Echo PB-265L User manual

Power Blower
Operator'sManual
MODEL PB-265L
WARNING
Read rules for safeoperationandinstructions carefully. ECHOprovidesthisOperator's
Manual,whichmustbereadandunderstoodforproperand safe operation.
X753002580
10/06
X7531180400

2
Copyright© 2006 By Echo, Incorporated
All Rights Reserved.
TABLE OF CONTENTS
Introduction .................................................................. 2
- The Operator's Manual .......................................... 2
Safety ............................................................................ 3
- Manual Safety Symbols and Important Information3
- InternationalSymbols ............................................ 3
- Personal Condition and Safety Equipment ............ 3
- Equipment .............................................................. 6
EmissionControl........................................................... 6
Description ................................................................... 7
Contents ....................................................................... 9
Assembly .....................................................................10
- InstallBlowerPipes ..............................................10
Operation .....................................................................11
- Fuel .......................................................................11
- StartingColdEngine .............................................12
- StartingWarmEngine ...........................................13
- Stopping Engine ...................................................13
- OperatingBlower ..................................................14
Maintenance ................................................................15
- SkillLevels ............................................................15
- Maintenance Intervals ..........................................15
- AirFilter ................................................................16
- FuelFilter ..............................................................16
- SparkPlug .............................................................17
- CoolingSystem.....................................................17
- ExhaustSystem.....................................................18
- Carburetor Adjustment .........................................19
Troubleshooting ..........................................................20
Storage.........................................................................21
Specifications...............................................................22
ServicingInformation...................................................24
- Parts/SerialNumber ..............................................24
- Service ..................................................................24
- ECHOConsumerProductSupport........................24
- Warranty Card ......................................................24
- Additional or Replacement Manuals ....................24
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-
dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and
SAFETYmessages.
THE OPERATOR'SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specifications and information for
operation, starting, stopping, maintenance, storage, and assembly
specific to this product.

3
POWER BLOWER
OPERATOR'SMANUAL
SAFETY
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages
preceded by symbols or key words. The following is an explanation of those symbols and key words.
INTERNATIONALSYMBOLS
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Read and understand
Operator's Manual. Fuel and oil mixture
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Carburetor adjustment
- Idle speed Carburetor adjustment
- High speed mixture
Wear eyes, ears and
head protection
Emergency stop
Finger Severing Carburetor adjustment
- Low speed mixture
Safety/Alert
Wear hand
protection.Use
twohanded.
DONOTsmoke
nearfuel.
DONOTallow
flamesorsparks
nearfuel.
Wear slip
resistantfoot
wear.
Ignition
ON/OFF
Primerbulb
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)
WARNING
Thesafetyalertsymbolaccompaniedbytheword
“WARNING”callsattentiontoanactorcondition
whichCANleadtoseriouspersonalinjuryordeath
ifnotavoided.
CIRCLEANDSLASHSYMBOL
This symbol means the specific action
shown is prohibited. Ignoring these
prohibitions can result in serious or fatal
injury.
CAUTION
Thesafetyalertsymbolaccompaniedbytheword
“CAUTION”callsattentiontoanactorcondition
whichmayleadtominorormoderatepersonalinjury
ifnotavoided.
NOTE
This enclosed message provides tips for use, care
and maintenance of the unit.
IMPORTANT
The enclosed message provides information
necessary for the protection of the unit.
DANGER
Thesafetyalertsymbolaccompaniedbytheword
“DANGER”callsattentiontoanactorcondition
whichWILLleadtoseriouspersonalinjuryordeath
ifnotavoided.
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING
Power Blower users risk injury to themselves and others if the power blower is used improperly or safety precautions
are not followed. Proper clothing and safety gear must be worn when operating a blower.
IdleSpeed Fast Speed

4
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your grip on the blower handle. Gloves also reduce the transmission
of machine vibration to your hands.
Breathing Protection
Wear a facemask to protect against dust.
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARVES,andJEWELRY.
Wear sturdy work shoes with nonskid soles:
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Keep long hair away from engine and blower intake. Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue, which may lead to heat stroke. Schedule heavy work for early
morning or late afternoon hours when temperatures are cooler.
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be
brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning
sensations, followed by loss of color and numbness in the fingers. The following precautions are strongly recom-
mended,because theminimum exposure,which mighttrigger theailment, isunknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physi-
cian before further exposing yourself to cold and vibration.

