Eaton SPD Series Manual

Instruction Leaet IL158006EN Effective November 2020
PX-SPD quick start guide
Device information
Features and benefits
• Surge protective device (SPD)
Designed to protect against damaging transient
voltage events
• Surge counter
Captures surge events on each phase, which
are categorized as low, medium, and high
according to the IEEETstandard C62.41 and
logs up to 5000 events
• Time-and-date stamped surge log
Logs transient surge events from your system,
records and saves in an event log with time
and date stamp viewable on a local display and
webpage, as well as a downloadable .csv file
• Alarm
When an audible alarm is produced, an alarm
message is viewable on the display as well as
the web interface; an activated alarm can be
silenced locally
• LED indicators
The tricolored (green/red/yellow) LED
protection status indicators are standard for
each phase and for neutral-ground protection
mode, when applicable
• Percentage protection status
Indicates the amount of surge protection
active per phase and for neutral-ground,
when applicable
• Connectivity
The RJ45 Ethernet port provides
communication between the Power Xpert™
SPD and webpage, ModbusTTCP/IP, or
BACnet/IP communications
• Form C relay contact
Provides remote SPD status; the NO and NC
contacts change states when any phase detects
a total loss of protection
Remote monitoring capabilities
• Onboard webpage
• BACnet/IP
• Modbus TCP/IP
• PXG900 Gateway
• Power Xpert Dashboard

2
Instruction Leaet IL158006EN
Effective November 2020
PX-SPD quick start guide
EATON www.eaton.com
Configuring your LCD display
Up and Down buttons
Use these to move between options in the menu and select an
alphanumeric character where appropriate in the menus.
Back and Enter buttons
Use these to make menu selections, navigate to other menus, and
exit or edit/save your selection.
1. Apply power to the product.
2. Press the Enter button (>) to navigate from the home screen to
the next menu.
3. Select the Setting menu and press Enter.
a. Enter a 6-digit numeric password for the LCD
b. Use the Up and Down buttons to scroll through the numbers
c. Press Enter to skip to the next digit
d. Press Enter at the end of the 6th digit to save the password
4. Select Set Date and Time under the Settings menu and
press Enter.
a. Set the date and time using the navigation buttons
b. Scroll to the end of the seconds in time setting
row to save the date and time
Time will initially be read as UTC time on the webpage
and can be changed later through the webpage
5. Select Set Device Name under the Settings menu and
press Enter.
a. Use the Up and Down buttons to scroll through the
alphanumeric characters
b. Press enter to skip to the next character
There is a selection to enter a blank space; it is located
between the number 0 and character Z
ote:N You must enter a blank space in between words to separate them.
c. When finished entering the name and to save the results,
keep pressing the Enter button until the cursor reaches end
of the row, and then press the Enter (>) button one more
time to save the entry

3
Instruction Leaet IL158006EN
Effective November 2020
PX-SPD quick start guide
EATON www.eaton.com
Communications setup
Configuration of Ethernet communication
Device default IP Address (192.168.1.254)
Connect Cat 5, or better, Ethernet cable between product and PC.
ote:N Configuring Modbus and BACnet/IP communication settings can be
found in the Instruction Manual.
Changes to WindowsTPC Ethernet adapter settings for IPv4
1. Search for Change Adapter Settings in your Control Panel
Network Settings.
2. Right click on Local Area Connection.
3. Click on Properties.
4. Click on Internet Protocol Version 4 (TCP/IPv4).
5. Click on Properties.
6. On General Tab, select Use the Following IP Address:
a. Enter 192.168.1.10 for the IP Address
b. Enter 255.255.255.0 for the Subnet Mask
c. Enter 192.168.1.1 for Default Gateway
7. Click on OK button and then exit out of all these open windows.
ote:N Configuration of IPv4 was done with Windows 10 in this guide.

Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2020 Eaton
All Rights Reserved
Printed in USA
Publication No. IL158006EN / Z24391
November 2020
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
PX-SPD quick start guide
Instruction Leaet IL158006EN
Effective November 2020
Accessing the PX-SPD webpage
1. Open a web browser (e.g., Chrome).
2. Type in the Stored IP Address (e.g., 192.168.1.254) into a web browser search field.
ote:N When directed to unsecure site warning page, click advanced and proceed to site.
3. Log on to PX-SPD webpage with the following default parameters:
a. Username: admin
b. Password: Admin*1
4. Change password when prompted.
a. Make a note of the new admin password for future webpage access
5. Now you can view the status of the PX-SPD remotely. View the Instruction Manual for
steps to download the site security certificate to avoid the warning page in the future.
ote:N For more detailed instructions, refer to the integrated or side-mounted Instruction Manuals, IM01005019E and IM01005031E, respectively.
For more information, visit
Eaton.com/PXSPD
Sidemounted
instruction manual
SCAN ME
Integrated
instruction manual
SCAN ME
Sidemounted
technical data
SCAN ME
Integrated
technical data
SCAN ME
Cybersecurity
Guide
SCAN ME
