MBL Series Testing Kit User Manual
New Generation Package Compatible
Sub-1G Wireless Module
E07-400MBL-01

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 1
Contents
I. Product Overview .............................................................................................................................3
1.1 Product Introduction ................................................................................................................. 3
1.2 Dimensions, interface description .............................................................................................4
1.3 Support List ...............................................................................................................................5
II. Software Introduction .................................................................................................................... 6
2.1 Directory structure .................................................................................................................... 6
2.2 IAR Engineering ....................................................................................................................... 7
2.3 Main function ............................................................................................................................8
2.4 Transceiver Timing ................................................................................................................... 8
2.5 Programming ...........................................................................................................................10
III. Quick Demo ................................................................................................................................. 13
3.1 Signal cable connection .......................................................................................................... 13
3.2 Serial Assistant ........................................................................................................................14
IV. FAQ ............................................................................................................................................... 15
4.1 The transmission distance is not ideal .....................................................................................15
4.2 The module is easily damaged ................................................................................................ 15
4.3 The bit error rate is too high ....................................................................................................16
Revision history ..................................................................................................................................16
About us ..............................................................................................................................................16

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 2
Disclaimer and Copyright Notice
Information in this document, including URL addresses for reference, is subject to change
without notice. Documentation is provided "as is" without warranty of any kind, including any
warranties of merchantability, fitness for a particular purpose, or non-infringement, and any
warranties referred to elsewhere in any proposal, specification or sample. No liability is assumed in
this document, including any liability for infringement of any patent rights arising out of the use of
the information in this document. This document does not hereby grant, by estoppel or otherwise,
any license, express or implied, to any intellectual property rights.
The test data obtained in this article are all obtained by the Ebyte laboratory test, and the actual
results may be slightly different.
All trade names, trademarks and registered trademarks mentioned herein are the property of
their respective owners and are hereby acknowledged.
The final interpretation right belongs to Chengdu Ebyte Electronic Technology Co., Ltd.
Notice :
Due to product version upgrade or other reasons, the contents of this manual may be changed.
Ebyte Electronic Technology Co., Ltd. reserves the right to modify the contents of this manual
without any notice or prompt. This manual is only used as a guide. Chengdu Ebyte Electronic
Technology Co., Ltd. does its best to provide accurate information in this manual. However,
Chengdu Ebyte Electronic Technology Co., Ltd. does not ensure that the contents of the manual are
completely error-free. All statements in this manual , information and advice do not create any
express or implied warranties.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 3
I. Product Overview
1.1 Product Introduction
MBL series testing kits are designed to help users quickly evaluate Ebyte's new generation of
package-compatible wireless modules. Most of the pins on the board have been led out to pin
headers on both sides, and developers can easily connect various peripheral devices through jumpers
according to actual needs.
The kit provides complete software application examples to help customers quickly get started
with wireless data communication development. According to customer needs, different types of
Sub-1G wireless modules can be mounted on board. Supported modules are available in
pin-compatible packages for quick replacement.
1.2 Dimensions, interface description

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 4
Pin
Definition
Function Description
1
VCC
Module power supply pin. It needs to
be shorted with pin 2 to supply power
to the module.
2
3.3V
3.3V power pin
3
3.3V
3.3V power pin
4
VIO
MCU power supply pin. It needs to be
shorted with pin 3 to power the MCU.
5
GND
Backplane reference ground
6
REST
MCU external reset pin
7
SWIM
MCU's SWIM pin
8
VIO
MCU power supply pin
9
PC0
Module reset pin
10
PB7
Module MISO pin
11
PB6
Module MOSI pin
12
PB5
Module SCLK pin
13
PB4
Module NSS pin
14
TXD
MCU serial port TXD
15
RXD
MCU serial port RXD
16
M1
Module mode switching pin (see
module product manual for details)
17
GND
Backplane reference ground
18
M0
Module mode switching pin (see
module product manual for details)
19
GND
Backplane reference ground

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 5
1.3 Support List
Chip solution
Manufacturer
Module model
1
CC1101
Texas Instruments
E07-400M10S
2
CC1101
Texas Instruments
E07-900M10S
3
SI4438
Silicon Labs
E30-400M20S
4
SI4463
Silicon Labs
E30-900M20S
5
LLCC68
Semtech
E220-400M22S
6
LLCC68
Semtech
E220-900M22S
7
SX1278
Semtech
E32-400M20S
8
SX1276
Semtech
E32-900M20S
9
SX1268
Semtech
E22-400M22S
10
SX1262
Semtech
E22-900M22S
11
AX5243
ON Semiconductor
E31-400M17S
12
LLCC68
Semtech
E220-400MM22S
13
LLCC68
Semtech
E220-900MM22S

