Eccotemp EM-2.5 User manual

2
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
Important Safety Instructions ________________________________________________ 2
Technical Data _________________________________________________________ 3-4
General Information ______________________________________________________ 5
Technical Description ______________________________________________________ 6
Installation Instructions __________________________________________________ 6-10
Plumbing Connections _____________________________________________________ 7
Temperature & Pressure Relief Valve __________________________________________ 7-8
Filling The Water Heater ____________________________________________________ 9
Electrical Connections _____________________________________________________ 9
Instructions For Use ______________________________________________________ 10
Maintenance Instructions ___________________________________________________ 11
Troubleshooting ________________________________________________________ 14
Schematic & Parts List __________________________________________________ 15-16
Warranty _______________________________________________________ Back Cover
Table of Contents

3
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
1. READ All.. INSTRUCTIONS BEFORE USING THIS WATER HEATER.
2. This water heater must be grounded. Connect only to properly grounded outlet.
See GROUNDING INSTRUCTIONS found on page 10.
3. Install or locate this water heater only in accordance with the provided installation
instructions.
4. Use this water heater only for its intended use as described in this manual.
5. Do not use an extension cord with this water heater. If power is not
available adjacent to the water heater, contact a qualified electrician to
have a receptacle properly installed.
6. As with any appliance, close supervision is necessary when used by children.
7. Do not operate this water heater if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
8. Only qualified service personnel should service this water heater. Contact
nearest authorized service facility when questions arise or service is
required.
9. If the unit is installed in an area where there is a potential for freezing, the
instructions found in the subsequent section SETTING THE FREEZE PROTECTION
must be followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using electrical appliances, safety precautions
to reduce the risk of fire, electric shock or injury to persons should
be followed, including:
The manufacturer and/or distributor is not responsible for damages caused by
improper installation, or failure to follow the instructions in this manual.
A QUALIFIED, LICENSED TECHNICIAN MUST ALWAYS INSTALL THE WATER HEATER
AND CONDUCT ALL SUBSEQUENT SERVICE WORK AND/OR MAINTENANCE.
KEEP THESE INSTRUCTIONS
FILL THE TANK COMPLETELY FULL WITH WATER AND HAVE WATER FLOWING
FROM THE HOT WATER FAUCET BEFORE ACITVATING POWER TO THE
HEATER FOR THE FIRST TIME OR DAMAGE WILL RESULT.
IMPORTANT!!!!

4
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
Technical Data
MODEL
Capacity
Voltage
Power @ 120 VAC
Max. Water Pressure
Weight (empty)
Amperage
Phases
gallons
VAC
Watts
psi
lbs.
Amps
EM2.5
2.5
110-120
1440
150
20
12
1
EM4
4.0
110-120
1440
150
24
12
1
EM6
6.0
110-120
1440
150
26
12
1

5
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
Model I Barang
EM2.5
EM4
EM6
A(mm)
14. 7”
14. 5•
17. 7”
B(mm)
11. 7”
14. 5”
17. 7”
C(mm)
10. 2”
12. 9”
14. 6”
dispositif de protection contre la surchauffe
thermostat
lumière indicatrice
Element chauffant
fiche d’alimentation
EM2.5/EM4
EM6

6
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
GENERAL INFORMATION
The Seisco Mini-Tank Water Heaters can be used in most under the counter, point
of use applications. EM models are designed to supply hot water for all hand
wash and kitchen sinks in a residential,
commercial or industrial environment.
EM models can replace traditional central hot water heaters thereby conserving
water and reducing energy waste. EM models can also be plumbed in series with
the central water heater and act as a booster.
The Seisco Mini-Tank Water Heaters are lightweight and compact and
manufactured for easy installation. EM models can be mounted on the wall with
included hardware, or freestanding.
EM models are designed to operate at 150-psi maximum water pressure. Install a
pressure-reducing valve if your water pressure is greater than 150-psi.
CAUTION!: The manufacturer cannot be responsible for the damage caused by
improper installation or by failure to follow instructions in this manual. Comply
with the Installation Instructions before connecting to
electrical outlet.
CAUTION!: The thermostat has been pre-set at the factory between 105m ( 41 C)
and 113m ( 45 C).
CAUTION!: Hydrogen gas can be produced in a hot water system served by this
heater that has not been used for a long period of time (generally 2 weeks or
more). Hydrogen gas is extremely flammable. To
reduce the risk of injury under these conditions, it is recommended that the hot
water faucet be opened for several minutes at the nearest and most distant sink
being served by this water heater before using any
electrical appliance connected to the hot water system {i.e. Dishwasher). If
hydrogen gas is present, there will probably be an unusual sound such as air
escaping through the faucet as the water begins to flow. There
should be no smoking or open flame near the faucet at this time.
WARNING: Installer should review the contents of this manual with
the owner upon completion of the installation, and the manual should
remain with the owner and placed in a location close to the water
heater.