5
POWER BLOWER
OPERATOR'SMANUAL
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high
riskfor developingaRepetitive StressInjury(RSI). Anextreme RSIcondition isCarpalTunnel Syndrome(CTS), which
could occur when your wrist swells and squeezes a vital nerve that runs through the area.
Some believe that prolonged exposure to vibration may contribute to CTS. CTS can cause severe pain for months or
even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead, try to maintain a straight wrist position. Also, when
grasping, use your whole hand, not just the thumb and index
finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a
doctor if you feel tingling, numbness, or pain in the fingers,
hands, wrists, or arms. The sooner RSI/CTS is diagnosed, the
more likely permanent nerve and muscle damage can be pre-
vented.
DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can
cause serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual
and Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animalsprevented fromcoming nearerthan 15m(50 ft.)while the
unit is in use.
• Take wind conditions into account: avoid open doors and
windows.
• Do not point blower at people or animals.
Keep a Firm Grip
• Hold the stick handle with thumb and fingers encircling the
handle.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on
slippery, uneven, or unstable surfaces. Do not work in odd
positions or on ladders. Do not over reach.
Avoid Hot Surfaces
• Keep exhaust area clear of flammable debris. Avoid contact
duringandimmediatelyafter operation.

6
EQUIPMENT CHECK
WARNING
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which
have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and
safety manual.
• Check unit for loose/missing nuts, bolts and screws. Tighten
and/or replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO NOT operate unit if leaks are found.
• Do not use blower if any part is missing or damaged.
• Have repairs done only by an authorized ECHO Service dealer.
• Do not use any attachment, accessory or replacement part unless it is recommended in this Operator's Manual.
EMISSION CONTROL
EPA Phase 2
The emission control system for these engines are EM/TWC (Engine and Catalyst Modification).
PRODUCT EMISSION DURABILITY
The 300 hour emission durability compliance period is the time span selected by the manufacturer certifying the
engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are
followed as listed in the Maintenance Section of this manual.
AnEmissionControl Labelislocatedon theunit. (This isan EXAMPLE
ONLY,informationonlabelvariesbyengineFAMILY).
IMPORTANTENGINEINFORMATION
ENGINE FAMILY: 6EHXS.0254KF DISPLACEMENT: 25.4 CC
EMISSIONCOMPLIANCEPERIOD: 300 HRS.
THIS ENGINE MEETS U.S. EPA PH2 AND 2005 - 2006
CALIFORNIA EMISSION REGULATIONS FOR SOREs.
REFER TO OWNER'S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.

7
POWER BLOWER
OPERATOR'SMANUAL
P/N89016006361
P/N89016009461
65 Category I
dB(A)
Measured at 50 ft. (15m) per ANSI B175.2
Hot Decal (near muffler and engine)
General Warning Decal (located on blower housing)
P/NX508000120
DESCRIPTION
Locate the safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc-
tions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING
instructionsfor specificinformation.
Sound Label (located on blower housing)
14
16
17
15
13
12
11
10 98
7
6
1
5
4
3
2
1
3
2
18

8
1. SAFETYDECAL-Listsimportantsafetyprecautions.
2. SAFETYDECAL-Listsimportantsafetyprecautions.
3. SAFETYDECAL-Listsimportantsafetyprecautions.
4. SPARKPLUG-Providessparktoignitefuelmixture.
5. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
6. SERIALNUMBERLABEL- Listsmodelnumberandserialnumberofunit.
7. RECOILSTARTERHANDLE-Pullrecoilhandleslowlyuntilstarterengages,thenquicklyandfirmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
8. FUELTANKCAP-Coversandsealsfueltank.
9. FUELTANK-Containsfuelandfuelfilter.
10. AIRCLEANER-Containsreplaceableairfilterelement.
11. HANDLE- Rotatesdownwardfor throttlecontrolaccess. Springloadedfor flexibleoperation.
12. THROTTLEPOSITIONLEVER/STOPSWITCH-Combinationstopswitchandvariablespeedthrottlelever.
When the lever is moved all the way forward the blower is at Wide Open Throttle (W.O.T.). When the lever is
moved rearward to detent, the blower is at idle. When the lever is moved rearward past the idle detent the blower will
stop.
13. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close choke
for cold starting. Move choke lever to "RUN" ( ) position to open choke.
14. PURGEBULB - Pumpingpurgebulb beforestarting enginedraws freshfuel fromthe fueltank, purgingairfrom
the carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump purge
bulb an additional 4 or 5 times.
15. SHOULDER HARNESS - Used to support unit on operator's back. The straps are adjustable.
16. BLOWERPIPES-Exclusivepositivelockingsystem.
17. FLEXIBLEPIPE-Allowsforfullrangeofmovement.
18. STICKHANDLE-Usedbyoperatortodirectairflow.

