INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and
SAFETYmessages.
THE OPERATOR’SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specifications and information for
operation, starting, stopping, maintenance, storage, and assembly
specific to this product.
THE SAFETY MANUAL
Copyright©2003ByEcho,Incorporated
All Rights Reserved.
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.
Read and understand this manual before operation. Keep it in a safe
place for future reference. It explains possible hazards involved with
the use of this product and what measures you should take to make
their use safer.

HEDGE CLIPPER
OPERATOR'SMANUAL 3
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
P/NX505000270
P/NX505000290
P/N 89016006361
Throughout this manual and on the product itself, you will find safety
alerts and helpful, informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words and what they mean to you.
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead to
serious personal injury to operator and bystanders.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
IMPORTANT
The enclosed message provides
information necessary for the protec-
tion of the unit.
NOTE
This enclosed message provides tips
for use, care and maintenance of the
unit.
SAFETY
DECALS
Locate these safety decals on your unit. Make sure the decals are
legible and that you understand and follow the instructions on them. If
a decal cannot be read, a new one can be ordered from your ECHO
dealer. SeePARTSORDERINGinstructionsforspecificinformation.
Right Front Handle Guard
Hot Decal (near muffler)

4
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Carburetor adjustment
- Idle speed
Carburetor adjustment
- High speed mixture
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Read and understand
owners manual.
Wear eyes, ears and
head protection
Emergency stop
Fuel and oil mixture
Finger Severing
Carburetor adjustment
- Low speed mixture
Safety/Alert
Avoid all power
lines. This unit is not
insulated against
electrical current.
Do not operate clos-
er than 15 M (50 ft.)
from electrical haz-
ards.
Plan retreat path
from falling
objects.
Wear hand protec-
tion. Use two handed.
DO NOT smoke
near fuel.
DO NOT allow
flames or sparks
near fuel.
Wear slip resistant
foot wear.
Ignition Ignition
ON/OFF
Do not operate
without guards
in place.
Keep bystanders at least
4.5 meters (15 feet) away.
Primer bulb
INTERNATIONAL SYMBOLS
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)
SAFETYINSTRUCTIONS
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions
are not followed. Proper clothing and safety gear must be worn when operating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE
requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your
grip on the handle. Gloves also reduce the transmission
of machine vibration to your hands.
Hearing Protection
ECHOrecommendswearinghearingprotectionwhenever
unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARVES,andJEWELRY.
Wear sturdy work shoes with nonskid soles:
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Keep long hair away from engine and blower intake.
Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue,
which may lead to heat stroke. Schedule heavy work for
early morning or late afternoon hours when temperatures
arecooler.

HEDGE CLIPPER
OPERATOR'SMANUAL 5
EQUIPMENT
WARNING DANGER
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combi-
nation. ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories which have
not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety
manual.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Inspect hand guard for damage. Replace if damaged or missing.
• Check that the blade assembly is firmly attached and in safe operating
condition. Dull, loose or damaged blades should not be used.
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals, may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations, followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommended,becausetheminimumexposure, which might trigger the
ailment,isunknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands,
and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms, and shoulders may cause soreness, swelling, numbness,
weakness, and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged expo-
sure to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the
following:
• Avoid using your wrist in a bent, ex-
tended, or twisted position. Instead try to
maintain a straight wrist position. Also,
when grasping, use your whole hand, not
just the thumb and index finger.
• Takeperiodicbreakstominimizerepeti-
tion and rest your hands.
• Reduce the speed and force with which
you do the repetitive movement.
• Do exercise to strengthen the hand and
armmuscles.
• Immediately stop using all power equip-
ment and consult a doctor if you feel
tingling, numbness, or pain in the fingers,
hands, wrists, or arms. The sooner RSI/
CTSisdiagnosed, themorelikelyperma-
nent nerve and muscle damage can be
prevented.

