OX® TRADE TELESCOPIC
MULTI-PURPOSE LADDER
OPERATING PROCEDURE AND
SAFETY INSTRUCTIONS
1. Read these instructions completely before
using the ladder. If you don’t understand call
[phone] for assistance.
2. Failure to comply with all instructions may
result in serious injury.
3. This Manual should be read in conjunction with
instructions on the ladder itself.
TELESCOPIC MULTI-PURPOSE LADDER
1. DESCRIPTION
• Product overview 2
• Terminology 3
2. SAFETY
• Inspection of product 4
• Proper set-up and use 4
• Proper care of product 5
3. SOFT TOUCH PUSH KNOB LOCKING HINGE
• Hinge operations (adjust angle of ladder) 6
4. SPRING LOADED “J” LOCKS
• Lock operation (adjust height) 7
5. PROPER USE
• How to setup positions 8
WARNING

1 DESCRIPTION
PRODUCT OVERVIEW
The OX Trade Telescopic Multi-Purpose Ladder is a professional grade, multi-purpose ladder that can be
changed into different positions and working heights. (See Positions 1-3)
WARNING
Use ladder only in positions as shown below. Any other
position is misuse of the product which could result in
serious injury or death.
CAUTION
DO NOT overload ladder. Maximum weight of person,
tools, and materials are not to exceed duty rating of
150 kg.
STORAGE POSITION
Position #1
TWIN STEPLADDER
See page 8
Position #2
STAIRWAY STEPLADDER
See page 10
Position #3
TWIN STEPLADDER
See page 8
2

WORKING HEIGHTS
The following chart shows the working heights of each of the available units in each of the 4 main positions.
Working Length Range OXTL03 OXTL04 OXTL05
A Frame 1100-1700mm 1400-2320mm 1700-2930mm
Extension 2100-3320mm 2700-4530mm 3300-5720mm
POSITIONS
The following chart shows the number of available positions for each of the available units in each of the
4 main positions.
These ladders are all rated 150kgs
Positions OXTL03 OXTL04 OXTL05
Step 3 4 5
Stair 3 6 10
Extension 5 7 9
TERMINOLOGY
Spend time to look at the figure below. Become familiar with names used to describe parts of the OX Trade
Telescopic Multi-Purpose Ladder. They will be used throughout this manual.
Hinge lock
‘J’ lock
End cap
Inner ladder
Section
Ladder side rail
Outer ladder
section
Rung/step
3

2 SAFETY
INSPECTION OF PRODUCT
For safety, follow these inspection instructions:
• Never use ladder with missing, worn or damaged parts. Inspect before each use.
• Never repair a damaged ladder without permission from Easy Access Co.
• Destroy ladder if exposed to excessive heat (such as in a house fire) or corrosive agents (like acids or
alkalis).
• For information on replacing parts or labels contact Easy Access Co. at the address given below. If possible,
know model number of ladder for reference.
• For additional care, use and safety instructions, contact your employer, dealer or Easy Access Co.
WARNING
Failure to follow these instructions could result in
serious injury or death.
PROPER SET-UP AND USE
For safety, follow these set-up and use instructions:
• READ ALL LABELS
• You should never use a ladder if you are not in good physical condition.
• Do NOT use in front of unlocked doors.
• Place feet on firm, level ground.
• If forced to use on slippery surface, secure ladder from sliding before climbing.
• The use of ladders on drop cloths may present a sliding hazard.
• When using as a stepladder or extension ladder, always face ladder and maintain firm grip.
• Never place anything on or under ladder to gain height, or use unstable means to adjust for uneven
surfaces.
• Check that all four ladder ends are firmly supported to prevent excessive movements.
• Use extreme caution when getting on or off ladder.
• When possible, have someone hold the ladder.
Write or Call:
EASY ACCESS CO 1999 LTD
334 STATE HIGHWAY 12,
MAUNGATUROTO 0587
Ph:- [phone]
4

PROPER SET-UP AND USE (CONTINUED)
For safety, follow these set-up and use instructions:
- Never walk, bounce or move ladder while on it.
- DO NOT OVER REACH. Always keep belt buckle
between side rails when climbing or working. You
may lose your balance and/or tip ladder.
- Wind loading can cause unbalance.
- Use extreme caution when pushing or pulling
anything. You may lose your balance and/or tip
ladder.
- Never use the ladder as a brace
- The maximum weight of a person, tools, and
materials must not exceed 150kg
- DO NOT use any components not supplied or
approved by Easy Access Co. with this ladder.
- To set ladder up: Support ladder by laying it on
its side on the ground. Open to desired allowable
position and then stand ladder up. Watch for
overhead wires.
- Never use ladder jacks on this ladder, regardless of
the manner in which it is being used.
- When using as a single or extension ladder, distance
from base to base of support wall must be ¼ of
the working length of the ladder. The ladder must
extend one metre above the roof, where applicable.
PROPER CARE OF PRODUCT
For safety, follow these care instructions:
- Always keep ladder clean of all foreign materials. Clean after each use.
- Check moving parts regularly. Lubricate all moving parts regularly. Use caution not to get lubricant on
rungs or side rail.
5

