preset periods of up to 60minutes. In order to
measure energy, the unit requires voltage and current inputs in addition to the supply required to
power the product. The requisite current input(s) are obtained via current transformers(CT).
This meter can be configured to work with a wide range of CTs, giving the unit a wide range of
operation. Built-in interfaces provides pulse and mbus outputs. Configuration is password
protected.
This unit can be powered from a separate auxiliary (AC or DC) supply. Alternatively it can be
powered from the monitored supply, where appropriate.
Unit Characteristics
The Unit can measure and display:
Line voltage and THD% (total harmonic distortion) of all phases
Line Frequency
Currents, Current demands and current THD% of all phases
Power, maximum power demand and power factor
Active energy imported and exported
Reactive energy imported and exported
The unit has password-protected set-up screens for:
Changing password
Supply system selection 1p2w, 3p3w,3p4w
Demand Interval time
Reset for demand measurements
Pulse output duration
Two pulse output indicates real-time energy measurement. An mbus output allows remote
monitoring from another display or a computer.
Current Transformer Primary Current
The unit can be configured to operate with CT ratio between primary current and secondary
current. The secondary CT has two options: 1A/5A
Mbus
This uses an MBus port with EN13753-3 protocol to provide a means of remotely monitoring and
controlling the Unit.
Set-up screens are provided for setting up the MBus port.

EASTRON SDM630M CT User Manual
-2 -
Pulse output
This provides two pulse outputs that clock up measured active and reactive energy. The constant
for active energy is 3200imp/kWh(Terminals 10&11). The pulse width for pulse 1(Terminals 9&10)
can be set from the set-up menu.
Start Up Screens
1
The first screen lights up all display segments
and can be used as a display check.
2
The second screen indicates the firmware
installed in the unit and its build number.
3
The interface performs a self-test and
indicates
the result if the test passes.
*After a short delay, the screen will display active energy measurements.
Measurements
The buttons operate as follows:
1
Selects the Voltage and Current display screens
In Set-up Mode, this is the “Left” or “Back”
button.
2
Select the Frequency and Power factor display
screens
In Set-up Mode, this is the “Up” button
3
Select the Power display screens
In Set-up Mode, this is the “Down” button

EASTRON SDM630M CT User Manual
-3 -
4
Select the Energy display screens
In Set-up mode, this is the “Enter” or “Right”
button
Voltage and Current
Each successive pressing of the button selects a new range:
1-1
Phase to neutral voltages(3p4w)
1-2
Phase to neutral voltages(3p3w)
2
Current on each phase
3-1
Phase to neutral voltage THD%(3p4w)
3-2
Phase to neutral voltage THD%(3p3w)

EASTRON SDM630M CT User Manual
-4 -
4
Current THD% for each phase
Frequency and Power factor and Demand
Each successive pressing of the button selects a new range:
1
Frequency and Power Factor (total)
2
Power Factor of each phase
3
Maximum Current Demand
4
Maximum Power Demand

EASTRON SDM630M CT User Manual
-5 -
Power
Each successive pressing of the button select a new range:
1
Instantaneous Active Power in kW
2
Instantaneous Reactive Power in kVAr
3
Instantaneous Volt-amps in KVA
4
Total kW, kVArh, kVA
Energy Measurements
Each successive pressing of the button selects a new range:
1-1
Imported active energy in kWh
--- PLEASE NOTE ---
The two lines of the displays in "E" show the
full value of the energy display. This means
you need to read from the top left to the
bottom right.
(e.g. current display show 0000031.4 kWh for import)

EASTRON SDM630M CT User Manual
-6 -
1-2
Exported active energy in kWh
2-1
Imported reactive energy in kVArh
2-2
Exported reactive energy in kVArh
3-1
Total active energy in kWh
3-2
Total reactive energy in kVArh
4
Mbus secondary address
It ranges from 00 00 00 01 to 99 99 99
99

EASTRON SDM630M CT User Manual
-7 -
Setting Up
To enter set-up mode, pressing the button for 3 seconds, until the password screen
appears.
Setting up is password-protected so you must enter the correct password (default ‘1000’) before
processing.
If an incorrect password is entered, the display will show: PASS Err
To exit setting-up mode, press repeatedly until the measurement screen is restored.
Set-up Entry Methods
Some menu items, such as password and CT, require a four-digit number entry while others, such
as supply system, require selection from a number of menu options.
Menu Option Selection
1) Use the and buttons to select the required item from the menu. Selection
does not roll over between bottom and top of list
2)Press to confirm your selection
3) If an item flashes, then it can be adjusted by the and buttons. If not, there
maybe a further layer.
4)Having selected an option from the current layer, press to confirm your selection. The
SET indicator will appear.