6
SAFE OPERATION
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can
cause serious injury or death.
ReadtheManuals
• Provide all users of this equipment with the Operator’s Manual and
Safety Manual for instructions on Safe Operation.
CleartheWorkArea
• Spectators and fellow workers must be warned, and children and
animalspreventedfromcoming nearer than 15 m (50 ft.) whilethe unit
is in use.
KeepaFirmGrip
• Hold the front and rear handles with both hands, with thumbs and
fingers encircling the handles.
KeepaSolidStance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
AvoidHotSurfaces
• Keep exhaust area clear of flammable debris. Avoid contact during
andimmediatelyafteroperation.
WARNING DANGER
Never perform blade maintenance procedures while engine is
running.
IMPORTANTENGINEINFORMATION
ENGINE FAMILY: 4EHXS.0214ED DISPLACEMENT: 21.2 CC
EMISSIONCOMPLIANCE PERIOD : 300 HRS.
THIS ENGINE MEETS U.S. EPA PHA 2 EMISSION REGULA-
TIONS FOR SMALL NON ROAD ENGINE. REFER TO
OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS
AND ADJUSTMENTS.
EMISSIONCONTROL
EPA Phase 2
The emission control system for this engine is EM (Engine
Modification).
EmissionControlLabel (locatedonEngine) (EXAMPLEONLY,
informationonlabelvariesbyFAMILY).
PRODUCTEMISSION DURABILITY
The 300 hour emission durability compliance period is the time span selected by the manufacturer certifying the
engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures
are followed as listed in the Maintenance Section of this manual.

HEDGE CLIPPER
OPERATOR'SMANUAL 7
DESCRIPTION
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
CONTENTS
__ 1 - Hedge ClipperAssembly
__ 1 - Operator’s Manual
__ 1 - Safety Manual
__ 1 - Warranty Statement
__ 1 - Warranty Registration Card
__ 1 - T-Wrench13x19
__ 1 - BladeStiffener
__ 4 - Blade Locknuts
__ 4 - Stiffener Washers
__ 1 - EchoPowerBlend TM 2-strokeoilsample
__ 1 - BladeCover
15
12
4
7
8
9
4
5
16
5
6
10
11
12
13 14
3
17

8
1. FRONTHANDLE/GUARD-Comfortable,texturedfinishprovidesanti-slipgripforfronthand.Guardprotectshand
from the blades. Warning decals are located on guard.
2. BLADES - Double reciprocating blades mounted to a blade support bar. The blades are double sided, capable of
cutting on either side.
3. BLADESTIFFENER -Attaches to top of blades and guides material being cut into blades.
4. SPARKPLUG-Providessparktoignitefuelmixture.
5. CHOKE - The choke control lever is located on the front of the air cleaner case. Move choke lever to "COLD
START" ( ) to close the choke for Cold Starting. Move choke lever to "RUN" ( ) position to open choke.
6. PRIMERBULB -Pumpingprimerbulb beforestartingenginedraws freshfuelfromthefueltankprimingthecarbure-
tor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an
additional4or 5 times.
7. AIRCLEANER-Containsreplaceablefilterelement.
8. RECOILSTARTERHANDLE-Pullhandleslowlyuntilrecoilstarterengages,thenquicklyandfirmly. DONOTpull
rope all the way out or allow the handle to snap back, damage to the starter will occur.
9. FUELTANK-Containsfuelandfuelfilter.
10. FUELTANKCAP-Coversandsealsfueltankopening.
11. REARHANDLE-ContainsStopSwitch,ThrottleLockoutandThrottleTrigger.
12. THROTTLETRIGGERLOCKOUT-ThislevermustbedepressedbeforeThrottleTriggercanbeactivated.
13. THROTTLETRIGGER-Springloadedtoreturntoidlewhenreleased. TriggerLockoutmustbedepressedfully
before Throttle Trigger will move. During acceleration, depress gradually for best operating technique.
14. STOPSWITCH-"TOGGLESWITCH"located on the left side of the rear handle. Move switch UP to RUN, DOWN
toSTOP.
15. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
16. BLADE COVER - Used to cover blades during transportation or storage. Remove blade cover before using unit.
17. SAFETYVIDEO-(Notincludedwithunit)P/N99922202800EnglishversionandP/N99922203513Spanishversion
areavailableat a cost of $5.00from ECHO, INC.or any authorizedECHO dealer. Thevideo overviews safetyprecau-
tions and proper operating techniques and is supplemental to the Safety Manual. Read and understand the Safety
Manual for complete information on safe operation.

