EAW MS20 User guide

FRONT
9.75
4.62
7.44
REMOVABLE GRILLE
PARTIALLY SHOWN
TOP/BOTTOM
DIMENSIONS APPLY
TO TOP AND BOTTOM
C
L
DIMENSIONS APPLY
TO BOTH SIDES
PRODUCTION EASTERN ACOUSTIC WORKS
MS20 LEFT
NOTES:
1. SYMBOL INDICATES MOUNTING POINT, 1/4-20
THREADED HOLE (T-NUT).
2. SYMBOL INDICATES CENTER OF BALANCE.
3. WEIGHT APPROX. 18 LBS.
4. SHIPPING WEIGHT APPROX. 19 LBS.
14.87
2.75
2.75
4.25
L
BACK
C
INPUT
5.00
RIGHT
9.75
4.50
