Chapter 1 — Door Keypad OPTRMT-KIT-9000X Contents
The EATON Door Keypad is used for standard control keypad purposes and it is installed on the door of an electrical enclosure.
For the installation, you need the following parts (see Figure 1-1):
G Door Keypad (1) — OPTRMT-KIT-9000X
G 4 Screws (2) — Phillips Pan Head Thread Forming, 10 – 14 x 1/2
G Connection Cable (3)
G Mounting Plate (4)
MAKE SURE THAT YOU HAVE RECEIVED ALL NECESSARY PARTS!

8
Installation Manual MN04003016E
Effective July 2011
Door Keypad OPTRMT-KIT-9000X
EATON CORPORATION www.eaton.com

9
Door Keypad OPTRMT-KIT-9000XInstallation Manual MN04003016E
Effective July 2011
EATON CORPORATION www.eaton.com
Chapter 2 — Mounting of Door Keypad OPTRMT-KIT-9000
1. Make an opening in the cabinet door for the control keypad using the Drilling Template Dimensions in Figure 3-1.
2. Also drill the mounting holes for the screws using the dimensions of Figure 3-1.
3. Place the control keypad in the opening so that the screw holes you made in the cabinet door are aligned to the holes on the
backside of the control keypad.
4. Install the mounting plate to the inside of the cabinet door by installing the screws. The tightening torque is 10 lb-in (1.13 Nm).
5. Connect the drive cable to the terminal of the control keypad and the remote mount keypad.
6. Your EATON Door Keypad is now ready for operation.