3 SOFT TOUCH PUSH KNOB LOCKING HINGE
HINGE OPERATION
For safety, follow these Soft Touch push knob hinge
instructions:
The OX Telescopic Multi-ladder inner section allows the ladder to be
folded into 3 set positions; extension ladder, twin stepladder, and
storage. Each of these configurations is made possible by using
the Soft Touch push knob locking hinge located on each side of the
ladder.
To adjust the angle of the ladder:
1) With the center hinges in the closed position (See Figure 1) push
the push knobs with the palm of your hand directly into the
center of the ladder, they will stay in the open position.
2) In the open position (See Figure 2) the ladder angle can be
adjusted.
Note: The open position can be verified by the exposed triple inner
posts on the push knob (See Figure 2).
3) When the ladder reaches any of the 3 set positions the push knobs
will automatically spring back into the closed position.
4) To close ladder to the folded position repeat steps 1-3.
Note: Excess pressure on the centre hinge will make the push knob
difficult to operate. Do Not Use any tools to pry or manipulate the hinge
and or the push knob. If the push knob is difficult to use simply move
one of the leg sections in or out to unbind the lock.
WARNING
- Serious injury or death could result if supporting hinges
are NOT LOCKED when ladder is in use.
- Make certain supporting hinges are LOCKED before
using ladder EACH TIME.
6

4 SPRING LOADED “J” LOCKS
LOCK OPERATION
For safety, follow these ‘J’ Lock instructions:
The OX Telescopic Multi-Ladder outer sections allow
the ladder to telescope and change heights in all the
configurations, besides the scaffold mode. Each of these
configurations is made possible using the 4 Spring Loaded
“J” locks 2 each on either side.
The Spring Loaded “J” locks are operated by pulling straight
out and then rotating them away from the holes in the rails.
Each “J” lock works independently allowing the end user to
work the lock with one hand while holding the ladder with
the other.
To adjust the height of the ladder:
1) Unlock the 4 “J” locks by pulling out and rotating the “J”
lock away from the rung hole (See Figure 3).
2) Raise the inner section to the desire height.
3) While holding the inner ladder section with one hand,
lock the 4 “J” locks by rotating them into the locked
position (See Figure 4).
CAUTION
- Ensure all ‘J’ locks are secure in a rung hole before climbing.
- Maintain control of the inner section while raising or lowering,
failure to do so could result in injury.
7

5 PROPER USE
HOW TO SETUP POSITIONS
The OX Telescopic Multi-ladder can be used in positions shown below with no additional equipment
required. The following instructions will demonstrate how to change the OX Telescoping Multi-ladder.
POSITION #1
TWIN STEPLADDER
1) To configure the OX Telescopic Multi-Ladder into
the stepladder position, follow the directions for
changing the angle of the ladder (Section 3) using
the push knob locking hinge.
Note: The stepladder position is easiest completed
with the ladder standing up. In this position excess
pressure is not exerted on the hinge.
2) At this point the height of the ladder can be
changed to the desired height using the Spring
Loaded “J” locks and the instructions for them
(Section 4).
CAUTION
- For every position all hinges are supporting hinges and must be locked.
- Never straddle front and rear sections.
- Always face ladder and maintain firm grip while on it.
- DO NOT stand on or above second rung from top of ladder.
8

POSITION #2
STAIRWAY STEPLADDER
CAUTION
- Always face ladder and maintain firm grip while on it.
- DO NOT stand on or above second rung from top of ladder.
1) To configure the OX Multi-Ladder into the
Stairway Stepladder position – this position
is used when the user needs to work in a
stairway.
2) To achieve this position, configure the ladder
in the stepladder configuration as described
in position #1. Raise to desired height.
3) Lower one side of the inner section until the
desired step height is reached as described
in position #2 above.
4) Position ladder on stairway, ensuring all legs
are on firm ground or steps.
9

FREEPHONE 0800 394 222
[email protected] www.easyaccess.co.nz
POSITION #3
EXTENSION LADDER
1) Configuring the OX Multi-Ladder into the extension ladder position,
as with the stepladder position, the extension ladder position starts
with changing the angle.
Note: The push knob hinge will catch in each of the 3 positions.
Continue to disengage and rotate the sections until the desired
position is reached.
2) With the ladder standing up, unlock the upper section “J” locks
and walk the upper ladder section out. If more height is needed,
extend the opposite section in the same way. Slide outer sections
apart until desired length is met.
CAUTION
- Hinges and ‘J’ Locks must be secure before climbing ladder
- Never use ladder jacks on this ladder.
- Always face ladder and maintain firm grip while on it.
- DO NOT stand on or above second rung from top of ladder.