HEDGE CLIPPER
OPERATOR'SMANUAL 9
SPECIFICATIONS
MODEL ------------------------------------------ HC-150
Length-------------------------------------------- 1,040mm (41.0in.)
Width--------------------------------------------- 240mm(9.45in.)
Height -------------------------------------------- 200mm(7.87in.)
Weight, dry-------------------------------------- 4.8kg(10.7lb.)
Type of Engine---------------------------------- Air cooled, two-stroke, single cylinder, gasoline engine
Displacement ------------------------------------ 21.2cc(1.29cu.in.)
Bore----------------------------------------------- 32.2mm(1.27in.)
Stroke--------------------------------------------- 26.0mm(1.02in.)
ExhaustSystem --------------------------------- SparkArrestorMuffler
Carburetor --------------------------------------- Zama w/purge
Ignition System --------------------------------- Flywheel Magneto, Capacitor discharge ignition
SparkPlug --------------------------------------- BPM-8Y(Gap0.65mm(0.026in.)
Fuel ----------------------------------------------- Mixed Fuel - gasoline and oil
Fuel/OilRatio------------------------------------ 50:1two-stroke aircooledengineoil
Gasoline ------------------------------------------ 89 Octane unleaded. DO NOT use fuel containing methyl alcohol, more than
10%ethylalcoholor15%MTBE.
Oil ------------------------------------------------- PowerBlendTM PremiumUniversal2-StrokeOil
FuelTankCapacity ----------------------------- 0.5lit.(16.9fl.oz)
Starter System ----------------------------------- AutomaticRecoilStarter
Clutch -------------------------------------------- CentrifugalType
GearCaseRatio --------------------------------- 5.88:1
Cutter --------------------------------------------- DoubleReciprocatingBlade,Double Edge
Length ----------------------------------------- 490mm (19.3in.)
Pitch -------------------------------------------- 35mm (1.38in.)
Height ------------------------------------------ 21mm (0.83in.)
IdleSpeed(RPM) ------------------------------- 2,400-3,200
WideOpenThrottle(RPM)-------------------- 10,000-11,000

10
3. Tighten blade bolts (B) until snug, then loosen ½ turn.
4. Install blade stiffener. Secure with washers and new locknuts (A).
Do not allow blade bolts to turn.
NOTE
Use new locknuts every time blade stiffener in installed.
ASSEMBLY
NOTE
For normal cutting, Echo strongly recommends the blade stiffener
be installed. In extreme conditions, such as commercial cutting, or
when cutting thick and/or dense branches, efficiency may be
increased by trimming without the blade stiffener.
Tools required: (2)10mmWrenches
Parts Required: BladeStiffener,BladeLockNuts(P/N43302206460),
Washers
WARNING DANGER
Hedge Clipper blades are very sharp. Wear gloves to protect
hands.
IMPORTANT
Follow blade bolt adjustment instructions exactly. Failure to do so
could result in damage to blades or gearbox.
INSTALL BLADE STIFFENER
1. Disconnect spark plug wire.
2. Remove first four blade locknuts (A) closest to handle. Do not
remove blade bolts.
BLADE STIFFENER REMOVAL
1. Disconnect spark plug wire.
2. Remove blade stiffener locknuts (A). Do not remove blade bolts.
3. Removebladestiffener
4. Tighten blade bolts (B) until snug, then loosen ½ turn.
5. Secure blades with new locknuts (A). Do not allow blade bolts to
turn.
B
A
B
A

HEDGE CLIPPER
OPERATOR'SMANUAL 11
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.ContactyourECHOdealerfor
orderinginformation.
AfterRefueling
• Wipe any spilled fuel from the unit.
• Moveat least 3 m (10ft.) fromrefueling
location before starting the engine.
After use
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to an
approved fuel storage container.
Storage - Fuel storage laws vary by locality.
Contact your local government for the laws
affecting your area. As a precaution, store
fuel in an approved, airtight container. Store
in a well-ventilated, unoccupied building,
away from sparks and flames. Do not store
fuel longer than 30 days.
IMPORTANT
Storedfuelages.Do not mix more fuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizerisadded.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container
thoroughly before each use.
PRE-OPERATION
FUEL
Fuel Requirements
Gasoline-Use89Octane[R+M/2](midgradeorhigher)gasoline
known to be good quality. Gasoline may contain up to 15% MTBE
(methyl tertiary-butyl ether). Gasohol containing methyl (wood) alcohol
is NOT approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)and J.A.S.O. FC Standardsmust be used. Echo brand premium
Power Blend TM Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an
ISO-L-EGDandJ.A.S.O.FCcertifiedoil,suchasEchopremiumPower
BlendTM,willvoidthetwo-strokeenginewarranty. (Emissionrelated
parts only are covered for two years, regardless of two-stroke oil used,
per the statement listed in the Emission Defect Warranty Explanation.)
IMPORTANT
EchopremiumPowerBlendTM Universal2-StrokeOilmaybemixed
at 50:1 ratio for application in all Echo engines sold in the past
regardless of ratio specified in those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from container
and surrounding area.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallowflamesorsparksnear fuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhen the engine is HOT!
• NEVERrefuelaunitwiththeenginerunning.
• DONOT fill fueltanks indoors.ALWAYSfill fuel tanks outdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.