EASTRON SDM630M CT User Manual
-8 -
5)Having completed a parameter setting, press to return to a higher menu level. The
SET indicator will be removed and you will be able to use the and buttons for
further menu selection.
6) On completion of all setting-up, press repeatedly until the measurement screen is
restored.
Number Entry Procedure
When setting up the unit, some screens require the entering of a number. In particular, on entry
to the setting up section, a password must be entered. Digits are set individually, from left to
right. The procedure is as follows:
1) The current digit to be set flashes and is set using the and buttons
2) Press to confirm each digit setting. The SET indicator appears after the last digit has
been set.
3) After setting the last digit, press to exit the number setting routine. The SET indicator
will be removed.
Change password
1
Use the and to choose
the change password option
2-1
Press the to enter the change
password routine. The new password
screen will appear with the first digit
flashing

EASTRON SDM630M CT User Manual
-9 -
2-2
Use and to set the first
digit and press to confirm your
selection. The next digit will flash.
2-3
Repeat the procedure for the remaining
three digits
2-4
After setting the last digit, SET will show.
Press to exit the number setting routine and return to the Set-up menu. SET will be
removed
DIT Demand Integration Time
This sets the period in minutes over which the current and power readings are integrated for
maximum demand measurement. The options are: off, 5, 8, 10, 15,20, 30, 60 minutes
1
From the set-up menu, use and
buttons to select the DIT option.
The screen will show the currently
selected integration time.
2-1
Press to enter the selection
routine. The current time interval will
flash

EASTRON SDM630M CT User Manual
- 10 -
2-2
Use and to select the time
required.
2-3
Press to confirm the selection.
SET indicator will appear.
Press to exit the DIT selection routine and return to the menu.
Backlit set-up
The meter provides a function to set the blue backlit lasting time.
1
The backlit lasting time is settable
Default lasting time is 60minutes
For example, if it’s set as 5, the backlit
will be off in 5minutes from the last time
operation on the meter.
Notes: If it’s set as 0, the backlit will
always be on.
2
Press to enter the selection
routine. The current time interval will
flash
The options can be:
0/5/10/30/60/120minutes
Use and buttons to select the time required. Then press to confirm
the set-up,
Supply System
Use this section to set the type of power supply being monitored.

EASTRON SDM630M CT User Manual
- 11 -
1
From the Set-up menu, use and
buttons t o select System
option. The screen will show the
currently selected power supply.
2
Press to enter the selection
routine. The current selection will flash
3-1
Use and buttons to
select the required system option:
1P2(W),3P3(W) ,3P4(W)
3-2
Press to confirm the selection.
SET indicator will appear.
Press to exit the system selection routine and return to the menu. SET will disappear
and you will be returned to the main Set-up Menu
CT
The CT option sets the secondary current (CT2 1A or 5A) of the current transformer (CT) that
wires to the meter.
1
From the Set-up menu, use and
buttons to select the CT option.

EASTRON SDM630M CT User Manual
- 12 -
2
Secondary CT setting
Press to enter the CT secondary
current selection routine.:5A/1A
3
Set CT Ratio value
Press to enter the CT Ratio
setting screen. The range is from 0001 to
9999.
Example: If set the ratio to be 100,it means the primary current equals secondary currentx100
The PT option sets the secondary voltage (PT2 100 to 500V) of the Voltage transformer (PT)
that wires to the meter.
1
From the Set-up menu, use and
buttons to select the PT option.
The screen will show the voltage PT
secondary voltage value. The default
value is 400V
2 Secondary PT setting
Press to enter the PT secondary
voltage selection routine. The range is
from 100 to 500V
3 Set PT ratios value
Press to enter the PT ratio
screen.
The range is from 0001 to 9999
For example, if set the ratio to be 100,it means the primary voltage equals secondary
voltagex100
PT

