EAW MK2299 User guide

NOTES:
1. SYMBOL INDICATES MOUNTING POINT 3/8-16
THREADED HOLE (NUT PLATE).
2. SYMBOL INDICATES MOUNTING POINT 3/8-16
THREADED HOLE (PI ANGLE).
3. SYMBOL INDICATES CENTER OF BALANCE.
4. WEIGHT APPROX 60 LBS.
5. SHIPPING WEIGHT APPROX 70 LBS.
5.25
PROTOTYPE
BACK
(8.23)
INPUT
7.25
6.81
30.00 26.10
15.00
DIMENSIONS APPLY
TO BOTH SIDES
VIEW A-A
FRONT
GRILLE PARTIALLY SHOWN
1.95
(14.12)
(6.27)
A
30°
7.23
6.69 7.25
15°
TOP
DIMENSIONS APPLY
TO TOP AND BOTTOM
L
C
15.54
14.75
8.75 A
26.07
1.97
13.03
EASTERN ACOUSTIC WORKS
MK2299
L
C