12
WARNING DANGER
The blades should not move at idle. If blades move, readjust
carburetor according to “Carburetor Adjustment” instructions in
this manual or see your ECHO Dealer, otherwise serious personal
injurymayresult.
6. Throttle Trigger
After engine warm-up, grip the handle to depress the throttle trigger
lockout, and gradually depress throttle trigger to increase engine
RPM to operating speed.
4. Recoil Starter
Lay the unit on a flat, clear area. Grip the front handle securely with
one hand, and pull the recoil starter handle (D) until engine fires (or
5pullsmaximum).
5. Choke
After engine fires or 5 pulls, move choke (B) to the RUN ( )
(OPEN) position. Restart engine if necessary and allow unit to warm
up at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions 2 - 5.
OPERATION
NOTE
The blade cover is used for transportation and storage. Remove
blade cover before using the unit.
STARTING COLD ENGINE
A
D
B
4
5
B
C
1. Stop Switch
Move stop switch (A) away from the STOP position.
2. Choke
Movechoke(B)to the Cold Start ( ) (CLOSED) position.
3. Primer
Pumpprimer bulb (C)untilfuel is visibleandflows freely inthe clear
fuel tank return line. Pump bulb an additional 4 or 5 times.

HEDGE CLIPPER
OPERATOR'SMANUAL 13
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke.
WARNING DANGER
The blades should not move at idle. If blades move, readjust
carburetor according to “Carburetor Adjustment” instructions in
this manual or see your ECHO Dealer, otherwise serious personal
injurymayresult.
1. Stop Switch
Move stop switch (A) away from the STOP position.
2. Primer
Pumpprimer bulb (C)untilfuel is visibleandflows freely inthe clear
fuel tank return line. Pump bulb an additional 4 or 5 times.
3. Recoil Starter
Place the unit on a flat, clear area. Grip the front handle securely
with one hand, and pull the recoil starter handle (D) until engine
starts.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
A
D
A
STOPPING ENGINE
1. Throttle
Release throttle and allow engine to return to idle before shutting
off engine.
2. Stop Switch
Move stop switch (A) to STOP position.
WARNING DANGER
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using hedge
clipperagain.

14
HEDGETRIMMING
NOTE
This unit is designed to cut shrubs and hedges with branches no
largerthan6mm(1/4in.)indiameter.
1. Hold trimmer firmly and squeeze throttle trigger to accelerate engine.
2. Tilt trimmer so cutting teeth are angled slightly toward the hedge or
shrub and proceed to cut.
WARNING DANGER
Never remove hands from unit when blades are moving.
WARNING DANGER
The engine continues running even when the blades have stopped
due to an obstruction. If this occurs, stop the engine, disconnect
ignition cable and remove the obstruction.
MAINTENANCE
Your ECHO unit is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your unit achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have
the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.
SKILL LEVELS
Level1= Easy to do. Most required tools come with unit.
Level2= Moderate difficulty. Some specialized tools may be required.
Level3= Experience required. Specialized tools are required. Echo recommends that the unit be returned to your
ECHOdealerforservice.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Just below each task
heading are listed the various part numbers required for that task. See your ECHO dealer for these parts.

