EasyPro Spirit TLS1850 Operation and maintenance manual

Pond & Waterfall Pumps
Instructions for Operation • Safety • Warranty
Designed for minimal solids applications
TLS1850 • TLS2750 • TLS4250
Thank you for purchasing the Spirit Pond &
Stream pump from EasyPro. These pumps are
designed for continuous duty use in small ponds,
statuary, Just-A-Falls, etc. A great choice for
ponds with light debris laden water.
Specications
• Can be run in vertical or horizontal positions
for compact applications
• Oil-lessdesign,shandplantsafe
• Impeller designed for passing debris up to
1/4" diameter
• 11/4" female threaded outlet with a 11/4" x
11/2" elbow included
• Triple sealed 115v motors with 18 month warranty
• Automatic overload and thermal protection with self reset
Run in vertical or horizontal position

Safety & Electrical Connections
1. Always disconnect the electricity supply before handling,
maintaining, repairing or installing any pond equipment.
2. Always make sure you know the correct amps and voltage required
before installing.
3. Use dedicated power outlet only. Sharing the outlet with other equip-
mentmaycauseoverheatingandre.
4. EasyPro TLS pumps come in 115 volt only.
5. Always connect to a Ground Fault Circuit (GFCI) to prevent electrical
shock. Never submerge connecting power cable plug in water.
6. Never let the pump run without water as this will damage the
impeller, over heat and possibly burn out the pump. This pump
must stay submerged entirely when opeating. If used in a skimmer,
thedebrisnetmustbekeptcleantoensureadequatewaterowto
pump. Running pump low on water will cause overheating, premature
failure and will void warranty.
7. Do not use this product in bathrooms or swimming pools.
8. Do not let the water level in your water feature fall below the top of the
pump body.
9. Allelectricalworkmustbeperformedbyaqualiedtechnician.
Always follow the National Electrical Code (NEC) or the Canadian
Electrical Code as well as all local, state and provincial codes. Code
questions should be directed to your local electrical inspector. Failure
to follow electrical codes and OSHA safety standards may result in
personal injury or equipment damage. Failure to follow manufactur-
er’sinstallationinstructionsmayresultinelectricalshock,rehazard,
personal injury or death, damaged equipment, provide unsatisfactory
performance and may void manufacturer’s warranty.
10. Do not attempt to disassemble pump during the warranty period. If
there are any questions please contact your local EasyPro dealer.
11. Never use an extension cord or tamper with power cord. Power cord
cannot become bent, twisted, abraded or cut. A damged cable may
causeelectricleakage,shockorre.
12. The motor has a built-in protection system which stops the pump
when overheating occurs due to excessive load or low water, this can
becausedbycloggingatinlet/outletorwhenucuationsoccurin
power supply. The cooling time is roughly 15 to 20 minutes, then the
pump will automatically come back on. If the overload is tripped, it is
essential to identify and remedy the cause of the overheating.

Installation
• Do not paint casing, over heating may occur
• Liftonlybyhandle,notbypowercableoroatswitch
• Donothangpumpinwater,installonsolidatbaseinuprightor
horizontal position
• Install proper outlet adapter for pipe or hose
• Make sure that power cable plug and power outlet are away from
water and water discharge pipe/hose.
Operation
1. Do not start operation with people standing near intake or
outlet.
2. Do not operate out of water.
3. Pump must remain fully submersed.
4. Only use pump for circulation, transfer or removal of water with limit-
ed solids 1/4" or smaller.
5. Do not pump oil, salt water, sewage, food or chemical liquids.
6. Do not allow dry operation
7. Do not allow foreign objects to clog or enter intake
8. Incaseofpoweroutage,turnopowerswitchtoavoiddamagewhen
power is restarted.
9. Ifexcessivevibrationoccursturnopowerimmediately.
Service & Maintenance
1. Disconnect all power supplies before inspection or service to
avoid possible electrical shock.
2. The pump should be removed from the pond on a regular basis,
cleaned and checked over for damage to prolong the life of the pump.
3. Cleantheimpellerandintakescreenwhentheowisvisiblyreduced.
4. Clean the pump and impeller with clean fresh water.
5. Check inside the impeller housing for large debris or algae, which
couldreducetheow.
6. Check and tighten nuts and bolts if required, refer to dealer for advice
on other repairs.
7. Winterization/Storage: When the pump is out of use for extended time
- wash and dry it then store indoors in a non-freezing location. It is
best to store in a bucket with about an 8" water depth. It is essential
to prevent any risk of the pump freezing.
8. If the pump is left in water but not operating regularly, test run it at
least once a week.