9
POWER BLOWER
OPERATOR'SMANUAL
CONTENTS
__ 1 - PowerHead
__ 1 - FlexPipe
__ 1 - SwivelPipe
__ 1 - StraightPipe
__ 1 - StraightPipew/decal
__ 1 - Operator's Manual
__ 1 - Warranty Registration Card
__ 1 - ECHOEmissions andWarranty Statement
__ 1 - PlasticBag
__ 2-Clampsw/screws
__ 1- StickHandle Assembly
__ 1 - EchoPowerBlend TM 2-strokeoil sample

10
ASSEMBLY
WARNING
Never perform maintenance or assembly procedures with engine
running or serious personal injury may result.
INSTALL BLOWER PIPES / STICK HANDLE
1. Assemble clamps (A) onto both ends of flexible pipe (B).
2. Assembleswivel pipe(C)intoflexible pipe(B)and tightenclamp
(A).
3. Assemble flexible pipe (B) to elbow (D) on blower and tighten
clamp(A).
NOTE
A light lubricant may be used to ease assembly of flexible pipe to
blowerelbow.
4. Loosen wing nut (E) completely and open stick handle clamp.
5. Align notches (F) in handle clamp with tabs (G).
6. Slide stick handle onto swivel pipe (C). Stick handle should be
angled away from operator.
7. Position stick handle (H) for comfortable operation, and tighten
wingnut(E).
8. Assemble straight pipe (I) onto swivel pipe (C), until you feel light
resistance. Do not force connection. Hold swivel pipe and turn
straight pipe counter clockwise, engaging positive locking
channels,until connection is firm. Do not force connention.
9. Assemble straight pipe with decal (J) to straight pipe (I) as in step
8.
NOTE
Blower use will eventually loosen pipe connections. Exclusive
positive locking system allows pipes to be tightened. If loosening
occurs, remove two straight pipes and install according to instruc-
tions 8 & 9.
B
B
G
H
D
H
C
E
C
I
J
F
A

11
POWER BLOWER
OPERATOR'SMANUAL
oitaR1:05-xiMliOotleuF
.S.UCIRTEM
SAGLIOSAGLIO
snollaG.zo.lFretiL.cc
1
2
5
6.2
2.5
31
4
8
02
08
061
004
Mixing Instructions
1. Fill an approved fuel container with half
of the required amount of gasoline.
2. Add the proper amount of 2-stroke oil to
gasoline.
3. Close container and shake to mix oil with
gasoline.
4. Add remaining gasoline, close fuel
container,andremix.
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.
After use
• DO NOT store a unit with fuel in its
tank. Leaks can occur. Return unused
fuel to an approved fuel storage
container.
Storage - Fuel storage laws vary by locality.
Contact your local government for the laws
affecting your area. As a precaution, store
fuel in an approved, airtight container. Store
in a well-ventilated, unoccupied building,
away from sparks and flames.
IMPORTANT
Storedfuel ages.Donot mixmore fuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizeris added.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container
thoroughly before each use.
OPERATION
NOTE:Useofunmixed,improperlymixed,orfuelolderthan90days,
(stale fuel), may cause hard starting, poor performance, or severe
engine damage and void the product warranty. Read and follow
instructions in the Storage section of this manual.
FUEL
Fuel Requirements
Gasoline-Use89 Octane[R+M/2](mid gradeorhigher) gasoline
known to be good quality. Gasoline may contain up to 15% MTBE
(methyl tertiary-butyl ether). Gasohol containing methyl (wood) alcohol
is NOT approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)andJ.A.S.O.FC Standardsmustbe used.Echo brandpremium
Power Blend TM Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an
ISO-L-EGDandJ.A.S.O.FCcertifiedoil,suchasEchopremiumPower
BlendTM, willvoid thetwo-strokeengine warranty. (Emissionrelated
parts only are covered for two years, regardless of two-stroke oil used,
per the statement listed in the Emission Defect Warranty Explanation.)
IMPORTANT
EchopremiumPowerBlendTM Universal2-StrokeOilmaybemixed
at 50:1 ratio for application in all Echo engines sold in the past
regardless of ratio specified in those manuals.
Handling Fuel
DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOT allowflames orsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhentheengineisHOTorRUNNING!
• DONOT fillfuel tanksindoors. ALWAYSfill fueltanks outdoors
over bare ground.
•DONOToverfillfueltank. Wipeupspillsimmediately.
• Securely tighten fuel tank cap and close fuel container after
refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
• Move at least 3m (10 ft.) from refueling location before starting
the engine.

