PSFi Series Portable Surge Filter
(Single Phase, 10A & 16A, 60kA Mass Aggregate)
APPLICATIONS:
Plug-in UPS Systems
Servers
Portable Instrumentation
Point of Sale Systems
Small office systems
Industrial/surge prone sites
FEATURES:
Surge suppression and filtering in a single package
3 Mode protection
Surge suppression rating of 40kA (8/20μS) L – N, 10kA L – E, 10kA N – E
Rugged IP24 enclosure
IEC Input & Output connectors
FUNCTIONAL DESCRIPTION
The PSFi is a 3-stage protection surge protector utilising high kA primary and secondary MOV protection in
conjunction with an L/C filter. In addition, the PSFi also provides filtering of line harmonics and high-
frequency noise with a cut-off frequency of ~10kHz and a nominal attenuation of 40dB.
The PSFi series is designed to provide secondary protection against power surges caused by external
sources such as lightning strikes and electrical switching as well as providing a measure of protection from
surge events generated on the secondary side of the filter. The PSFi has been designed in accordance
with AS3100, AS1768, IEC61643-11, IEC61000-6-1, 2, 3, 4 and other standards and codes as applicable.
FUNCTIONAL DIAGRAM
Technical Specification & Operating Guide

Page 2 of 2
OPERATION
1. Find a suitable location for the PSFi. The PSFi requires free airflow for cooling. Do not stack items
on top of the PSFi.
2. Connect load equipment to PSFi filter using appropriate leads.
3. Connect to a suitable power outlet. As the unit has no power switch, it is important that the power
outlet’s switch be easily accessible.
4. Apply power. “Power’ indicator should light. If not, check connections or test power outlet with a
known ‘good’ device.
TECHNICAL SPECIFICATION
PSF10i PSF16i
Number of ports 2 Port
Method of mounting Portable.
Input voltage – Uc 200-250VAC 1
Maximum continuous voltage – MCOV 320VAC
Temporary overvoltage - TOV 350VAC 15 mins
Service type Single-phase, Line/Neutral/Earth
Test classification Class III
Nominal discharge current - In 8/20us In L-N 20kA, N-E 3kA, L-E 3kA
Current rating - continuous 10 Amps 16 Amps
Recommended maximum over current protection 20A upstream circuit breaker or fuse.
Residual current <0.5 mA
Protection modes Line-Neutral, Line-Earth, Neutral-Earth
Maxi surge current - Ismax 8/20us (Line-Neutral) 40kA
Nominal surge lifetime 15 hits @ 20kA (8/20uS, each mode)
Filter attenuation 40dB nominal at 1MHz
Initial clamp voltage (Line-Neutral) 560V (350Vac RMS)
Initial clamp voltage (Line-Earth, Neutral-Earth) 680V (420Vac RMS)
Residual voltage (Vpl) Line-Neutral 8/20us <900V @ 3kA
Internal protection (fusing) Thermal fusing on primary MOVs
Terminations Input - IEC C14 10A (1)
Output - IEC C13 10A (1)
Input - IEC C20 16A (1)
Output - IEC C19 16A (1)
Alarms/indicators 2 part display, Power OK, Protection fault.
Location Category Indoor
Enclosure rating IP24
Standards. Designed in accordance with : IEC61643-11, IEC610006-1,2,3,4 ANSI/IEEE C62.41 Cat B
AS1768-1991 Cat B AS3000,AS3100,
Dimensions 205mm (L) x 90mm (W) x 55mm (H)
Weight 1kg
Environment -10 to 50C, 0 to 95%RH (non-condensing)
Warranty 1 year, workmanship and materials
Specifications are subject to change without notice. Copyright 2015 Eaton Industries Pty Ltd
Two indicator lights are fitted to the unit for mains power and
protection failure indication:
Normal operation is indicated with the blue ‘Power On’ LED
being lit.
In the event of MOV failure, the 'Fault' LED will light to inform
the operator that the unit requires replacement.
IMPORTANT: If the ‘Fault’ light illuminates during operation, or
the unit appears to malfunction in any way, return the unit for
service or replacement.
Service Hotline [phone].