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 6
II. Software Introduction
2.1 Directory structure
Item
Description
1
File
Directory
You can download the sample file from the official website, and open the
directory as shown in the figure below.
2
Catalog
description
You can use the IAR For STM8 development environment to find the entry
file and open the project.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 7
2.2 IAR Engineering
Item
Description
Engineering
structure
Use the IAR For STM8 development environment to open the project, and
you can see the basic structure.
Switch
workspace
The global macro definition and file path are defined in the C/C++ Compiler
option, which are used to distinguish the driver files of different modules.
When switching the workspace, different macro definitions will be used to
switch the driver files of different modules.
When the "Exclude from build" attribute of "Drivers/Ebyte/RF" is changed,
the target module driver folder is selected to participate in the compilation
process. When the "Additional include" in the project "C/C++ Compiler" is
changed, the module driver file path is specified. When the "Defined
symbols" in the project "C/C++ Compiler" is changed, the global macro
definition is defined to help configure the module driver properties.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 8
2.3 Main function
main.c is the main function entry. The demo function process is simplified as follows:
Item
Description
1
Key Function
When a button is pressed, the command data is sent wirelessly.
Essentially sending a specific string "ping" and expecting a "pong" in
response.
2
Serial data to
wireless
transmission
After the serial port receives the data, it automatically starts wireless
transparent transmission of data. Of course, it contains some special
command responses, which are mainly used for special tests and can be
ignored by users. After the sending is completed, the user function will
be automatically called back to process the sending logic by itself.
3
Receive data
wirelessly
Generally, the internal status flag of the module is read to determine
whether there is data, and the underlying driver will copy the data and
pass it to the user callback function, so as to process the receiving logic
by itself.
The software process is simplified as shown in the figure below:
2.4 Transceiver timing
There are multiple operating states of the wireless module, and specific functions can only be
completed in the corresponding states. From the simplest sending and receiving data, only the
sending mode and receiving mode are considered.
Item
Description
1
Receiving mode
After the default initialization is completed, it automatically enters the
receiving mode. In essence, the receiving function is called in the
initialization to enter the receiving mode. If you need to consider
entering other modes after initialization, such as sleep, you can directly

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 9
replace it with the same type of function Go_xxxxx().
2
Sending mode
When calling the sending function, the underlying driver actually
switches the module into standby mode first, and usually completes the
modulation parameter configuration in this mode, such as frequency,
power, frequency offset, etc. After the parameters are configured
correctly, gradually enter some intermediate modes, open the internal
FIFO, PA, external XTAL, etc., and the current consumption will
gradually increase. Eventually switch into send mode, triggering
wireless data transmission. After completion, the module enters the
standby mode. In this state, sending and receiving cannot continue, and
the user needs to handle the next step in the callback function. When the
function is complex, if continuous reception or continuous transmission
is required, please further switch to other modes according to the
characteristics of the chip.
The timing diagram is as follows:

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 10
2.5 Programming
Document
Key Description
1
ebyte_core.h
A module structure is defined, the basic functions are abstracted, and
the functions of the underlying module will be bound to the structure.
When used in simple sending and receiving applications, there is no need
to understand the underlying working details of each module, and the data
can be sent and received by directly calling the abstracted function. If you
need to customize some functions, you can also consider integrating them
into the structure. If you know enough about the functions of the

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 11
underlying modules, you can also directly remove the ebyte_core.c/h file,
and there is no strong coupling between the
layers.
2
ebyte_exx.c
It is a specific module driver file, which is generally packaged and does
not need to be modified by the user. It only needs to consider how to input
and output data from this "box".
3
ebyte_port.c
It is specially used to bind SPI and GPIO under different hardware
platforms, abstracted as the input of "box". Users need to fill the
communication interface in their own hardware platform to a fixed
position according to the comments. Generally speaking, it is to provide
the SPI transceiver function and the level control of the pin. Some
modules are slightly special. For example, E49 uses half-duplex SPI. If
you don’t want to write a communication driver, you can directly bind the
IO to a fixed position, and leave the rest to the module driver to simulate
IO to realize communication. As shown in the figure below, in the
comments, it is required to provide the SPI interface position to fill in the
specific sending and receiving functions, send the data into the SPI to send
data, and return the SPI to receive data from the
result.
ebyte_callback.c
It is specially used to bind the user's own sending and receiving logic,
abstracted as the output of the "box". Essentially, the module driver is to
directly call the user's callback function after confirming that the sending
or receiving is completed. As shown in the figure below, just fill in the
user's logic function in the To-do prompt position. The state is transmitted
by the module driver, and is actually processed by the Exx_GoTransmit()
function. When the function is complex, it can be considered to be
modified to support more