HEDGE CLIPPER
OPERATOR'SMANUAL 15
/TNENOPMOC METSYS ECNANETNIAM ERUDECORP
D'QER LLIKS LEVEL ROYLIAD EROFEB ESU
YREVE LEUFER
3SHTNOM 09RO SRUOH 6SHTNOM 072RO SRUOH
YLRAEY 006 SRUOH
serudecorPecnanetniaMrelaeDohcEdednemmoceR
roterubraCecalpeR/naelC/tcepsnI 3)1(C/I)1(R
troPtsuahxErednilyCnobraceD/naelC/tcepsnI 3C/I
sedalBneprahSnaelC/tcepsnI 3)3(I
serudecorPecnanetniaMflesruoY-tI-oD
retliFriAecalpeR/naelC/tcepsnI 1C/I*R
ekohCnaelC/tcepsnI 2C/I
retliFleuFecalpeR/tcepsnI 1I*R
eniLleuFecalpeR/tcepsnI 1*II
metsySgnilooCnaelC/tcepsnI 2C/I
rotserrAkrapSrelffuMecalpeR/tcepsnI 2*I
gnisuoHraeGesaerG 2)2(I
sedalBnaelC/tcepsnI 1)3(C/I
epoRretratSlioceRnaelC/tcepsnI 1*C/I
skaeLleuFtcepsnI 1*I*I
gulPkrapSnaelC/tcepsnI 2C/I*R
stloB/stuN/swercSecalpeR/nethgiT/tcepsnI 1*R/I
SEDOCRETTELERUDECORPECNANETNIAM NAELC=C,ECALPER=R,TCEPSNI=I:
-ETONTNATROPMI deriuqerfoycneuqerfehtenimretedlliwecneirepxeruoydnaesulautcA.mumixameranwohsslavretniemiT
.ecnanetniam :SETONERUDECORPECNANETNIAM)1( .deriuqersishtnom6yrevegninaelc,esuremusnoCroF.sruoh006retfaesulaicremmoCrofderiuqereblliwtnemecalpeR
)2( OHCEylppA
®
EBUL
MT
.esufosruoh52-51yreve
)3( .esugnirudyllacidoirepsedalbetacirbuL.dedeensaneprahsdnanaelcdnaedalbtcepsnI
*.noitcepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA
MAINTENANCEINTERVALS

16
AIR FILTER
Level1.
Tools required: 25or50mm(1or2 in.)cleaningbrush
Parts required: 90008REPOWERTM AIR&FUELFILTERKIT
1. Close choke (Cold Start Position [ ]). This prevents dirt from
entering the carburetor throat when the air filter is removed. Brush
accumulateddirt from the air cleanerarea.
2. Remove the air cleaner cover. Clean and inspect the element for
damage. If element is fuel soaked and very dirty, replace.
3. If element can be cleaned and reused, be certain it:
• still fits the cavity in the air cleaner cover.
• is installed with the original side out.
NOTE
Carburetor adjustment may be needed after air filter cleaning/
replacement.
FUEL FILTER
Level1.
Tools required: 200-250mm (8-10in.)lengthofwirewithoneend
bent into a hook, clean rag, funnel, and an approved
fuel container
Parts required: 90008REPOWERTM AIR&FUELFILTERKIT
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and empty
fueltank.
2. Use the “fuel line hook” to pull the fuel line and filter from the tank.
3. Remove thefilter fromtheline and install thenewfilter.

HEDGE CLIPPER
OPERATOR'SMANUAL 17
0.65 mm
(0.026 in.)
SPARK PLUG
Level2.
Tools required: T-wrench, Feeler gauge, Soft metal brush
Parts required: REPOWERTMTune-UpKitP/N90074
1. Remove spark plug and check for fouling, worn and rounded center
electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean.Remainingsand will damageengine.
3. Adjust spark plug gap by bending outer electrode.
4. Tightensparkplugto145-155kg/cm(125-135in.lb.).
COOLING SYSTEM CLEANING
Level2.
Tools required: 3mmHexwrench,25or50mm(1or2in.)cleaning
brush
Parts required: None if you are careful.
IMPORTANT
To maintain proper engine operating temperatures, cooling air
must pass freely through the cylinder fin area. This flow of air
carries combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes in the crankcase are blocked, preventing cooling air from
reaching the cylinder.
• Dust and grass build up on the outside of the cylinder. This build up
insulates the engine and prevents the heat from leaving.
Removal of crankcase cooling passage blockages or cleaning of
cooling fins is considered “Normal Maintenance.” Any failure attrib-
uted to lack of maintenance is not warranted.
1. Remove spark plug lead and spark plug.
2. Remove (4) starter cover hex socket bolts and starter.