7
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
TECHNICAl DESCRIPTION
There are three Seisco Mini tank models, a 2.5-gallon, a 4-gallon and a
6-gallon model. The pressure vessel (water tank) is welded, glass lined
steel and is equipped with an anode rod.
The water heater is equipped with a thermostat and a high limit
temperature switch. A temperature/pressure relief valve is supplied with
the unit.
INSTALLATION INSTRUCTIONS
MODELS: EM2.S - EM4 - EM6
A licensed professional must complete the installation adhering to all
state and local codes. The manufacturer will not be liable for any
damages because of failure to comply with these installation instructions
or because of improper installation performed by an unqualified installer.
CHOOSE A LOCATION that allows ease of access for maintenance
ideally with at least 9 clearance at the top from the ceiling, cabinet, or
any adjacent walls.
WALL MOUNTING
Fasten the supplied mounting bracket to the wall. Use screws that are
suitable for the wall material and the weight of the water heater filled to
capacity (EM2.5-41 lbs.; EM4-57 lbs.; EM6-76 lbs.). Hang the water
heater on the bracket and pull downwards on the water heater to ensure
that both ~ingers?of the bracket are seated in the mounting slots.
Confirm your water piping orientation (hot and cold) before wall
mounting. ONLY INSTALL IN VERTICAL POSITION.
Heater can also sit on the floor. ONLY INSTALL IN VERTICAL
POSITION! EM models can be installed under the sink.

8
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
PLUMBING CONNECTIONS
Connect the cold-water inlet pipe to the inlet nipple (marked with a blue
ring) and the hot water outlet pipe to the outlet nipple (marked with a
red ring).
IMPORTANT: If Water pipes are copper or bronze, use dielectric
connections to prevent corrosion. Failure to provide dielectric insulation
may result in premature tank or nipple failure and may void your
warranty. Ensure that the water heater is installed in a level position.
Install a shut off valve on the cold water side of the water heater. The
valve is for servicing and the valve should be in the open position when
the water heater is in operation. In order to protect the water heater
from heat damage due to soldering, solder a piece of tubing to a
threaded UNION fitting before screwing the UNION to the tank.
DO NOT APPLY HEAT DIRECTLY TO INLET OR OUTLET CONNECTIONS.
TEMPERATURE AND PRESSURE RELIEF VALVE:
CAUTION!: Install the Temperature/Pressure Relief Valve
supplied with the water heater!
Install a discharge pipe from the temperature/pressure relief
valve terminating at a sink or drain. DO NOT CAP OR PLUG THE
END OF THE DISCHARGE PIPE. THE DISCHARGE PIPE MUST BE
UNOBSTRUCTED AND FULLY SIZED.
A nationally recognized test lab that maintains periodic inspections of the
listed equipment and meets the requirements for relief valves certifies the
T/P valve and automatic shut off devices for hot water supply systems
ANSI 121.22-1979.
The T/P valve is marked with a maximum pressure, which does not
exceed the maximum working pressure of the water heater (150 PSI).
Install the T /P valve into the threaded opening at the top of the
water heater and orient the discharge tubing so that any discharge
from the valve will exit within 6 inches above, or at any
distance below the structural floor, and cannot contact any live
electrical part.

