TECHNICAL SPECIFICATIONS MQ1364
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# MQ1364-888141 (A) /2 pp/4/15/99 • Printed In USA
DESCRIPTION
• Mid/High VA4 loudspeaker system
• Optimized for permanent installation only
• Horn-loaded 10-in cone with VA4 phase plug
• 2-in exit/75mm voice coil compression driver on
constant directivity horn
The new MQ Series represents the next generation of perma-
nent installation loudspeaker systems. Using VA4 Technol-
ogy developed for the new KF700 Series, the MQ range re-
places the MH and BV ranges of Virtual Array systems. The
Series comprises matched sets of mid/high and low frequency
enclosures that enjoy complementary dimensions and
trapeziod angles to facilitate the creation of optimized-cov-
erage arrays.
The MQ1364 uses a single, horn-loaded 10-in midrange cone
with a specially designed geometry that produces a time-
coherent wavefrontthroughtheupperportionof themidrange
that is critical to vocal articulation. A phase plug with radial
slots then serves to reduce the mechanical reactance of the
subsystem without affecting the directivity of the source,
allowing for flawless arraying of multiple MQ mid/high mod-
ules.
A high power 2-in exit/75mm voice coil high frequency com-
pression driver is mounted on a constant directivity horn for
consistent, accurate dispersal of HF information. The MQ1364
provides a nominal coverage pattern of 60°(h) x 40°(v).
APPLICATION
The MQ1364 mid/high module works with the MQ1312 triple
12-in low frequency module to create arrays for use in a
wide variety of permanently installed applications.
The most common array configuration is 2x MQ1364’s sepa-
rated by a single MQ1312. In such an array, a certain amount
of splay must be provided to achieve optimal coverage. Rig-
ging systems currently available allow users up to 10°of
overlap between the mid/high enclosures.
All MQ Series enclosures feature a comprehensive system of
3/8”-16 threaded mounting points for maximum flexibility
when suspending arrays overhead.
Applications include:
Large House of Worship
Arena
Stadium
Theater
Performing Arts Center
DESCRIPTIVE DATA
Configuration Mid/High
Powering Biamplified
MF Subsystem 1x 10-in Horn-Loaded Cone,
Radial Phase Plug
HF Subsystem 1x 2-in Exit/75mm Voice Coil
Compression Driver on Constant
Directivity Horn
Cabinet Type (shape) Trapezoid
Enclosure Materials Baltic Birch Plywood
Finish Black Polyurethane
Connectors 4-Terminal Barrier Strip &
1x Neutrik NL4 Speakon
Suspension Hardware (16) 3/8"-16 Threaded Mounting
Suspension Points (4 each top,
bottom and sides)
Grill Powder Coated Perforated Steel
Dimensions inches millimeters
Height 40.00 1016
Width (front) 32.00 813
Width (rear) 8.12 206
Depth 25.61 650
Trapezoid Angle 50°
Weights pounds kilograms
Net Weight 148 67.3
Shipping Weight 156 71.0
Companion Systems
Sub Bass SB528, BH822e
LF MQ1312

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA • Phone [phone] • Toll Free 800/992-5013 • Fax [phone] • Web http://www.eaw.com • email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
TECHNICAL SPECIFICATIONS MQ1364
DIMENSIONAL DRAWINGS ARCHITECTURAL SPECIFICATIONS
The two-way mid/high loudspeaker system shall incorporate
a 10-in cone MF transducer and a 2-in exit compression driver
HF transducer.
The MF driver shall be loaded into a midrange horn con-
structed of 3mm birch plywood reinforced with high density
polyurethane foam. The MF horn shall incorporate a phase/
displacement plug. The HF driver shall be loaded on con-
stant directivity horn with a nominal coverage pattern of
60°(h) x 40°(v). An internal passive filter network shall
provide system equalization.
System frequency response shall vary no more than ±3 dB
from 190 Hz to 19 kHz measured on axis. The midrange fre-
quency section shall produce a Sound Pressure Level (SPL) of
109.5 dB SPL on axis at 1 meter with a power input of 1
Watt, and shall be capable of producing a peak output of
141.5 SPL on axis at 1 meter. The high frequency section
shall produce a Sound Pressure Level (SPL) of 114 dB SPL on
axis at 1 meter with a power input of 1 Watt, and shall be
capable of producing a peak output of 143 SPL on axis at 1
meter. The midrange frequency section shall handle 400 Watts
of amplifier power (AES Standard) and shall have a nominal
impedance of8 Ohms.Thehigh frequency sectionshallhandle
200 Watts of amplifier power (AES Standard) and shall have
a nominal impedance of 8 Ohms.