18
4. Remove heat shieldbolt(C)fromthemufflercover.
5. Carefully pull cylinder cover forward disengagingmufflergasket
tabs and ignition lead and lay aside.
6. Loosely install spark plug to keep debris out of the cylinder. Use
brush to remove dirt from cylinder fins.
IMPORTANT
DO NOT use a metal scraper to remove dirt from the cylinder fins.
7. Assemble components in reverse order.
NOTE
When installing the cylinder cover, be certain the muffler gasket
tabs (D) are locked into the muffler grill slots and the stop switch
lead is seated in the rubber grommet.
Cylinder Exhaust Port
Level3.
IMPORTANT
The cylinder exhaust port must be inspected and cleaned of excess
carbon every 3 months or 90 hours of operation in order to maintain
this engine within the emissions durability period. ECHO strongly
recommends that you return your unit to your ECHO dealer for this
importantmaintenance service.
3. Remove bottom right (A) and bottom left (B) hex socket bolts from
cylindercover.
AB
C
A
EXHAUSTSYSTEM
Spark Arrestor Screen
Level2.
Tools required: 3mmHexwrench,CrossHeadScrewdriver,Soft
metal brush
Parts required: ScreenP/N14586240630,GasketP/N14586642031
1. Remove engine cover. See “Cleaning Cooling System” for step by
step instructions.
2. Place piston at Top Dead Center (TDC) to prevent carbon/dirt from
enteringcylinder.
3. Remove exhaust guide(A),gasket(B),andscreen(C)frommuffler
body.
4. Clean carbon deposits from muffler components.
B
CD

HEDGE CLIPPER
OPERATOR'SMANUAL 19
5. Replace screen if it is cracked, plugged or has holes burned
through.
6. Assemble components in reverse order.
NOTE
When installing the cylinder cover, be certain the muffler gasket
tabs (D) are locked into the muffler grill slots and the stop switch
lead is seated in the rubber grommet.
CARBURETORADJUSTMENT
Engine Break-In
New engines must be operated a minimum duration of two tanks of fuel
break-in before carburetor adjustments can be made. During the break-
in period your engine performance will increase and exhaust emissions
will stabilize. Idle speed can be adjusted as required.
High Altitude Adjustment
High altitude adjustment is not required for proper operation of this
engine.
Level2.
Tools required: Screwdriver,Tachometer(ECHOP/N99051130017).
Parts required: None.
NOTE
Every unit is run at the factory and the carburetor is set in compli-
ance with emission regulations. This carburetor does not have
acceleration and high-speed adjustment needles.
1. Check idle speed and reset if necessary. If a tachometer is available,
idle speed screw (A) should be set to the specifications found on
page 9 “Specifications” of this manual. Turn idle screw (A) clock-
wise to increase idle speed; counter clockwise to decrease idle
speed.
WARNING DANGER
When carburetor adjustment is completed, the cutting attachment
should not move at idle, otherwise serious personal injury may
result.
A
D

20
LUBRICATION
Blades
Level1.
Tools required: Cleanrag,25or 50 mm(1or2in.)cleaningbrush
Parts required: 20WEngineOil(lubrication),50-50mixtureof
kerosene and 20W oil (cleaning).
WARNING DANGER
Hedge Clipper Blades are very sharp. Wear gloves to protect
hands.
1. Disconnect spark plug wire from spark plug.
2. Brush loose debris from blade and coat both sides of blade with the
50-50cleaningmixture.
3. Allow cleaning mixture to soften the remaining gummy residue then
wipeitfromtheblade.
4. Apply clean oil to the entire length of the blade. Be certain the
blade bolts are lubricated.
5. Wipe excess oil from the blade before putting the unit back in
service.
Gear Box Assembly
Level1.
Tools required: GreaseGun,Cleanrag
Parts required: ECHO®LUBETM 14oz.(P/N91015)orLithiumBased
Grease.
1. Clean dirt fromthegrease fitting (A).
2. Carefully pump grease into fitting (A). DO NOT force grease. Too
much pressure will force grease past seals and cause damage.
Apply 1-2 pumps of grease every 15-25 hours of operation.
3. Wipe excess grease from around grease fitting.
A
