EasyBraid EB-9000S User manual

1
USER MANUAL
EB-9000S
CURIE HEAT TECHNOLOGY
SOLDERING/REWORK STATION
9.24.10

2
TABLE OF CONTENTS
EB-9000S SPECIFICATIONS PAGE 3
INTRODUCTION PAGE 4
SYSTEM FEATURES PAGE 5
HANDPIECE FEATURES PAGE 7
WORKSTAND FEATURES PAGE 8
UNPACKING/ASSEMBLY/OPERATION PAGE 9
TIP CARTRIDGE REPLACEMENT/MAINTENANCE PAGE 10
ORDERING GUIDE PAGE 11
WARRANTY AND SERVICE PAGE 12

3
EB-9000S SPECIFICATIONS
Input Line Voltage:EB-9000S 100-110 VAC
Tip to Ground Potential: <2mV, true RMS 50-500Hz
Tip to Ground Resistance: <2 Ohms DC
Idle temperature Stability: +/-1.1oC (2 oF)
Ambient Operating Temperature: 10-40 oC (50 oF -104 oF)
Maximum Enclosure Temperature: 50 oC (122 oF)
Fuse: 250V 2A “Slo-Blo”
Output Power (Maximum): 40 Watts
Output Frequency: 13.56 MHz
Size (W x H x D): 8.36” x 4.65” x 5.2”
Weight: 7.65 lbs.
LCD display: 2.36” x 0.63”
Input Line Frequency:50/60 Hz
Certification marks: cTUVus, CE, GS

4
INTRODUCTION
Congratulations on your purchase of the EB-9000S soldering/rework station.
This unit has been tested and inspected by Easy Braid prior to shipment, and
with proper maintenance will give you years of reliable performance.
A complete EB-9000S station consists of:
•13.56 MHz Power Supply
•Detachable soldering iron stand with sponge and brass curl
•Tip removal Pad
•EBM8CH176 Solder tip cartridge
Soldering Station Components:
EB-9000PS Power Supply
EBSHH-1 Soldering Handpiece Holder
EBSHP-1 Soldering Handpiece
EBRMP-1 Tip Removal Pad
EBSG-1-G Soldering handpiece grip, Green
EBSG-1-GY Soldering handpiece grip, Gray
EBBC-1 Brass Curls
EBSPG-1 Sulphide Free Sponge
EBM8CH176 Soldering tip cartridge

5
SYSTEM FEATURES
Power Supply:
The EB-9000S power supply is manufactured from the finest materials and is the
most compact 13.56MHz power supply available on the market today. It
includes:
•LCD display with built in power indicator and tip cartridge status
•Dual switchable output
•External fuse for ease of service
Power Switch
LCD Display
External Fus e
Power
Indicator LED
Left Output
Connector
Channel
Selection Switch
Right Output
Connector
ESD Paint
PPainPPain
tPaPaint

6
Power Supply LCD Mode
Start up
Working Mode
Ready Mode
Handpiece not connected
Error Codes are factory set. If a
malfunction occurs, contact your
local distributor.

7
HAND-PIECE FEATURES
The unique EBSHP-1 hand piece is comfortable to use, lightweight and well
balanced. The clever handle design incorporates an aluminium front section, with
either gray or green grips and an ESD safe, nylon rear that minimizes heat
transfer and ensures operator comfort.
Complete Handpiece assembly including cartridge removal pad
To change grip, unscrew the front retaining cap and slide off the old grip.
Insert new grip and retighten front cap.