The loudspeaker enclosure shall be trapezoidal in shape. It
shall be constructed of 15mm thickness void-free cross-grain-
laminated Baltic birch plywood and shall employ extensive
internal bracing. It shall be finished in black catalyzed poly-
urethane. Input connectors shall be 4-terminal barrier strip
and one Neutrik NL4 Speakon. A total of sixteen 3/8"-16
threaded mounting/suspension points (4 each top, bottom
and sides) shall be provided. The front of the loudspeaker
shall be covered with a powder coated perforated steel grill.
The two-way mid/high loudspeaker shall be the EAW model
MQ1364.
NOMINAL DATA
Frequency Response (1 W @ 1m)
±3 dB 190 Hz to 19 kHz
-10 dB 140 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
MF 109.5
HF 114.0
Impedance (Ohms) MF 8
HF 8
Power Handling, AES Standard (Watts)
MF 400
HF 200
Calculated Maximum Output (dB SPL)
MF Peak 141.5
HF Peak 143.0
MF Long Term 135.5
HF Long Term 137.0
Nominal Coverage Angle/-6 dB points (degrees)
Horizontal 60
Vertical 40
Recommended High-Pass Frequency
24 dB/Octave 190 Hz
FRONT
SIDES BACK
MOUNTING POINT, 3/8-16 THREADED HOLE.
510834 (A)
exp 4/8/99 dpm
MQ1364
CENTER OF BALANCE, TBD.
L
C
7.38
10.57
5.63
INPUT
5.00
23.28
12.16
11.91
L
C
(8.12)
25.61
50°
TOP
32.00
40.00
GRILL PARTIALLY
SHOWN
36.10
6.37
1.95
13.15

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA • Phone [phone] • Toll Free 800/992-5013 • Fax [phone] • Web http://www.eaw.com • email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
FREQUENCY RESPONSE
INPUT IMPEDANCE
PERFORMANCE SPECIFICATIONS MQ1364
60
80
100
120
50 100 1000 10000 2000
0
dB SPL
Frequency
(
Hz
)
MQ1364 Axial Response
K
B
0
5
10
15
20
20 100 1000 10000 2000
0
Ohms
Frequency (Hz)
HF Tri-Amp Input Impedance (Magnitude)
MF Tri-Amp Input Impedance (Magnitude)
MQ1364 Input Impedance (Magnitude)
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
BEAMWIDTH
Q & DIRECTIVITY INDEX (DI)
PERFORMANCE SPECIFICATIONS MQ1364
0
30
60
90
120
150
180
210
240
270
300
330
360
200 1000 1000
0
Degrees
Frequency (Hz)
Horizontal Beamwidth (1/3 Octave)
Vertical Beamwidth (1/3 Octave)
MQ1364 Beamwidth vs Frequency
K
B
0.1
1
10
100
0.1
1
10
100
200 1000 10000
Q
Directivit
y
Index
Frequency (Hz)
Horizontal Q and Directivity (1/3 Octave)
Vertical Q and Directivity (1/3 Octave)
Total Q and Directivity (1/3 Octave)
MQ1364 Q and Directivity
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
POWER RESPONSE
PERFORMANCE SPECIFICATIONS MQ1364
60
80
100
120
200 1000 10000 2000
0
dB SPL
Fre
q
uenc
y
(
Hz
)
MQ1364 Beamwidth Delimited Power Response
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
Q & DIRECTIVITY & BEAMWIDTH BY FREQUENCY
Frequency Hor Beamwidth Ver Beamwidth Hor Q & Dir Ver Q & Dir Tot Q & Dir
80 360 360 4.3 1.8 2.7
100 360 360 3.9 3.2 3.5
125 360 360 2.2 2.4 2.3
160 360 130 2.7 5.1 3.5
200 119 155 4.5 4.7 4.6
250 124 294 5 1.4 2.4
315 101 109 6.9 3.8 5
400 83 102 9 6.4 7.5
500 70 91 11.5 7.3 9
630 56 65 14.6 11.3 12.8
800 58 43 14.7 16 15.3
1000 61 25 15.1 24.4 18.3
1250 59 28 15.4 30.9 20.1
1600 62 38 14.6 28.6 19
2000 62 40 14.5 29.8 19.3
2500 63 39 15.2 33.5 20.7
3150 62 38 15.2 33.8 20.8
4000 63 38 13.8 33.2 19.4
5000 64 39 14.2 34.3 20.1
6300 67 33 10.3 46 17.8
8000 65 38 10.5 38.1 17.6
10000 62 48 15.5 23.6 18.6
12500 64 41 13.2 26.9 16.5
16000 47 39 24.3 32.9 27.7
20000 71 33 13.4 32.4 17.9
PERFORMANCE SPECIFICATIONS MQ1364

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL OFF-AXIS RESPONSE
On-axis response normalized to 0 dB.