9
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
T /P Valve Discharge pipe:
1. Must NOT be smaller in diameter than the outlet
diameter of the valve, or have any reducing couplings.
2. Must NOT be plugged or blocked.
3. Must be made of suitable material for hot water.
4. Must not be over 15 in length.
5. Must not have more than two elbows.
6. Must terminate at an adequate drain.
7. Must not have a shut off valve between relief valve and
tank or relief valve and termination of discharge.
CLOSED SYSTEM THERMAL EXPANSION: Periodic discharge of
the T /P relief valve or failure of the element gasket may be due
to thermal expansion in a closed water supply system. The water
utility supply meter may contain a check valve, backflow
preventer or water pressure-reducing valve that will create a
closed water system. During the heating cycle of the water
heater, the heated water expands causing pressure inside the
water heater to increase. The T /P relief valve may discharge hot
water under these conditions that results in a loss of energy and
a build up of lime on the relief valve seat.
To prevent this from happening, there are two recommendations:
1. Install a diaphragm-type domestic hot water expansion
tank (suitable for potable water) on the cold water
supply line. The expansion tank must have a minimum
capacity of 1.5 U.S. gallons for every 50 gallons of
stored water.
2. Install a 125-PSI pressure relief valve in the cold water
supply line. Make sure the discharge of this valve is
directed to an open drain and protected from freezing.
Contact your local water utility or plumbing inspector
for information on how to control this situation. Never
plug the outlet of the relief valve.

10
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
FILLING THE WATER HEATER
CAUTION!: Before powering the water heater, be sure that the
system is completely filled with water and All AIR IS REMOVED. If Water pipes
Before connecting the power, fill the tank and system with water and
check for leaks. To be sure that all air is out of the water system, open
the hot water faucets on your fixtures until constant water flows. Any air
remaining in the tank will cause the water heater element to fail.
filling the water heater:
1. Open the hot water faucet.
2. Open the cold water supply valve.
3. When continuous water flows out of the faucet, the tank is filled.
4. Close the hot water faucet.
5. Check entire system for leaks.
ELECTRICAL CONNECTIONS
To be certain that all of the air is out of the water heater, open the HOT
water faucet on your fixtures until constant water flows from them. If air
remains in the tank, the element will be damaged when the electric cord
is plugged in.
Connect the water heater to a GROUNDED OUTLET.
The water heater is fitted with a power cord that is intended to
plug into a grounded 110-120 V/AC receptacle. Adhere to all
pertinent State and local codes. Install the correct size circuit
breaker into the master panel. The Seisco EMT water heater was
manufactured and wired in accordance with UL requirements.
The water heater is equipped with an overheat limiting device
with a manual reset. Also known as the temperature high limit,
this device has been factory installed to interrupt the power
supply in the event of a thermostat failure.
THIS WATER HEATER IS DESIGNED FOR 110-120V
SERVICE - DO NOT CONNECT TO ANY OTHER VOLTAGE.
Failure to use proper voltage may result in personal injury and/or
property damage. If the supplied electrical power cord is either damaged
or not long enough, do NOT use an extension cord. Have a licensed
electrician replace the power cord.

11
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
INSTRUCTIONS FOR USE
CONGRATULATIONS! You are now ready to use your water
heater. Run the hot water at a nearby sink and evaluate the hot
water temperature. Make any temperature adjustment using the
section below:
SETTING THE THERMOSTAT:
The water heater is equipped with an adjustable thermostat that once set
will automatically control water temperature. The lamp remains
illuminated while the water is being heated. If the water in the tank is at
the desired temperature the lamp will NOT be illuminated.
The temperature-adjusting knob will increase the temperature by turning
the knob clockwise and decrease the water temperature by turning the
knob counter clockwise.
When not being used for a lengthy period of time, you can conserve
energy by reducing the water temperature setting.
SETTING THE FREEZE PROTECTION:
When the water heater is not being used for an extended period of time
and there is a risk of freezing, either unplug and drain the water heater
OR turn the thermostat knob to the snowflake position to guard against
freezing. This position will keep the internal water temperature above
the freezing point.

12
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
MAINTENANCE INSTRUCTIONS
Do not attempt to repair this water heater yourself. Call a
qualified service person for service assistance. Always unplug
the power supply cord when the water is turned off or when
servicing or draining the water heater.
Before calling for service, first confirm that the water heater is
properly filled and that 110VAC power has not been interrupted.
WARNING: Before servicing or cleaning the water heater,
disconnect the power cord from the electrical outlet.
NOTE: For most maintenance operations, the water heater will
be drained. In all cases before draining you must unplug the
power cord.
DRAINING AND REMOVING THE WATER HEATER:
1. Unplug the water heater.
2. Open a hot water faucet to let hot water run out. Allow water to
flow until water is no longer hot.
3. Turn off the cold water supply to the water heater.
4. Close the hot water faucet.
5. Disconnect the water heater from both the hot and cold water
connections.
6. If possible siphon out remaining water.
7. Carefully detach the water heater from the wall.
8. Tilt the water heater to drain remaining water out of the heater.
REMOVING THE HEATING ELEMENT:
1. Turn off power supply; unplug water heater power cord and drain
(see above).
2. Remove cover.
3. Remove all the line wires from the heating element.
4. Unscrew the heating element retaining nuts.
5. Remove the element.

