easyRAID S8A2-PETT Instructions for use

easyRAID S8A2-PETT
Hardware User Manual
PCIe to Serial ATA II
Disk Array System
Version 1.0

ESC
Power
P/S Fail
Access
Enter
1
2
3
4
5
6
7
8
easyRAID S8A2-PETT
PCIe to Serial ATA II
Disk Array System
Hardware User Manual

i
Table of Contents
Preface................................................................................................................... i
Chapter 1 System Requirements
Operating Environment ....................................................................................1
VT100 Terminal Settings ..................................................................................1
Chapter 2 Basic Configuration
Unpacking .............................................................................................................3
Components ..........................................................................................................4
Front Panel ......................................................................................................4
Disk Tray ..........................................................................................................5
easyRAID S8A2-PETT Rear View ...................................................................6
Installing Disks ......................................................................................................7
Making Connections .............................................................................................9
Connecting the Host Interface ..........................................................................9
Connecting PCIe cable to the server ..............................................................10
Connecting and Turning on the Power ........................................................... 11
Chapter 3 Maintenance
Replacing a Disk ................................................................................................. 13
Replacing a Power Supply .................................................................................. 14
Upgrading Memory ............................................................................................. 16
Replacing a FAN module ....................................................................................18
Appendix
Hardware Specifications ..................................................................................... 21

i
Preface
About this Manual
This manual is designed to make the disk array system as easy to use as possible.
Information contained in this document has been checked for accuracy, but no guaran-
tee is given that the contents are correct. Information and specifications are subject
to change without notice.
Copyright Notice
© Copyright 2007
All rights reserved. This disk array system and related documentation are protected by
copyright and are distributed under licenses restricting their use, copying, and distribu-
tion. No part of this documentation may be reproduced in any form by any means with-
out prior written authorization and its licensors, if any.
Conventions
Caution
This symbol is used to remind users to pay attention to important
descriptions regarding usage and maintenance (repair) or additional
important information related to this disk array system.
Note
This symbol is used to remind users of useful information that can make
procedures such as configuration easier to accomplish.

ii
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
Preface – Important Safety Instructions, Care and Handling
Important Safety Instructions, Care and Handling
Before starting, take a few minutes to read this manual.
Read all of these instructions and save this manual for
later reference.
Protect the disk array system from extremely high or low
temperatures. Let the disk array system warm (or cool)
to room temperature before using it.
Protect the disk array system from being bumped or
dropped. Do not place the disk array system on an
unstable cart, stand, or table. It may fall, causing serious
damage to the product.
Keep the disk array system away from magnetic forces.
Do not use the disk array system near water.
Keep the disk array system away from dust, sand, or dirt.
Gaps and openings in the cabinet are provided for venti-
lation. Never block or cover these openings, because
the disk array system may overheat and become unreli-
able. Don’t place the disk array system on a bed, sofa,
rug, or other similar surface.
Do not place the disk array system near or over a radia-
tor or other heat source.
Refer to the rating plate for the correct voltage and
ensure that the appliance voltage corresponds to the
supply voltage.
V

easyRAID S8A2-PETT Serial ATA II Disk Array Systems
iii
Preface – Important Safety Instructions, Care and Handling
The appliance must be grounded. The disk array system
is equipped with a 3-wire grounded type of power cord.
This power cord will only fit into a grounded type of
power outlet.
If an extension cord or a power center is used with the
disk array system, make sure that the total current con-
sumption of all products plugged into the wall outlet
does not exceed the ampere rating.
Do not place the disk array system where the cord will
be walked on.
Never push any kind of object into the disk array system
through cabinet gaps and openings, since they may
touch dangerous voltage points and cause a risk of fire
or electric shock.
Unplug the power cord from the wall outlet before clean-
ing. Keep the disk array system dry. Do not use liquid
cleaners, aerosol cleaners, or a wet cloth. Use a damp
cloth for cleaning.
Except as specifically explained in this User Manual, do
not attempt to service the disk array system by yourself.
Opening or removing the covers may expose you to
dangerous voltages.
Unplug this product from the wall outlet and refer servic-
ing to qualified service personnel under the following
conditions.
• If the disk array system has been exposed to
water or any liquid.
• If the disk array system has been dropped or the
cabinet damaged.
Users should not remove the cover.
Disconnect all power supply cords before servicing.
Fan1
Power1
oGGwGGY

iv
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
Preface – Important Safety Instructions, Care and Handling
Placement Notes
• The disk array system LCD panel can be damaged by exposure to
direct sunlight. Limit exposure to subdued or indirect sunlight only.
• The disk array system should be used only in clean environments
that are free from airborne contaminants such as dust, dirt, and
smoke. Excessive moisture or oil particles in the air can also hinder
disk array system performance.
• To reduce the possibility of data errors caused by electromagnetic
interference, locate the disk array system at least five feet away
from electrical appliances and equipment that generates magnetic
fields.
Power Supply Safety Notes
• To avoid electric shocks, do not use an extended power cord or an
outlet that does not match the disk array system plug or leaves the
plug exposed.
• The disk array system has a 3-wire grounded plug. The third pin
connects to ground; do not remove it.
• If the power cord or plug is damaged or worn, unplug it immediately
and contact a qualified service technician for maintenance.
• To avoid fire or electric shocks, do not overload electric power out-
lets.
CAUTION : MULTIPLE POWER SOURCES
Disconnect all AC power cords to completely power from the unit
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
CAUTION
The thumbscrews on the rear surface shall be secured by the screw-
driver, which cannot be loosened by bare hands to prevent the uninten-
tional access to the hazardous parts inside the equipment.

