Eaton 3SMini Assembly instructions

1 | Page 01/03/2021 AUG_Eaton-3SMini_V0
X²
Eaton 3SMini
3SM36
3SM36B
Advanced User Guide
Copyright © 2021 EATON
All rights reserved.
AUG_EATON-3SMINI_V0
3SMini EMEA

2 | Page 01/03/2021 AUG_Eaton-3SMini_V0
Special symbols
The following are examples of symbols used on the UPS or accessories to alert you
to important information:

3 | Page 01/03/2021 AUG_Eaton-3SMini_V0
1. Table of contents
1. Table of contents ...................................................................................................... 3
2. Introduction ............................................................................................................... 4
3. Presentation .............................................................................................................. 5
4. Installation ................................................................................................................. 6
4.1. Package contents ............................................................................................... 6
4.2. Safety.................................................................................................................. 7
4.3. Power supply cord / socket ............................................................................... 8
4.4. Start UPS ............................................................................................................ 9
4.5. Voltage setup.................................................................................................... 10
4.6. Connect the equipment ................................................................................... 12
5. Other functions ....................................................................................................... 13
5.1. Turn OFF, turn ON............................................................................................ 13
5.2. Display battery level ......................................................................................... 13
6. Troubleshooting ...................................................................................................... 14
7. Technical specifications .......................................................................................... 16
8. Equipment care....................................................................................................... 17
9. Service and support ................................................................................................ 17

4 | Page 01/03/2021 AUG_Eaton-3SMini_V0
2. Introduction
Thank you for selecting an Eaton product to protect your equipment.
The Eaton 3SMini range has been designed with the utmost care. We recommend
that you take the time to read this advanced user guide and documentations provided
to take full advantage of the many features of your UPS (Uninterruptible Power
System).
Before installing your Eaton 3SMini, please read the information and safety
instructions provided. Follow the instructions in the quick start guide and if necessary,
refer to this advance user guide.
To discover the entire range of Eaton products, we invite you to visit our web site at
eaton.com or contact your Eaton representative.
The Eaton 3SMini Uninterruptible Power System (UPS) is designed for small electrical
such as, but not limited to, Internet gateways, switches or routers, IP cameras etc. It
must not be used to supply other electrical equipment (lighting, household appliances,
etc.). It prevents your critical equipment from power failures and power surges.

5 | Page 01/03/2021 AUG_Eaton-3SMini_V0
3. Presentation
Mini UPS (plastic casing)
Removable AC input cord (CEE7/7 FR/DIN shown here)
Attached DC output cord
4x green LED: Voltage (Chapter 4.5), battery level (Chapter
5.2) and abnormal situations (Chapter 6)
ON/OFF button, battery level display and voltage selector
1
2
3
5
4

6 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4. Installation
4.1. Package contents
Included with the Eaton 36W AC-to-DC UPS:
Barrel adaptor polarity:
Supplied input cord (x1):
Supplied barrel
connectors (x4):
Supplied Quick
start/Safety notes (x1):
BS1363: 3SM36B models
or
CEE7/7 (FR/DIN): 3SM36 models
Note: Extended replacement
kit can be ordered through
your local customer service
eaton.eu/3SMini

7 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4.2. Safety
For product installation or additional information refer to the Quick Start and Advanced
User Guide. For customer support please contact your local after sales services.
DANGER: Dangerous voltage levels are present within the UPS. Do not
attempt to open the unit.
CAUTION: Do not dispose of batteries in a fire. When exposed to flame,
batteries may explode. Do not open or mutilate the battery or batteries. Released
electrolyte is harmful to the skin and eyes and may be extremely toxic.
Installation
Check that the indications on the rating plate correspond to your AC-power
system and to the actual electrical consumption of all the equipment to be connected
to the UPS. For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near
the equipment and shall be easily accessible. Ensure that AC main outlet is properly
earthed.
The UPS and their batteries must be kept in a ventilated place. Never expose the UPS
to direct sunlight or source of heat. This equipment should only be used in a dry indoor
environment. The admissible storage conditions are -20°C to +45°C (around 3 Months)
and +25°C max (1 year+). 0% to 95% of humidity non-condensing.
Do not place the UPS on any heat source or electronic equipment.
Use and Maintenance
There are no user serviceable parts inside the UPS.
Environmental Notice
Eaton has implemented an environmental-protection policy. Our products are
developed according to an eco-design approach (eaton.com/productstewardship).
Battery: The product contains batteries that must be processed according to
applicable local regulations concerning batteries.
The product includes Li-ion batteries, follow end-of-life instruction in view of
correct waste disposal

8 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4.3. Power supply cord / socket
Connect the UPS to the AC power source through a wall-protected outlet equipped with an
earth connector, using the attached cord for a UPS with FR/DIN (CEE7/7) or British (BS1363)
sockets.
Figure 1 FR/DIN example
Initial power-on requires that the UPS is plugged to main first.

9 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4.4. Start UPS
Do not connect load until the voltage has been appropriately setup (see 4.5)
Press the ON/OFF button for three seconds. The battery level is first displayed for five
seconds then the LED indicates the output voltage level (default 12V):
Figure 2 Start UPS
Battery levels:
Slow blinking LED
Fast blinking LED
Figure 3 Battery levels

10 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4.5. Voltage setup
Before entering voltage setup, ensure that the protected equipment is
disconnected from the UPS:
Figure 4 Disconnect the equipment
Then enter voltage setup mode and select the appropriate output DC voltage
corresponding to equipment nominal input voltage (9V, 12, 15V or 19V):
•Press the ON/OFF button (5) for eight seconds
Important: The LED and UPS will briefly shut down (OFF to 0V) during the
process and it will turn off any connected equipment, just keep pressing the
button until eight seconds have passed.When LED start flashing (slow), release
the button.