EASTRON SDM630M CT User Manual
- 13 -
This option allows you to configure the pulse output. The output can be set to provide a pulse for
a defined amount of energy active or reactive.
Use this section to set up the pulse output 1—Units: Total kWh, Total kVArh
1
From the Set-up menu, use and
buttons to select the Pulse
output option.
2
Press to enter the selection
routine. The unit symbol will flash.
3
Use and buttons to
choose kWh or kVArh.
to confirm the setting and press
Use this to set the energy represented by each pulse. Rate can be set to 1 pulse
per 0.01kWh/0.1kWh/1kWh/10kWh/100/1000kWh.
(It shows 1 impulse = 10kWh/kVArh)
Pulse rate
On completion of the entry procedure, press
to return to the main set up menu.
Pulse output

EASTRON SDM630M CT User Manual
- 14 -
1
From the Set-up menu, use and
buttons to select the Pulse Rate
option.
2
Press to enter the selection
routine. The current setting will flash.
0.01/0.1/1/10/100/1000kWh/kVArh per
pulse
Use and buttons to choose pulse rate. On Completion of the entry procedure,
press to confirm the setting and press to return to the main set up menu.
Pulse Duration
The energy monitored can be active or reactive and the pulse width can be 200, 100 or 60ms.
(It shows pulse width of 200ms)
1-1
From the Set-up menu, use and
buttons to select the Pulse width
option.

EASTRON SDM630M CT User Manual
- 15 -
1-2
Press to enter the selection
routine. The current setting will flash.
Use and buttons to
choose pulse width.
On completion of the entry procedure, press to confirm the setting and press
to return to the main set up menu.
Communication
There is a Mbus port can be used for communication using Mbus protocol. For Mbus
communication, parameters are selected from Front panel.
Mbus Address
1
From the Set-up menu, use and
buttons to select the first
Address
2-1
Press button to enter the
selection routine. The current setting
will be flashing.
2-2
Use and buttons to
choose the first Address(001 to 247)

EASTRON SDM630M CT User Manual
- 16 -
3
Mbus secondary address
It ranges from 00 00 00 01 to 99 99 99 99
On completion of the entry procedure, press button to confirm the setting and press
button to return the main set-up menu.
Baud Rate
1
From the Set-up menu, use and
buttons to select the Baud Rate
option.
2-1
Press to enter the selection
routine. The current setting will flash.
2-2
Use and buttons to
choose Baud rate 2.4k. 4.8k, 9.6k, 19.2k,
38.4k
On completion of the entry procedure, press to confirm the setting and press
to return to the main set up menu.
Parity

EASTRON SDM630M CT User Manual
- 17 -
1
From the Set-up menu, use and
buttons to select the Parity
option.
2-1
Press to enter the selection
routine. The current setting will flash.
2-2
Use and buttons to
choose Parity (EVEN / ODD/ NONE)
Default is NONE.
On completion of the entry procedure, press to confirm the setting and press
to return to the main set up menu.
Stop bits
1
From the Set-up menu, use and
buttons to select the Stop Bit
option.
2-1
Press to enter the selection
routine. The current setting will flash.

EASTRON SDM630M CT User Manual
- 18 -
2-2
Use and buttons to
choose Stop Bit (2 or 1)
On completion of the entry procedure, press to confirm the setting and press
to return to the main set up menu.
Note: Default is 1, and only when the parity is NONE that the stop bit can be changed to 2.
CLR
The meter provides a function to reset the maximum demand value of current and power.
1
From the Set-up menu, use and
buttons to select the reset
option.
2
Press to enter the selection
routine. The MD will flash.
Press to confirm the setting and press to return to the main set up menu.
Reverse connected current inputs correction set-up
1
use and buttons to
select page “SET sys cont”

EASTRON SDM630M CT User Manual
- 19 -
2-1
Press to enter Phase A , the
default is Frd (forward)
2-2
use and buttons to
Phase B or C setting pages
How to operate if phase A is reversely connected
1
Go to phase A setting page
2
Press to enter the selection
routine. The Frd will flash.
Use button to change Frd to Rev.
Press to confirm the setting and press to return to the main set up menu.
Specifications
Measured Parameters
The unit can monitor and display the following parameters of a single phase two wire(1p2w),
three phase three wire(3p3w) or four phase four wire(3p4w) supply.
Voltage and Current
Phase to neutral voltages 100 to 275V a.c. (not for 3p3w supplies)
Voltages between phases 173 to 480V a.c. (3p supplies only)