1
1 System Requirements
Ensure that the following requirements are met before installing the disk array system.
Operating Environment
• 15 cm (6-inches) of space around the disk array system for proper ventilation
• ambient temperature of 5°C to 40°C (40°F to 104°F)
• ambient non-condensing relative humidity of 10% to 85%
• dust, smoke, and oil free environment
• no large magnetic fields, such as those generated by a high voltage power cables
and motors, etc.
• no direct sunlight
• a flat, stable surface capable of supporting the disk array system
VT100 Terminal Settings
Refer to the following table for a summary of VT100 terminal settings required to com-
municate with the disk array system. Refer to your system manual for instructions on
setting up the VT100 terminal settings.
Item Required Setting
Connection Serial Port (COM1 or COM2)
Protocol RS232 (Asynchronous)
Cabling Null Modem cable
Baud Rate 115200
Data Bits 8
Stop Bit 1
Parity None

3
2 Basic Configuration
This chapter describes disk array system connections and disk installation.
Unpacking
Contact your supplier if any of the following items are missing or damaged.
Caution
The disk array system is heavy. Be careful when lifting and moving it.
ESC
Power
P/SFail
Access
Enter
1
2
3
4
5
6
7
8
Hardware User Manual
easyRAID S8A2-PETT
PCI-e to Serial ATA II
DiskArraySystem
easyRAID S8A2-PETT
Software User Manual
PCI-e to Serial ATA II
DiskArraySystem
ESC
Power
P/SFail
Access
Enter
1
2
3
4
5
6
7
8
ESC
Power
P/SFail
Access
Enter
1
2
3
4
5
6
7
8
Power Cables
Hardware and software
user Manuals
Disk Array System
RS-232 Cable
PCIe cable Screw pack
Re-drive card

4
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
2 Basic Configuration – Components
Components
easyRAID S8A2-PETT Front Panel
No. Name Description
1-8 Disk trays 1 to 8 Removable hot swap disk trays.
9Up function button Moves up in the LCD menus.
10 Escape function button Returns to the previous LCD menu without making
changes.
11 Power-on indicator (green) Indicates the disk array system power is on.
12 Power supply fail indicator (red) Indicates a failed power supply.
13 Host computer access indicator Indicates data transfer between the disk array sys-
tem and the host computer.
14 Enter function button Selects a menu item or confirms a choice or entry.
15 Down function button Moves down in the LCD menus.
16 LCD panel Displays warning, operating, and configuration
information.
1
2
3
4
5
6
7
8
ESC
P/S Fail
Power
Access
Enter
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
16

easyRAID S8A2-PETT Serial ATA II Disk Array Systems
5
2 Basic Configuration – Components
Disk Tray
No. Name Description
1
Power/Error indicator LED Different colors indicate different disk states:
• Green – Disk online
• Orange – Disk full
• Red – No disk
2Access indicator LED This blue LED indicates that the disk is being
accessed.
3Tray handle Releases the disk tray.
21
Front
3

6
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
2 Basic Configuration – Components
easyRAID S8A2-PETT Rear View
1
Fan 1
Fan 2
Host 1
COM
2
3
4
56
11
78
9
10
No. Name Description
1Host Port 1 (PCIe channel) Connects to the host server.
2Cooling fan 1 System cooling fan.
3Cooling fan 2 System cooling fan.
4Power Supply 1 Removable redundant power supply 1.
5Power Supply Handle For power supply removal.
6Power Supply AC In Connects to a 100-240 VAC power source.
7Power Supply 2 Removable redundant power supply 2.
8Power Supply Handle For power supply removal.
9Power Supply AC In Connects to a 100-240 VAC power source.
10 Power Switch Switches the power on or off.
11 RS-232 Port Connects to a VT100 terminal or equivalent

easyRAID S8A2-PETT Serial ATA II Disk Array Systems
7
2 Basic Configuration – Installing Disks
Installing Disks
This section describes how to install disks in the disk array system.
1Unlock the fan, then pull it open.
2Push the button to release the disk tray handle.
3Pull the handle to release the tray.

8
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
2 Basic Configuration – Installing Disks
4Insert the disk into the disk tray and fix into place with screws supplied with the
disk.
5Insert the disk tray back into the empty slot.
6Repeat steps 2 to 5 until all of the required disk have been installed.
7Push the fan closed, and lock it.

easyRAID S8A2-PETT Serial ATA II Disk Array Systems
9
2 Basic Configuration – Making Connections
Making Connections
After the required number of disks have been installed, external connections to the disk
array system must be made. This section describes how to make all of the necessary
connections.
Connecting the Host Interface
The disk array system has PCIe interface. Refer to the following sections to make host
interface connections.
The easyRAID S8A2-PETT has PCIe interface. Follow these instructions to make con-
nections.
1Connect the PCIe cable to the left connector of the easyRAID S8A2-PETT host
port 1 at the rear of the disk array system.
Host 1

10
easyRAID S8A2-PETT Serial ATA II Disk Array Systems
2 Basic Configuration – Making Connections
Connect PCIe cable to the server
While the PCIe cable has connected to the easyRAID S8A2-PETT, the other side of the
cable connect to the re-drive card (A). Then install the re-drive card (A) into the PCI slot
in the server (B).
A
B
server
re-drive card
Host 1