12
STARTING COLD ENGINE
• Recoil starter: Use short pulls - only 1/2-2/3 of rope length for
starting. Do not allow the rope to snap back in. Always hold the unit
firmly.
• Rotate throttle handle downward to a comfortable operating position.
1. Throttle Position Lever
Movethrottlepositionlever(A)toSTART/IDLEDETENT
position( ).
2. Choke
Move choke (B) to "Cold Start" ( ) position.
3. Purge Bulb
Pump purge bulb (C) until fuel is visible and flows freely in the
clearfueltank returnline.
4. Recoil Starter
Pullrecoilstarterhandle(D)untilenginefires,ormaximum5pulls.
5. Choke
Move choke (B) to run ( ) position and if necessary, restart
engine.
NOTE
If engine does not start after 5 pulls, repeat instructions 2-5.
NOTE
Allow engine to warm up before use.
D
B
A
C

13
POWER BLOWER
OPERATOR'SMANUAL
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke.
1. Throttle Position Lever
Move throttle position lever (A) to start/idle detent posi-
tion( ).
2. Purge Bulb
Pump purge bulb (C) until fuel is visible and flows freely in the
clearfueltank returnline.
3. Recoil Starter
Pull recoil starter handle (D) and engine should start.
NOTE
If engine does not start after 5 pulls, use cold start procedures.
STOPPING ENGINE
1. Throttle Position Lever
Move throttle position lever (A) to idle detent position( ) and
allow engine to return to idle before shutting off engine.
2. Move throttle lever (A) to " " (Stop) position.
WARNING
If engine does not stop when throttle lever is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using blower
again.
A
D
A
C

14
A
OPERATING BLOWER
WARNING
Always wear safety glasses, hearing protection, face filter mask and
take all safety precautions or serious personal injury may result.
Do not point the blower pipe in the direction of people or pets.
Read the Safety Section carefully.
IMPORTANT
To avoid engine damage due to over revving, do not block
blower pipe opening.
1. Use only during appropriate hours.
2. Allow the engine to warm up at a fast idle for a few minutes.
3. Set engine speed with throttle position lever (A).
4. Use lower speed to blow dry grass and leaves from walks, patios
and drives.
5. Additional speed may be necessary to clean leaves from a lawn or
flowerbed.
6. Higher speed may be necessary to move gravel, dirt, snow, bottles
or cans from a driveway, street, parking lot or stadium.
NOTE
Never use a higher speed setting than necessary to perform a task.
Remember, the higher the engine speed, the louder the blower noise.
Minimize dust by using blower at lower speeds and by dampening
material with water/mist when necessary. Keep debris on your
property.
Be Smart - be a good neighbor.

