ECA Interface I TT User manual

PDF provided by Conference Room AV
ECA Interface l TT Cable Well w/ Tilt Up Lid, 4 Power, HDMI, VGA, USB, Data

Page 1of 2
9065-0024 Rev J
Interface I TT
Installation Instructions
ECA • 10 Mountain View Drive • Shelton, CT 06484 • Phone: [phone] • Fax: [phone]
www.electri-cable.com
Installation Instructions
1. Select the location on the table surface for the installation of the Interface
2. Remove a section of the surface measuring 13-5/8” x 6”.
3. Remove the installed Clamping Bracket from the underside of the Interface
by removing the thumb-nuts and washers
4. Insert the Interface through the opening in the table surface until flange is
flat on surface
5. From the underside of the table surface reinstall the Clamping Bracket,
thumb nuts and washers. Tighten until Interface is snug.
6. The holes alongside the data openings in bottom of Interface can be used
for strain relieving data cables if needed.
13.39
14.27
6.68
2.85
5.80
Thumb-nuts
& Washers
Clamping Bracket
Innovative Power + Data Solutions

Page 2of 2
9065-0024 Rev J
ECA • 10 Mountain View Drive • Shelton, CT 06484 • Phone: [phone] • Fax: [phone]
www.electri-cable.com
Innovative Power + Data Solutions