8
WORKSTAND FEATURES
The EBSHH-1 work stand is manufactured from durable phenolic material; the
unique “surelock ” iron holder has an open design that will keep the handpiece
stable and cool when in use.
“Surelock” open
design
Brass Tip
Cleaning curl
Sulphide free
cleaning sponge
Tip Cartridge
holder
Durable phenolic
material
Stable heavy base

9
UNPACKING/ASSEMBLY/OPERATION
Please read this manual and follow the directions before using the equipment.
The carton contains:
1. Instruction manual
2. EB-9000PS power supply
3. EBSHH-1 Soldering handpiece holder, including Brass curls and sponge
4. EBSHP-1 Soldering handpiece, with green and gray grips,
5. EBRMP-1 Tip removal pad
6. EBM8CH176 Soldering Cartridge
Important: Keep all shipping materials until satisfactory operation has been verified.
Assembly and Operation
1. Remove EB-9000PS power supply base from its box and place on a
suitable work bench equipped with AC power.
2. Remove the EBSHH-1 work stand from its box. The unit should include a
brass tip cleaning curl and a rectangular sulphide free sponge.
3. Remove the EBSHP-1 handpiece from its box and place into iron holder.
4. Plug the handpiece cord into one of the front connectors and ensure that
the slide switch is positioned towards the plugged handpiece.
5. Plug tip cartridge into handpiece
6. Moisten the sponge with DE-Ionized water.
7. Connect the AC plug to a suitable AC power outlet.
8. Switch the power switch to the “on” position.
9. Allow a few seconds for tip cartridge to reach soldering temperature.
10. The unit should be ready to use.
Temperature Calibration
Easy Braid “Curie Heat Technology” systems do not require temperature
calibration. The technology is very precise and is self regulating. The alloy used
in the construction of the tip cartridge will maintain the set temperature for its
entire life.

10
TIP CARTRIDGE
REPLACEMENT/MAINTENANCE
Tip Cartridge replacement
Easy Braid tip cartridges are very easy to install and remove; make sure that you
turn off the power supply first. A simple “pull action” will disengage the tip
from its connector. When reinserting a new tip, the cleverly designed inner shaft
of the handpiece will self-center the tip in order to ensure quick and easy
assembly. A tip removal pad is included and should be used when inserting or
removing hot tips from the handpiece. This tip removal device is made of a
special heat shielded material and will protect the operator.
Important notice: Pliers should not be used when tip cartridges are being extracted from or inserted into
the handpiece. Any undue mechanical force may damage the heater coil and will result in premature
failure of the tip cartridge.
Tip Care
1. Use good quality solder, impurities in the solder can build up on the tip,
effecting heat transfer and making it difficult to solder.
2. Do not overfill the sponge tray with water, and always use DE-Ionized
Water. Please change the sponge regularly; solder residue can have an
abrasive effect on the end of tips and cause premature failure. Brass mesh
pads can also be used for the same purpose.
3. Avoid using tip tinning pastes as they are corrosive and often leave black
residue on the tips. This black residue is hard to remove and will affect the
ability of the tip to take solder.
4. Keep the tip tinned at all times--a non-tinned hot tip will oxidize quickly
and performance will be compromised.
5. When reinserting tips, make sure they are properly seated in the shaft of
the soldering handpiece.

11
ORDERING GUIDE
EB-9000S
CURIE HEAT TECHNOLOGY SOLDERING SYSTEM
EASY BRAID 100-110V SYSTEM
PART NUMBER
EB-9000S
POWER
SUPPLY
HANDPIECE
WORKSTAND
TIP
CARTRIDGE
EB-9000PS
EBSHP-1
EBSHH-1
EBM8CH176

12
WARRANTY
All equipment and accessories are warranted by Easy Braid to be free from
defects in materials and workmanship as follows:
Part Number Description Warranty Period
EB-9000PS 100-110V Power supply 4Years
EBSHP-1 Handpiece 90 Days
EBSHH-1 Workstand 90 Days
This warranty does not apply to equipment or goods which have been tampered
with, misused, damaged through improper installation or used in a manner
contrary to supplier instructions. Normal “wear and tear” of equipment or
goods is not covered by this warranty. If the product should become defective
within the warranty period, Easy Braid will repair or replace it free of charge at
its sole option. Warranty period is from the date of purchase by the original
owner. If the date of purchase cannot be substantiated the date of manufacture
will be used as the start of the warranty period.