15
POWER BLOWER
OPERATOR'SMANUAL
MAINTENANCE
Your ECHO blower is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your blower achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the
ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.
SKILL LEVELS
Level1= Easy to do. Most required tools come with unit.
Level2= Moderate difficulty.Some specializedtools maybe required.
Level3= Experiencerequired.Specializedtoolsarerequired.Echorecommends
that the unit be returned to your ECHO dealer for service.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Just below each task
heading are listed the various part numbers required for that task. See your ECHO dealer for these parts.
/TNENOPMOC
METSYS
ECNANETNIAM
ERUDECORP
D'QER
LLIKS
LEVEL
YLIAD
RO
EROFEB
ESU
YREVE
LEUFER
3
SHTNOM
09RO
SRUOH
6
SHTNOM
072RO
SRUOH
YLRAEY
serudecorPecnanetniaMrelaeDohcEdednemmoceR
troPtsuahxErednilyCnobraceD/naelC/tcepsnI 3C/I
serudecorPecnan
etniaMflesruoY-tI-oD
retliFriAecalpeR/naelC/tcepsnI 1C/I*R
ekohCnaelC/tcepsnI 2C/I
retliFleuFecalpeR/tcepsnI 1I*
R
skaeL,metsySleuFecalpeR/tcepsnI 1I*R/I
metsySgnilooCnaelC/tcepsnI 2C/I
rotserrAkrapSrelffuMecalpeR/tcepsnI 2*
R/I
epoRretratSlioceRnaelC/tcepsnI 1C/I*R/I
gulPkrapSnaelC/tcepsnI 2C/I*R
stloB/stuN/swercSecalpeR/nethgiT/tcep
snI 1*R/I
SEDOCRETTELERUDECORPECNANETNIAM NAELC=C,ECALPER=R,TCEPSNI=I:
-ETONTNATROPMI deriuqerfoycneuqerfehtenimretedlliwecneirepxeruoydnaesulaut
cA.mumixameranwohsslavretniemiT
.ecnanetniam
:SETONERUDECORPECNANETNIAM
*.noitcepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA
MAINTENANCE INTERVALS

16
AIR FILTER
Level1.
Tools required: 25-50mm(1-2in.)Cleaningbrush
Parts required: Airfilter
1. Close choke (Cold Start Position [ ]). This prevents dirt from
entering the carburetor throat when the air filter is removed. Brush
accumulateddirtfromaircleanerarea.
2. Removeairfilter cover.Brushdirt frominsidecover.
3. Removeairfilterandlightlybrushdebrisfromfilter.Replacefilter
if it is damaged, fuel soaked, very dirty, or the rubber sealing
edges are deformed.
4. If filter can be reused, be certain it:
• Fits tightly in the air filter cavity.
• Is installed with the original side out.
5. Installairfiltercover.
FUEL FILTER
Level1.
Tools required: 200-250mm(8-10in.)lengthofwire with one end bent
into a hook, clean rag, funnel, and an approved fuel
container
Parts required: Fuellineandfilter
DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and
emptyfuel tank.
2. Use the “fuel line hook” to pull the fuel line and filter from the
tank.
3. Remove thefilterfrom thelineandinstall thenew filter.

17
POWER BLOWER
OPERATOR'SMANUAL
SPARK PLUG
Level2.
Tools required: T-Wrench, Feeler gauge
Parts Required: Spark plug
IMPORTANT
Use only NGK BPM8Y spark plug otherwise severe engine
damagemay occur.
1. Remove spark plug and check for fouling, worn and rounded
center electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean.Remainingsand willdamage engine.
3. Adjust spark plug gap by bending outer electrode.
4. Tightensparkplugto150-170kg/cm(130-150in.lb.).
COOLING SYSTEM
Level2.
Tools required: 4mmx130mm(5")longhexwrench,cleaningbrush
Parts Required: None, if you are careful.
IMPORTANT
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder fin area. This flow of air carries
combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes are blocked, preventing cooling air from reaching the
cylinder.
• Dust and grass build up on the outside of the cylinder. This build
up insulates the engine and prevents the heat from leaving.
Removal of cooling passage blockages or cleaning of cooling fins is
considered “Normal Maintenance.” Any failure attributed to lack of
maintenance is not warranted.
INTAKE GRILL
0.65 mm
(0.026 in.)
Cleaning Grill and Cylinder Fins
1. Removeaccumulateddebrisfrom intakegrillbetweenbackpack
frame and blower housing.
2. Disconnect spark plug lead from spark plug.

18
3. Remove spark plug
4. Remove engine cover - 7 screws.
5. Loosely install spark plug to keep dirt out of cylinder.
6. Clean cylinder fins to allow cooling air to pass freely.
7. Reassemble parts in reverse order.
IMPORTANT
Do not over-tighten screws, otherwise mounting holes may become
stripped.
EXHAUST SYSTEM
Spark Arrestor Screen
Level2.
Tools required: CrossHeadScrewdriver,4mmHexWrench,
Soft metal brush
Parts Required: Spark arrestor screen, Gasket
IMPORTANT
Carbon deposits in muffler will cause a drop in engine output and
overheating. Spark arrestor screen must be checked periodically.
1. Disconnect spark plug lead from spark plug.
2. Remove engine cover - 7 screws.
3. Remove exhaustdeflector (A),spark arrestorcover (B),gasket (C),
andspark arrestorscreen (D)from muffler.Replace screenif
plugged with carbon deposits.
NOTE
When cleaning carbon deposits, be careful not to damage the
catalyticelementinsidemuffler.
4. Install spark arrestor screen, gaskets, and covers.
5. Install engine cover.
A
DCB