11 | Page 01/03/2021 AUG_Eaton-3SMini_V0
•You can then cycle through the different LED position which indicate the
voltage output by pressing the ON/OFF button (quick press).
Note that the voltage is not active until the selection is confirmed.
Figure 5 Cycle through the voltage levels
•Once the voltage is selected, then simply press eight seconds to confirm the
choice. The LED will stop blinking and steady itself.
The DC output is now delivering the new voltage.

12 | Page 01/03/2021 AUG_Eaton-3SMini_V0
4.6. Connect the equipment
•Select the correct barrel adaptor
and clip it on the UPS output
connector
•Plug your equipment
Your equipment is now backed-up

13 | Page 01/03/2021 AUG_Eaton-3SMini_V0
5. Other functions
5.1. Turn OFF, turn ON
Simply press three seconds the ON/OFF button (5), ON ➔OFF or OFF ➔ON
Figure 6 Turn ON or OFF the UPS
5.2. Display battery level
•The battery level is automatically displayed when the UPS is on battery (no
mains)
•On mains, you can simply press the ON/OFF button once (quick press), battery
level will be displayed for five seconds and return to voltage indication.

14 | Page 01/03/2021 AUG_Eaton-3SMini_V0
6. Troubleshooting
Main LED-indicated abnormal situations:
Auto-recovery (AR) mode: when fault condition occurs, UPS will shut down then
recover to normal when fault condition is removed.
LED blinking code
Situation description
Abnormal situation (OCP)
Over Current Protection
If situation remains the UPS enters AR mode to
protect the equipment.
UPS automatically returns to normal state once
situation is back to normal
Abnormal situation (OTP)
Over Temperature Protection (NTC temperature)
If situation remains the UPS enters AR mode to
protect the equipment.
UPS automatically returns to normal state once
situation is back to normal
Abnormal situation (OVP)
Over Voltage Protection
If situation remains the UPS enters AR mode to
protect the equipment.
UPS automatically returns to normal state once
situation is back to normal
Internal failure
Keeps blinking for 20 seconds then enters
shutdown mode
The unit needs replacement. Contact your
customer service.

15 | Page 01/03/2021 AUG_Eaton-3SMini_V0
Problem
Possible cause
Action
All LED are OFF
The UPS is turned OFF
Press 3s the ON/OFF button.
UPS does not start
This could be linked to
initial state (out-of-box)
Make sure that the UPS is plugged in a
wall outlet that delivers power and
press three seconds the ON/OFF
button.
If this does not work, contact your
local customer service.
One LED remains
OFF when UPS is
fully charged, and
battery level
displayed
LED is defective
Contact your local customer service.
UPS does not
charge
Power is not delivered to
UPS or batteries may be
defective
1) Ensure that charging is not
interrupted.
2) Check mains are delivering power.
3) Check that the input cord is well
plugged in the UPS.
4) Contact your local customer service.
Load is not
powered
UPS is in Auto-Recovery
(AR) mode
Unplug the equipment.
1) Verify load electrical characteristics
(voltage, power).
2) Let the UPS cool down (keep device
away from any heat source).
Wait several minutes and try again.
UPS is frozen and
ON/OFF button is
ineffective
UPS is locked
Disconnect equipment, turn OFF UPS
and unplug it from mains.
Wait a minute and reconnect UPS.
Turn it back ON.
Other option: Reset to factory settings:
press 15 seconds from the OFF state
(unplugged). Then plug UPS and
restart UPS.

16 | Page 01/03/2021 AUG_Eaton-3SMini_V0
7. Technical specifications
T e chnical specifications
Technical specifications
AC Input voltage
100-240V~ AC
AC Input current
CEE7/7 (FR/DIN): 1.6A
BS 1363: 1.6A
Input frequency
50/60Hz
Output voltage/Amps
9V/3A
12V/3A
15V/2,4A
19V/1,89A
Output connection Barrel adaptors
5,5 x 2,5
5,5 x 2,1
4,75 x 1,7
3,5 x 1,35
Power rating
36W
Battery type
Li-Ion x2 (ICR18650)*
Cell weight: 45g Max
Battery capacity
3,7 V/2200mAh (x2)
UPS dimensions (W x H x D)
95,5 x 30 x 136 mm
UPS weight
0,4 kg
Operating temperature
0 - 35°c
Safety
IEC 62477-1, CE mark, CB report
EMC
IEC 62040-2
Performance
IEC 62040-5-3
Warranty
2 years
* Typical full charge time (may vary): ~4h
Part number
Input cord
3SM36
FR/DIN (1m long)
3SM36BS
BS1363 (1m long)

17 | Page 01/03/2021 AUG_Eaton-3SMini_V0
8. Equipment care
For full battery life, keep the equipment at an ambient temperature of 25 °C (77 °F).
Battery service life is reduced as follows;
0<T≤10℃，440mAh
10<T≤45℃，2200mAh
45<T≤55℃，1100mAh
It is recommended to fully charge the battery after initial setup and if possible,
to perform two or three cycles of charge/discharge.
If the UPS requires any type of transportation, verify that the UPS is turned off.
More information on Eaton recycling:
9. Service and support
If you have any question or problem with the UPS, call Eaton or your local service
representative in your country / region.
Please have the following information ready when you call for service:
• catalog number,
• serial number,
• date of failure or problem,
• symptoms of failure or problem,
• customer return address and contact information,
• description of the installation.
Register warranty at www.powerquality.eaton.com/EMEA/Product-Registration
====================== END ======================