Trouble Shooting
Before taking any trouble shooting action, disconnect pump from the
power supply. If there is any damage to the power cord or pump, repairs
orreplacementsmustbehandledbyEasyProoraqualiedparty.
Does not start • Make sure power cord is plugged in
• Float (not included) may not be moving
freely, increase depth
Doesnotshut-o •Pumpisnotdisabledbyoat(notincluded),
  makesureoatcanmovefreely
Humming •Linecircuitbreakeriso,fuseisburnedorloose
• Pump cord is not making contact in receptacle
Running, no water • Suction grid or piping are clogged
• Impeller is worn or stuck
 •Requiredheadistoohighforthepumpspecications
• Water level is too low
Running, very • Pump is air-locked, start and stop several times by
little water plugging and unplugging cord, check for clogged
vent hole
• Vertical pumping distance is too high or the pipe
size is too small
• Inlet or impeller clogged
• Low water conditions with pump sucking air
GFCI breaker • Mechanical seals may need to be replaced
tripping • Power cord may be damaged and getting wet
• Nuisance trip due to improper grounding
• Overloaded circuit
Motorbriey •Lowwaterconditions,pumpoverheating
starts and stops • Inlet or impeller clogged
• Improper power supply
Pumps stops • Make sure water being pumped is not too dense,
causing the pump to overheat.
• Clear obstructions on impeller
• Check power supply to comply with nameplate data
• Wait for pump to cool, correct reason for overheating,
plug back in and resume operation

30
25
20
15
10
5
0
0 10 20 30 40 50 60 70
Head (ft)
Capacity (GPM)
TLS1850 TLS2750 TLS4250
EasyPro TLS Pump Performance
35
Discharge 11/4" fpt • Elbow 11/2" fpt
Voltage 115v, 60 hz • Power Cord 20'
Part # Maximum Gph Hp Watts Maximum Head
TLS1850 1850 1/4 260 21'
TLS2750 2750 1/3 370 29'
TLS4250 4250 1/2 820 33'
Specications

800-448-3873 • Grant, Michigan
www.easypropondproducts.com • [e-mail]
11-13
Limited Warranty
• Pump is warranted against any
mechanical or material defects for 18
months from date of purchase
• This warranty does not cover acci-
dental damage to the product due to
abuse or negligence by the consumer.
• An RMA number must be obtained
by calling EasyPro Pond Products at
800-448-3873 and be included on
package before returning for warranty.
Return warranty items to:
EasyPro Pond Products, 4385 East
110th, Grant, MI 49327
Be sure to include RMA number, original receipt, name, return ad-
dress and phone number in package.
• In the event of a warranty claim, please return the pump postage
prepaid with the original receipt for repair or exchange. No warranty
claims will be honored without the original receipt.
• The manufacturer or supplier shall not be held liable for any damag-
es caused by defective components or materials of this pump; or for
loss incurred because of the interruption of service; or any conse-
quential/incidental damages and expenses arising from the produc-
tion, sale, use or misuse of this product.
• The manufacturer or supplier shall not be held liable for any loss of
sh,plantsoranyotherlivestockasaresultofanyfailureordefect
of this product.
• This pump must stay submerged entirely when operating. If used
in skimmer, the debris net must be kept clean to ensure adequate
waterowtothepump.Runningpumplowonwaterwillcauseover-
heating and premature failure which is not covered under warranty.
• If you experience a failure of your pump, please check the following
before returning to us:
 1.Removelterhousing,cleanandinspectimpellerandsurrounding
chamber, reassemble and test pump;
2. Verify electrical supply.
Return warranty
pumps to:
EasyPro
Pond Products
4385 East 110th
Grant, MI 49327
Be sure to include RMA
number, original receipt,
return address and phone
number in package!