13
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
DESCALING THE HEATING ELEMENT:
Scale deposits can affect the heating capability of the element. Heavy
scale can even cause the element to burn out. The element can be
descaled chemically or manually.
1. Remove the heating element (see above).
2. To descale chemically, soak the heating element in white vinegar or
other descaling solution and then rinse well with fresh water.
3. To descale manually, let element dry and then using a non metallic
brush similar to a tooth brush; brush the residue from the element.
Avoid damaging the surface of the element.
4. Reinstall the element and gasket.
5. Refill tank with water before turning on the power to the water
heater.
REPLACING THE HEATING ELEMENT:
1. Unplug and drain the water heater (see prior instructions).
2. Remove heating element noting original positions of all connections.
3. Install new element with gasket making sure the new element and
gasket are positioned correctly.
4. Tighten retaining nuts and make the wire connections to their
original locations.
CHANGING THE THERMOSTAT:
1. Unplug the water heater from the electrical outlet.
1. Drain and remove the water heater. (see page 12)
2. Remove the bottom panel of the water heater and remove the
panel.
3. Remove thermostat knob and unscrew two retaining screws. It
maybe necessary to pry the knob off of the thermostat spindle. Now
remove front panel.
4. Disconnect the push-pull wire connectors on the thermostat noting
which connector goes to which terminal. Terminals are marked.
5. Remove the thermostat probe from the well.
6. Install new thermostat, attach wires and tighten screws.

14
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
RESETTING THE HIGH LIMIT SWITCH:
The high limit safety shut off switch will shut the water heater down when
water temperatures exceed 190 F. Power is automatically turned off to
the heating element. The shut off device may activate as a result of a
power outage or an electrical storm.
NOTE: Do not attempt to reset the high limit switch without first allowing
the water heater to cool down the high temperature water inside the
heater.
WARNING: Do not tamper with the reset button to override overheating
shut down.
1. Unplug the
water heater from the electric outlet.
2. Drain and remove the water heater. (see page 12)
3. Remove six screws retaining the bottom panel of the water heater
and remove the panel. Locate the high limit reset button.
4. Depress the small red button in the center of the junction box,
replace the bottom panel and place the water heater back into
service.
NOTE: A lower temperature setting saves energy and reduces the risk of
scalding.
CAUTION!: Call a technician if the high limit needs to be reset
frequently.

15
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
TROUBLESHOOTING
PROBLEM: Water does not get hot
1. Make sure the power supply is on and working.
2. If light does not come on, check that the reset button is pushed in;
follow steps from previous section.
3. If the indicator light is illuminated, but water temperature does not
get hot at the sink, test for a plumbing crossover as follows; shut
off cold water supply to water heater and open hot water tap. There
should be no water flowing. Any continuous flow indicates a cross
over which will effect the temperature and will need to be corrected.
4. If there is no crossover, then replace the heating element (see
previous sections).
PROBLEM: Indicator light not on
1. If the light does not come on, but water gets hot, check for faulty
bulb.
2. Check reset button; follow steps from previous section.
PROBLEM: Brown water
1. Brown or rusty water indicates a spent anode rod. Replace anode
rod.
PROBLEM: Odor in water
1. Smelly water could be due to an unusual reaction between local
water and the heaters anode rod. Check anode rod.
PROBLEM: Water is too hot
1. Turn the temperature knob counter clockwise to a lower
temperature setting. If temperature does not lower within 60
minutes, then replace thermostat.
PROBLEM: Water is not hot enough
1. Under Instructions for Use, see Setting the thermostat.
PROBLEM: Water is leaking
1. Unplug water heater from 110 VAC outlet.
2. Check water fittings and T&P fitting in the top of the tank.
3. Remove cover and inspect heating element gasket.

16
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

17
Product Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483