19
POWER BLOWER
OPERATOR'SMANUAL
A
Cylinder Exhaust Port
Level3.
IMPORTANT
The cylinder exhaust port must be inspected and cleaned of excess
carbon every 3 months or 90 hours of operation in order to maintain
this engine within the emissions durability period. ECHO strongly
recommends that you return your unit to your ECHO dealer for this
importantmaintenance service.
CARBURETORADJUSTMENT
Level2.
Tools required: Screwdriver,tachometer(EchoP/N99051130017)
Parts required: None.
NOTE
Every unit is run at the factory and the carburetor is set in compli-
ance with Emission Regulations. This carburetor does not have
acceleration and high speed adjustment needles. Do not attempt to
use carburetor adjustment procedures provided in the Warranty
EmissionsBooklet.
BeforeAdjustment
Checkthat:
• Air filter is clean and properly installed.
• Spark arrestor screen is free of carbon.
• Blowerpipesareinstalled.
1. Start engine, run at idle for one minute.
2. Complete warm up by running at full throttle for 5 minutes,
operating choke twice to clear air from carburetor chambers.
3. Check idle speed and reset if necessary. If a tachometer is
available, idle speed screw (A) should be set to the specifications
found on Page 22 "Specifications" of this manual. Turn idle screw
(A) clockwise to increase idle speed; counter clockwise to
decrease idle speed.

20
WARNING
Fuel vapors are extremely flammable and may cause fire and/or explosion. Nevertest for ignition spark by grounding
spark plug near cylinder plug hole, otherwise serious personal injury may result.
TROUBLESHOOTING
TRAHCGNITOOHSELBUORT
melborPkcehCsutatSesuaCydemeR
enignE
-sknarc
/drahstrats
t'nseod
trats
roterubractaleuFroterubractaleufoN
deggolcreniartsleuF
deggolcenille
uF
roterubraC
ecalperronaelC
ecalperronaelC
relaedohcEruoyeeS
rednilyctaleuF
rednilyctaleufoNroterubraCrelaed
ohcEruoyeeS
leufhtiwtewrelffuM
hcirooterutxiMleuFekohcnepO
retlifriaecalper/naelC
roterubractsujdA
relaedoh
cEruoyeeS
dnetakrapS
eriwgulpfo krapsoN
ffohctiwspotS
melborplacirtcelE
hctiwskcolretnI
NOothctiwsnruT
relaed
ohcEruoyeeS
relaedohcEruoyeeS
gulptakrapSkrapsoN
tcerrocnipagkrapS
nobrachtiwderevoC
leufhtiwdeluoF
evitcefe
dgulP
).ni620.0(mm56.ottsujdA
ecalperronaelC
ecalperronaelC
gulpecalpeR
,snurenignE
roseidtub
tonseod
etarele
cca
ylreporp
retlifriAytridretlifriAraewlamroNecalperronaelC
retlifleuFytridretlifleuF seudiser/stnanimatnoCni
leuf
ecalpeR
tnevleuFdeggulptnevleuF niseudiser/stnanimatnoC
leuf
ecalperronaelC
gulPkrapSnrow/ytridgulP raewl
amroNecalperrotsujdadnanaelC
roterubraCtnemtsujdareporpmI noitarbiVtsujdA
metsySgnilooC metsysgnilooC
deggulp
/ytrid
ninoitarepodednetxE
snoitacolytsud/ytrid
naelC
rotserrAkrapS
neercS
rotserrakrapS
deggulpneercs
raewla
mroNecalpeR
seodenignE
knarcton A/NA/NmelborpenignelanretnIrelaedohcEruoyeeS
,snurenignE
rewolb
krowt'nseod
siro
nevenu/kaew
epiprewolB
deggolcepiP sirbedfopu-dliuBgolcnU
esoolepiP noitarbiVnethgiT
degamadepiP esusiM/raeWeca
lpeR
