Ecolab SP-10N-MOBYSPRAY User manual

USER
MANUAL
MODEL NUMBER:
SP-10N-MOBYSPRAY
AND RELATED UNITS
10 Gallon Air Operated Portable Spray
Equipment
English (Original Instrucons)

Page 2 of 7 | 20180822
User Manual: Rotomolded Portable Spray Units | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Model Number: SP-10N-MOBYSPRAY
Specicaons:
Hose .............. 30 feet reinforced hose, 3/8 inch inside diameter
(9 meters reinforced hose, 9.5 mm inside diameter)
Tank Capacity...........................................12.5 gallons (47.3 liters)
Spray Output....................... 2 gallons/minute (7.5 liters/minute)
Spray Output Distance..................... 10 to 12 feet (3 to 4 meters)
Liquid Temperature ........................ 40˚F to 100˚F (4.4˚C to 37˚C)
Dimensions:
Length ....................................... 18 in (457 mm) approximately
Width ........................................ 14 in (356 mm) approximately
Height ....................................... 42 in (1067 mm) approximately
Weight, including discharge hose and wand:
(Empty) ................................ 40 lbs (18 kg) approximately
Requirements:
Compressed Air Source Requirements: Air regulator (R25) is
factory set at 50 psi (3.4 bar). Operang range is 40 to 80 PSI (3
to 5 bar) with 2 CFM (56.6 l/min).
Chemical Requirements: Follow all instrucons from chemical
manufacturer and Material Safety Data Sheet (MSDS).
Air Operated Double Diaphragm Pump Models Oered:
P56: Polypropylene body with Santoprene diaphragm
P56V: Polypropylene body with Viton diaphragm
P56K: Polypropylene body with Kalrez diaphragm
Acceptable Products:
Chemical products used with this equipment must be
formulated for this type of applicaon and compable with unit
materials and pump seals. For more informaon on chemical
compability, consult the manufacturer or SDS for your product.
DO NOT USE: All hydrocarbons
Read this manual completely and understand the
machine before operang or servicing it.
• Read all instrucons before installing or operang unit.
• Always wear appropriate personal protecve equipment
(PPE) when operang or servicing unit.
• Always follow all chemical safety precauons and
handling instrucons provided by the chemical
manufacturer and Safety Data Sheet (SDS).
• Never point the discharge trigger gun at yourself,
another person, or any object you do not want covered
in chemical.
• Always depressurize unit aer use (as described in the
Aer Use Instrucons), and store unit depressurized.
• Do not exceed an incoming air pressure of 100 psi (7
bar).
• Do not exceed a uid temperature of 100˚F (37˚C).
• Only use clean and dry air. Air must be ltered and free
of moisture or pump life will be diminished. If needed,
install an air dryer before unit.
• Do not use an air lubricator before the unit.
PROTECT THE ENVIRONMENT
Please dispose of packaging materials, old machine
components, and hazardous uids in an environmentally safe
way according to local waste disposal regulaons.
Always remember to recycle.
*Specicaons and parts are subject to change without noce.
WARNING

Page 3 of 7 | 20180822
User Manual: Rotomolded Portable Spray Units | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Model Number: SP-10N-MOBYSPRAY
Operaon Instrucons
Wearing all PPE and observing all safety precauons dictated by
the MSDS for your chemical:
1. Fill the tank with the soluon to be sprayed.
2. Connect an appropriate compressed air line into the air
inlet ng (AP25).
3. Squeeze the discharge trigger gun (PSG12) to begin
spraying.
Aer Use Instrucons:
1. Flush the unit with fresh water for 5 minutes.
2. Disconnect the air line from the air ng (AP25) and
relieve any pressure remaining in the system by squeezing
the discharge trigger gun (PSG12).
3. Release the discharge trigger gun (PSG12) aer all
pressure has been relieved from the system.
Maintenance Instrucons:
To keep your portable unit operang properly, periodically
perform the following maintenance procedures:
• Check the air pump (P56/P56K/P56V) for wear and leaks.
• Inspect hoses for leaks or excessive wear. Make sure all
hose clamps are in good condion and properly secured.
• Replace lter (AFR25) in regulator (R25) as needed.
• Check the sucon tube and screen for debris and clean as
needed.
• Drain compressor tank on a regular basis to ensure proper
operaon of pump.
Troubleshoong Instrucons:
• Check to ensure that the discharge hose is uncoiled
properly, and that there are no kinks that could obstruct
uid ow.
• Check the air regulator bowl (ABR25) and air lter (AFR25)
for debris such as water, oil, or rust parcles. Clean by
unthreading the air regulator bowl (ABR25) from the air
regulator (R25).
• Check the strainer (STR38-IL) for debris or other
blockages, and clean as needed. Replace strainer if
damaged. Strainer must be used.
• If air passes through the pump (P56/P56K/P56V) without
cycling, the pump needs to be replaced.
• Check for proper air pressure on the air gauge (AG100).
The air regulator (R25) is factory set at 50 psi (3.4 bar).
Operang range is 40 to 80 PSI (3 to 5 bar) with 2 CFM
(56.6 l/min).
• If the unit operates at a reduced pressure:
• Check the air compressor supplying the unit. If the
pressure is less than 40 psi, turn the unit o unl the
compressor can catch up.
• If the air supply is 50 psi (3.4 bar) or above, check the
air gauge (AG100), which should read near 50 psi (3.4
bar). If the air gauge reads more or less than 50 psi
(3.4 bar), adjust the pressure by turning the knob on
the top of the air regulator (R25).

Page 4 of 7 | 20180822
User Manual: Rotomolded Portable Spray Units | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Model Number: SP-10N-MOBYSPRAY
HBSS1238
ST2520
PSG12
PW124-120
SSP12
SSAXLE14
AS1-VS
W15
FWAX15
PVCV34FM
COT
TANK-10N
DFP7
(see parts list
for color opons)
DP-A
TANK ASSEMBLY
ITEM NUMBER: TANK-10N-A
SPRAY GUN ASSEMBLY
ITEM NUMBER: SGA14
HBSS1238
H38B-F
(Available per )
SSC38
DISCHARGE HOSE ASSEMBLY
ITEM NUMBER: H38-30

Page 5 of 7 | 20180822
User Manual: Rotomolded Portable Spray Units | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Model Number: SP-10N-MOBYSPRAY
HBSSEL1438
HHPB3414
P56-BRK
PVCV34FM
P56-BRKT-SCREW
SSC38
SSC38
STR38-IL
FWP12
EC14-2
SC1212
BPS-58SO
HBSSEL1814 BPS-58SO
HBSS1238
AG100
P56, P56K, or P56V
P14
R25
BACK PLATE
Inside View
BACK PLATE
Outside View
OPTIONAL COMPONENTS
WATER SEPARATOR
ITEM NUMBER: WS-20CFM
AIR HOSE ASSEMBLY
ITEM NUMBER: AH30
PLUG 3/4
FWP12
HBSS1238
TW916 SSA14
AP25