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 12
situations.
ebyte_exx.h
Some conventional modulation parameters are defined, generally do not
need to be modified, you can adjust them by yourself. Note, please
understand the instructions in the comments when modifying. There is a
range check for parameters in the module driver, and wrong modulation
parameters will cause initialization failure. The following figure shows an
example of FSK modulation
parameters:
board.c
STM8 peripheral initialization, involving SPI, TIMER, GPIO, etc., is
strongly coupled with the hardware used.
board_button.c
The key event queue is a FIFO in terms of data structure. After the timer
detects the button, it will store the corresponding event in the queue and
wait for the main loop to respond.
board_mini_printf.c
Simplified printf, although the function has shrunk, it occupies a small
volume. The DEBUG macro in the project mainly depends on the mprintf
provided by this file.
ebyte_kfifo.c
Used for serial port data reception, optimized general-purpose FIFO
queue, suitable for cache.
ebyte_debug.c
It is used to connect to a PC for some tests, and generally does not need to
be used.
stm8l15x_it.c
All interrupt function entries are concentrated here for interrupt service
functions such as serial ports, timers, key IO, etc.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 13
III. Quick Demo
3.1 Signal line connection
Item
Description
1
Power jumper cap
2
Mode selection
jumper cap
3
Auxiliary
USB cable, antenna, PC, etc.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 14
3.2 Serial Assistant
Item
Description
1
Device manager
View the serial port
number
2
Serial software
3
Example of push
button
communication
#RECV Identifier, used only for prompting, indicates the data received
by the wireless module.
#SEND identifier, only used for prompting, indicating the data sent by
the wireless module.
4
Serial data
transparent
transmission
Serial data transparent transmission Directly transmit the required
content through XCOM

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 15
IV. FAQ
4.1 The transmission distance is not ideal.
When there is a straight-line communication obstacle, the communication distance will be
attenuated accordingly；
Temperature, humidity, and co-channel interference will increase the communication packet loss
rate;
The ground absorbs and reflects radio waves, and the test effect is poor when it is close to the
ground;
Sea water has a strong ability to absorb radio waves, so the seaside test effect is poor;
There are metal objects near the antenna, or placed in a metal case, the signal attenuation will be
very serious;
The power register is set incorrectly, and the air speed is set too high (the higher the air speed,
the closer the distance);
The low voltage of the power supply at room temperature is lower than the recommended value,
and the lower the voltage, the lower the power output;
The matching degree between the antenna and the module is poor or the quality of the antenna
itself is problematic.
4.2 The module is fragile
Please check the power supply to ensure that it is within the recommended power supply voltage.
If it exceeds the maximum value, the module will be permanently damaged;
Please check the stability of the power supply, the voltage cannot fluctuate greatly and
frequently;
Please ensure anti-static operation during installation and use, and high-frequency devices are
electrostatically sensitive;
Please ensure that the humidity during installation and use should not be too high, some
components are humidity sensitive devices;
If there is no special requirement, it is not recommended to use it at too high or too low
temperature.

成都亿佰特电子科技有限公司 MBL 评估套套件用户手册
Copyright ©2012–2021，成都亿佰特电子科技有限公司 16
4.3 BER is too high
There is co-channel signal interference nearby, stay away from the source of interference or modify the
frequency and channel to avoid interference;
Unsatisfactory power supply may also cause garbled characters, so ensure the reliability of the power supply;
Poor quality or too long extension cables and feeders will also cause high bit error rates.
Revise history
Version
Revision date
Revision Notes
Maintenance
man
1.0
2021-09-22
Initial version
JH
1.1
2022-12-29
Modify the schematic diagram of the module and
how to use it
HWJ
About us
Technical support: supp[email protected]m
Tel：[phone]
Fax：[phone]
Web：https://www.cdebyte.com
Address：Innovation Center B333-D347, 4# XI-XIN Road, Chengdu, Sichuan, China
