ECA Intercept 2 Assembly instructions

ECA • 10 Mountain View Drive • Shelton, CT 06484 • Phone: [phone] • Fax: [phone]
www.electri-cable.com
9065-0002 RevF
1
InnovativePower+ DataSolution
s
Intercept 2
Installation Sheet
NOTE: DO NOT ATTEMPT TO INSTALL THE INTERCEPT PRIOR TO READING THESE INSTRUCTIONS
Step 1. Prepare table per instructions on separate sheet. Be sure to retain portion of cut out tabletop if it will become
the finished top of the INTERCEPT 2.
Step 2. Unpack the INTERCEPT 2, being careful not to damage any part, and check to ensure that no items were
damaged during shipping. Review parts list to be sure all parts are present.
Step 3. TABLE THICKNESS ADJUSTMENT - The INNER PAN ASSY has four (4) adjustable mounting flanges that
can be set for your specific table thickness between .656” - 1.625”. The flanges come set for the thinnest table.
To change the flanges remove the lock nuts (2 per flange) and move the flanges to the hole that corresponds
with the table thickness that the INTERCEPT 2 will be mounted in.
Tighten the lock nuts; be sure all of the flange tops are at the same height
Step 4. TABLE CUTOUT MOUNTING - Attach CUTOUT PIECE, from table preparation, to top of MAIN HOUSING.
The 8 pilot holes should line up. From underside of the INNER PAN, insert screws (use magnetic screwdriver)
and secure the CUTOUT PIECE to the MAIN HOUSING.
Inner Pan
Assembly
Screws
Qty 8
Cutout Piece
Main Housing
Table Thickness
1.125” – 1.375”
Table Thickness
.83” – 1.125”
Table Thickness
.656” - .83”
Top of Inner Pan
Flange
Table Thickness
1.375” – 1.625”

ECA • 10 Mountain View Drive • Shelton, CT 06484 • Phone: [phone] • Fax: [phone]
www.electri-cable.com
9065-0002 RevF
2
InnovativePower+ DataSolution
s
Step 5. INNER PAN MOUNTING - Place the INNER PAN ASSY. to the underside of the table and secure with twelve
(12) #10 X ½ screws provided, use pilot holes to ensure proper alignment. NOTE: USE CAUTION WHEN
POSITIONING THE INTERCEPT 2 ON THE TABLE, ENSURE THAT THE GRAIN OF THE CUTOUT PIECE
MATCHES THE TABLE.
Step 6. OUTER PAN MOUNTING - Position the OUTER PAN ASSY. below the mounted INNER PAN ASSY. Connect
the power feed (Twist-Lock), and motor feed wires (RED and BLACK) from the OUTER PAN ASSY to the
MAIN HOUSING Twist-Lock and motor. Be sure to feed the wire through the cutout in the OUTER PAN.
Attach the OUTER PAN ASSY to the underside of table with six (6) #10 X ½ screws provided. Use pilot holes
to ensure proper alignment.
Step 7. Plug the ROCKER SWITCH ASSY onto the cable utilizing the 4-pin connector, plug in the unit and test for
proper operation. By pressing the “Raise” side of the ROCKER SWITCH the INTERCEPT 2 should elevate
and lock at top. By pressing the “Lower” side of the ROCKER SWITCH the INTERCEPT 2 should return to the
original, retracted, position.
#10 x ½ Screws
Qty 12
(If other than
included screws are
used, be careful not
to pierce finished
side)
Inner Pan
Assembly
Underside of
Table
#10 x ½ Screws
Qty 6
(If other than
included screws
are used, be
careful not to
pierce finished
side)
Outer Pan
Assembly
Inner Pan
Assembly
Underside of
Table
Rocker
Switch
Assembly
Twist-Lock
Connector
4-Pin
Connector

ECA • 10 Mountain View Drive • Shelton, CT 06484 • Phone: [phone] • Fax: [phone]
www.electri-cable.com
9065-0002 RevF
3
InnovativePower+ DataSolution
s
If INTERCEPT 2 doesn’t operate, check:
1. INTERCEPT 2 is plugged into a powered outlet.
2. Twist-Lock connector between Power Unit and MAIN HOUSING is completely locked into place by
twisting.
3. Motor connector is completed latched.
Step 8. ROCKER SWITCH MOUNTING – Mount the ROCKER SWITCH ASSY. in a convenient location using #10 x
½ screws provided. Secure wire as needed.
Step 9. VOICE/DATA CONNECTIONS - Raise the INTERCEPT 2, remove the 4 VOICE/DATA Plates, using the
special tool provided, and snake the VOICE/DATA wires up through the OUTER PAN and through the 2
SHUTTER BUSHINGS in the bottom of the MAIN HOUSING. Wires should be dressed to move freely up and
down with the movement of the MAIN HOUSING. This step can be done before mounting the INTERCEPT 2
however, be sure all wires are run through the cutout in the OUTER PAN before completing step 5.
Congratulations. Enjoy your Intercept 2.
PARTS LIST
Inner Pan Assembly Qty 1
OuterPanAssembly Qty1
Rocker Switch Assembly Qty 1
TableBrush Qty4
7/64 Allen Wrench Qty 1
#10 X ½ Pan Head Screw Qty 20
#4 X ½ Pan Head Screw Qty 12
Table Preparation Instructions Qty 1
Installation Instructions Qty 1
Housing Adjustment Instructions Qty 1