PERFORMANCE SPECIFICATIONS MQ1364
-20
-10
0
10
20
100 1000 1000
0
Attenuation in dB
Frequency
(
Hz
)
Horizontal +10 degrees
Horizontal -10 degrees
MQ1364 Horizontal ±10°
K
B
-20
-10
0
10
20
100 1000 1000
0
Attenuation in dB
Frequency
(
Hz
)
Horizontal +20 degrees
Horizontal -20 degrees
MQ1364 Horizontal ±20°
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
PERFORMANCE SPECIFICATIONS MQ1364
VERTICAL OFF-AXIS RESPONSE
On-axis response normalized to 0 dB.
-20
-10
0
10
20
100 1000 1000
0
Attenuation in dB
Frequency
(
Hz
)
Horizontal +30 degrees
Horizontal -30 degrees
MQ1364 Horizontal ±30°
K
B
-20
-10
0
10
20
100 1000 1000
0
Attenuation in dB
Frequency
(
Hz
)
Horizontal +40 degrees
Horizontal -40 degrees
MQ1364 Horizontal ±40°
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OFF-AXIS RESPONSE
On-axis response normalized to 0 dB.
PERFORMANCE SPECIFICATIONS MQ1364
-20
-10
0
10
20
100 1000 10000
Attenuation in dB
Fre
q
uenc
y
(
Hz
)
Vertical +10 degrees
Vertical -10 degrees
MQ1364 Vertical ±10°
K
B
-20
-10
0
10
20
100 1000 10000
Attenuation in dB
Fre
q
uenc
y
(
Hz
)
Vertical +20 degrees
Vertical -20 degrees
MQ1364 Vertical ±20°
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OFF-AXIS RESPONSE
On-axis response normalized to 0 dB.
PERFORMANCE SPECIFICATIONS MQ1364
-20
-10
0
10
20
100 1000 10000
Attenuation in dB
Fre
q
uenc
y
(
Hz
)
Vertical +30 degrees
Vertical -30 degrees
MQ1364 Vertical ±30°
K
B
-20
-10
0
10
20
100 1000 10000
Attenuation in dB
Fre
q
uenc
y
(
Hz
)
Vertical +40 degrees
Vertical -40 degrees
MQ1364 Vertical ±40°
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL 1/3 OCTAVE POLAR DATA MQ1364
6 db/div.
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
100
125
160
200
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
250
315
400
500
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°630
800
1000
1250
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°1600
2000
2500
3150
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°4000
5000
6300
8000
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°10000
12500
16000
20000
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL 1/3 OCTAVE POLAR DATA MQ1364
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
100
125
160
200
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°10000
12500
16000
20000
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
1600
2000
2500
3150
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
250
315
400
500
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
4000
5000
6300
8000
K
B
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°630
800
1000
1250
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 125 Hz Horizontal Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 250 Hz Horizontal Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 500 Hz Horizontal Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 1000 Hz Horizontal Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 2000 Hz Horizontal Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 4000 Hz Horizontal Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
HORIZONTAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 8000 Hz Horizontal Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 16000 Hz Horizontal Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 125 Hz Vertical Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 250 Hz Vertical Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 1000 Hz Vertical Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 500 Hz Vertical Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 2000 Hz Vertical Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 4000 Hz Vertical Octave Polar Data
K
B

Acoustic Performance Partnership Eastern Acoustic Works MQ1364
One Main Street, Whitinsville MA, 01588 USA •Phone [phone] •Toll Free 800/992-5013 •Fax [phone] •Web http://www.eaw.com •email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
VERTICAL OCTAVE POLAR DATA MQ1364
6 db/div.
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 8000 Hz Vertical Octave Polar Data
K
B
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
MQ1364 16000 Hz Vertical Octave Polar Data
K
B
